StarTech.com ST5GPEXNB User manual

Quick-start guide
FR: Guide de l’utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l’uso - it.startech.com
JP: 取扱説明書 - jp.startech.com
Manual Revision: 02/16/2018
For the latest information, technical specications, and support for
this product, please visit www.StarTech.com/ST5GPEXNB.
Package contents
• 1 x network card
• 1 x low-prole mounting bracket
• 1 x driver CD
• 1 x instruction manual
Requirements
• PCI Express enabled computer with an available PCI Express slot
(x4, x8, or x16)
• Any of the following operating systems:
• Windows® 10 (32-bit or 64-bit)
• Windows 8.1 (32-bit or 64-bit)
• Windows 8 (32-bit or 64-bit)
• Windows 7 (32-bit or 64-bit)
• Windows Server® 2016
• Windows Server 2012
• Windows Server 2008 R2
• macOS 10.13
• macOS 10.12
• Linux kernel 2.6.36 – 4.4
Note: For 5GBase-T and 2.5GBase-T connections, Cat5e network
cable is required.
System requirements are subject to change. For the latest
requirements, please visit www.StarTech.com/ST5GPEXNB.
ST5GPEXNB
1-Port PCIe 4-Speed 5GBASE-T/NBASE-T Ethernet Network Card
*actual product may vary from photos
Product diagram
Link speed LED
Link state and activity LED
Ethernet port PCIe x4
connector
Installation
Install the PCI Express card
Warning! PCI Express cards can be severely damaged by static
electricity. Make sure that you are properly grounded before you
open your computer case or touch the PCI Express card. You should
wear an anti-static strap when you install any computer component.
If an anti-static strap isn’t available, discharge any built-up static
electricity by touching a large grounded metal surface for several
seconds. Only handle the PCI Express card by its edges and don’t
touch the gold connectors.
1. Turn o your computer and any peripherals that are connected
to it (for example, printers, external hard drives, etc.).
2. Unplug the power cable from the back of your computer.
3. Disconnect any peripheral devices that are connected to your
computer.
4. Remove the cover from your computer case. Consult the
documentation that came with your computer for details about
how to do this safely.
5. Locate an open PCI Express slot and remove the corresponding
metal cover plate from the back of your computer case. Consult
the documentation that came with your computer for details
about how to do this safely.
6. Gently insert the card’s PCIe x4 connector into the open PCI
Express slot and fasten the bracket to the back of the case.
Note: If you install the card into a small form-factor or a low-
prole desktop system, it may be necessary to replace the pre-
installed standard-prole bracket with the included low-prole
(half-height) installation bracket.
7. Place the cover back onto your computer case.
8. Reconnect the power cable to the back of your computer.
9. Reconnect all of the peripheral devices that you disconnected in
step 3.
10. Turn on your computer and peripherals.
Install the drivers
Windows
1. If the Found New Hardware dialog box appears, close or cancel
the dialog box.
2. Insert the driver CD into your computer.
3. Using Windows Explorer, browse to the main directory on the CD,
and open the ST5GPEXNB folder.
4. Open the folder that corresponds with your operating system.
5. Run the setup(.exe) le.
6. Click Install and follow the on-screen instructions to nish
installing the driver.

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void the user’s authority to operate the
equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to StarTech.com. Where they occur
these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the
third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all trademarks, registered trademarks,
service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and
access our comprehensive selection of online tools, documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty Information
This product is backed by a two-year warranty.
StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be returned for
repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages arising from
misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,
consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not
allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.
7. Optional: To verify that the driver installation was successful,
navigate to Device Manager. Under Network adapters, right-
click TN9710Q 5Gbase-T/NBase-t Ethernet Adapter and
click Properties. If installation was successful the driver will be
installed and working as expected.
About the LED indicators
The network card features two LED indicators, one on either side of
the Ethernet port:
Link speed LED
LED behavior Scenario
Green LED is illuminated Link speed is 5Gbps, 2.5Gbps, or
1Gbps
Neither LED is illuminated Link speed is 100Mbps
Link state and activity LED
LED behavior Scenario
Green LED is illuminated Network port is connected
Green LED is blinking Network port is active
macOS
1. On your computer, open an internet browser and navigate to
www.StarTech.com/ST5GPEXNB.
2. Click the Support tab.
3. Under Driver(s), download the driver for your operating system.
4. Follow the on-screen instructions to nish installing the driver.
5. Optional: To verify installation, on your computer, in the nderbar,
click the Apple icon.
6. Click About This Mac > System Report > PCI Cards. Check to
make sure that Yes is listed next to Driver Installed.
