StarTech.com ST4202USB User manual

USB Hub
ST4202USB
ST7202USB
Instruction Manual
Actual product may vary from photo
4 Port USB 2.0 Hub
7 Port USB 2.0 Hub

FFCCCCCCoommpplliiaanncceeSSttaatteemmeenntt
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
UUsseeooffTTrraaddeemmaarrkkss,,RReeggiisstteerreeddTTrraaddeemmaarrkkss,,aanndd
ootthheerrPPrrootteecctteeddNNaammeessaannddSSyymmbboollss
This manual may make reference to trademarks, registered trademarks, and other
protected names and/or symbols of third-party companies not related in any way to
StarTech.com. Where they occur these references are for illustrative purposes only and
do not represent an endorsement of a product or service by StarTech.com, or an
endorsement of the product(s) to which this manual applies by the third-party company in
question. Regardless of any direct acknowledgement elsewhere in the body of this
document, StarTech.com hereby acknowledges that all trademarks, registered
trademarks, service marks, and other protected names and/or symbols contained in this
manual and related documents are the property of their respective holders.

Instruction Manual
i
TTaabblleeooffCCoonntteennttss
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Before You Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
System Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Windows 98SE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Windows 2000/XP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Windows Vista . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Accessory Products from StarTech.com . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Technical Support . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7

Instruction Manual
1
Thank you for purchasing a StarTech.com Multi-port USB 2.0 Hub. This product allows
you to connect multiple USB 2.0 devices to your computer, while taking up minimal
deskspace. Perfect for notebook users or those with confined workspaces, this product
delivers the performance you expect from USB 2.0 while maintaining backward
compatibility with the USB 1.1 standard, so your existing devices still function flawlessly.
For added convenience, this product includes a USB-to-power converter so that unused
USB ports on your computer can power your high performance devices.
IInnttrroodduuccttiioonn
Features
BBeeffoorreeYYoouuBBeeggiinn
•Compact space-saving design
•Maximum data transfer rate of up to 480 Mbps
•Backward compatible with USB 1.1 standard
•Quick, easy installation
•A computer with one available USB 2.0 port
System Requirements
•Windows 98SE / ME / 2000 / XP / Vista, MAC 8.6/9.x/10.x and later
•1 x USB 2.0 Hub
Package Contents
•1 x USB Cable
•1 x Power Adapter
•1 x User Manual
This package should contain:

Instruction Manual
2
IInnssttaallllaattiioonn
Windows 98SE
1. Windows will launch the
Add New Hardware Wizard . Press Next to begin the
software installation process.
2. When the Add New Hardware Wizard
appears, click Next:
3. Windows will inform you that it is ready to
install the driver for the device Generic
USB Hub on USB 2.0 Bus. Click Next:
4. Follow any remaining prompts. When Windows informs you it has finished installing
the drivers. Click Finish.
5. To verify that the drivers have successfully been
installed, right-click on My Computer and select
Manage. Select Device Manager, and click on
the [+] symbol located next to
Universal Serial
Bus Controllers
. Here, you should notice a listing
for Generic USB Hub on USB 2.0 Bus:
6. You can now attach USB devices to the hub.
To begin the installation process, connect the USB 2.0 Hub to an available USB 2.0 port.
Software installation will commence as follows:

1. Windows will launch the Add New Hardware Wizard . Press Next to begin the
software installation process.
2. When the Found New Hardware Wizard
appears, click Next:
3. Windows will then search for the driver
files required for the Generic USB Hub.
Click Next:
4. Windows will locate the driver file. Click
OK to proceed, and follow any remaining
prompts to complete installation.
Instruction Manual
3
Windows 2000/XP

5. To verify that the drivers have successfully been
installed, right-click on My Computer and select
Manage. Select Device Manager, and click on
the [+] symbol located next to
Universal Serial
Bus Controllers
. Here, you should notice a listing
for Generic USB Hub:
6. You can now attach USB devices to the hub.
Instruction Manual
4
Windows Vista
Windows Vista driver installation requires no interaction. Simply connect the USB Hub to
an available USB port on the host computer, and wait for the Windows notification that
your device is now installed:

Instruction Manual
5
SSppeecciiffiiccaattiioonnss
Bus Type USB
Connectors
1 x USB Mini B Male
4 x USB Type A Male (ST4202USB)
7 x USB Type A Male (ST7202USB)
Cables 1 x 3 ft. USB Type B to Type A Cable
Maximum Data Transfer Rate 480 Mbps
Operating Temperature 0 to 70° C (0 to 158° F)
Regulatory Certifications FCC, CE, ROHS

Instruction Manual
6
USB2HAB6
6 ft High Speed Certified USB 2.0 Cable
USB2HAB10
10 ft High Speed Certified USB 2.0 Cable
AAcccceessssoorryyPPrroodduuccttssffrroommSSttaarrTTeecchh..ccoomm
Contact your local StarTech.com dealer or visit www.startech.com for cables or other
accessories that will help you get the best performance out of your new product.
USB2HAB15
15 ft High Speed USB 2.0 Cable
PCI225USB
Value 2 Port USB 2.0 PCI Card
CBUSB220
2 Port USB 2.0 CardBus Adapter

Instruction Manual
7
TTeecchhnniiccaallSSuuppppoorrtt
StarTech.com’s lifetime technical support is an integral part of our commitment to provide
industry-leading solutions. If you ever need help with your product, visit
www.startech.com/support and access our comprehensive selection of online tools,
documentation, and downloads.
WWaarrrraannttyyIInnffoorrmmaattiioonn
This product is backed by a one-year warranty. In addition, StarTech.com warrants its
products against defects in materials and workmanship for the periods noted, following
the initial date of purchase. During this period, the products may be returned for repair, or
replacement with equivalent products at our discretion. The warranty covers parts and
labor costs only. StarTech.com does not warrant its products from defects or damages
arising from misuse, abuse, alteration, or normal wear and tear.
Limitation of Liability
In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their
officers, directors, employees or agents) for any damages (whether direct or indirect,
special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business,
or any pecuniary loss, arising out of or related to the use of the product exceed the
actual price paid for the product. Some states do not allow the exclusion or limitation of
incidental or consequential damages. If such laws apply, the limitations or exclusions
contained in this statement may not apply to you.

Revised: 19 February 2007 (Rev. A)
AAbboouuttSSttaarrTTeecchh..ccoomm
StarTech.com is “The Professionals’ Source for Hard-to-Find Computer
Parts”. Since 1985, we have been providing IT professionals with the
quality products they need to complete their solutions. We offer an
unmatched selection of computer parts, cables, server management
solutions and A/V products and serve a worldwide market through our
locations in the United States, Canada, the United Kingdom and Taiwan.
Visit www.startech.com for complete information about all our products
and to access exclusive interactive tools such as the Parts Finder and the
KVM Reference Guide. StarTech.com makes it easy to complete almost
any IT solution. Find out for yourself why our products lead the industry in
performance, support, and value.
