StarTech.com USB31000S User manual

Manual Revision: 11/28/2012
For the most up-to-date information, please visit: www.startech.com
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
USB31000S/USB31000SW
USB 3.0 to Gigabit Ethernet Adapter
*actual product may vary from photos

Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.

Instruction Manual
i
Table of Contents
Introduction............................................................................................1
Packaging Contents ................................................................................................................................. 1
System Requirements.............................................................................................................................. 1
USB31000S/USB31000SW Diagram....................................................................................................2
Installation ..............................................................................................3
Verify Installation....................................................................................................................................... 4
Specications..........................................................................................5
Technical Support ..................................................................................6
Warranty Information............................................................................6

Instruction Manual
1
Introduction
The USB31000S/ USB31000SW USB 3.0 to Gigabit Ethernet Adapter adds a single
RJ45 Ethernet port to a USB-enabled computer system, with support for connecting
to Gigabit networks at full bandwidth, unlike USB 2.0 adapters. The USB network
adapter is backward compatible with older USB 2.0/1.x computer systems (speed
limited by USB bus), making this compact and portable USB Gigabit LAN adapter an
ideal replacement network adapter or laptop accessory. With support for features such
as Jumbo Frames, VLAN tagging and Wake on LAN (WOL), the adapter is suitable for
home and business users alike. The USB31000S/USB31000SW USB 3.0 Gigabit adapter
is backed by a StarTech.com 2-year warranty and free lifetime technical support.
Packaging Contents
• 1x USB 3.0 Gigabit Adapter
• 1x Driver CD
• 1x Instruction Manual
System Requirements
• USB enabled computer system with available USB 3.0 port
• Microsoft® Windows® XP/ Vista/ Server 2003/ Server 2008 R2/ 7/ 8 (32/64-bit), or
Apple® Mac OS® 10.6/ 10.7/ 10.8

Instruction Manual
2
USB31000S/USB31000SW Diagram
RJ-45 Ethernet
Port
Link LED
USB 3.0
Type A
Activity LED
*Black model shown

Instruction Manual
3
Installation
Windows XP/ Server 2003
1. Connect the USB adapter to the computer.
2. When the Found New Hardware wizard appears on the screen, insert the Driver CD
into your CD/DVD drive. If you are prompted to connect to Windows Update, please
select the “No, not this time”option and click Next.
3. Select the option “Install Drivers Automatically (Recommended)” and then click the
Next button.
4. Windows will now start searching for the drivers and install them automatically.
Once this has completed, click the Finish button.
Windows Vista/ 7/ 8
1. Connect the USB adapter to the computer.
2. When the Found New Hardware window appears on the screen, click on the “Locate
and install drivers software (recommended)”option. If prompted to search online,
select the “Don’t search online” option.
3. When prompted to insert the disc, insert the Driver CD that came with the adapter,
into your CD/DVD drive and Windows will automatically proceed to search the CD.
4. If a Windows Security dialog window appears, click the “Install this driver software
anyway” option to proceed.
5. Once the driver is installed, click the Close button.

Instruction Manual
4
Verify Installation
Windows XP/ Server 2003/ Vista/ 7/ 8
From the main desktop, right-click on “My Computer” (“Computer” in Vista/7/8), then
select Manage. In the new Computer Management window, select Device Manager
from the left window panel.
In the Device Manager, under the Network Adapters category, you should see a new
USB networking device listed.

Instruction Manual
5
Specications
Host Interface USB 3.0
Chipset ID ASIX AX88179
Connectors 1x RJ45 Ethernet female
1x USB 3.0 type A male
LEDs 1x Link
1x Activity
Supported Network
Standards IEEE 802.3i/802.3u/802.3ab
Compatible Networks 10/100/1000 Mbps
Auto MDIX Support Yes
Full Duplex Support Yes
Enclosure Material Plastic
Power Adapter USB powered
Operating Temperature 0°C ~ 40°C (32°F ~ 104°F)
Storage Temperature -20°C ~ 60°C (-4°F ~ 140°F)
Humidity < 80% RH
Dimensions 67.0mm x 26.0mm x 15.5mm
Weight 27g
Compatible Operating
System
Windows XP/ Vista/ Server 2003/ Server 2008 R2/
7/ 8 (32/64-bit), Mac OS 10.6/ 10.7/ 10.8

Instruction Manual
6
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty Information
This product is backed by a two year warranty.
In addition, StarTech.com warrants its products against defects in materials
and workmanship for the periods noted, following the initial date of purchase.
During this period, the products may be returned for repair, or replacement with
equivalent products at our discretion. The warranty covers parts and labor costs only.
StarTech.com does not warrant its products from defects or damages arising from
misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
ocers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation
of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.
