OPERATOR'S MANUAL
Trailer Wood Splitter
WX530 – S/N 260265 & Up
WX 530
Part Number: Z97161_EnRev Jun-2021

Introduction WX530
Trailer Wood Splitter
2
1. Introduction
1.1 Foreword
Congratulations on choosing a Wallenstein WX530 Trailer
Wood Splitter! The 20-ton WX530 model features horizontal
and vertical splitting.
This high-quality machine is designed and manufactured to
meet the needs of an efficient wood splitting operation.
Units of measurement in Wallenstein Equipment technical
manuals are written as:
US Customary (SI metric).
Keep this manual handy for frequent reference and to pass
on to new operators or owners. Call your Wallenstein dealer
or distributor if you need assistance, information or additional
copies of the manuals.
Wallenstein Equipment Inc. • © 2021. All rights reserved.
No part of this work may be copied, reproduced, replaced,
distributed, published, displayed, modified, or transferred in
any form or by any means except with the prior permission of
Wallenstein Equipment Inc.
Review all safety, operation and maintenance information
contained in this manual.
WARNING!
Do not attempt to start or operate the machine
without thoroughly reviewing this manual for
safe and proper operation.
Always keep this manual with the machine.
W034
www.wallensteinequipment.com

WX530
Trailer Wood Splitter Introduction
3
Table of Contents
1. Introduction............................................................2
1.1 Foreword ..................................................................... 2
1.2 Delivery Inspection Report............................................ 4
1.3 Serial Number Location ................................................ 5
1.4 Warranty ...................................................................... 6
1.5 Types of Decals on the Machine................................... 7
2. Safety......................................................................8
2.1 Safety Alert Symbol...................................................... 8
2.2 Signal Words................................................................ 8
2.3 Why is SAFETY important?........................................... 9
2.4 Safety Rules................................................................. 9
2.5 Equipment Safety Guidelines ...................................... 10
2.6 Safety Training ........................................................... 10
2.7 Refueling Safety ......................................................... 10
2.8 Tire Safety.................................................................. 10
2.9 Hydraulic Safety......................................................... 10
2.10 Gas Engine Safety ...................................................... 11
2.11 Being Prepared........................................................... 12
3. Safety Signs .........................................................14
3.1 Safety Sign Explanations ............................................ 14
3.2 Safety Sign Explanations ............................................ 15
4. Familiarization......................................................16
4.1 To the New Operator .................................................. 16
4.2 Machine Components................................................. 17
5. Controls ...............................................................18
5.1 Engine........................................................................ 18
5.2 Hydraulic Valve .......................................................... 19
5.3 Stroke Limiter Accessory............................................ 21
6. Operating Instructions ........................................22
6.1 Operating Safety......................................................... 22
6.2 Before Starting the Engine .......................................... 22
6.3 Pre-operation Checklist .............................................. 23
6.4 Machine Break-In ....................................................... 23
6.5 Engine Oil Level Check ............................................... 24
6.6 Hydraulic Oil Level Check ........................................... 24
6.7 Fuel Level Check ........................................................ 25
6.8 Machine Set-up.......................................................... 25
6.9 Starting the Engine ..................................................... 26
6.10 Stopping the Engine ................................................... 26
6.11 Log Placement ........................................................... 27
6.12 Splitting Wood............................................................ 27
6.13 Vertical Splitting ........................................................ 28
6.14 Transporting............................................................... 29
6.15 Connecting a Tow Vehicle .......................................... 30
6.16 Storing the Wood Splitter............................................ 30
6.17 Removing from Storage.............................................. 30
7. Service and Maintenance....................................31
7.1 Maintenance Safety.................................................... 31
7.2 Fluids and Lubricants ................................................. 31
7.3 Maintenance Schedule ............................................... 32
7.4 Grease Points............................................................. 33
7.5 Hydraulic Oil – Changing ............................................ 34
7.6 Hydraulic Oil Filter – Changing .................................... 34
7.7 Engine Air Cleaner...................................................... 35
8. Troubleshooting...................................................36
9. Specications ......................................................37
9.1 Machine Specifications............................................... 37
9.2 Common Bolt Torque Values ...................................... 38
9.3 Hydraulic Fitting Torque.............................................. 39
9.4 Wheel Lug Torque ...................................................... 39
10. Alphabetical Index .............................................40

Introduction WX530
Trailer Wood Splitter
4
WALLENSTEIN
WX530 Trailer Wood Splitter
Pre-delivery Inspection
Inspect for damage from shipping. Immediately contact the
shipping company if damage is found.
Trailer Wood Splitter
Hydraulic Valve Control Function
Hydraulic Cylinder Function
Hydraulic Reservoir level
Engine Oil Level
Horizontal / Vertical Pivot Moves Freely (as equipped)
Front and Rear Support Stands Move freely
All fasteners are Tight
Lubricate all Pivot Points (as equipped)
Check that all Hydraulic Connections are tight
Review Operating and Safety Instructions
Safety Checks
All Safety Decals Installed
Guards and Shields Installed and Secured
Check Function of Brake and Signal Lighting
Supports Function Correctly
Safety Chain on Hitch
Retainer Installed Through Ball Hitch
Review Operating and Safety Instructions
_________________________________________
Customer’s Name
_________________________________________
Contact Name
_________________________________________
Dealer Name
(_________)_______________________________
Phone Number
_________________________________________
Serial Number
__________ /__________ /__________
Delivery Date
I have thoroughly instructed the buyer on the equip-
ment care, adjustments, safe operation and applicable
warranty policy and reviewed the manual.
_________________________________________
Dealer’s Rep. Signature
__________ /__________ /__________
Date
The product manuals have been received by me and
I have been thoroughly instructed as to care, adjust-
ments, safe operation and applicable warranty policy.
_________________________________________
Owner's Signature
__________ /__________ /__________
Date
1.2 Delivery Inspection Report
To activate warranty, register your product online at
http://www.wallensteinequipment.com

WX530
Trailer Wood Splitter Introduction
5
00664
1.3 Serial Number Location
lways provide the model and serial number of your Wallenstein
product when ordering parts, or requesting service or other
information. The product information plate location is shown in
the illustration.
Record your product Model and Serial Number in the spaces
provided below for future reference.
Record Product Information Here
Model:
Serial Number:
Fig. 1 – Product Information Plate Location
VIN/
NLV:
MODEL: ##########
#########
Manufactured by:
Wallenstein Equipment Inc., 7201 Line 86, Wallenstein ON N0B2S0, Canada
TYPE OF VEHICLE/TYPE DE VEHICLE:
TRA / REM
GAWR/PNBE (KG): GVWR/PNBV (KG):
###
DIMENSION- RIM/JANTE /ERIT: PNEU:
COLD INFL. PRESS/PRESS DE
CONFLA A FROID (PSI/LPC):
THIS VEHICLE CONFORMS TO ALL APPLICABLE STANDARDS
PRESCRIBED UNDER THE CANADIAN MOTOR SAFTEY REGULATIONS
IN EFFECT ON THE DATE OF MANUFACTURE / CE VEHICLE EST
CONFORME A TOUTES LES NORMES QUI LUI SONT APPLICABLES EN
VERTU DU REGLEMENT SUR LA SECURITE DES VEHICLES
AUTOMOBILES DU CANADA EN VIGUEUR A LA DATE DE SA FABRICATION.
###
### ###
###

Introduction WX530
Trailer Wood Splitter
6
1.4 Warranty
rev. Nov-2018
LIMITED WARRANTY
Wallenstein products are warranted to be free of defects in materials and
workmanship under normal use and service, for a period of
Five Years for Consumer Use
Two Years for Commercial/Rental Use
from the date of purchase, when operated and maintained in accordance with the operang
and maintenance instrucons supplied with the unit. Warranty is limited to the repair of the
product and/or replacement of parts.
This warranty is extended only to the original purchaser and is not transferable.
Repairs must be done by an authorized dealer. Products will be returned to the dealer at the
customer’s expense. Include the original purchase receipt with any claim.
This warranty does not coverthe following:
1) Normal maintenance or adjustments
2) Normal replacement of wearable and service parts
3) Consequen damage, indirect damage, or loss of prots
4) Damages resulng from:
•Misuse, negligence, accident, theor re
•Use of improper or insucient fuel, uids or lubricants
•Use of parts or aermarket accessories other than genuine Wallenstein parts
•Modicaons, alteraon, tampering or improper repair performed by pares other
than an authorized dealer
•Any device or accessories installed by pares other than an authorized dealer
5) Engines. Engines are covered by the manufacturer of the engine for the warranty period
they specify. For the details of your engine warranty, see your engine owner’s manual.
Informaon about engine warranty and service is also available in the FAQ secon at
www.wallensteinequipment.com

WX530
Trailer Wood Splitter Introduction
7
1.5 Types of Decals on the Machine
When getting familiar with the Wallenstein product, notice that
there are numerous decals located on the machine. There are
different types of decals for safety, information, and product
identification. The following section explains what they are for
and how to read them.
Safety Decals are pictorial with a yellow background and
generally two panel. They can be either vertical or horizontal.
Safety Notice Decals are pictorial with a blue background and
generally rectangular with single or multiple symbols. This decal
informs what Personal Protective Equipment is required for safe
operation.
Informative Decals are generally pictorial with a white
background and can vary in the number of panels. This type of
decal provides additional information to the operator or explains
the operation of a control.
Product Decals indicate machine model and serial number, and
other important information.
VIN/
NLV:
MODEL: ##########
#########
Manufactured by:
Wallenstein Equipment Inc., 7201 Line 86, Wallenstein ON N0B2S0, Canada
TYPE OF VEHICLE/TYPE DE VEHICLE:
TRA / REM
GAWR/PNBE (KG): GVWR/PNBV (KG):
###
DIMENSION- RIM/JANTE /ERIT: PNEU:
COLD INFL. PRESS/PRESS DE
CONFLA A FROID (PSI/LPC):
THIS VEHICLE CONFORMS TO ALL APPLICABLE STANDARDS
PRESCRIBED UNDER THE CANADIAN MOTOR SAFTEY REGULATIONS
IN EFFECT ON THE DATE OF MANUFACTURE / CE VEHICLE EST
CONFORME A TOUTES LES NORMES QUI LUI SONT APPLICABLES EN
VERTU DU REGLEMENT SUR LA SECURITE DES VEHICLES
AUTOMOBILES DU CANADA EN VIGUEUR A LA DATE DE SA FABRICATION.
###
### ###
###
Maintenance Decals have a green background and can vary
to the number of panels. This decal shows a type maintenance
required and frequency interval.
See the section on safety signs for safety decal definitions.
For a complete illustration of decals and decal locations,
download the parts manual for your model product at
www.wallensteinequipment.com.

Safety WX530
Trailer Wood Splitter
Safety
8
2. Safety
2.1 Safety Alert Symbol
This Safety Alert Symbol means:
ATTENTION! BE ALERT!
YOUR SAFETY IS INVOLVED!
The Safety Alert Symbol identifies important safety messages
on the Wallenstein wood splitter and in the manual. When you
see this symbol, be alert to the possibility of personal injury or
death. Follow the instructions in the safety message.
2.2 Signal Words
The signal words DANGER, WARNING and CAUTION determine
the seriousness level of the warning messages in this manual.
The appropriate signal word for each message in this manual
has been selected using the following guidelines:
DANGER –
Indicates an imminently hazardous situation that, if not avoided,
will result in death or serious injury. This signal word is to be
limited to the most extreme situations typically for machine
components which, for functional purposes, cannot be guarded.
WARNING –
Indicates a potentially hazardous situation that, if not avoided,
could result in death or serious injury, and includes hazards that
are exposed when guards are removed. It may also be used to
alert against unsafe practices.
CAUTION –
Indicates a potentially hazardous situation that, if not avoided,
may result in minor or moderate injury. It may also be used to
alert against unsafe practices.
IMPORTANT – To avoid confusing equipment protection with
personal safety messages, a signal word IMPORTANT indicates
a situation that if not avoided, could result in damage to the
machine.

WX530
Trailer Wood Splitter Safety
Safety
9
2.3 Why is SAFETY important?
Three Big Reasons:
• Accidents Disable and Kill
• Accidents Cost
• Accidents Can Be Avoided
The policy of Wallenstein Equipment Inc. is to produce products
that are safe and reliable. However, even when using well-
engineered equipment, there is always an element of risk. To
minimize the risks and promote safety at all times, this section
of the operator’s manual details a number of safety rules that
must always be followed and obeyed.
YOU are responsible for the SAFE operation and maintenance of
your Wallenstein Trailer Wood Splitter. YOU must ensure that you
and anyone else who is going to use, maintain or work around
the wood splitter be familiar with the operating and maintenance
procedures and related safety information contained in this
manual. This manual provides good safety practices that should
be followed while using the wood splitter.
Remember, YOU are the key to safety. Good safety practices
not only protect you but also the people around you. Make
these practices a working part of your safety program. Be
certain that EVERYONE using this equipment is familiar with the
recommended use and maintenance procedures and follows all
the safety precautions.
2.4 Safety Rules
• DO give operating instructions to operators or employees
before allowing them to operate the machine, and REVIEW
annually thereafter.
• DO read and understand ALL Safety and
Operating instructions in the manual and
follow them. The most important safety
device on this equipment is a SAFE
operator.
• DO review safety related items annually with all personnel
who are operating the machine or performing maintenance.
• DO wear appropriate Personal Protective Equipment (PPE).
The suggested equipment includes but is not limited to the
following:
-Hearing Protection
-Protective glasses, goggles or face shield
-Heavy work gloves
-Protective shoes with slip resistant soles
• DO have a first-aid kit available for use
should the need arise and know how to
use it.
• DO read and understand all safety signs located on the
machine before operating, servicing, adjusting, or cleaning.
• DO inspect and secure all guards before starting.
• DO check engine intake and exhaust. Make sure they are
clear of debris prior to starting the machine.
• DO have a fire extinguisher available for use
should the need arise. Know how to use it.
• DO think SAFETY! Work SAFELY!
• DO NOT touch hot engine parts, muffler cover, hydraulic
hoses, engine body, engine oil, and so on during operation
or if the engine was recently shut off. Contact may cause
burns.
• DO NOT expect a person who has not read and understood
all operation and safety instructions to use the machine.
An untrained operator is not qualified and is exposed
to possible serious injury or death. It is the owner's
responsibility to make sure to the operator has familiarity
and understanding of the machine.
• DO NOT allow riders during transport.
• DO NOT risk injury or death by ignoring good safety
practices.

Safety WX530
Trailer Wood Splitter
Safety
10
2.5 Equipment Safety Guidelines
Always place the machine in a Safe Condition before
performing any service work, maintenance procedures, or
storage preparation.
SAFE CONDITION
• Shut off engine.
• Make sure all moving parts have stopped.
• Disconnect battery ground (-) cable.
• Block or chock wheels.
• Never use equipment with safety shields removed. Keep all
shields in place. If shield removal becomes necessary for
repairs, reinstall the shield prior to use.
• Replace any safety sign or instruction sign that is not
readable or is missing. Location of safety signs is indicated
in this manual.
• Do not allow anyone other than a responsible, properly
trained and physically able person to operate this machine.
This equipment is dangerous to children and persons
unfamiliar with its operation.
• Do not modify the equipment in any way. Unauthorized
modification may result in serious injury or death and may
impair the function and life of the equipment.
• Never exceed the limits of the machine. If its ability to do
the job or to do it safely is in question—
STOP IMMEDIATELY!
2.6 Safety Training
• The best safety feature is an
informed, careful operator—we ask
you be that kind of operator. It is
the operator's responsibility to read,
understand and follow ALL safety
and operation instructions in the
manual.
• Train all new personnel and review instructions frequently
with existing workers. Only properly trained and physically
able operators should use this equipment. A person who
has not read and understood all operation and safety
instructions is not qualified to use the machine. Untrained
operators expose themselves and bystanders to possible
serious injury or death. If elderly people are assisting with
the work, their physical limitations need to be recognized
and accommodated.
• Learn the controls and how to stop the machine quickly in
an emergency.
• If this machine is loaned or rented, it is the machine
owner's responsibility to make certain that every operator:
-Reads and understands the owner's manual
-Is instructed in safe and proper use of the equipment
-Understands and knows how to perform the Safe
Condition procedure
2.7 Refueling Safety
• Engine fuel is highly flammable. Handle with care.
• Fill fuel tank outdoors.
• Stop the engine before refueling. Allow engine to cool for
five minutes. Clean up spilled fuel before restarting engine.
• Do not overfill the fuel tank.
• If fuel is spilled, wipe it away carefully and wait until the fuel
has dried before starting the engine.
• Do not refuel the machine while
smoking or when near open flame or
sparks.
• After refueling, make sure that the fuel cap is secured to
prevent spillage.
• Prevent fires by keeping machine clean of accumulated
trash, grease, and debris.
2.8 Tire Safety
• Failure to follow proper procedures when mounting a tire on
a wheel or rim can produce an explosion which may result
in serious injury or death.
• Do not attempt to mount a tire unless you have the proper
equipment and experience to do the job.
• Have a qualified tire dealer or repair service perform
required tire maintenance.
• When replacing worn tires, make sure they meet the
original tire specifications. Never install undersized tires.
2.9 Hydraulic Safety
• Make sure that all the components in the hydraulic system
are kept in good condition and are clean.
