State Water Heaters SCC 40-40 Troubleshooting guide

Installation,
User and
Service Manual
Installation,
User and
Service Manual
4617 - Changes Reserved.0312884
40-40
40-70
50-40
50-70
65-80
65-110
75-80
75-110
100-110
SCC

your installer

Preface
Copyright
Copyright © 2017 STATE Water Heaters
All rights reserved.
Nothing from this publication may be copied, reproduced and/or published by means of
printing, photocopying or by whatsoever means, without the prior written approval of
STATE Water Heaters.
STATE Water Heaters reserves the right to modify specifications in this manual.
Trademarks
Brand names in this manual are registered trademarks of their respective owners.
Warranty
Refer to the appendix Warranty (see section 13.6) for the warranty provisions.
Liability
STATE accepts no liability for claims from third parties caused by:
unauthorized use
use other than stated in this manual
use other than in accordance with the General Conditions registered at the Chamber
of Commerce.
For more information, refer to the General Conditions. These are available on request, free
of charge.
We believe that this manual provides you with accurate and complete descriptions of all
relevant components. If you, nonetheless find errors or inaccuracies in this manual, please
inform STATE. This helps us to further improve our documentation.
•
•
•
0312884_SCC_UKUK_V1.0, 2017-10-03 3

Compliance
To safely produce domestic hot water, the design and construction of the SCC water
heaters is in accordance with:
the European Gas Appliance Directive (GAD).
the European Standard for Gas–fired storage water heaters for the production of
domestic hot water (EN89).
The European ECO-Design Directive.
The European Energy Labeling Directive
Refer to the appendix Declaration of conformity (see section 13.5).
Regulations
Gas Safety (installations and Use) Regulations 1998 (as
amended).
It is law that all gas appliances are installed by competent persons, in accordance with the
above regulations. Failure to install appliances correctly could lead to prosecution. It is in
your own interest and that of safety, to ensure that this law is complied with.
The installation of the water heater MUST be in accordance with the relevant requirements
of the Gas Safety Regulations, Building Regulations, IEE Regulations and the Water Supply
(water fittings) Regulations. The installation should also be in accordance with any
relevant requirements of the HSE, local gas region and local authority and the relevant
recommendations of the following documents:
British and European Standards
BS 6891:
Installation of low pressure gas pipework of up to 35 mm (R1¼) in domestic
premises (2nd family gas) - Specification. Note: for lager installations see IGE/UP/2
below.
BS 6798:
Specification for installation and maintenance of gas-fired boilers of rated input not
exceeding 70 kW net.
BS 6644:
Specification for installation of gas-fired hot water boilers of rated inputs between 70
kW (net) and 1.8 MW (net) (2nd and 3rd family gases).
BS 6700:
Design, installation, testing and maintenance of services supplying water for
domestic use within buildings and their cartilages - Specifications
BS EN 806-2:
Specification for installations inside buildings conveying water for human
consumption. Part 2: Design.
BS 5546:
Specification for installation of hot water supplies for domestic purposes, using gas-
fired appliances of rated input not exceeding 70 kW.
BS 5440:
Flueing and ventilation for gas appliances of rated input not exceeding 70 kW net
(1st, 2nd and 3rd family gases).
Part 1: Specification for installation of gas appliances to chimneys and for
maintenance of chimneys.
Part 2: Specification for installation and maintenance of ventilation for gas
appliances.
•
•
•
•
•
•
•
•
•
•
•
-
-
4

Institute of Gas Engineers and Managers (IGEM) Publications
IGE/UP/1:
Soundness testing and purging of industrial and commercial gas installations.
IGE/UP/1A:
Soundness testing and direct purging of small low pressure industrial and commercial
natural gas installations.
IGE/UP/2:
Gas installation pipework, boosters and compressors on industrial and commercial
premises.
IGE/UP/10:
Installation of flued gas appliances in industrial and commercial premises.
CIBSE Publications
Guide G:
Public Health Engineering
Contact information
In the event of problems with your gas, electricity or water supply connections or when
you have any comments or questions, please contact your supplier.
•
•
•
•
•
0312884_SCC_UKUK_V1.0, 2017-10-03 5

6

About this manual
Scope
This manual gives information about safe and correct use of the water heater and how
installation, maintenance and service activities have to be done correctly. You must obey
the instructions in this manual.
Caution
Read this manual carefully before you start the water heater. It can cause personal injury
and damage to the water heater when you do not read the manual and/or do not obey
the instructions.
The purpose of this manual is to:
describe the working principles and layout of the water heater
explain the safety devices
highlight possible hazards
describe the use of the water heater
describe the installation, service and maintenance of the water heater
This manual has two parts:
An User part that describes the correct usage of the water heater.
An Installation, Maintenance and Service part, that describes the correct installation
and maintenance procedures.
Target group
The information in this manual applies to three target groups:
users
installation engineers
service and maintenance engineers
The User part is intended for the (end) users. The Installation, Maintenance and Service
part is intended for the installation engineers and the service and maintenance engineers.
Notation conventions
This manual uses the following text conventions:
Numbers between parentheses e.g. (1), refer to elements in a figure that are
described by the text.
Texts displayed on the user interface always are shown similar to the characters in
the display, for example parameter 120 or Off.
Buttons are always shown between brackets, for example: [ ], [ENTER], [RESET].
Cross-references to sections, tables, figures etc. are underlined and written as (see
section "..."). In the digital version, the cross-references function as hyperlinks that
can be used to navigate through the manual by clicking on them. Example: Safety
(see section 2).
c
•
•
•
•
•
•
•
•
•
•
•
•
•
•
0312884_SCC_UKUK_V1.0, 2017-10-03 7

This manual contains the following text styles/symbols for situations that may endanger
users/engineers, cause damage to equipment or need special attention:
Note
A note gives more information on a topic.
Caution
Obey the caution instructions to prevent damage of the water heater.
Warning
Obey the warning instructions to prevent danger of personal injury, and serious damage
to the water heater.
Document identification
Article number Language Version
0312884 EN 1.0
n
c
w
8

Table of Contents
Preface........................................................................................ 3
Copyright.......................................................................... 3
Trademarks....................................................................... 3
Warranty...........................................................................3
Liability.............................................................................3
Compliance....................................................................... 4
Regulations....................................................................... 4
Contact information............................................................ 5
About this manual....................................................................... 7
Scope............................................................................... 7
Target group..................................................................... 7
Notation conventions.......................................................... 7
Document identification.......................................................8
User part.................................................................. 13
1 Introduction.............................................................................. 15
2 Safety........................................................................................17
3 Interface................................................................................... 19
3.1 Operator interface............................................................ 19
3.1.1 Control Switch..................................................................19
3.1.2 Buttons........................................................................... 20
3.1.3 LCD display..................................................................... 20
3.2 Status of the water heater................................................. 21
3.2.1 Operating modes.............................................................. 21
3.2.2 Error conditions................................................................22
3.2.3 Service conditions.............................................................22
3.2.4 Anode warning................................................................. 23
4 Use............................................................................................ 25
4.1 Set a parameter value.......................................................25
4.2 Turn on the water heater...................................................25
0312884_SCC_UKUK_V1.0, 2017-10-03 9

4.2.1 Switch to ON mode........................................................... 25
4.2.2 Set the water temperature.................................................25
4.3 Turn off the water heater...................................................26
4.3.1 Turn off for a short period..................................................26
4.3.2 Isolate from the mains...................................................... 26
4.3.3 Turn off for a long period...................................................26
Installation, Maintenance and Service part.............. 27
5 Introduction.............................................................................. 29
5.1 About the water heater..................................................... 29
5.2 Working principle..............................................................29
6 Safety........................................................................................31
6.1 Safety instructions............................................................31
6.2 Instructions on the water heater.........................................32
6.3 Safety devices..................................................................33
6.4 Environmental aspects...................................................... 34
6.4.1 Recycling.........................................................................34
6.4.2 Disposal.......................................................................... 34
7 Water heater............................................................................. 35
7.1 Structure of the water heater............................................. 35
8 Installation............................................................................... 37
8.1 Packaging........................................................................37
8.2 Conditions....................................................................... 37
8.2.1 Ambient conditions........................................................... 37
8.2.2 Maximum floor load.......................................................... 37
8.2.3 Water composition............................................................38
8.2.4 Working clearances...........................................................38
8.2.5 Level the water heater...................................................... 38
8.3 Installation diagram..........................................................40
8.4 Water connections............................................................ 40
8.4.1 Cold water connection....................................................... 40
8.4.2 Hot water connection........................................................ 41
8.4.3 Circulation connection....................................................... 41
8.5 Condensate drain............................................................. 41
8.6 Gas connection.................................................................41
8.7 Venting system................................................................ 42
8.7.1 C13/C33 concentric systems.............................................. 44
10

8.7.2 C13/C33 parallel systems.................................................. 46
8.7.3 C43/C53/C63 systems.......................................................48
8.8 Electrical connections........................................................ 49
8.8.1 Preparation......................................................................49
8.8.2 Mains power.................................................................... 50
8.8.3 Optional electrical connections............................................50
8.8.4 Finalization...................................................................... 51
8.9 Commissioning.................................................................51
8.9.1 Filling..............................................................................51
8.9.2 Air pressure differential..................................................... 52
8.9.3 Gas supply pressure..........................................................53
8.9.4 CO2 value........................................................................53
8.9.5 Turn on the water heater...................................................55
8.10 Decommisioning...............................................................55
8.10.1 Turn off the water heater...................................................55
8.10.2 Draining.......................................................................... 55
9 Conversion of gas type.............................................................. 57
10 Settings.....................................................................................59
10.1 Operator interface............................................................ 59
10.2 Parameters......................................................................59
10.3 Hysteresis....................................................................... 61
10.4 Error history.................................................................... 61
10.5 Test cycle........................................................................ 62
11 Maintenance.............................................................................. 63
11.1 Performance check........................................................... 63
11.2 Preparation......................................................................64
11.3 Water-side maintenance....................................................64
11.3.1 Descale the tank.............................................................. 64
11.3.2 Clean the condensate drain................................................65
11.4 Gas-side maintenance....................................................... 65
11.4.1 Clean the burner.............................................................. 65
11.4.2 Clean the combustion chamber...........................................67
11.4.3 Assemble the burner......................................................... 68
11.5 Finalization...................................................................... 68
12 Troubleshooting........................................................................ 71
12.1 Errors and warnings..........................................................71
12.1.1 General errors..................................................................71
0312884_SCC_UKUK_V1.0, 2017-10-03 11

12.1.2 Displayed errors............................................................... 74
12.1.3 Warnings.........................................................................80
13 Appendices................................................................................81
13.1 Technical details...............................................................81
13.2 Dimensions......................................................................82
13.3 Gas details...................................................................... 84
13.3.1 Energy labeling................................................................ 85
13.4 Electrical wiring diagram....................................................87
13.5 Declaration of conformity...................................................89
13.6 Warranty.........................................................................90
Index........................................................................................ 93
12

User part
0312884_SCC_UKUK_V1.0, 2017-10-03 13

14

1 Introduction
The SCC water heater stores and heats water for sanitary purposes.
Cold water enters the bottom of the tank through the water inlet (1). The heated water
leaves the tank at the top through the hot water outlet (2). To operate the water heater,
the operator interface (3) and control switch (4) are used.
Fig. SCC water heater
1
2
3
4
1. Water inlet
2. Water outlet
3. Operator interface
4. Control switch
0312884_SCC_UKUK_V1.0, 2017-10-03 15

16 User part

2 Safety
STATE cannot be held responsible for damages or injuries leading back to:
Failure to follow the instructions provided in this manual.
Carelessness during use or maintenance of the water heater.
Every user has to study the user part of this manual and has to follow the instructions in
this part of the manual strictly. Do not change the sequence of the actions to be done.
This manual has to be available for the user and service engineer all the time.
Warning
If you smell gas:
Shut off the mains gas supply valve!
Avoid causing sparks! Do not use any electrical equipment or switch, i.e. no
telephones, plugs or bells!
No naked flames! No smoking!
Open windows and doors!
Warn occupants and leave the building!
After leaving the building, alert the gas distribution company or your
installation engineer.
w•
•
•
•
•
•
Caution
Do not store or use chemical substances in the room where the water heater is installed
because of the risk of explosion and corrosion of the water heater. Some propellants,
bleaching agents and degreasing agents etc. disperse of explosive vapors and/or cause
accelerated corrosion. If the water heater is used in a room where such substances are
stored or used, the warranty will be void.
Caution
Installation, maintenance and service may only by carried out by a qualified engineer.
Caution
The water heater is not intended for use by persons with reduced physical, sensory or
mental capacities, or who lack the necessary experience or knowledge. When the person
responsible for their safety is supervising them or has explained to them how the water
heater should be used, these persons can use the water heater.
Caution
This water heater is not intended to be used by children. Always supervise children, and
make sure that they do not play with the water heater.
Note
Regular maintenance extends the service life of the water heater. To determine the
correct service interval, the service and maintenance engineer has to do a check on both
the water and gas side of the water heater three months after installation. Based on this
check, the best service interval can be determined.
•
•
c
n
0312884_SCC_UKUK_V1.0, 2017-10-03 17

18 User part

3 Interface
3.1 Operator interface
The operator interface consists of:
a control switch (see section 3.1.1) on the left side of the water heater
5 push buttons (see section 3.1.2) to navigate through the menu
a LCD-display (see section 3.1.3) that shows settings, functions, values and errors.
The operator interface is parameter driven and enables the user to change parameters and
to verify the status and history of the water heater.
Fig. Operator interface
1. LCD display
2. Push buttons
3.1.1 Control Switch
With the control switch you can activate and deactivate the controller of the water heater.
Warning
The power of the water heater stays on when the control switch is set to 0.
When the control switch is set to I, the display first shows ini for some seconds. After
that, the display shows OFF.
Fig. Display
•
•
•
w
0312884_SCC_UKUK_V1.0, 2017-10-03 19
21

3.1.2 Buttons
The 5 buttons on the operator panel give access to the menu of the water heater.
Button Function
[ ] Scroll up / Raise
[ ] Scroll down / Lower
[ENTER] Enter / Confirm
[RESET] Reset / Cancel
[MENU] Go to menu
3.1.3 LCD display
The LCD display shows 7 different symbols around the outer edge of the display and 3
characters in the center of the display. The characters represent parameters.
Fig. LCD display
2
1
1. Characters
2. Symbols
The symbols on the display show visual information about the status of the water heater.
Symbol Explanation
Heat demand present
Water heater in operation
Water heater not in operation - ERROR
Frost protection is activated
Scroll through menu
Shown on the right side corners of the display
External ON mode is activated
Shown on the upper left side corner
20 User part
