StarTech.com SVID2USB22 User manual

USB Video Capture Adapter
USB to S-Video/Composite
Video Capture Cable Adapter
with Audio
SVID2USB22
Instruction Manual

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.•
Increase the separation between the equipment and receiver.•
Connect the equipment into an outlet on a circuit different from that to which the receiver•
is connected.
Consult the dealer or an experienced radio/TV technician for help.•
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an
endorsement of the product(s) to which this manual applies by the third-party company
in question. Regardless of any direct acknowledgement elsewhere in the body of
this document, StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this
manual and related documents are the property of their respective holders.

i
Table of Contents
Introduction ..................................................................... 1
Packaging Contents.....................................................................1
System Requirements .................................................................1
Installation....................................................................... 2
Verifying Installation.....................................................................2
Software Installation (Optional) ...................................................3
Specifications.................................................................. 4
Technical Support........................................................... 5
Warranty Information...................................................... 5

1
Introduction
The StarTech.com SVID2USB22 USB 2.0 S-Video/Composite video
Capture Cable lets you connect devices that output S-Video or
Composite video to a computer, through an available USB 2.0 port.
The cable also features two channel RCA stereo audio inputs, that let
you capture the audio that accompanies the S-Video or Composite
video signal. Support for TWAIN drivers to enable various third party
video capture software, the capture cable offers real time MPEG1 and
MPEG2 recording.
Packaging Contents
1 x SVID2USB22 video capture adapter•
1 x Driver Installation CD•
1 x Software Installation CD•
1 x Instruction Manual•
System Requirements
USB 2.0 enabled computer system with available port•
Microsoft• ®Windows®2000/XP/Vista/7 (32/64-bit)

2
Installation
Please insert the included Driver CD into the CD-ROM Drive.1.
At the Windows desktop, click Start, Run.2.
Type D:\ AV Grabber\Setup.exe, click OK. (Change D: to match your3.
CD-ROM drive letter)
If a Windows Security dialog window appears, click the “Install this4.
driver software anyway” or “Continue Anyways” option to proceed
Restart Windows to complete the driver installation.5.
Once the computer has booted into Windows, plug the SVID2USB226.
adapter cable into an available USB2.0 port.
Windows should automatically detect new hardware and begin to7.
load the drivers.
If a Windows Security dialog window appears, click the “Install this8.
driver software anyway” or “Continue Anyways” option to proceed.
Connect the video source to the video capture adapter either9.
through S-Video (black) or composite video (yellow) using the
appropriate cables. Stereo audio (red/white) can also be connected
to the adapter.
Verifying Installation
From the main desktop, right-click on “My Computer” (“Computer”
in Vista/7), then select Manage. In the new Computer Management
window, select Device Manager from the left window panel.

3
Click on the “+” (plus sign) in front of “Sound, video and game
controllers”, “AV Grabber” should be displayed under this category.
Software Installation (Optional)
To install Ulead®VideoStudio®for use as video capture and editing
software, follow these installation steps. If other video capture/editing
software is to be used, then this is not necessary.
Place the Ulead Video Studio SE CD into a CD-ROM drive and1.
setup should launch automatically. If setup does not launch, use
Windows Explorer to navigate to appropriate CD-ROM drive and run
the Setup.
The installation wizard will start the installation process, click OK to2.
start installing.
NOTE: The serial installation key is included on the back of the CD
sleeve.
Follow the installation wizard and complete the steps to finish Ulead3.
VideoStudio 11 SE DVD software.
NOTE: For any further assistance with installation, how-to-use or
troubleshooting VideoStudio problems, please contact the developer of
the software, Ulead (www.ulead.com).

4
Specications
Bus Interface USB 2.0
Connectors
1 x USB type A
1 x RCA composite (yellow)
2 x RCA stereo audio (red/white)
1 x S-Video female (black)
LEDs 1 x Power
Video System NTSC, PAL, SECAM
Maximum Video Resolution 720x480 (NTSC), 720x576 (PAL)
Video Encoding Support MPEG1, MPEG2
Dimensions 92.0mm x 33.0mm x 11.0mm
Weight 60g
Compatible Operating
Systems
Windows 2000/XP/Vista/7
(32/64-bit)

5
Technical Support
StarTech.com’s lifetime technical support is an integral part of our
commitment to provide industry-leading solutions. If you ever need
help with your product, visit www.startech.com/support and access
our comprehensive selection of online tools, documentation, and
downloads.
Warranty Information
This product is backed by a one year warranty.
In addition, StarTech.com warrants its products against defects in
materials and workmanship for the periods noted, following the initial
date of purchase. During this period, the products may be returned
for repair, or replacement with equivalent products at our discretion.
The warranty covers parts and labor costs only. StarTech.com does
not warrant its products from defects or damages arising from misuse,
abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA
LLP (or their officers, directors, employees or agents) for any damages
(whether direct or indirect, special, punitive, incidental, consequential, or
otherwise), loss of profits, loss of business, or any pecuniary loss, arising
out of or related to the use of the product exceed the actual price paid
for the product. Some states do not allow the exclusion or limitation of
incidental or consequential damages. If such laws apply, the limitations
or exclusions contained in this statement may not apply to you.
