Operator’s Manual
Combination
Blanket/Fluid Warmer
P-2140
MN-47320
REV.01
1/21
EN

C omb in at ion W a rme r ▪ Op erato r ’s Ma nual ▪ M N-473 20 ▪ Rev 1 ▪ 1/21
2
Manufacturer’s Information
Copyright © Copyright 1/21 by Pedigo Products, Inc.
All rights reserved.
This manual or any portion thereof may not be reproduced or used in any
manner whatsoever without the express written permission of Pedigo Products,
Inc.
Trademarks All trademarks referenced in this documentation are the property of their
respective owners.
Manufacturer Pedigo Products, Inc.
4000 S.E. Columbia Way
Vancouver, WA 98661, USA
1-800-822-3501
www.pedigo-usa.com
Original instructions The content in this manual is written in American English.

FOREWORD
Co mbina tion W armer ▪ Op e rat or ’s Manua l ▪ MN -47320 ▪ Rev 1 ▪ 1 /2 1
3
FOREWORD
Thank you for your Purchase!
This warmer has been thoroughly tested and inspected to ensure only the
highest quality is provided. We supply the most durable, convenient, efficient
and safe warming equipment on the market. All warmers are manufactured and
fully inspected in the USA with a commitment to quality.
Pedigo Repair Service
Call Call 262-509-6517 to reach our service call center for immediate access to local
authorized service agencies. This service is provided exclusively for Pedigo
Product, Inc. equipment and is available throughout the United States.

FOREWORD
C omb in at ion W a rme r ▪ Op erato r ’s Ma nual ▪ M N-473 20 ▪ Rev 1 ▪ 1/21
4
This page intentionally left blank.

FOREWORD
Co mbina tion W armer ▪ Op e rat or ’s Manua l ▪ MN -47320 ▪ Rev 1 ▪ 1 /2 1
5
TABLE OF CONTENTS
Manufacturer’s Information . . . . . . . . . . . . . . . . . . . . . . . . 2
Foreword 3
Thank you for your Purchase! . . . . . . . . . . . . . . . . . . . . . . . 3
Pedigo Repair Service . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety 7
The Meaning of Signal Words . . . . . . . . . . . . . . . . . . . . . . . 7
Safety Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Labels 11
Label Locations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Specifications 13
Specification Information . . . . . . . . . . . . . . . . . . . . . . . . . 13
Dimension Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Installation 15
How to Unpack the Warmer . . . . . . . . . . . . . . . . . . . . . . . . 15
How to Install the Warmer . . . . . . . . . . . . . . . . . . . . . . . . . 16
Operation 17
Preparing the Warmer for First Use. . . . . . . . . . . . . . . . . . . . 17
How to Turn On and Turn Off the Warmer . . . . . . . . . . . . . . . . 18
How to Operate the Blanket Warmer . . . . . . . . . . . . . . . . . . 19
How to Use the Timer. . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
How to Operate the Fluid Warmer . . . . . . . . . . . . . . . . . . . . 22
How to Change the Temperature Scale. . . . . . . . . . . . . . . . . . 24
How to Change the Sound Settings . . . . . . . . . . . . . . . . . . . . 25
How to Lock and Unlock the Controller. . . . . . . . . . . . . . . . . . 26
Maintenance 27
Maintenance Schedule . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
How to Clean the Warmer . . . . . . . . . . . . . . . . . . . . . . . . . 29
Troubleshooting 31
What to do if the Warmer Malfunctions . . . . . . . . . . . . . . . . . 31
How to Manually Reset the Warmer . . . . . . . . . . . . . . . . . . . 32
Error Codes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Warranty 37
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

FOREWORD
C omb in at ion W a rme r ▪ Op erato r ’s Ma nual ▪ M N-473 20 ▪ Rev 1 ▪ 1/21
6
This page intentionally left blank.

SAFETY
Co mbina tion W armer ▪ Op e rat or ’s Manua l ▪ MN -47320 ▪ Rev 1 ▪ 1 /2 1
7
SAFETY
The Meaning of Signal Words
This manual contains signal words where needed. These signal words must be
obeyed to reduce the risk of death, personal injury, or equipment damage. The
meaning of these signal words is explained below.
DANGER
Danger indicates a hazardous situation which, if not avoided,
will result in serious injury or death.
WARNING
Warning indicates a hazardous situation which, if not avoided,
could result in serious injury or death.
CAUTION
Caution indicates a hazardous situation which, if not avoided,
could result in minor or moderate injury.
NOTICE
Notice indicates a situation which, if not avoided, could result
in property damage.
NOTE: Note indicates additional information that is important to a
concept or procedure.

SAFETY
C omb in at ion W a rme r ▪ Op erato r ’s Ma nual ▪ M N-473 20 ▪ Rev 1 ▪ 1/21
8
Safety Precautions
Before you begin Read and understand all instructions in this manual.
Electrical precautions Obey these electrical precautions when using the warmer:
▪Connect the warmer to a properly grounded outlet. Do not use the warmer if it is
not properly grounded. Consult an electrician if there is any doubt that the outlet
used is properly grounded.
▪Keep the cord away from hot surfaces.
▪Do not attempt to service the warmer or its cord and plug, when plugged in.
▪Do not operate the warmer if it has a damaged cord or plug.
▪Do not immerse the cord or plug in water.
▪Do not let the cord hang over the edge of a table or counter.
▪Do not use an extension cord.
Usage precautions Obey these usage precautions when using the warmer:
▪Only use this warmer for its intended use of warming medical solution bags,
bottles, and/or blankets. Follow facility and solution manufacturer guidance
regarding warming temperature for any item to be placed in the warmer.
▪Do not use this warmer for warming blood or blood products.
▪Do not cover or block any of the openings of this warmer.
▪Do not use this warmer in a wet location.
▪Only clean the warmer when the power cord is unplugged.
▪Do not use corrosive chemicals when cleaning the warmer.
▪Do not use the warmer cavity for storage.
▪Do not remove exterior panels from the warmer or attempt repairs. The warmer
has no user-serviceable internal components. Only perform routine cleaning and
maintenance procedures specifically described in this manual. Inspection and
servicing of internal components must only be performed by qualified service
personnel.
▪Only a qualified Pedigo service representative may make modifications to the
warmer. Modifications to the warmer could be hazardous to users and patients.
Operator training All personnel using the warmer must have proper operator training. Before
using the warmer:
▪Read and understand the operating instructions contained in all the
documentation delivered with the warmer.
▪Know the location and proper use of all controls.
▪Keep this manual and all supplied instructions, diagrams, schematics, parts lists,
notices, and labels with the warmer if the warmer is sold or moved to another
location.

SAFETY
Co mbina tion W armer ▪ Op e rat or ’s Manua l ▪ MN -47320 ▪ Rev 1 ▪ 1 /2 1
9
Operator
qualifications
Only trained personnel with the following operator qualifications are permitted
to use the warmer:
▪Have received proper instruction on how to use the warmer.
▪Are familiar with the purpose, limitations, and associated hazards of the warmer.
The warmer must not be used by:
▪People impaired by drugs or alcohol.
Condition of warmer Only use the warmer when:
▪All controls operate correctly.
▪The warmer is installed correctly.
▪The warmer is clean.
▪The warmer labels are legible.
Servicing the warmer ▪Obey precautions in the manual, on tags, and on labels attached to or shipped
with the warmer.
▪Only trained personnel are permitted to service or repair the warmer. Repairs
that are not performed by a trained technician, or the use of non-factory parts,
will void the warranty and relieve all liability.
▪Any troubleshooting guides and components views included with this manual
are for reference only and are intended for use by qualified and trained service
technicians.
▪To prevent serious injury, death or property damage, have the warmer inspected
and serviced at least every twelve (12) months by a trained technician.
▪Contact Pedigo for the authorized service partner in your area.
Incident notice ▪Any serious incident that has occurred in relation to the warmer should be
reported to the manufacturer and the competent authority of the Member State
in which the user and/or patient is established.

SAFETY
C omb in at ion W a rme r ▪ Op erato r ’s Ma nual ▪ M N-473 20 ▪ Rev 1 ▪ 1/21
10
This page intentionally left blank.

LABELS
Co mbina tion W armer ▪ Op e rat or ’s Manua l ▪ MN -47320 ▪ Rev 1 ▪ 1 /2 1
11
LABELS
Label Locations
EC-PHD-011846
a
c
db

LABELS
C omb in at ion W a rme r ▪ Op erato r ’s Ma nual ▪ M N-473 20 ▪ Rev 1 ▪ 1/21
12
1
Security seal
2
Electrical warning label
3
Pedigo contact information
4
Quality inspected
5
Do not load baskets beyond recommended
capacity. Overloading may cause uneven
temperature of product and damage to basket and
basket rail support.
Security Seal Security Seal Security Seal Security Seal Security Seal Security Seal Security Seal Security Seal

SPECIFICATIONS
Co mbina tion W armer ▪ Op e rat or ’s Manua l ▪ MN -47320 ▪ Rev 1 ▪ 1 /2 1
13
SPECIFICATIONS
Specification Information
Transportation and
storage conditions
▪Ambient temperature range of -40°F to +159°F (-40°C to +70°C).
▪Relative humidity range of 10% to 95%, non-condensing.
▪Atmospheric pressure range of 7.25 psi to 15.37 psi (50kPa to 106kPa).
Operating conditions ▪The warmer must acclimate to the room temperature it will be placed in—24
hours is recommended.
▪The recommended environmental temperature range is 60°F to 90°F
(15°C to 32°C).
▪The recommended relative humidity is above 20%, non-condensing.
Standards for
electrical equipment
▪Medical equipment listed by Underwriters Laboratories with respect to
electrical shock, fire, and mechanical hazards only, in accordance with UL
60601-1 and CAN/CSA C22.2 No. 601.1.
▪Grounding reliability can only be achieved when the appliance is
connected to an equivalent receptacle marked “Hospital Grade.”
▪IP-XO ordinary
Model P-2140
Intended use Top cavity—warming blankets
Bottom cavity—warming irrigation or injection fluids
Weight Net: 374 lb (170 kg)
Ship: 494 lb (224 kg)
Storage cavity
capacity
Blanket cavity: 20–25 blankets (15.4 ft3)
Fluid cavity: 72 1-liter bags or 54 1-liter bottles
Temperature range
Blanket: 98°F to 180°F (37°C to 82°C)
Irrigation fluid (IRR): 98°F to 150°F (37°C to 66°C)
Injection fluid (INJ): 98°F to 104°F (37°C to 40°C)
Clearance
requirements
3” (76mm) from rear
1” (25mm) from top
1” (25mm) from sides
E471516
Protective Earth
Ground Symbol

SPECIFICATIONS
C omb in at ion W a rme r ▪ Op erato r ’s Ma nual ▪ M N-473 20 ▪ Rev 1 ▪ 1/21
14
Dimension Drawings
P-2140
EC-DIM-011765
TIME R
(285mm)
11 .2"
54.6" (1387mm)
CORD LENGTH
8.0' (2,438mm) (est.)
33.1" (841mm)
7.5"
(189mm)
17.1"
(434mm)
22.1" (561mm)
22.3" (566mm) 28.9" (735mm)
35.1" (891mm)
70.2" (1784mm)
26.9" (683mm)
CAVITY
26.9" (683mm)
CAVITY
25.1" (639mm)
30.1" (765mm)
26.6" (676mm)
CAVITY
18.7" (476mm)
25.2" (639mm)
CAVITY
5.5"
(141mm)
72.7" (1846mm)
67.1" (1705mm)
SHELF
9.8" (248mm)
23.7" (603mm)
INSERT
16.9" (430mm)
INSERT

INSTALLATION
Co mbina tion W armer ▪ Op e rat or ’s Manua l ▪ MN -47320 ▪ Rev 1 ▪ 1 /2 1
15
INSTALLATION
How to Unpack the Warmer
Before you begin Make sure you have:
▪Reviewed the warmer specifications.
▪An appropriate lifting device and enough personnel to safely move and position
the weight of the warmer.
▪Cutting tools to remove the packaging.
Unpack the warmer To unpack the warmer, do the following.
Step Action
1. Remove the box or crate. Save all packing materials for inspection by the
carrier.
2. Cut and remove the retaining straps and plastic wrap.
3. Remove the warmer from the pallet using an appropriate lifting device.
4. Remove the paperwork from the cavity.
Result The warmer is now unpacked.
WARNING: Crushing hazard.
An unstable warmer can lead to a crushing hazard. Observe your
facility’s best practices for moving large equipment.
NOTE: Examine the warmer for damage. If the warmer has
been damaged, do not use the warmer until it has been
inspected by an authorized service provider. Contact your
carrier or customer service.

INSTALLATION
C omb in at ion W a rme r ▪ Op erato r ’s Ma nual ▪ M N-473 20 ▪ Rev 1 ▪ 1/21
16
How to Install the Warmer
Before you begin Make sure you have:
An appropriate lifting device and enough personnel to safely move and position
the weight of the warmer.
Requirements ▪The warmer must be installed on a level surface.
▪The warmer must not be installed in any area where it may be affected by steam,
dripping water, high temperature, or any other severely adverse conditions.
Voltages
Position the warmer To position the warmer, do the following.
Step Action
1. Make sure that:
▪The location where the warmer is being installed is rated to support the
weight of the warmer;
▪The warmer is within five feet of the appropriate electrical outlet;
▪You follow the warmer clearance guidelines. Refer to topic Specification
Information for clearance requirements.
2. Move the warmer to the installation location and onto the final resting
surface.
3. Lock the casters, if equipped.
The warmer is now correctly positioned.
Connect power To connect electric power to the warmer, do the following.
4. Connect the plug to the electrical outlet.
Result The warmer is now installed and ready to be used.
Model V Ph Hz kW
P-2140 120
230
1
1
50/60
50/60
1.92
1.7

OPERATION
Co mbina tion W armer ▪ Op e rat or ’s Manua l ▪ MN -47320 ▪ Rev 1 ▪ 1 /2 1
17
OPERATION
Preparing the Warmer for First Use
Before you begin
Procedure To prepare the warmer for first use, do the following.
Step Action
1. Make sure that the warmer is turned off and cool.
2. Wipe the outside of the warmer:
▪with a stainless steel cleaner, if stainless steel panels.
▪with an approved cleaning agent, if painted panels.
3. Clean the interior of the warmer with a damp cloth or approved cleaning
agent.
4. Dry the interior and exterior of the warmer with a clean, lint-free cloth.
Leave the door open until the interior of the warmer completely dries.
5. Clean each side of the window pane with glass cleaner or distilled vinegar.
Result The warmer is now ready for use.
CAUTION: Burn hazard.
Allow the warmer to cool before cleaning.
NOTICE
Do not use:
▪abrasive cleaning compounds.
▪chloride based cleaners.
▪commercial or household cleaners containing ammonia.

OPERATION
C omb in at ion W a rme r ▪ Op erato r ’s Ma nual ▪ M N-473 20 ▪ Rev 1 ▪ 1/21
18
How to Turn On and Turn Off the Warmer
Before you begin The warmer must be connected to electric power.
Turning on the
warmer
To turn on the warmer, do the following.
Step Action
1. Set the power switch a to the ON (l) position.
2. Press the ON/OFF button . The screen turns on.
The warmer is now on.
Turning off the
warmer
To turn off the warmer, do the following.
3. Press and hold the ON/OFF button until the screen turns off, then
release the button.
The warmer is now off.
NOTE: A temporary odor may be noticeable upon initial
start-up of the warmer. Contact the manufacturer if the
odor persists after a day or more of continuous use.
EC-TS-011849
a
NOTE: If equipped, the fan will continue to operate after
the warmer is turned off using the ON/OFF button.

OPERATION
Co mbina tion W armer ▪ Op e rat or ’s Manua l ▪ MN -47320 ▪ Rev 1 ▪ 1 /2 1
19
How to Operate the Blanket Warmer
Before you begin The warmer must be connected to electric power and turned on.
Procedure To operate the warmer, do the following.
Step Action
1. Set the temperature using the arrow buttons .
2. Open the door and load the dry, cotton blankets into the warmer.
Close the door.
During the warming
process
3. Press and hold the timer button and the up arrow at the same
time.
The actual temperature will display for five seconds. Then, the set-point
temperature will display.
4. Rotate the blankets daily from the bottom to the top of the load to ensure
equal heating and to prevent discoloration.
Result The blankets are now warming.
WARNING: Personal injury hazard.
Do not operate the warmer in the presence of a flammable
anesthetic mixture with air, oxygen, or nitrous oxide; in
oxygen-enriched environments; or in any other potentially
explosive environment.
WARNING: Personal injury hazard.
Make sure the blanket support assembly and shelves are
installed to prevent the blankets from being scorched or
discolored.
NOTICE
Do not overload the cavity.
Allow 1” (25mm) between the blankets and the interior walls.
NOTE: The temperature set-point range is 98°F – 180°F
(37°C – 82°C).
NOTICE
Do not warm items containing plastic, rubber, metal
snaps, studs, hooks, etc.

OPERATION
C omb in at ion W a rme r ▪ Op erato r ’s Ma nual ▪ M N-473 20 ▪ Rev 1 ▪ 1/21
20
How to Use the Timer
Before you begin The warmer must be turned on (screen is on).
Background The timer feature allows the user to program the controller to automatically turn
on and off during a 24 hour period. This allows the warmer to turn off at night to
save energy, then turn on automatically in the morning.
Setting the timer To use the timer function, do the following.
Step Action
1. Press and hold the TIMER button .The TIME icon a illuminates.
2. Press the up and down arrow buttons to change the time of day.
3. Press the TIMER button again. The START icon b illuminates.
Press the up and down arrow buttons to change the start time.
4. Press the TIMER button again. The STOP icon c illuminates.
Press the up and down arrow buttons to change the stop time.
5. Press the TIMER button again to enable the timer.
The time status LED indicator illuminates.
Continued on next page
NOTE: The screen displays the time of day in a 24-hour
format (hh:mm).
NOTE: Make sure the start and stop times are different.
The timer will not operate if both times are the same.
180°F
EC-TS-005077
abc
