Rev. 081103
INSTRUCTIONMANUAL
FOOD WARMER
GB
STAYHOT FOODWARMER
MODEL
V-570,V-640,V-945,V-1250
VL-750,VL-820,VL-1125,VL-1430

2.
How to mount / How to connect / Operate and maintenance
To mount
STAYHOTisdeliveredwithadjustableelbowbracket
formountingundershelforinchainsfrom ceiling.
Ifchain isused itshould takea weightof atleast 5times
thewarminglist.
STAYHOTwarminglistshallbemountedvertical;
- longsides- not closerthan 40 cmfrom flamable material.
- 30cm from deliveryshelf in stainlesssteel
- 45-50cm from bufféttable, but
- notcloser than 40cm from flammable material
To connect
STAYHOTwarming list is equippedwitha plug.
Connectthe plug to a separate wall socket230 V/10 ampere, earthed.
Theappliancemust no be wiredtoautomatic clutch ortimer.
Operate and maintenance
When cleaning: Make sure that the food warmer is disconnected .
Takethe plug outtoeliminate the riskforelectrical chock.
-Besure that the quartztubeis cold before youstart
cleaningthereflector.
Clean theSTAYHOTchassiswith a damp clothwitha
mildliquidcleaner.
Clean thereflectorregularly as greaseanddirt reduce theeffectof
theelement.Unscrewthescrewsthatholdsthewireguard and lift
offthewireguard.
Beawareof the fragile quartztube.
Remount the wire guard.
DONOTEVERIMMERSETHEFOODWARMER INTOWATER.
ANDDONOT CLEAN WITHHIGHPRESSURE CLEANER.
Repairs
Repairsmaybeeffectedbyauthorised specialist shopsonly.
Improperrepairsmayresultinconsiderable dangers for theuser.
Children should be supervised to ensure that
they do not play with the appliance.
STAYHOT

96066 B03 Electrical drawing stay hot V
96067 B02 Electrical drawing stay hot VL
3.
Circuit diagram STAYHOT
modell V-570, V-640, V-945, V-1250
Circuit diagram STAYHOT
modell VL-750, VL-820, VL-1125, VL-1430

SPARE PART LIST - STAYHOT FOOD WARMER
PART ART NO SIZE EFFECT
QuartsTube 600103LB 480 mm 575 W
QuartzTube 600100LB 550 mm 575 W
QuartzTube 600101LB 850 mm 750 W
QuartzTube 600102LB 1155 mm 1000 W
Lamp 25 W
LightningFitting
Pilot Lamp
On/OffSwitch
InfinitControlSwitch
WireGuard 445x128
WireGuard 515x128
WireGuard 820x128
WireGuard 1125x128
Manufactured in Sweden: COFFEE QUEEN AB, Arvika for
LOBELIUS AGENTURER AB, SOLLENTUNA, [phone], fax [phone]
