StarTech.com 104B-USBC-MULTIPORT User manual

Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: September 22, 2022 1:50 PM
(Side A)
(Side B)
Product Diagram
Component Function
1Built-in USB-C Host Cable
• Connect to a USB-C Port on a Host Computer
• USB 3.2 Gen 1 (5 Gbps)
• Power Delivery 3.0 Specication
2USB-C 100W Power
Delivery Port
• Connect a USB-C power adapter
• USB Power Delivery 3.0 (up to 100W, with up to
86W available for charging)
3HDMI Output Port
• Connect to an HDMI Display Device
• HDMI 2.0
• Up to 4K (4096x2160) 60Hz
• Via DisplayPort 1.4 DP Alt Mode
42x USB-A Data Ports
• Connect USB-A Peripherals
• USB 2.0 (480 Mbps)
• Supports up to 5 V/0.5 A (2.5 W) of Power
5USB-A Data Port
• Connect USB-A Peripherals
• USB 3.2 Gen 1 (5 Gbps)
• Supports up to 5 V/0.9 A (4.5 W) of Power
Product ID
104B-USBC-MULTIPORT
USB-C Multiport Adapter - Works With Chromebook - HDMI 4K 60Hz HBR3 - 1 x USB-A (5Gbps) - 2 x USB 2.0 - 100W PD - Extended Cable
4
1
4
32
Requirements
• Computer
• DP Alt Mode enabled USB-C Port
• Video performance, such as resolution, and refresh rate depends upon your
host computer’s video controller. Please verify the specications of your
computer.
For the latest drivers, manuals, product information, technical specications, and
declarations of conformance, please visit: www.StarTech.com/104B-USBC-MULTIPORT
Package Contents
• USB-C Multiport Adapter x 1
• Quick-Start Guide x 1
Installation
1. Connect the Built-in USB-C Host Cable, located on the Multiport Adapter to a
USB-C port on your host computer. Your computer will automatically detect the
device and install all the required drivers.
2. ( Optional) Connect a USB-C power adapter (up to 100W) from an AC outlet to the
USB-C 100W Power Delivery Port located the Multiport Adapter, to charge the
host computer that’s connected to Built-in USB-C Host Cable.
3. Connect an HDMI Enabled Display Device, to the HDMI Output Port, located on
the Multiport Adapter, using an HDMI cable.
4. Connect USB Peripheral Devices to the USB-A Data Ports, located on the
Multiport Adapter.
Note: High powered USB devices, such as bus powered SSD enclosures, are not
recommended for use with the USB-A Data Ports, located on this device.
This product works with devices capable of running the latest version of Chrome
OS and has been certied to meet Google’s compatibility standards. Google is not
responsible for the operation of this product or it’s compliance with safety requirements.
Chromebook and the Works With Chromebook badge are trademarks of Google LLC.
Ce produit est compatible avec les appareils en mesure d’exécuter la dernière
version de Chrome OS et a été certié conforme aux normes de compatibilité de Google.
Chromebook et
le badge Works With Chromebook sont des marques de commerce de Google LLC.
5
