StarTech.com TBT3TBTADAP User manual

Quick-start guide
FR: Guide de l’utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l’uso - it.startech.com
Manual Revision: 08/04/2016
For the latest information, technical specications, and support for
this product, please visit www.startech.com/TBT3TBTADAP.
Package contents
• 1 x Thunderbolt™ 3 to Thunderbolt adapter
System requirements
• Host desktop computer or laptop with a Thunderbolt 3 port
• Thunderbolt or Thunderbolt 2 device
• Thunderbolt cable
System requirements are subject to change. For the latest
requirements, please visit www.startech.com/TBT3TBTADAP.
TBT3TBTADAP
Thunderbolt™ 3 to Thunderbolt Adapter
*actual product may vary from photos
Introduction
Use the TBT3TBTADAP adapter to connect a Thunderbolt 3 desktop
or laptop computer to legacy Thunderbolt devices, including
external hard drives, Thunderbolt displays, and Mac computers that
are Thunderbolt capable. The TBT3TBTADAP is compatible with rst-
generation Thunderbolt and Thunderbolt 2 devices, making it a cost-
eective method to connect newer devices to older peripherals.
You can use the TBT3TBTADAP to connect to rst-generation
Thunderbolt devices at 10Gbps and Thunderbolt 2 devices at
20Gbps.
Product diagram
Thunderbolt 3 USB-C connector
Thunderbolt 2 port
Connect the Thunderbolt adapter
Your computer’s Thunderbolt 3 ports might not function properly
until you update one or more of the following on your computer:
• BIOS
• Thunderbolt rmware
• Thunderbolt 3 controller drivers
• Thunderbolt 3 software
The required updates will vary depending on your computer.
For an up-to-date list of aected computers and instructions, visit
http://thunderbolttechnology.net/updates. If your manufacturer
isn’t listed on the Thunderbolt website, contact your manufacturer.
Make sure that the Thunderbolt device that you’re using with the
TBT3TBTADAP is compatible with the OS that you’re running on your
computer.
1. Connect the Thunderbolt 3 USB-C connector to the Thunderbolt
3 USB-C port on your desktop or laptop.
2. Use a Thunderbolt cable to connect the Thunderbolt device to the
Thunderbolt 2 port on the Thunderbolt adapter.
3. If you’re using a Windows® operating system, a pop-up message
may appear requesting permission to allow the adapter to
connect to your computer. If this message appears, click OK > Yes.
In the drop-down list, select Connect always and click OK.
The following is an example of a setup that includes the Thunderbolt
adapter:

Troubleshooting
If you are experiencing issues, there are some quick tests that you
can complete to narrow down the source of the issue.
Update your computer to use Thunderbolt 3
• Visit http://thunderbolttechnology.net/updates and look for your
computer in the list of aected computers. If your computer is
listed, then you must update your computer for its Thunderbolt
3 ports to function properly. To update your computer, follow the
instructions on the website or contact your manufacturer.
Verify that your components are Thunderbolt compliant
1. Make sure that you are using Thunderbolt compliant cables.
First-generation Thunderbolt and Thunderbolt 2 use the same
connector type as Mini DisplayPort. If you are using a Mini
DisplayPort cable that is not Thunderbolt compliant, replace the
cable with one that is compliant.
2. Make sure that the port on your computer is Thunderbolt 3
compliant. Thunderbolt 3 uses the USB-C connector type, but not
all USB-C connectors are compatible with Thunderbolt 3. If you
are using a USB-C port that is not Thunderbolt 3 compliant, switch
to a port that is Thunderbolt 3 compliant.
3. Make sure that your peripheral is Thunderbolt compliant. If you’re
not sure, check with the manufacturer.
Replace the Thunderbolt cable
Use the Thunderbolt peripheral with a dierent cable that is
Thunderbolt compliant.
Test the Thunderbolt peripheral
1. Use a second Thunderbolt peripheral, and see if it works. Ideally,
the second peripheral is one that you know works in other setups.
If the second peripheral works in the current setup, then there is
probably an issue with the rst Thunderbolt peripheral.
2. Use the Thunderbolt peripheral with a second setup. If it works
in the second setup, then there is probably an issue with the rst
setup.
