WPM MS-130T User manual

Instruction Manual
MS-130T
Milk Steamer
P1 P2

1
Content
Thank you for purchasing the WPM Welhome Professional
Machine. Please read these instructions carefully to use the
product correctly and safely.
Before using this product please give your special attention
to“Safety Precautions”(Page 2-4).
Please keep this instruction manual for future use.
Safety Precautions ................................................................................. 2-4
Parts Names of MS-130T ...........................................................................5
Operation Guidelines of MS-130T .................................................... 6-8
Cleaning and Maintenance .................................................................. 8-9
Recycle and Disposal ........................................................................... 9-10
Product Specifications ............................................................................. 10

2
Safety Precautions
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
15.
In order to prevent accidents or injures to the user, other people, and
damage to property, please follow the instructions below.
Ensure that unit is used on a firm and flat surface.
Never immerse the appliance in water or other liquids.
Room temperature must range between 10° and 32°C
(50°F and 90°F).
Do not use the appliance under direct sunshine.
Do not operate with empty water tank. Do not fill with any
substance other than room temperature water.
Do not touch the hot steam wand directly after operation.
Please turn off the appliance when not in use otherwise it may
result in danger.
Please turn off the appliance and unplug the socket when unat-
tended otherwise it may result in danger.
Do not hang over the power cord at the edge of table or bench
top or contact with any hot surface.
This appliance can be used by children aged from 8 years and
above if they have been given supervision or instruction concern-
ing use of the appliance in a safe way and if they understand the
hazards involved. Cleaning and user maintenance shall not be
made by children unless they are older than 8 and supervised.
Keep the appliance and its cord out of reach of children less than
8 years.
Children should be supervised to ensure that they do not play
with the appliance.
Appliance can be used by persons with reduced physical, sensory
or mental capabilities or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved.
With any indication of malfunction (including power cord), please
stop using the appliance immediately to avoid hazard. Take it to
the authorized service center for repair. Do not attempt to repair
or change any parts by yourself.
Please turn off and unplug the appliance before cleaning or
maintenance.

3
16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29
30.
Clean the surface of the appliance with a dry cloth. Do not use
corrosive detergent or solvent to clean. Do not swash the appli-
ance with water.
Please turn off and unplug the appliance when not in use, make
sure the power is off before pulling out the plug and do not pull
the cord.
When the appliance is not in use for a prolonged period, please
turn it off, unplug it, pack it well, and store it in dry cool place.
Forbid to put flammable and explosive objects around the
appliance, and do not use the appliance in an environment full of
flammable gas and powder. Keep away from any fire and heat
sources.
Please put the power cord in the right place in order to avoid
tripping the appliance over.
Do not let the power cord hang over the edge of table counters
or touch hot surfaces.
Do not use your appliance with an extension cord unlessthe cord
has been checked and tested by qualifiedtechnician or service
person.
Do not operate the appliance without load to avoid damaging
the heat elements.
Do not place hands under the steam nozzle directly, as it can lead
to a scalding or injury.
Please use suitable power source (220-240V~/50Hz).
Never leave an appliance unattended while in use.
Do not place ontop of any other appliances.
The appliance is intended to be used in household and similar
applications such as:
• Staff kitchen areas in shops, offices and other working
environments;
• Farm houses;
• By clients in hotels, motels and other residential type
environments;
• Bed and breakfast type environments.
Never clean the steam wand with an abrasive pad as this will
damage the steam wand.
Clean the steam wand immediately after use because dried milk
may block the steam nozzle.

4
Failure to observe caution may result in personal injury!
ention: Users can refer online manual on WPM website
(https://www.wpm.hk/en/news_detail.php?id=22)
Att
31.
32.
33.
34.
35.
36.
37.
38.
39.
40.
Never clean the steam wand with an abrasive pad as this will
damage the steam wand.
Clean the steam wand immediately after use because dried milk
may block the steam nozzle.
The heating element surface is subject to residual heat after use.
Do not touch the hot surface.
The surfaces are liable to get hot during use.
Do not install in rooms (kitchens) that are cleaned with jets of
water.
Do not clean the machine with jets of water.
Operation and maintenance can only be done by
trained personnel.
WARNING: Avoid spillage on the connector.
WARNING: Potential injury from misuse.

Parts Names of MS-130T
1. Tank Lid
2. Removable Water Tank
3. Tank Entry
4. Steamer Body
5. Power Cord
6. Control Panel
7. Anti-heat Steam Wand
8. Main Power Switch
9. Pressure Outlet
10. Removable Drip Tray Cover
11. Removable Drip Tray
12. Stainless Steel Pitcher
1
2
3
4
5
6
7
8
10
11
12
9
5
High-efficiency Heating System
This milk steamer contains a 4 bar / 0.4 MPa pressure pump for
generating 1.5 bar / 0.15 MPa steam. With a high-efficient
heater, it is capable of generating continuous and powerful steam.

6
Operation Guidelines of MS-130T
REMINDER
1. Switch on the Main Power Button
(Left lower side of machine)
Control Panel
Display Steam
Button
Clean /
Flushing
Button
Temperature
Adjustment
Pre-set
Menu
P1 P2
Press and simultaneously to switch from Fahrenheit(° F) to
Celsius(° C) conversion.
O I
REMINDER
Temperature
setting range:
40°C- 90°C
(104°F - 194°F)
2. Preheating
3. Temperature Setting
Monitor shows for few minutes
to represent preheating. When the machine
is ready, previous target temperature is shown.
Setting Preset Menu
a. Pressing and holding / button,
the machine shows its preset
temperature.
b. Press or to adjust target
temperature.
P1 P2

7
Target temperature returns to previous setting after every use.
However, it will be rewritten after pressing / button.
REMINDER
User can stop
steam dispensing
Hot Water Caution!
Pressure outlet may release hot water after steam dispening!
4. Start Milk Frothing
Setting Normal Target Temperature
Press or to adjust target temperature.
with button.
a. Setting target temperature, press
to start frothing.
Liquid temperature will be shown in the
display.
b. During frothing, the display shows rising temperature.
When the target temperature is reached, machine
automatically stops dispensing steam.
Machine returns to ready mode and display shows previous target
temperature.
5. After frothing
Do not remove steam wand from liquid before completely
shutting down.
The maximum time of steam release is 4 minutes. If the liquid does
not reach the target temperature after 4 minutes, it will stop to
release steam automatically.
P1 P2
c. Release / button, machine beeps three times to
show that saving is successful.
d. Press / button to set target temperature rapidly.
P1 P2
P1 P2
ATTENTION
ATTENTION
CAUTION
WARNING

8
The surfaces are liable to get hot during use.
6. Clean after use
Press to start flushing. Machine dispenses
steam for 6 seconds to clean milk residual inside
steam ward. Then wipe the steam wand clean with
a damp cloth to clean milk residual on the surface
of the steam ward.
Press short clean button
and clean the steam wand with
a damp cloth.
Descaling agent should be
applied. Please follow the and
instruction in below.
Prevent blockage of steam wand, users MUST flush the machine
after each use.
ATTENTION
WARNING
Cleaning and Maintenance
Every single use After 1 week usage
With unique dispensing pattern, the machine can be cleaned
thoroughly. Cleaning agents are highly recommended to use.
Please refer to the manual of cleaning agents for detailed operation.

9
2. Place a heat-resistant large container below
steam nozzle.
3. Press and hold for 3 seconds to start cleaning
mode and display shows .
4. Press to start cleaning. Rhythmic hot water
dispension program start.
5. Program stops when water tank is empty and display shows .
User can refill water to keep cleaning or press and hold for 3
seconds to leave cleaning mode.
6. The machine will restart automatically for next use.
Be careful
of burns!
Warning:
hot water
temperature
40° C - 60° C
Disposal of the Packaging
The packaging protects the unit against transport damage. The pa-
cking materials are selected according to the environmental compatibil-
ity and disposal related aspects and can therefore be recycled.
Recycling and Disposal
REMINDER
Ensure all cleaning agent are consumed after cleaning.
1. Check and ensure water tank is filled.
The return of packaging into the material cycle saves raw material
cycle saves raw material and reduces the waste volume.

Disposal of the Unit
At the end of its service life, this product cannot be disposed of in no-
rmal domestic waste. The symbol on the product and in the operating
instructions point out to this fact. The materials are recyclable according
to your marking. With the reuse, recycling or other forms of recycling
of old equipment, you make an important contribution to the protection
of our environment. Please ask your municipal administration for the
disposal point.
10
Product Specifications
Attention: Product Specifications, designs and dimensions are subject
to change without prior notice.
Product name: Milk Steamer
Product model: MS-130T
Voltage and Power:
220V-240V~ 50-60Hz 1450W-1720W
Situations below are not accepted in the maintenance terms:
1. Formation of scale in thermoblock due to not using distilled water
or inadequate and irregular cleaning.
2. Blocking in steam wand due to inadequate and irregular cleaning.
G.M.P. Industrial Co Ltd
Address: 7/F, Meyer Industrial Building,
2 Chong Yip Street, Kwun Tong,
Kowloon, Hong Kong
Tel. No.: [phone]
Fax: [phone]
E-mail: [email protected]
Website: www.wpm.hk

“12
Ver.Cod.:MS-130T-HK-IB-V002-202011301620
