STARPLUS STSe Key System User manual

August 2005 - Issue 1.0
STARPLUS
STSe Key Systems
Installation Manual
TM

Copyright © 2005 VODAVI Technology, Inc.
All Rights Reserved
This material is copyrighted by VODAVI Technology, Inc., and may be duplicated by Authorized
Dealers only. Any unauthorized reproductions, use or disclosure of this material, or any part
thereof, is strictly prohibited and is a violation of the Copyright Laws of the United States
(17 U.S.C. Section 101 et. seq.).
VODAVI reserves the right to make changes in specifications at any time and without notice. The
information furnished by VODAVI in this material is believed to be accurate and reliable, but is
not warranted to be true in all cases.
STARPLUS™ is a Registered trademark of VODAVI Technology, Inc.
mlj/2005
Issue Release Date Changes Page
1.0 8-05 Initial Release --
LIFE SUPPORT APPLICATIONS POLICY
VODAVI Communications Systems products are not authorized for and should not be used
within Life Support applications. Life Support systems are equipment intended to support or
sustain life and whose failure to perform when properly used in accordance with instructions
provided can be reasonably expected to result in significant personal injury or death.
VODAVI Communications Systems warranty is limited to replacement of defective
components and does not cover injury to persons or property or other consequential damages.

Regulatory Information (U.S.A.)
The Federal Communications Commission (FCC)
established rules to allow the direct connection of the
STSe to a telephone network. Certain actions must be
undertaken or understood before the connection of
customer provided equipment is completed.
Telephone Company Notification
Before connecting the STSe to the telephone network,
the local serving telephone company must be given
advance notice of intention to use customer provided
equipment, and must be provided with the following
information:
Telephone Numbers
The telephone numbers to be connected to the system.
STSe System Information
The Ringer Equivalence Number is also located on
the KSU: 1.3B
The USOC jack required for direct interconnection
with the telephone network: RJ21
FCC Registration Number:
5JYMF07BV70E
Incidence of Harm
If the telephone company determines that the customer
provided equipment is faulty and possibly causing harm
or interruption to the telephone network, it should be
disconnected until repairs can be made. If this is not
done, the telephone company may temporarily
disconnect service.
Changes in Service
The local telephone company may make changes in its
communications facilities or procedures. If these
changes affect the use of the STSe or compatibility with
the network, the telephone company must give written
notice to the user to allow uninterrupted service.
Maintenance Limitations
Maintenance on the STSe System must be performed
only by the manufacturer or its authorized agent. The
user may not make any changes and/or repairs except as
specifically noted in this manual. If unauthorized
alterations or repairs are made, any remaining warranty
and the software license for the system will be voided.
Hearing Aid Compatibility
All STSe Digital Terminals are Hearing Aid Compatible,
as defined in Section 68.316 of Part 68 FCC Rules and
Regulations.
UL/CSA Safety Compliance
The STSe System has met all safety requirements and
was found in compliance with the Underwriters
Laboratories (UL) 1459. This system is authorized to bear
the “NRTL/C” marking.
Notice of Compliance
The STSe System complies with rules regarding
radiation and radio frequency emissions by Class A
computing devices. In accordance with FCC Standard 15
(Subpart J), the following information is supplied to the
end user:
“This equipment generates and uses RF energy
and if not installed and used in accordance with
the Instruction Manual, may cause interference to
Radio Communications. It has been tested and
found to comply with the limits for a Class A computing
device, pursuant to Subpart J of Part 15 of the FCC Rules,
which are designed to provide reasonable protection
against such interference, when operated in a commercial
environment. Operation of this equipment in a residential
area is likely to cause interference, in which case the user, at
his own expense, will be required to take whatever
measures may be required to correct the interference.”
“WARNING: Handling the cord on this product will
expose you to lead, a chemical known to the State of
California to cause [cancer, and] birth defects or other
reproductive harm. Wash hands after handling.”
Toll Fraud and DISA Disclaimer
“While this device is designed to be reasonably secure
against intrusions from fraudulent callers, it is by no
means invulnerable to fraud. Therefore, no express or
implied warranty is made against such fraud including
interconnection to the long distance network.”
“While this device is designed to be reasonably secure
against invasion of privacy, it is by no means
invulnerable to such invasions. Therefore, no express or
implied warranty is made against unlawful or
unauthorized utilization which results in the invasion of
one’s right of privacy.”
Vodavi has made every reasonable effort to ensure that
this product works in most business environments.
However, there may be some environments (RFI and EFI)
in which this product may not work properly. In such
cases, it is the responsibility of the installer to take the
necessary actions to correct the situation.

Contents i
STARPLUS STSe - Installation Manual August2005
Contents
1Introduction
General Information ................................................................................................... 1-3
System Overview .............................................................................................................................. 1-3
System Interface Boards ......................................................................................................... 1-3
CO Circuitry .................................................................................................................................. 1-3
System Programming / Database ........................................................................................ 1-3
Keyset / DSS Console ................................................................................................................ 1-3
Software Upgrades ................................................................................................................... 1-4
Key Service Unit .......................................................................................................... 1-4
Basic Cabinet ...................................................................................................................................... 1-4
Basic System Configuration ................................................................................................... 1-5
Main Board Unit ......................................................................................................................... 1-5
Single Line Interface Board (2 port) .................................................................................... 1-5
Ring Generator Unit .................................................................................................................. 1-6
Expansion Cabinet ........................................................................................................................... 1-6
Built-in Power Supply ...................................................................................................................... 1-6
Extension Boards ........................................................................................................ 1-6
Digital Telephone Interface Board (8 port) .............................................................................. 1-6
Single Line Telephone Interface Board (4 port) ..................................................................... 1-7
CO Interface Boards .................................................................................................... 1-7
Loop Start CO Line Interface Board ............................................................................................ 1-7
T1 Interface Board ............................................................................................................................ 1-7
Primary Rate Interface Board ........................................................................................................ 1-8
Add-On Boards ............................................................................................................ 1-8
Message Wait Unit ............................................................................................................................ 1-8
Modem Unit ........................................................................................................................................ 1-8
Phase Lock Loop Unit ...................................................................................................................... 1-8
2 System Specifications
Configuration Tables .................................................................................................. 2-3
System Capacity ................................................................................................................................ 2-3
Visual Specifications ........................................................................................................................ 2-4
CO Line Buttons ......................................................................................................................... 2-4
DSS/BLF Buttons ........................................................................................................................ 2-5
Feature/Function Buttons ...................................................................................................... 2-5
Tone Specifications .......................................................................................................................... 2-6
Audible Signals ........................................................................................................................... 2-6
Miscellaneous Specifications ........................................................................................................ 2-7
3Installation
Installation Overview ................................................................................................. 3-3
Basic Process ....................................................................................................................................... 3-3

ii Contents
STARPLUS STSe - Installation Manual August2005
Site Preparation .......................................................................................................... 3-3
General Site Considerations .......................................................................................................... 3-3
Backboard Installation .................................................................................................................... 3-4
Verify On-Site Equipment .............................................................................................................. 3-4
KSU Mounting ............................................................................................................. 3-5
Basic Cabinet ...................................................................................................................................... 3-5
Expansion Cabinet ........................................................................................................................... 3-6
System Preparation .................................................................................................... 3-6
KSU Grounding .................................................................................................................................. 3-6
Grounding Instructions ........................................................................................................... 3-6
Built-in Power Supply ...................................................................................................................... 3-7
Battery Backup Unit Installation .................................................................................................. 3-7
Battery Backup Wiring ............................................................................................................. 3-7
System Backup Duration ........................................................................................................ 3-7
System Battery Replacement - WARNING ........................................................................ 3-7
Power Line Surge Protection ........................................................................................................ 3-8
Lightning Protection ................................................................................................................ 3-8
KSU AC Power Plug ................................................................................................................... 3-8
Cable Connections ........................................................................................................................... 3-8
PCB Handling and General Installation ..................................................................................... 3-8
Inserting a PCB ........................................................................................................................... 3-8
Card Slot Configuration .................................................................................................................. 3-9
Board Capacity ........................................................................................................................... 3-9
Card Slot Positions .................................................................................................................... 3-9
BKSU & Main Board Unit Assembly ........................................................................... 3-10
Main Board Unit ................................................................................................................................ 3-10
Initialize Default Settings ........................................................................................................ 3-10
Retain Database ......................................................................................................................... 3-10
Digital Telephone Interface Board (built-in) ........................................................................... 3-11
Loop Start CO Interface Board (with Caller ID) ....................................................................... 3-11
Installing CIDU to Built-In LCOB ........................................................................................... 3-11
Program Module Unit ..................................................................................................................... 3-12
Installing the PMU ..................................................................................................................... 3-12
Single Line Interface Board (2 Port with built-in Msg Wait) .............................................. 3-12
Expansion Board Installation ..................................................................................... 3-13
Digital Telephone Interface Board ............................................................................................. 3-13
Loop Start CO Interface Board (with Caller ID) ....................................................................... 3-13
Installing CIDU Board to LCOB .............................................................................................. 3-14
Single Line Interface Board - 4 Port ............................................................................................ 3-14
Message Wait Unit .................................................................................................................... 3-15
T1 Interface Board ............................................................................................................................ 3-16
Phase Lock Loop Unit ............................................................................................................... 3-19
DTMF Tone Detection Units .................................................................................................. 3-20
Primary Rate Interface Board ........................................................................................................ 3-21
ISDN and T1 Clocking ...................................................................................................................... 3-23

Contents iii
STARPLUS STSe - Installation Manual August2005
Example - Settings .................................................................................................................... 3-23
Voice Mail Interface Boards ........................................................................................................... 3-24
Installing the Flash-Based Voice Mail Card ....................................................................... 3-24
Installing the Hard Drive-Based Voice Mail Card ............................................................ 3-25
Modem Unit ........................................................................................................................................ 3-26
System Software ......................................................................................................... 3-27
Station/CO Wiring ....................................................................................................... 3-28
Digital & Single Line Wiring .......................................................................................................... 3-28
Digital Stations ........................................................................................................................... 3-28
Single Line Stations .................................................................................................................. 3-28
CO Champ Connectors ............................................................................................................3-28
Digital Keyset & Terminal Wiring ................................................................................................ 3-32
ADP Modular Jack ..................................................................................................................... 3-32
Digital Loop Extender .............................................................................................................. 3-33
Computer Telephone Integration Module ....................................................................... 3-34
Single Line Adapter .................................................................................................................. 3-35
Single Line Telephone Wiring ...................................................................................................... 3-35
Keyset/Headset Installation ....................................................................................... 3-36
Wall Mounting the Digital Keyset ...............................................................................................3-36
Installing a Headset .......................................................................................................................... 3-37
System Checkout ........................................................................................................ 3-38
Preliminary Procedures .................................................................................................................. 3-38
Power Up Sequence ........................................................................................................................ 3-38
Door Box ...................................................................................................................... 3-39
4 Maintenance and Troubleshooting
System Programming and Verification ..................................................................... 4-3
Telephone and Terminal Troubleshooting ............................................................... 4-3
Keyset Self Test ........................................................................................................... 4-4
Keyset LCD/LED Test ........................................................................................................................ 4-4
Keyset Button Test ............................................................................................................................ 4-5
DSS LED/Button Test ....................................................................................................................... 4-5
Key Telephones/Terminals ............................................................................................................ 4-6
Single Line Telephones ................................................................................................................... 4-6
DSS/BLF Console ............................................................................................................................... 4-7
CO Line Card Functions .............................................................................................. 4-7
System Functions ........................................................................................................ 4-8
Remote Maintenance ................................................................................................. 4-9
General Overview ............................................................................................................................. 4-9
Maintenance Command Format .......................................................................................... 4-9
Maintenance Password ...........................................................................................................4-9
Exit Maintenance ....................................................................................................................... 4-9
System Configuration ..................................................................................................................... 4-10
Station Configuration ...................................................................................................................... 4-11
CO Line Configuration .................................................................................................................... 4-12

iv Contents
STARPLUS STSe - Installation Manual August2005
Event Trace Buffer ............................................................................................................................. 4-13
DTMF Receiver Trace ....................................................................................................................... 4-14
Basic Format for Commands ................................................................................................. 4-14
Examples ....................................................................................................................................... 4-14
Remote System Monitor ............................................................................................. 4-14
General Overview ............................................................................................................................. 4-14
Monitor Password ............................................................................................................................. 4-15
Help Menu ........................................................................................................................................... 4-15
Dump Memory Data ........................................................................................................................ 4-15
Event Trace Mode ............................................................................................................................. 4-16
Modify Memory Command ........................................................................................................... 4-17
Exit the Monitor Mode .................................................................................................................... 4-18
SMDR ............................................................................................................................ 4-18
Upload/Download Flash ROM ..................................................................................................... 4-20
Frequently Asked Questions ...................................................................................... 4-21

Figures v
STARPLUS STSe - Installation Manual August 2005
Figures
Built-In LCOB with CIDU ................................................................................................................................... 3-11
SLIB2 (2 port) ........................................................................................................................................................ 3-12
DTIB (8 Port) .......................................................................................................................................................... 3-13
LCOB with CIDU ................................................................................................................................................... 3-13
SLIB4 (4-Port) with MSGU48 ............................................................................................................................ 3-14
SLIBC (4-Port) with MSGU48 ........................................................................................................................... 3-15
T1IB (24 channel) with two DTRUs ................................................................................................................ 3-16
PLLU Location ...................................................................................................................................................... 3-20
PRIB w/DTRU4 Module Installation .............................................................................................................. 3-22
Flash-Based Voice Mail Card ........................................................................................................................... 3-24
Hard Drive-Based Voice Mail Card ................................................................................................................ 3-25
MODU Installation Location ............................................................................................................................ 3-26
U2 and U3 EPROM Locations .......................................................................................................................... 3-27
Digital Station Jack Wiring ............................................................................................................................... 3-32
SLA (Single Line Adapter) ................................................................................................................................ 3-35
Single Line Telephone Wiring ........................................................................................................................ 3-35
Door Box ................................................................................................................................................................ 3-39
Maintenance Help Menu .................................................................................................................................. 4-9
System Configuration ....................................................................................................................................... 4-10
Station Configuration ........................................................................................................................................ 4-11
CO Line Configuration ...................................................................................................................................... 4-12
Help Menu ............................................................................................................................................................. 4-15
Trace Mode Status .............................................................................................................................................. 4-16
Enable Event Trace ............................................................................................................................................. 4-17
Event Trace ............................................................................................................................................................ 4-18
SMDR Printout .................................................................................................................................................... 4-19

vi Figures
STARPLUS STSe - Installation Manual August 2005

Tables vii
STARPLUS STSe - Installation Manual August 2005
Tables
Function Capacity ............................................................................................................................................... 2-3
Visual Signals - CO Line Buttons .................................................................................................................... 2-4
Visual Signals - DSS/BLF Buttons ................................................................................................................... 2-5
Visual Signals - Feature / Function Buttons ............................................................................................... 2-5
Signals To Called Station (Digital Station) ................................................................................................. 2-6
Signals To Calling Station ................................................................................................................................ 2-7
Dialing Specifications ........................................................................................................................................ 2-7
Electrical Specifications .................................................................................................................................... 2-8
Environmental Specifications ......................................................................................................................... 2-8
Loop Limits ............................................................................................................................................................ 2-8
Dimensions and Weights ................................................................................................................................. 2-8
T1 Switch Positions ............................................................................................................................................ 3-17
T1 Ordering Specifications .............................................................................................................................. 3-17
T1 Ordering Information .................................................................................................................................. 3-17
Call Routing Criteria ........................................................................................................................................... 3-18
Call Routing Display Format ........................................................................................................................... 3-18
Telco to T1IB Interconnect Diagram - Pin Connections ........................................................................ 3-18
PRIB Ordering Information .............................................................................................................................. 3-21
Telco to PRIB Interconnect Diagram - Pin Connections ........................................................................ 3-21
Power Supply Tests ............................................................................................................................................ 3-38
Flash Rates ............................................................................................................................................................. 4-5
Key Telephones/Terminals .............................................................................................................................. 4-6
Single Line Telephone ....................................................................................................................................... 4-6
DSS/BLF Console ................................................................................................................................................. 4-7
CO Line Loop Start Board (LCOB) .................................................................................................................. 4-7
System Functions ................................................................................................................................................ 4-8
Event Trace Buffer Command ........................................................................................................................ 4-13

viii Tables
STARPLUS STSe - Installation Manual August 2005

STARPLUS STSe - Installation Manual August 2005
1Introduction
This manual provides the information necessary to operate and maintain the STSe System. The
described features are based on the current software release. If any of these features do not
work on your system, call your sales representative.
This chapter describes and illustrates the components that may be used with the STSe System.

» » » » » » » NOTES » » » » » » »

General Information 1-3
Chapter 1 - Introduction
STARPLUS STSe - Installation Manual August 2005
General Information
System Overview
The STSe Key Telephone System supports a maximum configuration of 28 CO/PBX/Centrex
lines and 50 station devices. The Basic Key Service Unit (BKSU) and Expansion Key Service Unit
(EKSU) accommodates plug-in boards that can be added to expand CO/STA capacity. Both
KSUs can generally support a 12x24 configuration for a total capacity of 28x50. The BKSU and
EKSU cabinets are installed using industry-standard blocks, jacks, and skinny wire cabling. This,
combined with the ability to program the system using a key terminal with a digital display,
reduces installation cost and maintenance requirements.
An optional 9600-baud Modem Unit (MODU) facilitates remote programming.
System Interface Boards
The STSe system can support the following types of interface boards:
CO card provides 4 loop start lines (LCOB)
Station card provides interface for 2 or 4 single line telephones or 8 digital key telephones
(SLIB or DTIB)
Primary Rate Interface Board (PRIB)
T-1 Interface Board (T1IB)
Primary Rate Interface Board (PRIB)
Voice Mail Interface Board (VMIB)
CO Circuitry
All CO interfaces are equipped with transformer barriers for system classification as a FCC fully
protected system. Each CO circuit supports rotary (out-pulse) dialing and loop supervision
(disconnect detection) under software control. The DTMF tone signals and system supervisory
tones can be generated in each keyset or on the main PCB. The STSe system uses a proprietary
tone plan for providing internal progress tones.
System Programming / Database
The system architecture allows system programmingchanges to be made without interrupting
state event software control of normal communications. Call processing continues while the
customer database is updated. All programming changes to the customer database
programming are made either from a digital terminal (Station 100) or from a terminal
connected to either an I/O port or remotely via the optional modem board.
Keyset / DSS Console
The STSe system features a digital telephone with 24 flexible buttons, 3 interactive soft keys, a
2 x 24 LCD display, and includes speakerphone capabilities. A 48-button DSS console is also
available. Each telephone can connect to an optional CTI "box". The optional CTI box provides
data connections and transmissions through an RS-232C connection on the phone.

1-4 Key Service Unit
Chapter 1 - Introduction
STARPLUS STSe - Installation Manual August 2005
Software Upgrades
Future software enhancements and upgrades are easily retrofitted and installed in the system.
This will in most cases, provide backward compatibility with existing Starplus hardware, further
reducing the cost to upgrade or add features to an installed system.
Key Service Unit
This diagram illustrates the basic layout of both KSU cabinets, the card slots for the extension
boards, and the locations of the Champ connectors.
Basic Cabinet
The Basic Key Set Unit (BKSU) has mounting holes so that it can be mounted on the wall. The
Main Board Unit (MBU) contains the main CPU – MC68LC302, Memory – the memory size is
1 Mbyte (4Mbit x 2), Data is 512 Kbytes (1 Mbit x 4), and all other system-operating type circuitry
to support the maximum configuration of 28 CO lines and 50 stations.
A power supply board is also installed to provide enough power to support all CO lines, stations,
and daughter board options. The BKSU has an external power switch to turn power on/off to
the BKSU and EKSU.
50-pin amphenol connectors are located on the side of the BKSU to provide the interface for the
Station and CO boards.
Basic
SLIB2
DTIB
or SLIB
LCOB,
PRI, or
T1IB, PRI,
or VMIB
EKSU
BKSU
CO Champ
(Male)
Sta Champ
(Female)
CO Champ
(Male)
Sta Champ
(Female)
LCOB
or T1IB
LCOB
or T1IB
DTIB
or SLIB
Slot 2 Slot 3 Slot 4 Slot 5 Slot 6 Slot 7
Slot 8 Slot 9 Slot 10 Slot 11 Slot 12 Slot 13
T1IB

Key Service Unit 1-5
Chapter 1 - Introduction
STARPLUS STSe - Installation Manual August 2005
Basic System Configuration
DEFAULT -- The following extension boards are installed in each BKSU and will support the
following types of CO lines / stations:
Main Board Unit
The Main Board Unit (MBU) controls and manages communication between peripheral
interface, supervises all resources in the system, controls gain adjustment of PCM signal,
generates system tone, and manages call processing of the system.
PERIPHERAL & DAUGHTER BOARDS -- The following can be installed on the
BKSU’s MBU:
1 - Modem Unit
2 - Digital Telephone Interface Boards (8 port)
1 - T1 Interface Board (24 channels) & 1 Phase Lock Loop Unit
2 - Single Line Interface Boards (4 port) & 2 Message Wait Units
1 - Primary Rate Interface Board (24 channels)
1 - VM Interface Board (8 port)
2 - Loop Start CO Line Boards w/caller ID Unit (4 port)
STANDARD CIRCUITRY -- The following circuitry is standard on the BKSU’s MBU:
1 - Music Input (MOH/BGM channel 1)
1 - Relay (s/w assignable)
1 - External page port
1 - Memory battery (lithium)
2 - DTMF receivers
1 - Alarm Sensing Port
2 - RS-232 (DB9) (male)
Single Line Interface Board (2 port)
The Single Line Interface Board (SLIB2) that is included with all BKSUs, provides two standard
24V 2500-type Single Line interfaces. Two SLT connections on the right side of the BKSU use
RJ11 modular connectors.
The Single Line station circuit specifications of the SLIB2 are as follows:
One-pair wiring to SLT devices
24 V power for both circuits
RGU power for both circuits
Built-in Message Wait Unit (MSGU) (2circuit)
Loop interrupt
Standard Boards Provides …
DTIB 8 Digital Telephone Lines
SLIB2 2 Single Line Telephone Lines
LCOB 4 Loop Start CO Lines (includes Caller ID Unit)

1-6 Extension Boards
Chapter 1 - Introduction
STARPLUS STSe - Installation Manual August 2005
Ring Generator Unit
The Ring Generator Unit (RGU) provides the ring voltage to the SLIB circuits to ring the SLT. The
RGU also provides the input to the Message Wait source on the SLIB cards. The output of the
RGU is 65V AC, 25 Hz. The RGU can support simultaneous ringing for all SLTs associated to the
SLIB. The RGU is built-into the SLIB2 and into the SLIB4.
Expansion Cabinet
The Expansion Key Service Unit (EKSU) mounts above the BKSU and is connected via cables that
extend the voice and data signaling to and from the BKSU. An integral power supply provides
enough power to support all CO lines, stations, and daughter board options.
The EKSU has mounting holes so that it can be mounted on the wall. The station connections
are via a 50-pin amphenol connector. This connector is located in the EKSU. CO connections are
50-pin type and are located on the EKSU board.
Built-in Power Supply
A Power Supply is built into each cabinet’s MBU.
The Power Supply converts commercial AC power (105 / 117 / 129 V AC @ 47-63 Hz) to ±5V DC
voltage output, regulates the voltage, and provides the appropriate DC voltage for distribution
to other system components.
The Power Supply includes circuitry to charge two externally-connected 12-volt batteries and
controls operation of the battery back-up circuits. The Power Supply provides system
operating voltages from the batteries if commercial AC power fails.
Extension Boards
These extension boards are capable of supporting the following types of telephones:
Digital Telephone Interface Board (8 port)
The Digital Telephone Interface Board (DTIB) provides 2-wire interfaces for telephone
connection. The DTIB provides digital voice and data communications to/from digital
telephones. This card provides eight standard Digital Telephone Interface circuits and installs
in the BKSU or EKSU.
An industry-standard amphenol-type female connector is mounted on the side of the KSU for
connection to the station interfaces. One LED is mounted on the PCB to indicate the in use state
of the connected telephones. It will turn on when one or more ports are busy.
The digital station circuit specifications: One-pair wiring to digital devices
Board Name Function
DTIB Provides 8 Digital Telephone interfaces
SLIB4 Provides 4 Single Line Telephone interfaces
SLIBC Provides 4 Single Line Telephone interfaces & Caller ID

CO Interface Boards 1-7
Chapter 1 - Introduction
STARPLUS STSe - Installation Manual August 2005
Single Line Telephone Interface Board (4 port)
The Single Line Telephone Interface Board (SLIB4/SLIBC) provides four standard 24V 2500-type
Single Line interfaces. The Single Line station circuit specifications for the SLIB4/SLIBC are as
follows:
One-pair wiring to SLT devices
24 V power for all four circuits
RGU power for all four circuits
Optional Message Wait Unit (MSGU4) (4 circuit)
Loop interrupt
CO Interface Boards
The types of CO Interface boards that can be added to the STSe System are listed in the table
and narrative that follow.
Loop Start CO Line Interface Board
The optional Loop Start CO Line Interface Board (LCOB) provides four Loop Start CO Lines which
support pulse/DTMF signal.
Each interface contains ring and loop current detection circuits, Analog-to-Digital and Digital-
to-Analog conversions, and pulse and ground flash signaling circuits.
The LCOB contains LEDs to indicate the in use status of each CO Line. The trunk circuit
specifications include: 50-pin amphenol connectors (located on the side of the KSU), Loop
detector, and Hybrid CO circuit.
T1 Interface Board
The T1 Interface Board (T1IB) provides the T1 (1.544Mbps, 24-Channel) interface circuit, control
circuitry, and synchronous clock control circuits.
DTMF tone detection units can be installed optionally on the T1IB.
The T1IB has eight LEDs on the front edge of the PCB which indicates errors of T1 line, in-use
status, and synchronous clock enable status.
Board Name Function
LCOB Provides 4 Loop Start CO Lines
T1IB Provides 24 channels
PRIB Provides 23 bearer channels and 1 data channel

1-8 Add-On Boards
Chapter 1 - Introduction
STARPLUS STSe - Installation Manual August 2005
Primary Rate Interface Board
The Primary Rate Interface Board (PRIB) provides one Primary Rate Interface circuit. Each circuit
contains 23 bearer and one data channel (23B+D). When a PRIB card is programmed into the
system, the system interprets all B channels as trunks. Thus, one PRIB which contains 23B+D
circuits provides 23 line appearances to the system. The PRIB card uses 24 time slots when
installed.
The PRIB must usually be used in conjunction with a Channel Service Unit (CSU). Connection is
made via a RJ-45 from the PRIB to the CSU.
The PRIB accepts two DTRU4 boards.
When ordering PRI lines from the telephone company, specify ESF framing and B8ZS line
coding. PRI only supports National ISDN 2 (NI-2). No other standards are supported.
» Add-on Boards: DTRU4
Add-On Boards
Message Wait Unit
The Message Waiting Unit (MSGU48) provides a 90V message voltage to light the message
indicator on single line telephones.
One MSGU can be installed on each SLIB4/SLIBC (required if message wait indication is
needed).
Modem Unit
The Modem Unit (MODU) provides a communication interface for remote maintenance and
remote PC Admin.
The MODU allows the system to function as follows:
Operates at 9600 baud and installs in the BKSU.
Provides an asynchronous modem for access to the system database and fault reporting
features from a remote site.
May be connected to a pre-selected CO Line through the system-switching matrix.
The MODU port is independent of the standard RS-232C port, allowing system database access,
etc., without the need to interrupt the SMDR output.
Phase Lock Loop Unit
The Phase Lock Loop Unit (PLLU) provides clocking for T1, required if T1 card is installed.
The PLLU supplies a 32.768MHz clock to GSXD by either internal clock generator or clock
received from the trunk card (e.g. T1IB).
Add-On Module Function Board
MSGU48 Provides message waiting light indication on SLTs SLIB4/SLIBC
MODU Provides a 9600-baud modem for local access MBU
PLLU Provides clocking for T1board MBU
