StarTech.com 8STUSB1000IP User manual

USB Device Server
10/100/1000Mbps Gigabit
1-Port USB over IP
Device Server
USB1000IP
InstructionManual
Manual Revision:06/01/2015
For the most up-to-date information, please visit www.startech.com

FCC Compliance Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment o and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit dierent from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Use of Trademarks, Registered Trademarks, and other Protected Names and Symbols
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes
only and do not represent an endorsement of a product or service by StarTech.
com, or an endorsement of the product(s) to which this manual applies by the
third-party company in question. Regardless of any direct acknowledgement
elsewhere in the body of this document, StarTech.com hereby acknowledges
that all trademarks, registered trademarks, service marks, and other protected
names and/or symbols contained in this manual and related documents are the
property of their respective holders.

i
Table of Contents
Introduction................................................................................................................................ 1
Packaging Contents.......................................................................................................................................1
System Requirements ...................................................................................................................................1
Side View 1 ........................................................................................................................................................2
Side View 2 ........................................................................................................................................................2
Installation................................................................................................................................... 3
Hardware Installation ....................................................................................................................................3
Software Installation......................................................................................................................................3
How to Use.................................................................................................................................. 4
USB Server Software Setup .........................................................................................................................4
Specications ............................................................................................................................. 7
Technical Support ..................................................................................................................... 8
Warranty Information .............................................................................................................. 8

1
Introduction
The USB1000IP 10/100/1000 Mbps Gigabit 1-Port USB over IP Device Server provides
a simple to use, and convenient way to extend a USB device over long distances
and allows for sharing that device with multiple users over your 10/100 or 1000 Mbps
Ethernet network.
This exible device auto-detects network link speed and is capable of connecting through
a network hub/switch/router, or directly to a PC to function as a simple USB extender.
Perfect for connecting and sharing a device such as mass storage, card reader, digital
camera, webcam, printer (including multi-function), fax, scanner or serial adapter with
multiple users.
The bundled software provides a simple interface to view the status of, and connect to
the detected device over the LAN and features the option to automatically connect to
your device after a reboot.
Packaging Contents
• 1 x Gigabit USB IP Device Server
• 1 x Installation CD
• 1 x Universal Power Adapter
• 1 x Instruction Manual
System Requirements
• 10/100 or 1000Mbps compatible TCP/IP Ethernet network
• Available AC power outlet
• Microsoft®Windows®XP/Vista/7 (32/64-bit)

2
SideView1
SideView2

3
Installation
Hardware Installation
1. Connect the USB device that will be shared to the USB IP device server.
NOTE: USB hubs are not supported by the USB IP device server.
2. Connect an RJ45 terminated Ethernet cable from the network to the USB IP device
server.
3. Connect the power adapter to the USB IP device server. The green LED should light
up solid and the yellow LED should blink if connected to the network.
NOTE: The device server uses DHCP by default to automatically obtain an IP address
from the network’s DHCP server (e.g. router). If a DHCP server is not available, the USB
IP device server will use 192.168.1.50 by default.
Software Installation
1. Insert the included Installation CD into the computer’s CD/DVD drive.
2. AutoPlay should automatically launch and display all of the folders on the CD. If not,
open “My Computer” and double-click on the CD/DVD drive.
3. Enter the folder“USB 2.0 Device”, then“Est_E3868” and double-click the le
“USBServer_Setup.exe”.
4. This should launch the software installation wizard. Continue through the wizard
and once complete, the following icons should appear on the desktop: “Launch USB
Server”.
5. The software must be installed on all computers that intend to make use of the USB IP
device server.

4
How to Use
USB Server Software Setup
1. Make sure the USB device is connected to the device server and it is powered on (if
applicable).
2. Double-click the “Launch USB Server” shortcut icon on the desktop to start the
program.
3. If the USB IP device server is properly connected to the network, it should appear in
the list of device servers with an IP address. By default, the USB IP device server
uses DHCP to obtain an IP address, so the assigned IP address should be in the
same IP range as the host computer running the software.
If the network does not use DHCP, the device server will use an IP address of
192.168.1.50 by default. To change the network settings to match the network,
right-click on the device server and select “Setting Sever”. This will bring up the
conguration settings for the device server. Deselect the “DHCP” option and enter in

5
the proper network settings. Consult with the network administrator if unsure how to
congure.
4. The USB device connected to the device server should appear below it and list what
type of device it is and it’s current status.
5. If the USB device is available, selecting it and clicking the “Connect” button will
automatically link the device to the computer system, making it appear as a locally
connected USB device. It can then be used as such.
6. When done using the USB device, make sure to click the “Disconnect” button, to allow
other computer systems to connect to it.

6
USB Device Status
Status Description
The attached USB device is ready and waiting for a connection.
The USB device is on a dierent IP range than the computer system.
The network settings need to be congured.
The USB device is currently connected to the computer system.
The USB device is currently connected to a dierent computer system
and unavailable.
The attached USB device is not supported by the IP device server and
will not work (e.g. USB hub).

7
Specications
Number of Ports 1
Bus Interface USB 2.0
Chipset ID Elite Silicon E3868M1
Connectors 1 x USB type A female
1 x RJ45 Ethernet female
LEDs 1 x Power
1 x Ethernet Link/Activity
Networking Standards IEEE 802.3-2002, 802.3ab
Maximum Data Transfer Rate USB 2.0: 480Mbps
Ethernet: 10/100/1000Mbps
Auto-MDIX Support Yes
Power Adapter 5VDC, 1000mA, center positive
Operating Temperature 5°C ~ 50°C (41°F ~ 122°F)
Storage Temperature -25°C ~ 70°C (-13°F ~ 158°F)
Humidity 15% ~ 90% RH
Dimensions (LxWxH) 77.0mm x 38.0mm x 23.0mm
Weight 35g
Compatible Operating Systems Windows XP/Vista/7 (32/64-bit)

8
Technical Support
StarTech.com’s lifetime technical support is an integral part of our commitment to provide
industry-leading solutions. If you ever need help with your product, visit www.startech.
com/support and access our comprehensive selection of online tools, documentation, and
downloads.
Warranty Information
This product is backed by a 2 year warranty.
In addition, StarTech.com warrants its products against defects in materials and
workmanship for the periods noted, following the initial date of purchase. During this
period, the products may be returned for repair, or replacement with equivalent products
at our discretion. The warranty covers parts and labor costs only. StarTech.com does not
warrant its products from defects or damages arising from misuse, abuse, alteration, or
normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
ocers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of prots, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the actual
price paid for the product. Some states do not allow the exclusion or limitation of incidental
or consequential damages. If such laws apply, the limitations or exclusions contained in
this statement may not apply to you.
