StarTech.com HD202A User manual

Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: July 16, 2019 8:45 AM
Product Diagram (HD202A)
Port Function
1HDMI OUT • Used to connect a Display Device to the
Extractor.
2S/PDIF OUT • Used to connect an Audio Device to the
Extractor.
3AUDIO OUT L/R • Used to connect an Audio Device to the
Extractor.
4 Mounting Brackets (2) • Used to mount the Extractor.
Port/LED Function
5DC 5V
• Used with the Universal Power Adapter to
power the Extractor.
Note: Universal Power Adapter has
components compatible for NA/JP, EU, UK, ANZ,
installation.
HDMI® Audio Extractor | HDR | 4K 60Hz
1
6POWER LED • Solid Red: Indicates that the Extractor is
properly connected and is receiving power.
7HDMI IN • Used to connect a Video Source Device to the
Extractor.
8EDID Switch
• Used to toggle between the Extended Display
Identication Data (EDID) modes (PASS, 2.0CH,
and 5.1CH).
Requirements
For the latest requirements, please visit www.startech.com/HD202A.
Installation
1. Connect an HDMI Cable (sold separately) to the HDMI IN Port on the Extractor and
connect the other end of the HDMI Cable to the HDMI port on the Video Source
Device.
2. Connect an HDMI Cable to the HDMI OUT Port on the Extractor and connect the
other end of the HDMI Cable to the HDMI port on the Display Device.
3. (Optional): Connect RCA Audio Cables (sold separately) to the AUDIO OUT
L/R Ports on the Extractor and the other end of the RCA Audio Cables to the
Speakers/Audio Receiver.
4. (Optional): Connect an Optical Audio Cable to the S/PDIF OUT Port and connect
the other end of the Optical Audio Cable to an audio out port on the Audio Device
(speakers, amplifer, etc.).
Note: The port used to connect the Audio Device will depend on your audio setup.
5. Connect the Universal Power Adapter to the DC 5V Port on the Extractor and
other end to an AC Electrical Outlet.
6. Power on the Video Display Device and the HDMI Video Source.
7. Slide the EDID Switch to adjust the EDID mode to one of the following:
• PASS (Default): EDID settings from the Display Device connected to the HDMI
OUT Port are passed through to the Video Source Device.
• 2.0CH: 2.0CH EDID settings are passed through the Video Source Device
connected to the HDMI IN Port and to the Display Device (video and 2.0CH
audio).
24
3
5 6 7 8

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including
interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void
the user’s authority to operate the equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions:
(1) This device may not cause interference, and (2) This device must accept any interference, including interference that may
cause undesired operation of the device.
Le présent appareil est conforme aux CNR d’Industrie Canada applicables aux appareils radio exempts de licence. L’exploitation
est autorisée aux deux conditions suivantes:
(1) l’appareil ne doit pas produire de brouillage, et (2) l’utilisateur de l’appareil doit accepter tout brouillage radioélectrique subi,
même si le brouillage est susceptible d’en compromettre le fonctionnement.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-
party companies not related in any way to StarTech.com. Where they occur these references are for illustrative purposes only
and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which
this manual applies by the third-party company in question. StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the
property of their respective holders.
Warranty Information
This product is backed by a two-year warranty.
For further information on product warranty terms and conditions, please refer to www.startech.com/warranty.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents)
for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of prots, loss of
business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations
or exclusions contained in this statement may not apply to you.
Safety Measures
• If product has an exposed circuit board, do not touch the product under power.
Mesures de sécurité
• Si l’un des circuits imprimés du produit est visible, ne pas touchez le produit lorsqu’il est sous tension.
安全対策
• 製品に露出した状態の回路基盤が含まれる場合、電源が入っている状態で製品に触らないでください。
Misure di sicurezza
• Se il prodotto ha un circuito stampato visibile, non toccare il prodotto quando è acceso.
Säkerhetsåtgärder
• Rör aldrig vid enheter med oskyddade kretskort när strömmen är påslagen.
FR: fr.startech.com
DE: de.startech.com
ES: es.startech.com
NL: nl.startech.com
IT: it.startech.com
JP: jp.startech.com
StarTech.com Ltd.
45 Artisans Cres
London, Ontario
N5V 5E9
Canada
StarTech.com Ltd.
Unit B, Pinnacle 15
Gowerton Rd,
Brackmills
Northampton
NN4 7BW
United Kingdom
StarTech.com LLP
2500 Creekside
Parkwy
Lockbourne, Ohio
43137
U.S.A.
Removing a Regional Power Clip
To remove a Regional Power Clip from the Universal Power Adapter:
1. Push the Release Button on the Universal Power Adapter.
2. Slide the Regional Power Clip upward aligning the Side Tabs on the Regional
Power Clip with the notches on the Universal Power Adapter.
3. Pull the Regional Power Clip away from the Universal Power Adapter.
EDID Specications
Audio EDID
Conguration of
Output Device HDMI Output (Audio) SPDIF Output
(Audio) L/R Output (Audio)
Pass (Default)
Dolby/DTS 7.1 Dolby/DTS 7.1 x x
Dolby/DTS 5.1 Dolby/DTS 5.1 Dolby/DTS 5.1 x
PCM 7.1 PCM 7.1 PCM 2.0 PCM 2.0
PCM 5.1 PCM 5.1 PCM 2.0 PCM 2.0
PCM 2.0 PCM 2.0 PCM 2.0 PCM 2.0
2.0CH
x PCM 2.0 PCM 2.0 PCM 2.0
5.1CH
Dolby/DTS 7.1 Dolby/DTS 5.1 Dolby/DTS 5.1 x
• 5.1CH: The Extractor passes 5.1CH EDID settings through the Video Source
Device connected to the HDMI IN Port and to the Display Device (video and
5.1CH audio).
Installing the Mounting Brackets
1. Align a Mounting Bracket with the two Mounting Holes on the side of the
Extractor.
Note: The Extractor has four Mounting Holes, two on each side.
2. Insert the Bracket Screws (x2) through the Mounting Bracket and into the
Mounting Holes.
3. Tighten the Mounting Screws using a Phillips Head Screwdriver, be careful not to
over-tighten.
4. Before installing the Mounting Bracket on the mounting surface, contact a
professional. Product mounting should be completed by a certied professional as
per the local safety and building code guidelines.
Connecting a Regional Power Clip
1. Select a Regional Power Clip.
2. Align the two Side Tabs on the Regional Power Clip with the notches on the face of
the Universal Power Adapter.
3. Slide the Regional Power Clip down until you hear an audible click, connecting
the contact prongs on the Regional Power Clip with the contact prongs on the
Universal Power Adapter.
