State Water Heaters SMGSS00108 User manual

RESIDENTIAL
225885_SMGSS00108.indd 1 6/14/10 12:46 PM
Complies with HUD Standards for Manufactured Housing
Installation. Design-Certified by CSA International -
Meets the Federal Energy Efficiency Standards effective January 20, 2004, according
to the National Appliance Energy Conservation Act (NAECA) of 1992.
FVIR Compliant
Gas Control Is Convertible for Natural and Propane Gas -
For flexibility to meet the varying needs of Manufactured Housing installations.
Side-Mounted 3/4” Cold Water Inlet - For ease of installation
when cold water supply originates below the structure. Top-mounted 3/4" hot water outlet.
Models Packaged with Bottom Intake Air Vent -
To draw all combustion make-up air from outside the structure.
Green Choice®Eco-Friendly Gas Burner - Patented design reduces NOx
emissions by up to 33% and complies with Air Quality Management Districts with similar
requirements for low NOx emissions.
Glass-Lined Tank - Protects the tank from corrosion.
Anode Rod - Maximizes tank life.
CSA Certified and ASME Rated T&P Relief Valve
Maximum Hydrostatic Working Pressure 150 PSI
1-Year Limited Tank Warranty
Standard Vent Gas Water Heaters
MANUFACTURED
HOUSING
SCOUT
For more information on Scout® contact:
State Water Heaters
500 Tennessee Waltz Parkway, Ashland City, TN 37015
800-365-0024 Toll-free
www.statewaterheaters.com
SMGSS00108 Revised August 2010
Low Lead Compliant
®
227970 SMGSS00108 1227970 SMGSS00108 1 8/23/10 10:10:45 AM8/23/10 10:10:45 AM

RESIDENTIAL
225885_SMGSS00108.indd 2 6/14/10 12:46 PM
GAS CONNECTOR
1/2” FEMALE
COLD
CONNECTION
3/4” FEMALE
CONNECTION
HOT
CONNECTION
3/4” FEMALE
CONNECTION
ANODE ROD
PLUG ON 30 & 40
GALLON
COLD INLET
ON 50 GALLON
T&P VALVE
Standard Vent Gas Water Heaters
For complete information on limited warranties, consult written warranty,
or contact the State Customer Care Center, 1-800-365-0024.
State Industries, Inc. reserves the right to make product changes or improvements without prior notice.
Recoveries are rounded to nearest gallon.
G
MODEL PEAK ENERGY GAL. BTU INPUT RECOVERY R DIMENSIONS IN INCHES APPROX.
NUMBER DEMAND FACTOR CAP. PER HOUR 90°F RISE VALUE SHIPPING
OUTPUT NATURAL/ GALLONS A B C D E F DRAFT WEIGHT
(1st Hour PROPANE HOOD (LBS.)
Rating OUTLET
Gallons)
SCI 30 YOMT 54 0.61 30 350000 31 16 59-1/2 56 18 15 16-3/4 51-1/4 3 125
SCI 40 YOMT 63 0.59 40 30,000 31 16 60 56-1/2 20 15 20-3/4 51-1/4 3 150
MANUFACTURED
HOUSING
Standard Vent Models
SCOUT
62
57
35,500/32,000
35,500/35,500
36
36
8
8
61-1/2
61-3/4
58
58-1/4
16
18
13-1/4
13-1/4
14-1/4
14-1/4
51-3/4
51-3/4
3-4
3-4
For more information on Scout contact:
State Water Heaters
500 Tennessee Waltz Parkway, Ashland City, TN 37015
800-365-0024 Toll-free
www.statewaterheaters.com
SMGSS00108 Revised August 2010
MODEL
NUMBER
SCI 30 YOMT
SCI 40 YOMT
SERIES
200
200
STANDARD-VENT MODELS
®
Low Lead Compliant
