Starlink St-8802 User manual

www.starlink7.com

[email protected]

Specifications are subject to change without notice. Please contact your sales representative for further information.

32-Channel Digital TV Channel Filtering Optimzer/Encoder

■

Programmable Terrestrial TV and Cable TV channel filter,

combiner, converter, equalizer and amplifier

■

Capture and compose 32 TV channels to multiplex output channel

plan with Automatic Gain Control (AGC)

■

Support all TV standards - ATSC, DVB-T, ISDB-T(b), DVB-C with

6, 7 or 8 MHz channel bandwidth

■

Compact, reliable, durable and cost-effective TV channel filter

■

4 input ports with integrated preamplifier and 12 VDC (antenna)

power supply

■

Adjustable output power level between 33 and 53 dBmV to drive

signal coverage of multiple TVs

■

Intuitive on-panel 2.4” LCD and keypad operation

■

Software upgrade via mini USB

■

Web based configuration via LAN (RJ45) port

■

Output test port with 20 dB attenuation

ST-8802

ST-8802 Digital TV Channel Filter Captures up to 32 Terrestrial or Cable TV Channels to Deliver Multiplexed TV Signals over Coax Network

■

Input

● 4 x 75Ω F

■

Output

● 1 x 75Ω F

● 1 x 75Ω F Test (-20dB)

■

System Interface

● 1 x mini USB

● 1 x 1000Base-T (LAN RJ45)

Authorized Distributor of SatLink Electronics Co., Ltd. in America

Up to 32 TV channels can be captured and configured for multiplexed output with consistent output power level

All Input Ports

Input and Output

174 to 862 MHz

max 113 dBµV

Output Frequency

Output Level

Input Level

45 to 109 dB

Interface

Input 75ΩF x 4, Output 75ΩF x 1, -20dB Test 75ΩF x 1

>32 dB

Output MER

Gain

VHF 35 dB, VHF 45 dB

Gain Control

Channel AGC

Aenuator

0 to 31 dB

Electrostac Discharge

Protecon (ESD)

12 VDC, 1.5A

10.25" x 7" x 1.75" (230 x 177 x 44 mm)

2.58 lb (1.15 kg)

5 to 50 °C (Opera�on)

-20 to 80 °C (Storage)

General

Power Supply

Dimensions with Rack

Weight

Temperature

ST-8802 Specification (subject to change without notice)

Specifications are subject to change without notice. Please contact your sales representative for further information.

ST-8802

32-Channel Digital TV Channel Filtering Optimizer/Encoder

Warranty

Safety Instructions

Basic safety precautions should always be followed to reduce the risk of fire, electrical shock, and personal injury, including the following:

• Do not use this product near water – for example, near a bathtub, kitchen sink, laundry tub, or swimming pool, or in a wet basement; only clean with dry cloth.

• Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. Do not install near any heat sources such as radiators, heat registers,

stoves, or other apparatus including amplifiers that produce heat.

• Do not remove the cover of the modulator, cover the modulator with thick or heavy objects.

• Use only the power cord indicated in this manual if applicable.

This device has two-year Limited Hardware Warranty and 90-day free software updates after purchase. This Limited Warranty Statement gives the customer specific legal rights.

The customer may also have other rights which vary from State to State in the United States, from province to province in Canada, and from country to country elsewhere in the

world. To the extent that this Limited Warranty Statement shall be deemed modified to be consistent with such local law. Under such local law, certain disclaimers and

limitations of this Warranty Statement may not apply to the customer.

Authorized Distributor of SatLink Electronics Co., Ltd. in America

ST-8802 Application Scenarios

ST-8802 can replace several components in delivery path of TV signals, including

channel (signal) booster, filter, frequency converter, combiner, equalizer and amplifier ST-8802 can work with HDMI to RF modulator to combine single HDMI video channel

with Terrestrial or Cable TV channels
