StarTech.com POEINJ4G User manual

Instruction Manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Manual Revision: 04/12/2021
Forthemostup-to-dateinformation,pleasevisit:www.startech.com
Packaging Contents
• 1x 4 Port Gigabit PoE+ Injector
• 1x Universal Power Adapter
• 4x Power Cords (NA/UK/EU/AU)
• 1x Instruction Manual
System Requirements
• RJ45 terminated Cat5 or higher Ethernet cabling
• 10/100/1000 Mbps compatible Ethernet network
• Available AC electrical outlet
Product Overview
Front View
POEINJ4G
4 Port Gigabit PoE+ Injector Midspan Hub 54V / 30W - 802.3at / 802.3af
*actualproductmayvaryfromphotos
LEDs
DC Power Input
RJ45 Gigabit Data Ports
RJ45 Gigabit PoE Ports
Side View - Data Only
Side View - PoE (Data and Power)
LED Indicators
LED Indication
Power (Green) Solid: Indicates that the POEINJ4G is
powered on
PoE in-Use(Green)*
Solid: Indicates that the specic
port (1 to 4) has a PoE or PoE+ device
connected
Installation and Operation
The POEINJ4G can be installed between a regular Ethernet switch
and PoE powered devices, and will provide power to the connected
PoE powered devices without impacting regular data transmission
performance.
1. Ensure there are no devices connected to the Data & Power (PoE)
ports prior to connecting the Power Adapter to the POEINJ4G.
2. Connect the provided Power Cord for your region (NA, UK, or EU)
to the provided Power Adapter, then to an AC electrical outlet.
Then connect the Power Adapter to the DC Power Input on the
POEINJ4G. Ensure that the“Power” LED is lit.
3. Using RJ45 Ethernet cable, connect up to four source network
devices (i.e. router, switch, computer, etc.) to the Gigabit Data
Ports on the POEINJ4G.
4. Using RJ45 Ethernet cable, connect up to four PoE (802.3af 15W)
or PoE+ (802.3at 30W) complaint device(s) to the Gigabit PoE
Ports on the POEINJ4G.
*Depending on your application, alternatively you can connect the
Ethernet cable to a PoE splitter device to separate data and power at
the remote end (for use with a non-PoE powered device).
Note: If the input DATA line contains any PoE power, the PoE In-Use
LED for that port may not light up.

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void the user’s authority to operate the
equipment.
Industry Canada Statement
This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe [A] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (A)/NMB-3(A)
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s)
to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all
trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and
access our comprehensive selection of online tools, documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty Information
This product is backed by a two year warranty.
In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be
returned for repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages
arising from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,
consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not
allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.
Typical PoE/PoE+ Injector Application
Notes
• The maximum RJ45 Ethernet cable length used cannot exceed 100
m / 330 ft
• If not connected to PoE IEEE 802.3af or IEEE 802.3at standard
devices, the POEINJ4G will not inject power to the connected
Ethernet cable(s) and/or device(s)
• The POEINJ4G does not oer a“standby” operation mode.
For energy savings, disconnect the Power Adapter from the
POEINJ4G. Without removing the Power Adapter, the POEINJ4G
can still consume power from your power source. It is strongly
recommended you disconnect the Power Adapter if the POEINJ4G
is not in use.
Wall-Mounting
The POEINJ4G features two mounting holes on the bottom side of
the unit. The mounting holes provide the option to wall-mount the
POEINJ4G as desired.
