Piper’s Design Basics Hot Food Tables are designed to
hold and maintain the temperature of hot food for use
in meal assembly on tray lines. The Design Basics line is
constructed of stainless steel tops, bodies, legs and base.
Only Piper's equipment has the advantage of
technology and certification. This ensures that your food
is kept "out of the DANGER-ZONE." Food spoilage occurs
mainly because of rapidly accelerated bacteriological
activity within the 40F-140F "DANGER-ZONE."
With hot food stays above 140°F longer and cold
food is kept below 40°F. Both are key factors in HACCP
compliance and the fight against foodborne pathogens.
STANDARD FEATURES
Die stamped 20-gauge stainless steel top
14-gauge stainless steel legs fastened to 20-gauge
stainless steel base with 14-gauge aluminized caster
channels
20-gauge stainless steel wrapper

20-gauge stainless steel bottom-mounted wells, 6-1/2”
deep with coved corners and drains
1” insulation on bottom of wells and 1/4” fiber frax all

around
750 watt tubular heating element for each well is

individually and infinately controlled
Wells can be run wet or dry
Heating elements are bottom accessible
18-gauge stainless steel cutting board with 1/2” poly board
Adjustable stainless steel bullet legs
DIMENSIONS
DB-2-HF - 34” x 31” x 30”
DB-3-HF - 34” x 31” x 44”
DB-4-HF - 34” x 31” x 58”
DB-5-HF - 34” x 31” x 72”
34” height on all standard units
31” width (includes cutting board)
ELECTRICAL
All units are available in 120, 208 & 240 volts
All units available in 208 or 240 volt, single- phase or
three-phase
Six foot electrical cord and plug
COMMON OPTIONS
Tray slides
Protector guards
Manifolded drains
See reverse side for additional options
WARRANTY
One year parts and labor. Warranty is detailed on inside
front cover of the price list.
DB-2-HF

DB-3-HF
DB-4-HF
DB-5-HF
Design Basics Hot Food Units
DB-4-HF
83

LIMITED WARRANTY: PIPER PRODUCTS warrants to the original purchaser parts and labor for a period of
twelve (12) months from the date of purchase. See manufacturer’s complete warranty for details.
It is our policy to build equipment which is design certified by companies that have been accredited at the Federal Level
by the Occupational Safety and Health Agency (OSHA) and ANSI as a National Recognized Testing Laboratory. These
companies include CSA International, Underwriters Laboratories, and the National Sanitation Foundation. However, a
continuing program of product improvement makes it necessary to submit new models to the agencies as they are
developed. Consequently, all models may not bear the appropriate labels at all times.
We reserve the right to change specifications and product design without notice. Such revisions do not entitle buyer to
corresponding changes, improvements, additions or replacements for previously purchased equipment. Information is not
for design purposes.
DISPENSERS DISPENSERS
ELITE 500 ELITE 500
STEAM TABLES STEAM TABLES
SUPPORT EQUIPMENT SUPPORT EQUIPMENT
DROP-INS DROP-INS
C-1 SPEC
300 S. 84th Avenue
Wausau, WI 54401
Phone: [phone]
Fax: [phone]
www.piperonline.net
Design Basics Hot Food Units
Model# # of
Wells A Wattage
Amperage NEMA Cap Number Ship
Wt.
(lbs)
120V 208V 240V 120V 208V 240V
DB-2-HF 2 30” 1500 12.5 7.2 6.25 5-20P 6-15P 6-15P 204
DB-3-HF 3 44” 2250 18.75 10.8 9.375 5-30P 6-15P 6-15P 229
DB-4-HF 4 58” 3000 25 14.42 12.5 5-50P 6-20P 6-20P 254
DB-5-HF 5 72” 3750 31.25 18.02 15.63 5-50P 6-30P 6-20P 279
OPTIONS / ACCESSORIES
Part # Description
DBMCB 8” maple cutting board in lieu of poly cutting board
DBSRTS Solid 3-ribbed tray slide, 18-gauge stainless steel
DBDRN Common drains and manifold
SDB Dish shelf
DBOHS Overhead shelf
DBCPG Cafeteria protector guard
DBBPG1 Buffet single side protector guard
DBBPG Buffet double side protector guard
DBCS Casters in lieu of legs
Spacing between wells is 2” Floor clearance of unit is 6”
A
10"
16.5" 34"
84
