StarTech.com SV565UTPDUA User manual

Manual Revision: 03/01/2012
For the most up-to-date information, please visit: www.startech.com
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
SV565UTPDUA
DVI USB KVM Console Extender with
USB 2.0 and Audio - 500m
*actual product may vary from photos

Instruction Manual
FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there
is no guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be determined by
turning the equipment o and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
•
Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not
represent an endorsement of a product or service by StarTech.com, or an endorsement of the
product(s) to which this manual applies by the third-party company in question. Regardless
of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby
acknowledges that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the property of
their respective holders.

Instruction Manual
i
Table of Contents
Introduction............................................................................................1
Packaging Contents ................................................................................................................................. 1
System Requirements.............................................................................................................................. 1
Connecting Your KVM Extender...........................................................2
Preparing Your Site ................................................................................................................................... 2
Local Unit Installation.............................................................................................................................. 2
Installing the Remote Unit..................................................................................................................... 2
How to Use .............................................................................................3
Audio ............................................................................................................................................................. 3
LEDs................................................................................................................................................................ 4
Compatibility ..........................................................................................4
Setup & Equipment .................................................................................................................................. 5
Specications..........................................................................................6
Technical Support ..................................................................................8
Warranty Information............................................................................8

Instruction Manual
1
Introduction
Packaging Contents
• 1 x Local Unit
• 1 x Remote Unit
• 2 x Universal Power Adapter
• 1 x USB cable
• 1 x DVI-D cable
• 1 x Instruction Manual
System Requirements
• USB and DVI-D enabled KVM switch or computer system
• A DVI-D (digital) enabled display device (i.e. monitor, projector, HDTV, etc)
• A standard 104-key wired USB keyboard
• A standard 3-button wired USB mouse
Front View
Rear View

Instruction Manual
2
Connecting Your KVM Extender
Preparing Your Site
Before you can install the product, you need to prepare your site.
1. Determine where the host computer will be located and set up the computer.
2. Determine where the console devices (mouse, keyboard, monitor) will be located
and place them appropriately.
3. a) If you are using surface cabling, ensure you have enough Category 5 unshielded
twisted pair (UTP) network cabling to connect the Local unit to the Remote unit’s
location, and that each end is terminated with a RJ45 connector. The cabling should
not go through any networking equipment (i.e. router, switch).
OR
b) If you are using premises cabling, ensure that the Category 5 unshielded twisted
pair (UTP) network cabling between the Local unit and the Remote unit has been
properly terminated in a wall outlet in each location and there is a patch cable long
enough to connect the Remote Unit and the Local unit to their respective outlets.
The cabling should not go through any networking equipment (i.e. router, switch).
Local Unit Installation
1. Switch o the computer and disconnect any unnecessary devices/peripherals.
2. Using the provided cables, connect the USB cable from the USB type B connector on
the Local unit to an available USB port on the computer system. Connect the DVI-D
cable from the Local unit to the DVI connector on the computer system.
NOTE: If using audio, no separate cables are required, as it will be carried over USB.
3. Connect the UTP cable connection for the Remote unit to the RJ45 connector on the
Local unit. If using premises cabling, connect the opposite end of the patch cable to
the terminated wall outlet.
Installing the Remote Unit
1. Place the Remote Unit near the remote station.
2. Using a DVI-D cable (not included) connect a monitor to the DVI-D connector on the
Remote unit.
3. Connect a USB keyboard and/or mouse to any of the USB Hub ports on the
Remote unit.
4. OPTIONAL: Connect any additional USB peripherals you wish to use to the Remote
unit. An external USB hub (powered) may be connected to the Remote unit, if
additional USB ports are required.

Instruction Manual
3
5. Connect the UTP cable connection from the Local unit to the RJ45 connector on the
Remote unit. If using premises cabling, connect the opposite end of the patch cable
to the terminated wall outlet.
6. Connect the power adapters to the Local and Remote units. Each unit uses a
specic power adapter (5VDC for Local, 24VDC for Remote), so ensure the correct
power adapter is connected, otherwise damage may occur.
7. The“Status”LED should light up on both units to indicate power. The“Link”LED should
also light up to indicate a connection between the Local and Remote units is established.
Note: It may take up to one minute for the system to boot up.
How to Use
Audio
The audio component of the extender uses a built-in USB Audio Device to transmit
audio from the Host computer to the Remote unit. The Host computer system should
detect and automatically install the audio adapter once the USB cable is connected,
usually setting it as the default audio adapter for the system. Check in the Audio
Properties of the operating system (i.e. “Sound and Audio Devices” in Control Panel for
Windows XP or “Sound” in System Preferences for Mac OS X) to verify the installation
and status of the USB audio adapter. If the audio component of the extender will not
be used, then you may wish to set the default audio device back to the onboard audio.

Instruction Manual
4
LEDs
LEDs Description
Status
• Solid green indicates ready status.
• Flashing green indicates the unit is
booting up.
• O indicates no power.
Link
• Solid green indicates a connection
between the Local and Remote units.
• O indicates no connection between
the Local and Remote units.
Video
• Solid green indicates a connection
to the Remote unit and the Host
computer.
• Flashing green indicates a video
signal from the Host computer is
being transmitted.
• Solid amber indicates that no video
source is connected to the Local unit
or no monitor isconnected to the
Remote unit.
• Flashing amber indicates an
incompatible video resolution is
detected.
• O indicates no connection between
the Local and Remote units.
USB
• Solid green indicates a successful USB
connection to the Host computer.
• Flashing green indicates USB data
transmission.
• Solid amber indicates no USB
connection to the Host computer.
• Flashing amber indicates over-
current (short) on one of the USB
connections.
• O indicates no connection between
the Local and Remote units.

Instruction Manual
5
Compatibility
The product is compatible with many graphic cards, Operating Systems, and monitors.There
is no guarantee that all devices are compatible with the product, as there are a number of
dierent congurations that may impact the operation of the KVM Extender.The product
complies with USB 1.1 and USB 2.0 specications governing the design of USB devices.There
is no guarantee that all USB devices are compatible with the product, as there are a number of
dierent congurations that may impact the operation of USB devices over extended distances.
Setup & Equipment
The following devices are recommended to be used in the system.
Monitors
• Samsung•Dell•HP
• Viewsonic•Acer•BENQ
• ASUS
Discrete Graphics Cards
• ATI Radeon HD 2000 Series and Above
• NVIDIAION•IntelGMA950andGMAHD
• MatroxP-Series•ATIFireGL/FireProSeries
• NVIDIAQuadroSeries•NVIDIAGeforce6000SeriesandAbove
• NVIDIAGeforceMobility9000
Resolutions
• 640x480(4:3)•1280x1024(5:4)
• 800x600(4:3)•1360x768(16:9)
• 1024x768(4:3)•1366x768(16:9)
• 1280x720(16:9)•1440x900(16:10)
• 1280x768(5:3)•1680x1050(16:10)
• 1280 x 800 (16:10)
Host Operating Systems
• Windows7(32bit&64bit)•WindowsXP(32bit)
• WindowsVista(32bit&64bit)•Linux
• Mac OS X (Leopard/Snow Leopard)
Peripherals
• Keyboard
• Mouse
• Mass Storage Device
• Speakers
• Printer/Scanner
• High Compression/Low Resolution Web Camera
• DAQs

Instruction Manual
6
Specications
Video Signal DVI-D (digital)
Connectors
Local Unit:
1 x 25-pin DVI-D female
1 x USB type B female
1 x RJ45 Ethernet female
1 x DC Power
Remote Unit:
1 x 25-pin DVI-D female
3 x USB type A female
1 x RJ45 Ethernet female
2 x 3.5mm mini-jack Audio female
1 x DC Power
LEDs
Local Unit:
1 x Status
1 x Link
1 x Video
1 x USB
Remote Unit:
1 x Status
1 x Link
1 x Video
1 x USB
Compatible Cabling Cat 5/5e/6, UTP
Maximum Cable Length 500m / 1640ft
Maximum Video Resolution 1680 x 1050
Maximum Data Transfer Rate USB 2.0: 80Mbps
Audio Support Yes (via built-in USB audio adapter)
DDC Support Yes

Instruction Manual
7
Power Adapter
Local Unit:
5VDC, 3000mA, center positive
Remote Unit:
24VDC, 1000mA, center positive
ESD Protection 4kV Contact, 8kV Air
Operating Temperature 0°C ~ 50°C (32°F ~ 122°F)
Storage Temperature -20°C ~ 70°C (-4°F ~ 158°F)
Humidity 20% ~ 80% RH
Dimensions (LxWxH) 175.0mm x 112.0mm x 30.0mm
Weight 400g

Instruction Manual
8
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to
provide industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty Information
This product is backed by a two year warranty.
In addition, StarTech.com warrants its products against defects in materials
and workmanship for the periods noted, following the initial date of purchase.
During this period, the products may be returned for repair, or replacement with
equivalent products at our discretion. The warranty covers parts and labor costs only.
StarTech.com does not warrant its products from defects or damages arising from
misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
ocers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation
of incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.

Hard-to-nd made easy. At StarTech.com, that isn’t a slogan. It’s a promise.
StarTech.com is your one-stop source for every connectivity part you need. From
the latest technology to legacy products — and all the parts that bridge the old and
new — we can help you nd the parts that connect your solutions.
We make it easy to locate the parts, and we quickly deliver them wherever they need
to go. Just talk to one of our tech advisors or visit our website. You’ll be connected to
the products you need in no time.
Visit www.startech.com for complete information on all StarTech.com products and
to access exclusive resources and time-saving tools.
StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology
parts. StarTech.com was founded in 1985 and has operations in the United States,
Canada, the United Kingdom and Taiwan servicing a worldwide market.
