StarTech.com PEXUSB3S42 User manual

Instruction Manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
Manual Revision: 01/28/2015
For the most up-to-date information, please visit: www.startech.com
Packaging Contents
• 1x 4 Port PCI Express USB 3.0 Card
• 1x Low-Prole Bracket
• 1x Driver CD
• 1x Instruction Manual
System Requirements
• PCI Express enabled computer with an available PCI Express x1 slot
or higher (x4, x8, x16)
• SATA power connector (highly recommended, but optional)
• Windows® 8 / 8.1 (32/64bit), 7 (32/64), Vista (32/64), XP (32/64),
Windows Server® 2012, 2008 R2, Linux 2.6.31 and up (Tested up to
3.5)
Product Overview
Top View
PEXUSB3S42
4 Port PCI Express SuperSpeed USB 3.0 Card with UASP - SATA Power
USB 3.0 Ports
Type “A” Female
x 3
SATA Power
Internal USB 3.0
Port Type “A”
Female
PCI Express x1
Installation
Hardware Installation
WARNING!
PCI Express cards, like all computer equipment, can be severely
damaged by static electricity. Be sure that you are properly
grounded before opening your computer case or touching your PCI
Express card. StarTech.com recommends that you wear an anti-
static strap when installing any computer component. If an anti-
static strap is unavailable, discharge yourself of any static electricity
build-up by touching a large grounded metal surface (such as the
computer case) for several seconds. Also be careful to handle the PCI
Express card by its edges and not the gold connectors.
1. Turn your computer o and any peripherals connected to the
computer (i.e. printers, external hard drives, etc.). Unplug the
power cable from the rear of the power supply on the back of the
computer and disconnect all peripheral devices.
2. Remove the cover from the computer case. (See your computer
system documentation for details).
3. Locate an open PCI Express x1 slot and remove the metal cover
plate on the rear of the computer case. (See your computer
system documentation for details).
Note: This card will work in PCI Express slots of additional lanes (i.e.
x4, x8, or x16 slots).
4. Gently insert the card into the open PCI Express slot and fasten
the bracket to the rear of the computer case.
Note: If installing the card into a small form-factor/low-prole
desktop system, replacing the pre-installed standard-prole bracket
with the included low-prole (half-height) installation bracket may
be necessary.
5. It is recommended you connect the optional SATA power using
an available SATA power connector from the computers power
supply.
Note: It is recommended that SATA power is connected to the card
to ensure sucient power is provided to each USB 3.0 port.
6. Place the cover back onto the computer case.
7. Insert the power cable into the socket on the power supply of the
computer, and reconnect all other connectors removed in Step 1.

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment o and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation. Changes or modications not expressly approved by StarTech.com could void the user’s authority to operate the
equipment.
Industry Canada Statement
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe [B] est conforme à la norme NMB-003 du Canada.
CAN ICES-3 (B)/NMB-3(B)
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s)
to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby acknowledges that all
trademarks, registered trademarks, service marks, and other protected names and/or symbols contained in this manual and related documents are the property of their respective holders.
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and
access our comprehensive selection of online tools, documentation, and downloads.
For the latest drivers/software, please visit www.startech.com/downloads
Warranty Information
This product is backed by a two year warranty.
In addition, StarTech.com warrants its products against defects in materials and workmanship for the periods noted, following the initial date of purchase. During this period, the products may be
returned for repair, or replacement with equivalent products at our discretion. The warranty covers parts and labor costs only. StarTech.com does not warrant its products from defects or damages
arising from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their ocers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental,
consequential, or otherwise), loss of prots, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. Some states do not
allow the exclusion or limitation of incidental or consequential damages. If such laws apply, the limitations or exclusions contained in this statement may not apply to you.
Driver Installation
Windows®
Depending on your Operating System version, the card may auto-
install with native drivers. Use the auto-install drivers if available.
Connect your USB devices to the 3x external ports, and 1x internal
port as desired.
If drivers do not auto-install, follow the below steps to complete the
driver installation process.
1. Upon starting Windows, if the Found New Hardware dialog
appears on the screen, cancel/close the window.
2. Download the latest drivers from the www.startech.com
website (recommended), applicable to the Operating System on
the host computer that you are installing the card to, or insert
the provided Driver CD into your computers DVD/CD drive.
3. Browse to the downloaded driver le location and run the “. e x e ”
install application applicable to the Operating System on the
host computer that you are installing the card to. Follow any on-
screen instructions to complete the driver installation process.
4. If using the Driver CD for installation, select the Open folder to
view les option from the AutoPlay menu. If AutoPlay is disabled
on your system, browse to your CD/DVD drive.
5. Run the “.exe” install application applicable to the Operating
System on the host computer that you are installing the card
to, and follow any on-screen instructions to complete the driver
installation process.
Note: You may be prompted to restart your system.
6. Connect your USB devices to the 3x external ports, and 1x internal
port as desired.
