Daewoo SDA2325 User manual

1
3 Tier Food Steamer
Model No. SDA2325
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE

2
3 Tier Food Steamer
Model No. SDA2325
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
READING AND STORING THE USER MANUAL
Before using this product, please read through this manual
carefully paying particular attention to the safety instructions.
Failure to do so may result in personal injury or damage to the
product.
Carefully save this instruction manual for future reference. Ensure the
user manual is included when passing the product on to any third
parties.
IMPORTANT SAFETY INSTRUCTIONS FOR PROPER USE
When using electrical appliances, basic safety precautions
should always be followed.
Only use the product as described in this user manual. Any other
use is considered improper and may result in damage to
property or persons.
The manufacturer or vendor cannot be held liable for damages
or injury incurred through improper or incorrect use.
Read and familiarise yourself with all operating instructions
before using this Steamer.
Before plugging your steamer into the mains, visually check
that the steamer is intact and has not suffered any transit
damage.
Check that the voltage indicated on the data plate corresponds
with that of the local network before connecting the appliance
to the mains power supply.
Close supervision is required when using this appliance near
children.
Never leave this appliance within reach of children.
This appliance can be used by children aged from 8 years and
above and persons with reduced physical, sensory and mental
capabilities or lack of experience or knowledge if they have
been given supervision or instruction concerning use if the
appliance in a safe way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children
unless they are older than 8 and supervised.

3
3 Tier Food Steamer
Model No. SDA2325
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Keep the appliance and its cord out of reach of children aged
less than 8 years.
DO NOT leave the appliance unattended during use.
DO NOT leave the appliance unattended whilst connected to
the mains supply.
Always use this appliance on a solid, level, non-flammable
surface.
DO NOT use this appliance outdoors.
It is imperative to unplug the power cord after the appliance
has been used, before it is cleaned and whilst being repaired.
If the power cable is damaged, it should only be replaced by
suitable qualified personnel in order to avoid a hazard.
Repairs to electrical appliances should only be performed by
qualified personnel. Improper repairs may place user at serious
risk.
DO NOT operate this appliance with a damaged plug or cord,
after a malfunction or after being dropped or damaged in any
way.
Regular, periodic checks should be carried out on the mains
cable to ensure no damage is evident. Should there be any
signs of damage the appliance should not be used.
DO NOT allow the mains cable to hang over sharp edges or
come in contact with hot surfaces.
DO NOT run the mains cable under carpets, rugs, etc.
Allow the unit to cool before storage.
Never place the appliance near to flammable material or high
pressure containers.
This appliance is intended for household use only and should
not be used for industrial purposes.
DO NOT use any accessories or attachments with this appliance
other than those supplied or recommended by supplier.
DO NOT immerse the appliance, base or its cord in water or
any other liquids.
DO NOT use this appliance for anything other than its intended
use.

4
3 Tier Food Steamer
Model No. SDA2325
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
DO NOT push objects into any openings as damage to the
appliance and/or electric shock may occur.
Ensure appliance is situated in an open area, do not allow it to
come in contact with or place beneath cupboards, curtains,
wall coverings, clothing or other flammable materials.
Unplug after each use. Grasp the plug, not the cord.
DO NOT cover this appliance.
Never place this appliance on an electric, gas, or any other type
of hob.
Never fill the steamer more than its capacity –ensure the
water level is between the min and max marks. If the steamer
is overfilled, boiling water may be ejected.
Always close the lid during use and do not open the lid whilst
the water is boiling.
CAUTION: The outside surface of the steamer will get hot
during use.
THIS APPLIANCE MUST BE EARTHED

5
3 Tier Food Steamer
Model No. SDA2325
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Explanation of Symbols
The following warning symbols or words are used in this instruction manual:
Products labelled with this symbol conform to applicable
provisions of the European Economic Area.
Products labelled with UK Conformity Assessment identifies
products conforming to UK statutory requirements.
You should now recycle your waste electrical goods and in
doing so help the environment. This symbol means waste
electrical products at the end of their useful life should not be
disposed of with normal household waste and not sent to
landfill. Please ensure it is taken to a suitable facility for
disposal. Check with your Local Authority or retailer for
recycling advice or Visit www.recycle-more.co.uk, click on “bank
locator” and enter your postcode to find out your nearest
recycling site.
This symbol provides useful additional information on the
use of this product.
This symbol indicates that the supply uses an alternating current
mains supply.
This symbol indicates that the surface is gets hot and care must
be taken.
This designates a hazard with moderate risk, which may result
in severe injury if not adhered to.

6
3 Tier Food Steamer
Model No. SDA2325
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Before the First Use of Your Three Tier Steamer
1.Remove all packing materials and discard responsibly.
2.Ensure all parts are present (if applicable) see Description of Parts below.
3.Wash the Lid (1), the three Steamer Baskets (3, 5&7) in warm soapy water.
Rinse and allow to dry before use.
4.Wipe the inside of Water Reservoir (8) with clean, damp cloth and dry
thoroughly, DO NOT Immerse the Base Unit (10) in water or any other liquid
or put it into a dishwasher.
Whilst using the steamer for the first time, a little smoke or odour may be
emitted, this is normal and will soon pass.
Description of parts
Setting up Your Three Tier Steamer
1.Do not insert the mains plug into the mains socket.
2.Place the steamer Base Unit (10) on a solid, level
heat resistant surface at a comfortable height for the
user.
2
3
4
1
1. Lid
2. Rice Bowl
3. Steamer Basket
4. Basket Spacer
5. Steamer Basket
6. Basket Spacer
7. Steamer Basket
8. Water reservoir
9. Timer
10.Base Unit
11.Non-Slip Feet
12.Power Indicator
5
6
7
10
8
11
9
12
1

7
3 Tier Food Steamer
Model No. SDA2325
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
3.Fill the Water Reservoir (8) with cold water,
ensuring that it does not exceed the ‘MAX’ mark
on the inside surface of the Water Reservoir (8).
This amount of water should be sufficient for up to 60
minutes of cooking; however, the water tank can be
topped up during cooking by adding water to the
Water Reservoir (8).
Do not allow the water level to fall below the ‘MIN’ mark on the Water
Reservoir (8) –always keep the water level above this mark.
4.After filling the tank with water, place the desired number of Steamer Baskets
(3,5&7) onto the Base Unit (10) as shown right:
5.Place the ingredients to be steamed into the first Steamer Basket (7).
6.Place the second Steamer Basket (5) on top of the first Steamer Basket (7) if a
second tier is required.
7.Finally, if desired, place the third Steamer Basket (3) on top of the second
Steamer Basket (5) for all three tiers.
8.Once the required number of baskets are fitted and the ingredients in, fit the
Lid (1) onto the top basket.
Cooking with Your Three Tier Steamer
1.Insert the mains plug into the nearest socket.
2.Left: Rotate the Timer (9) clockwise to the required
cooking time (in minutes), the Power Indicator (12) will
illuminate to show the unit has powered up and
cooking has started.
3.Once the cooking time is complete, the Timer (9) will return to zero and
the Power Indicator (12) will go out.
If the food is cooked before the cooking time has finished, turn the Timer (9) to
zero to switch off the steamer. Alternatively, if more cooking is required, rotate
the Timer (9) further clockwise for increased cooking time. If the appliance stops
producing steam or there is a clear visible reduction in steam before the food is
ready, add extra water to the Water Reservoir (8)–do not let the water level
drop below MIN.

8
3 Tier Food Steamer
Model No. SDA2325
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
4.Once the cooking is complete and the Power Indicator (12) has gone out,
unplug the steamer from the mains.
5.Food can then served from the baskets using heat resistant food tongs.
WARNING! Take care when removing the lid and steam baskets as they will
get hot during use and steam may be released. Use heat resistant oven gloves to
prevent injury.
Do not add anything to the water. Any seasonings or marinades should be
added to the food not the water as otherwise they will collect in the reservoir and
could cause damage.
WARNING! Voltage is still present even when the timer is at the “0” position,
to completely turn off the steamer remove the mains plug from mains power
supply.
Steaming Rice
Fill the steamer with water to the ‘MAX’ mark and place the Steamer Basket (7) on
the Base Unit (10).
Measure rice and water into the Rice Bowl (2) according to the cooking guide
below.
Place the Rice Bowl (2) centrally inside the basket and put on the Lid (1). Steam for
the appropriate cooking time according to the below guide, stirring halfway
through the cooking time. If cooking rice with other foods such as meat or fish,
place the rice on the higher tier basket.
After cooking drain then rinse the rice with boiling water before serving.
Item
Amount
Water Level
Cooking Time
Long Grain White Rice
130g Rice 350ml Water
Max
50-55 minutes
Brown Rice
175g Rice 285ml Water
Max
45-50 minutes
White Basmati Rice
175g Rice 285ml Water
Max
45-50 minutes
Boil dry protection
Should you accidentally let the appliance operate without water; the boil-dry
protection will automatically switch off the power. If this occurs, allow the
appliance to cool and reset before use.

9
3 Tier Food Steamer
Model No. SDA2325
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Lime scale removal
To maintain the performance of your steamer it is recommended you descale it
once every two to three months to increase the life expectancy and reduce
lime scale build up. In hard water areas we highly recommend using filtered
water in your steamer to increase the life expectancy and help prevent
excessive lime scale build up.
Do not use vinegar but a commercially available descaling agent; carefully
follow the quantities recommended in the instructions of the agent.
Care and Maintenance
Before carrying out any cleaning or maintenance, ensure that the timer dial is
set to “0”, the steamer is unplugged from the mains power supply and has fully
cooled.
Wipe the steamer base unit with a soft damp cloth and dry thoroughly, after
pouring out any remaining water from the reservoir.
The steam baskets and lid are not dishwasher safe, hand wash only. Clean the
accessories in warm soapy water then rinse and dry thoroughly, do not use
harsh or abrasive cleaning products.
The steamer should be cleaned after each use.

10
3 Tier Food Steamer
Model No. SDA2325
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Cooking Guide
The following is a guideline for cooking certain types of ingredients, in a single
layer, in the bottom steam basket of the 3-Tier Steamer. This is for guidance only
and cooking should always be monitored.
Food
Amount
Approx. Cooking Time
Meat and Poultry
Chicken breasts (boneless)
2
30-40 mins
Sausages
5
20-25 mins
Fish and Seafood
Fish fillets (fresh)
225g
20-40 mins
Clams
450g
10-15 mins
Prawns (fresh)
450g
11-14 mins
Crab
2
40-45 mins
Vegetables
Asparagus
450g
12-15 mins
Broccoli
225g
8-11 mins
Peas
280g
15-17 mins
Cabbage
225g
10-13 mins
Carrots
25g, sliced
10-12 mins
Cauliflower
1 head, cored
13-16 mins
Egg (Hard Boiled)
6
15-25 mins
Potatoes
225g, peeled and
sliced
10-12 mins
The further food is away from the Water Reservoir, the longer the cooking
time.
Experiment with cooking times and positioning of foods within the 3-Tier
Steamer.
Always ensure that food is piping hot and cooked thoroughly before serving.
Hints and Tips
1.Cut ingredients so that they are roughly the same size.
2.If steaming larger ingredients, place them into the lower steam basket, closest
to the Water Reservoir.
3.To allow room for steam to circulate, pack ingredients loosely in the steam
baskets, use single layers where possible and leave space between the
ingredients.
4.It is advised to have a plate or tray to hand when disassembling the 3-Tier
Steamer after use, as the steam baskets and lid will drip due to condensation.

11
3 Tier Food Steamer
Model No. SDA2325
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Non-Wireable Mains Plug
If your appliance is supplied with a non-wireable plug fitted to the mains lead
and should the fuse need replacing, you must use an ASTA approved one
(conforming to BS 1362 of the same rating). If in doubt, consult a qualified
electrician who will be pleased to do this for you. If you need to remove the plug
–DISCONNECT FROM THE MAINS –and then cut it off the mains lead and
immediately dispose of it safely. Never attempt to reuse the plug or insert it into
a socket outlet as there is a danger of electric shock.
Technical Data
Model No.
SDA2325
Rated Voltage
220-240V ~ 50/60Hz
Rated Power
400W
Protection Class
I (This Appliance must be Earthed)
Disposal of the packaging
Dispose of paper and cardboard in appropriate paper re-cycling
facilities.
Dispose of recyclable plastics in appropriate plastic re-cycling
facilities.
Dispose of non-recyclable plastics in the appropriate plastics
collection service.
Disposal of the product
You should now recycle your waste electrical goods and in doing so
help the environment. This symbol means waste electrical products
at the end of their useful life should not be disposed of with normal
household waste and not sent to landfill. Please ensure it is taken to
a suitable facility for disposal. Check with your Local Authority or
retailer for recycling advice or Visit www.recycle-more.co.uk, click
on “bank locator” and enter your postcode to find out your nearest
recycling site.

12
3 Tier Food Steamer
Model No. SDA2325
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
Troubleshooting Guide
Problem
Possible Cause
Possible Fix
Unit not powering up.
Mains plug not in socket
Check that the mains plug is inserted into
the socket and is switched on.
Timer not set.
Rotate the Timer (6) clockwise to the
required cooking time.
Fuse has blown in the mains
plug.
Check by substitution.
Food is undercooked
Timer not set to the correct
time.
Rotate the Timer (6) clockwise to the
correct cooking time.
Food stacked too thickly in
steamer basket.
Remove excess food and spread the
remaining food out in the steamer basket
to ensure steam can pass through.
Food is being cooked in a high
steamer basket.
Increase cooking time to allow for higher
basket.
Food is overcooked
Timer set for too long a
cooking time
Rotate the Timer (6) anticlockwise to the
correct cooking time.

13
3 Tier Food Steamer
Model No. SDA2325
User Manual
IMPORTANT –RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE
WARRANTY
Thank you for purchasing your Daewoo product.
As part of our commitment to quality, we are offering you an extra 2 years warranty in
addition to your 1 year guarantee
Your Daewoo product is guaranteed for 1 year from the date of original purchase, with proof
of purchase or receipt. If any defect should occur due to faulty workmanship or material, your
faulty product should be returned to the place of purchase, replacement or refund is at the
discretion of the retailer.
The guarantee is subject to the following provisions:
The product must be correctly installed and operated in accordance with the
requirements contained in the instruction manual.
Theproduct must be used solely for domestic purposes.
It does not cover general wear and tear, damage, misuse or any consumable parts.
The guarantee will be rendered invalid if the product is re-sold or has been damaged through
inexpert repair.
The guarantee is only valid within the UK and Eire.
Your standard 1 year guarantee will only be extended to the maximum available for your
individual product upon registration. (Note: products must be registered individually and
covers the main body and housing). If you do not register your product within 28 days of the
original purchase date, your product will only be guaranteed for 1 year.
To validate your extended 2 year warranty*please register your purchase online within 28
days of the original purchase date by registering at
www.daewoowarrantyregistration.com/warranty-registration
*Your extended warranty is only valid with proof of purchase receipt and subject to the
conditions outlined above.
Daewoo is a registered trademark.
Produced and imported under licence by ESG Ltd
Manchester M3 1JS www.esgltd.com
