Stark 650LB Original instruction manual

650LB 2-BAR ADJUSTABLE TRUCK LADDER RACK
SAVE THIS MANUAL: KEEP THIS MANUAL FOR SAFETY WARNINGS, PRECAUTIONS, ASSEMBLY,
OPERATING, INSPECTION, MAINTENANCE AND CLEANING PROCEDURES. WRITE THE PRODUCT’S
SERIAL NUMBER ON THE BACK OF THE MANUAL NEAR THE ASSEMBLY DIAGRAM (OR MONTH
AND YEAR OF PURCHASE IF PRODUCT HAS NO NUMBER).
OWNER’S MANUAL AND SAFETY INSTRUCTIONS
ITEM: 26500
FOR QUESTIONS PLEASE CALL OUR CUSTOMER SUPPORT: [phone] MON-FRI 9AM TO 3PM PST

IMPORTANT SAFETY INFORMATION
GENERAL SAFETY WARNINGS
Read all safety warnings and instructions. Failure to follow the warnings and instructions
may result in serious injury. Save all warnings and instructions for future reference.
SAFETY
The warnings, precautions, and instructions discussed in this instruction manual cannot cover
all possible conditions and situations that may occur. It must be understood by the operator that
common sense and caution are factors which cannot be built into this product, but must be supplied
by the operator. Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS
before operating. Failure to follow the safety rules and other basic safety precautions may result in
serious personal injury.
1
Read and understand all instructions. Failure to follow all instructions may result in serious injury
or property damage.
Do not allow persons to operate or assemble the product until they have read this manual and have
developed a thorough understanding of how it works.
Do not modify this product in any way. Unauthorized modication may impair the function and/or
safety and could affect the life of the product. There are specic applications for which the product
was designed.
Keep work area clean, free of clutter and well lit. Cluttered and dark work areas can cause
accidents.
Keep children and bystanders away while assembling the truck rack. Distractions can cause
you to lose control, so visitors should remain at a safe distance from the work area.
Be aware of all power lines, electrical circuits, water pipes, and other mechanical hazards in
your work area. Some of these hazards may be hidden from your view and may cause personal injury
and/or property damage if contacted.
Carrying any load can be hazardous. All loads must be tied down securely to the rack to prevent
them from vibrating or sliding forward, backward, laterally or being blown off or broken by unexpected
wind or road hazards such as potholes.
Check each time you install the rack, load the rack, as well as daily to ensure that all connections are
tight. Periodically check welds for cracking caused by metal fatigue.
Avoid roll over by ensuring that loads are not top-heavy. High loads must be transported with GREAT
CAUTION to prevent loads from striking low overhead objects or tipping during turns, abrupt stops, or
high winds.

2
FEATURES AND PARTS LIST
Verify that you have received the correct quantity of hardware and parts shown below.
HARDWARE LIST
PARTS LIST
This truck rack is great for hauling ladders, lumbers, pipes, and other long and big items on your truck and
pick-up. It features heavy duty durable steel construction for high durability. It is easy to install and t all
pickup trucks as it is adjustable.
Easy To Install
Fits All Pickup Trucks
500 Lbs RATED Capacity
650 lb stationary
Max Height: approx. 32” Plus the height of your truck’s
bed
Width: Adjustable for most pickup trucks (Adjustable
width of 5’ minimum to 6’ maximum where rack attaches
to track bed)

3
ASSEMBLY AND OPERATING INSTRUCTIONS
STEP 1. Position the front Mounting Plate of the Upright leg as close to the cab as possible. Locate the
pre-drilled hole in the footplate that is furthest from the leg and drill a 3/8” hole through the truck’s bed rail.
(FIG 1) A second hole for a bolt must be drilled through both the footplate and the truck’s bed rail as close
as possible to the front leg without sacricing access to the bolt underneath the truck’s bed rail. This bolt
must be accessible in order to put on the washer and nut. Attach the footplate to the truck using bolts (A),
washers (B) and nuts (C).
Repeat Step 1 as you position the remaining Upright leg for this section.
STEP 2. Set the rack to the high (FIG 2) or low (FIG 3) position, whichever is best for the cargo and the
truck, by ipping the Crossbrace. For bowed canoes, the high position is recommended. If you choose to
ip the Crossbrace, you will have to remove and replace the Caps.
DO NOT over tighten any bolts.
STEP 3. Insert the crossbrace into the crossbrace extension (Fig 4) and set the entire assembly on top of
the upright legs. Center the crossbrace left to right and secure it with the allen head set screws (D). Secure
the crossbrace to each upright leg with the included allen head set screws.
To install the rear portion of the cargo truck rack on the truck bed, repeat the above steps. Before drilling
the mounting plate, ensure that the plate does not overhang or interfere with the tail gate.
The cargo truck rack is not ready for use.
WARNING: DO NOT EXCEED 500LB LOAD CAPACITY

4
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR
DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT
HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS
QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE MANUFACTURER AND/OR
DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE
UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER
ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL
PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION
OF REPLACEMENT PARTS THERETO.
Record Product’s Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only and are not available individually
as replacement parts.
PLEASE READ THE FOLLOWING CAREFULLY
