State Water Heaters GPG 81-270 User manual
COMMERCIAL GAS WATER HEATERS
Instruction Manual
PRINTED 0313 195091-002
PLACE THESE INSTRUCTIONS ADJACENT TO HEATER AND NOTIFY OWNER TO KEEP FOR FUTURE REFERENCE.
MODELS GPG 81-140 Thru 81-370
SERIES 104/105
INSTALLATION - OPERATION - SERVICE
- MAINTENANCE - LIMITED WARRANTY
Read and understand this instruction
manual and the safety messages
herein before installing, operating or
servicing this water heater.
Failure to follow these instructions and
safety messages could result in death
or serious injury.
This manual must remain with the
water heater.
Low Lead Content
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or death.
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
Do not try to light any appliance.
Do not touch any electrical switch; do
not use any phone in your building.
Immediately call your gas supplier
from a neighbor’s phone. Follow the
gas supplier’s instructions.
If you cannot reach your gas supplier,
call the fire department.
Installation and service must be
performed by a qualified installer,
service agency or the gas supplier.
•
•
•
•
2
18
19
19-22
19
19
Installation Diagrams - Top Inlet/Outlet Usage 20
Burner Installation 20
Heater Wiring 21
Gas Piping 22
22
Purging 22
23
23
24
25
26
26
26
28-32
28
General 28
28
Temperature-Pressure Relief Valve Test 28
29
29
29
30
30
30-31
31-32
32
32
32
33
FOR YOUR INFORMATION 34
34
34
35-49
50
51-52
53-54
WARRANTY 55
TABLE OF CONTENTS
3
3
4-5
5
5
5
6
6
6
6
Preparing for the Installation 6
8 -12
Rough In Dimensions 8
10
10
Insulation Blanket11
11
11-12
12
13-16
13
13
13
13
14
14
14
Temperature-Pressure Relief Valve 14-15
15
15
16
16
16-19
Venting 16
16
18
3
SAFE INSTALLATION, USE AND SERVICE
WARNING:
DANGER
WARNING
CAUTION
CAUTION
DANGER indicates an imminently
hazardous situation which, if not avoided,
will result in injury or death.
This is the safety alert symbol. It is used to alert you to
potential personal injury hazards. Obey all safety
messages that follow this symbol to avoid possible
injury or death.
WARNING indicates a potentially hazardous
situation which, if not avoided, could result
in injury or death.
CAUTION indicates a potentially hazardous
situation which, if not avoided, could result in
minor or moderate injury.
CAUTION used without the safety alert
symbol indicates a potentially hazardous
situation which, if not avoided, could result in
property damage.
APPROVALS
Note:
Low Lead Content
4
GENERAL SAFETY INFORMATION
Fire Hazard
Do not install water heater on
carpeted floor.
Do not operate water heater if
flood damaged.
For continued protection against
risk of fire:
Fire or Explosion Hazard
Read instruction manual before
installing, using or servicing
water heater.
Avoid all ignition sources if you smell gas.
Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
Use only the gas shown on the water heater rating label.
Keep ignition sources away from faucets after extended
periods of non-use.
Maintain required clearances to combustibles.
Do not expose water heater controls to excessive gas
pressure.
Property Damage Hazard
All water heaters eventually leak.
•
Do not install without adequate drainage.
•
CAUTION
Fire and Explosion Hazard
Leak test before placing the
water heater in operation.
Disconnect gas piping and main
gas shutoff valve before leak
testing.
Install sediment trap in
accordance with NFPA 54.
Use joint compound or Teflon tape
compatible with propane gas.
Fire and Explosion Hazard
Turn off gas lines during installation.
Contact a qualified installer or service
agency for installation and service.
Excessive gas pressure to gas valve can
cause serious injury or death.
Do not use water heater with any gas
other than the gas shown on the rating
label.
Turn off power to the water heater
before performing any service.
Electrical Shock Hazard
•
Label all wires prior to disconnecting
when performing service. Wiring errors
can cause improper and dangerous
operation.
•
Verify proper operation after servicing.
•
Failure to follow these instructions can
result in personal injury or death.
•
Jumping out control circuits or components can
result in property damage, personal injury or death.
Service should only be performed by a qualified service
agent using proper test equipment.
•
Altering the water heater controls and/or wiring in any way
could result in permanent damage to the controls or water
heater and is not covered under the limited warranty.
•
Any bypass or alteration of the water
heater controls and/or wiring will result
in voiding the water heater warranty.
Altering the water heater controls and/or wiring in any way
could result in altering the ignition sequence allowing gas to
flow to the main burner before the hot surface igniter is at
ignition temperature causing delayed ignition which can
cause a fire or explosion.
•
5
PRECAUTIONS
WATER HEATER
GROUNDING INSTRUCTIONS
HYDROGEN GAS FLAMMABLE
Explosion Hazard
Flammable hydrogen gases
may be present.
Keep all ignition sources away
from faucet when turning on
hot water.
THERE
GENERAL SAFETY INFORMATION
Verify the power to the water heater is turned off before performing any service procedures.
Read and understand this instruction
manual and the safety messages
herein before installing, operating or
servicing this water heater.
Failure to follow these instructions and
safety messages could result in death
or serious injury.
This manual must remain with the
water heater.
Water temperature over 125°F (52°C)
can cause severe burns instantly
resulting in severe injury or death.
Children, the elderly and the
physically or mentally disabled are at
highest risk for scald injury.
Feel water before bathing or
showering.
Temperature limiting devices such as
mixing valves must be installed
when required by codes and to
ensure safe temperatures at fixtures.
Explosion Hazard
Overheated water can cause
water tank explosion.
Properly sized temperature and
pressure relief valve must be
installed in the opening provided.
Improper installation, use and service may result
in property damage.
Do not operate water heater if flood damaged.
•
Inspect anode rods regularly, replace if damaged.
•
Install in location with drainage.
•
Fill tank with water before operation.
•
Properly sized thermal expansion tanks are required on all
closed water systems.
•
Refer to this manual for installation and service.
CAUTION
GENERAL SAFETY INFORMATION
6
INTRODUCTION
ABBREVIATIONS USED
QUALIFICATIONS
QUALIFIED INSTALLER OR SERVICE AGENCY
ANSI Z223.1 2006 Sec. 3.3.83:
START UP REQUIREMENTS
PREPARING FOR THE INSTALLATION
HIGH LIMIT SWITCH
DIGITAL THERMOSTAT
FIGURE 1.
ELECTRONIC IGNITION CONTROL
IGNITION MODULE
FIGURE 2.
BAROMETRIC DRAFT CONTROL
BAROMETRIC DRAFT CONTROL
FIGURE 3.
COMBUSTION CHAMBER OBSERVATION PORT
FIGURE 4.
UNCRATING
FEATURES AND COMPONENTS
8
ROUGH IN DIMENSIONS
INSTALLATION CONSIDERATIONS
FIGURE 5.
TABLE 1 . MODELS GPG 81-140 THRU 81-370
MODELS A B
C
D E G
H
JGAS
APPROX. SHIP. WT.
(LBS.) IN OUT
ASME STD.
GPG 81-140
65
26 3/4
1/2 658 556
GPG 81-199
65
26 3/4
1/2 635 545
65
26 3/4
3/4 632
65
26 3/4
3/4 634
9
TABLE 2. HEATER PERFORMANCE DATA GPG MODELS
MODELS
STORAGE
CAPACITY
U.S. GALLONS
INPUT RATING BTU/HR. RECOVERY RATE
GPH@100°F RISE
RECOVERY RATE
GPH@140°F RISE
MAXIMUM
AMPERES
120V, 60Hz, 10
GPG 81-140 81 136 5
GPG 81-199 81 193 138 5
81 262 5
81 359 256 5
TABLE 3. GAS AND ELECTRICAL CHARACTERISTICS
Type of Gas
Volts/Hz AmperesMinimum
Natural 120/60 <5
* Propane 120/60 <5
GPG
INSTALLATION CONSIDERATIONS
10
CLEARANCES
PROPER INSTALLATION ON COMBUSTIBLE FLOORING
FIGURE 6.
TABLE 4.INSTALLATION CLEARANCES
A
(RIGHT SIDE)
B
(LEFTSIDE)
C
(BACK)
D
(CEILING)
GPG 81-140
GPG 81-199
LOCATING THE WATER HEATER
Property Damage Hazard
All water heaters eventually leak.
•
Do not install without adequate drainage.
•
CAUTION
Fire or Explosion Hazard
Read instruction manual before
installing, using or servicing
water heater.
Avoid all ignition sources if you smell gas.
Do not store or use gasoline or other flammable vapors and
liquids in the vicinity of this or any other appliance.
Use only the gas shown on the water heater rating label.
Keep ignition sources away from faucets after extended
periods of non-use.
Maintain required clearances to combustibles.
Do not expose water heater controls to excessive gas
pressure.
INSTALLATION CONSIDERATIONS
11
• DO NOT
• DO NOT
• DO NOT
• DO NOT
• DO
• DO
HARD WATER
CIRCULATION PUMPS
FIGURE 7.
INSULATION BLANKET
Do not obstruct water heater air intake
with insulating blanket.
Gas and carbon monoxide detectors
are available.
Install water heater in accordance with
the instruction manual.
Breathing carbon monoxide can cause brain damage or
death. Always read and understand instruction manual.
Breathing Hazard - Carbon Monoxide Gas
12
Breathing Hazard - Carbon Monoxide Gas
Breathing carbon monoxide can cause brain damage or
death. Always read and understand instruction manual.
Under no circumstances should
the input exceed the rate shown
on the water heater’s rating label.
Overfiring could result in damage to
the water heater and sooting.
Gas and carbon monoxide detectors
are available.
CIRCULATING PUMP WIRING DIAGRAM
STORAGE TANK OR BUILDING RECIRCULATION
FIELD SUPPLIED TEMPERATURE CONTROL
INSTALLED IN THE STORAGE TANK
OR CIRCULATING LOOP RETURN LINE
CIRC
PUMP
MOTOR
L1 HOT
L2 NEUTRAL
120 VAC
POWER
CIRCULATING PUMP WIRING DIAGRAM
DISHWASHER LOOP WITH TOGGLE SWITCH
FIELD SUPPLIED TEMPERATURE
CONTROL INSTALLED IN THE
CIRCULATING LOOP RETURN LINE
DISHWASHER
TOGGLE
SWITCH
CIRC
PUMP
MOTOR
L1 HOT
L2 NEUTRAL
120 VAC
POWER
NOTE: USE SEPARATE 120 VAC POWER
SUPPLY FOR PUMP CIRCUIT. DO NOT
SHARE POWER WITH WATER HEATER AS THIS
MAY CAUSE ELECTRICAL LINE NOISE AND
LEAD TO ERRATIC CONTROL SYSTEM
OPERATION.
NOTE: USE SEPARATE 120 VAC POWER
SUPPLY FOR PUMP CIRCUIT. DO NOT SHARE
POWER WITH WATER HEATER AS THIS MAY
CAUSE ELECTRICAL LINE NOISE AND LEAD
TO ERRATIC CONTROL SYSTEM OPERATION.
FIGURE 8.
CIRCULATING PUMP WIRING DIAGRAM
STORAGE TANK OR BUILDING RECIRCULATION
FIELD SUPPLIED TEMPERATURE CONTROL
INSTALLED IN THE STORAGE TANK
OR CIRCULATING LOOP RETURN LINE
CIRC
PUMP
MOTOR
L1 HOT
L2 NEUTRAL
120 VAC
POWER
CIRCULATING PUMP WIRING DIAGRAM
DISHWASHER LOOP WITH TOGGLE SWITCH
FIELD SUPPLIED TEMPERATURE
CONTROL INSTALLED IN THE
CIRCULATING LOOP RETURN LINE
DISHWASHER
TOGGLE
SWITCH
CIRC
PUMP
MOTOR
L1 HOT
L2 NEUTRAL
120 VAC
POWER
NOTE: USE SEPARATE 120 VAC POWER
SUPPLY FOR PUMP CIRCUIT. DO NOT
SHARE POWER WITH WATER HEATER AS THIS
MAY CAUSE ELECTRICAL LINE NOISE AND
LEAD TO ERRATIC CONTROL SYSTEM
OPERATION.
NOTE: USE SEPARATE 120 VAC POWER
SUPPLY FOR PUMP CIRCUIT. DO NOT SHARE
POWER WITH WATER HEATER AS THIS MAY
CAUSE ELECTRICAL LINE NOISE AND LEAD
TO ERRATIC CONTROL SYSTEM OPERATION.
FIGURE 9.
HIGH ALTITUDE INSTALLATIONS
Fire and Explosion Hazard
Gas and carbon monoxide detectors are
available.
Overfiring could result in fire or
explosion.
Under no circumstances should the
input exceed the rate shown on the
water heater’s rating label.
13
POWER SUPPLY
WATER TEMPERATURE CONTROL AND MIXING VALVES
Water temperature over 125°F (52°C)
can cause severe burns instantly
resulting in severe injury or death.
Children, the elderly and the
physically or mentally disabled are at
highest risk for scald injury.
Feel water before bathing or showering.
Temperature limiting devices such as
mixing valves must be installed
when required by codes and to
ensure safe temperatures at fixtures.
TABLE 5.
Time for 1st Degree Burn
Time for Permanent Burns
110
116
116 35 minutes 45 minutes
122 1 minute 5 minutes
131
140
149
154 instantaneous
GAS SUPPLY SYSTEMS
SUPPLY GAS REGULATOR
14
INSTALLATION REQUIREMENTS
14
HOT WATER
OUTLET
TO TANK
INLET
CHECK
VALVE
MIXING
VALVE
COLD
WATER
INLET
TEMPERED WATER
OUTLET
12” TO 15”
(30-38 cm)
CHECK
VALVE
FIGURE 10.
DISHWASHING MACHINES
CLOSED WATER SYSTEMS
THERMAL EXPANSION
TEMPERATURE-PRESSURE RELIEF VALVE
Explosion Hazard
Temperature-Pressure Relief Valve
must comply with ANSI Z21.22-
CSA 4.4 and ASME code.
Properly sized temperature-
pressure relief valve must be
installed in opening provided.
Can result in overheating and
excessive tank pressure.
Can cause serious injury or death.
15
Water Damage Hazard
Temperature-Pressure Relief Valve discharge
pipe must terminate at adequate drain.
•
CAUTION
T&P Valve Discharge Pipe Requirements:
Burn hazard.
Hot water discharge.
Keep clear of Temperature-
Pressure Relief Valve
discharge outlet.
NOTE: The purpose of a Temperature-Pressure Relief Valve is to
CONTAMINATED AIR
Breathing Hazard - Carbon Monoxide Gas
Install water heater in accordance with
the Instruction Manual and NFPA 54 or
CAN/CSA-B149.1.
To avoid injury, combustion and ventilation
air must be taken from outdoors.
Do not place chemical vapor emitting
products near water heater.
Breathing carbon monoxide can cause brain damage or
death. Always read and understand instruction manual.
AIR REQUIREMENTS
Breathing Hazard - Carbon Monoxide Gas
Install water heater in accordance with
the Instruction Manual and NFPA 54 or
CAN/CSA-B149.1.
To avoid injury, combustion and ventilation
air must be taken from outdoors.
Do not place chemical vapor emitting
products near water heater.
Breathing carbon monoxide can cause brain damage or
death. Always read and understand instruction manual.
16
DIRECT VENT APPLIANCES
EXHAUST FANS
LOUVERS AND GRILLES
UNCONFINED SPACE
UNUSUALLY TIGHT CONSTRUCTION
CONFINED SPACE
VENTING INSTALLATION
VENTING
BAROMETRIC DRAFT CONTROL ASSEMBLY
NOTE:
PROPER DRAFT CONTROLLER AND
VENT PIPE INSTALLATION
FIGURE 11.
FRESH AIR OPENINGS FOR CONFINED SPACES
OUTDOOR AIR THROUGH TWO OPENINGS
FIGURE 12.
2
2
OUTDOOR AIR THROUGH ONE OPENING
FIGURE 13.
2
OUTDOOR AIR THROUGH TWO HORIZONTAL DUCTS
FIGURE 14.
18
AIR FROM OTHER INDOOR SPACES
FIGURE 16.
2
2
OUTDOOR AIR THROUGH TWO VERTICAL DUCTS
DO NOT refer to these illustrations for the purpose of vent
FIGURE 15.
2
19
WATER HEATER INSTALLATION
VENT CONNECTION
TABLE 6. BAROMETRIC DRAFT CONTROL
ASSEMBLY OUTLET SIZE
MODEL DRAFT CONTROL
OUTLET DIAMETER
GPG 81-140
GPG 81-199
WATER PIPING DIAGRAMS
NOTE:
T&P VALVE DISCHARGE PIPE
Explosion Hazard
Temperature-Pressure Relief Valve
must comply with ANSI Z21.22-
CSA 4.4 and ASME code.
Properly sized temperature-
pressure relief valve must be
installed in opening provided.
Can result in overheating and
excessive tank pressure.
Can cause serious injury or death.
WATER LINE CONNECTIONS
WATER (POTABLE) HEATING AND SPACE HEATING
THERMOMETERS (NOT SUPPLIED)
20
Water Damage Hazard
Temperature-Pressure Relief Valve discharge
pipe must terminate at adequate drain.
•
CAUTION
T&P VALVE DISCHARGE PIPE REQUIREMENTS:
INSTALLATION DIAGRAMS - TOP INLET/OUTLET USAGE
TUBE INLET INSTALLATION
FIGURE 17.
BURNER INSTALLATION
POWER BURNER INSTALLATION
FIGURE 18.
Table of contents
Other State Water Heaters Water Heater manuals
State Water Heaters
State Water Heaters Hybrid Electric Heat Pump Water Heater User manual
State Water Heaters
State Water Heaters Power Direct Vented Gas models User manual
State Water Heaters
State Water Heaters GS6 40 YBVIT, GS6 40 HBVIT, GS6 50 YBVIT, GS6 50 HBVIT, GS6 40 YBVIT 2, GS6 40 HBVIT 2, GS6 50 YBVIT 2, GS6 50 HBVIT... User manual
State Water Heaters
State Water Heaters GS6 40 YBVIT, GS6 40 HBVIT, GS6 50 YBVIT, GS6 50 HBVIT, GS6 40 YBVIT 2, GS6 40 HBVIT 2, GS6 50 YBVIT 2, GS6 50 HBVIT... User manual
State Water Heaters
State Water Heaters SDV100-199 User manual
State Water Heaters
State Water Heaters 197425-004 User manual
State Water Heaters
State Water Heaters SUF 60 120NE User manual
State Water Heaters
State Water Heaters SSF 100 User manual
State Water Heaters
State Water Heaters Sandblaster SBD30 150 NE User manual
State Water Heaters
State Water Heaters Premier Residential Water Heaters User manual
State Water Heaters
State Water Heaters ULTRA FORCE 100 User manual
State Water Heaters
State Water Heaters PR6 40 CBDS User manual
State Water Heaters
State Water Heaters Gas User manual
State Water Heaters
State Water Heaters Collins User manual
State Water Heaters
State Water Heaters SBD71120 User manual
State Water Heaters
State Water Heaters SHE50 100 Application guide
State Water Heaters
State Water Heaters SCC 40-40 Troubleshooting guide
State Water Heaters
State Water Heaters Commercial Electric Water Heaters User manual
State Water Heaters
State Water Heaters 50 HXRT/YXRT User manual
State Water Heaters
State Water Heaters SandBlaster SBN 85-390NE Application guide
Popular Water Heater manuals by other brands
HTP
HTP SSU-10DB Installation, operation, maintenance, & troubleshooting
Ariston
Ariston NEXT OUTDOOR EVO user manual
Radiant
Radiant QUATTRO AQUA 4 Installation and maintenance manual
Lochinvar
Lochinvar 300 Installation and operating manual
Sigma
Sigma TRIUMPH Installation and technical manual
Ariston
Ariston BOOSTER user guide
Intellihot
Intellihot iE1 Operation & installation manual
Raypak
Raypak 992B-2342B Specifications
Noritz
Noritz EZ111DV owner's guide
Webasto
Webasto Thermo Top E installation instructions
Bradford White
Bradford White THROUGH-THE-WALL GAS WATER HEATER Install and operation instructions
PVI
PVI conquest 50 L 130 A-GCML Installation & maintenance manual
OSO HOTWATER
OSO HOTWATER Super SC 120 installation instructions
Rinnai
Rinnai V53De Installation and operation manual
GSW
GSW SUPERFLUE POWER VENTED GAS FIRED WATER... Installation and operating instructions
Rointe
Rointe Capri CWI700DHWU4 instruction & installation guide
clage
clage CEX-U Installing instructions for the professional
STIEBEL ELTRON
STIEBEL ELTRON Tempra 12 B installation instructions
