StarTech.com IDECASE35SAT Manual

3.5” External Serial ATA Drive Case
IDECASE35SAT
Instruction Guide
The Professionals’ Source For Hard-to-Find Computer Parts
EEXXTTEERRNNAALLDDRRIIVVEECCAASSEE
* Actual product may vary from photo

FCC COMPLIANCE STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

1
TTaabblleeooffCCoonntteennttss
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Connecting Your External Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Using Your External Case . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Technical Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5

2
IInnttrroodduuccttiioonn
Thank you for purchasing a StarTech.com 3.5” external drive case. Designed for 3.5” hard
drives, this device allows you to quickly connect and disconnect your hard drives, making
data storage, backup, and file sharing easier than ever. The IDECASE35SAT provides a
data transfer speed of up to 300 MBytes/sec. As well, the IDECASE35SAT is an ideal
solution for editing and storing space consuming videos and high-end graphic files and
making them portable. Additionally, the case is ideal for storing data from digital cameras,
DV camcorders, MP3 files and computer games.
FFeeaattuurreess
• Constructed with aluminum for durability and longer life
• Compatible with both Windows and Mac operating system environments
• Provides maximum storage taking up minimal desk space
• Backed by StarTech.com’s one year warranty
BBeeffoorreeYYoouuBBeeggiinn
To ensure a quick and easy device assembly, please read through the following
instructions before assembling your device.
WARNING: Hard drives require careful handling, especially when being transported. If
you are not careful with your hard disk, lost data may result. Always handle your hard
drive and storage device with caution. Hard drives, like all computer equipment can also
be severely damaged by static electricity. Be sure that you are properly grounded before
opening your computer case or touching any components. StarTech.com recommends
that you wear an anti-static strap when installing any computer equipment. If an anti-
static strap is unavailable, discharge yourself of any static electricity build-up by touching
a large grounded metal surface (such as the computer case) for several seconds. Do not
bump, jar, or drop the device. Do not disconnect any cables or power sources while the
hard drive is active. This can result in data loss and possible damage to the hard drive.
Always make sure that your hard drive is fully spun down before removing the device.
Contents
• 1 x IDECASE35SAT case
• 1 x Power Adapter - DC Output 12V (1.7A)
• 1 x Serial ATA Cable - 3 ft in length
• 1 x Bag of assorted screws
System Requirements
Windows - 98SE/ME/2000 and XP
Mac - OS 9.0 and up

3
IInnssttaallllaattiioonn
This section will guide you through the installation of your external drive case. Please
read through the instructions carefully and complete each step in the order listed.
NOTE: Before installing the hard disk in the case, make sure that you have properly
configured your hard disk according to your hard disk manufacturer’s specifications.
1. Make sure that the external case is not plugged in and that you are grounded.
2. Using a Phillips screwdriver, remove the two screws from the back of the external
case. Slide the caddy free of the aluminum case by pulling on the clear plastic tab
until the caddy is free from the case.
3. Connect the case’s power connector to your hard drive’s power port.
4. Plug one end of the Serial ATA cable into an open port on your computer. Plug the
other end into the port on the case.
5.
Gently place the hard drive in the caddy, making sure that the screwholes in the hard
drive are aligned with the screw holes in the caddy. Secure the hard drive in place
using the provided screws.
6.
Gently slide the caddy back into the aluminum case and re-attach the caddy to the
case using the screws you removed in Step 2.
CCoonnnneeccttiinnggYYoouurrEExxtteerrnnaallCCaassee
1. Make sure that your system is turned off.
2. Plug one end of the Serial ATA cable into an open port on your computer. Plug the
other end into the port on the case.
3. Plug the power adapter into the case and plug the other end into an available power
source.
4. Power the device on by pushing in the small button on the back of the case.
5. Turn your computer on.
UUssiinnggYYoouurrEExxtteerrnnaallCCaassee
When the new drive is connected, it will appear as an icon on the bottom right of your
screen. You can double-click the icon for information on the drive. The device will also
appear under your “My Computer” window. You can now use the drive as you would any
other device on your system.
When you want to remove your external case, first make sure that there is no activity on
the hard drive contained in the case. Do not remove or shut down the case if the green
activity LED is on. When you are certain the hard drive has “spun down”, right-click the
drive icon and click on “Safely remove device.” When the icon is removed from your
screen, turn off the power to the external drive by pushing the power button on the back
and disconnect the Serial ATA cable.

4
TTeecchhnniiccaallSSppeecciiffiiccaattiioonnss
Enclosure Dimensions
Length 7.6 inches (194 mm)
Width 5.0 inches (128 mm)
Height 1.5 inches (40 mm)
Enclosure Construction/Color Aluminum/Silver
Hard Drive Compatibility Compatible with 3.5” Serial ATA
Hard Drives
Data Transfer Rate Up to 300 MBytes/sec.
Power Supply Output 12V (1.7A)
Safety Certifications CE

5
TTeecchhnniiccaallSSuuppppoorrtt
The following technical resources are available for this StarTech.com product:
On-line help:
We are constantly adding new information to the
Tech Support section of our web site. To
access this page, click the
Tech Support link on our homepage, www.startech.com.In
the tech support section there are a number of options that can provide assistance with
this product.
Knowledge Base - This tool allows you to search for answers to common issues using
key words that describe the product and your issue.
FAQ - This tool provides quick answers to the top questions asked by our customers.
Downloads - This selection takes you to our driver download page where you can
find the latest drivers for this product.
Call StarTech.com tech support for help:
USA/Canada: 1-519-455-4931
UK/Ireland/Europe: 00-800-7827-8324
Support hours: Monday to Friday 9:00AM to 5:00PM EST (except holidays)
WWaarrrraannttyyIInnffoorrmmaattiioonn
This product is backed by a one-year warranty. In addition, StarTech.com warrants
its products against defects in materials and workmanship for the periods noted,
following the initial date of purchase. During this period, the products may be
returned for repair, or replacement with equivalent products at our discretion. The
warranty covers parts and labor costs only. StarTech.com does not warrant its
products from defects or damages arising from misuse, abuse, alteration, or
normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
officers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive incidental, consequential, or otherwise), loss of profits, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the actual
price paid for the product.
Some states do not allow the exclusion or limitation of incidental or consequential
damages. If such laws apply, the limitations or exclusions contained in this statement may
not apply to you.

Revised: 8 February, 2006
