Stealthbox SB-J-GCHER2/10W3v2 User manual

➔
➔
Stealthbox®
INSTALLATION GUIDE
SB-J-GCHER2/10W3v2, JL AUDIO, Inc 2004 Sheet SKU#011147 6/3/2004Page 1
for the
‘99-’04 Jeep Grand
Cherokee
SB-J-GCHER2/10W3v2
(Does not fit earlier years or Jeep
Cherokee)
This Stealthbox is a product which
requires professional installation skills and
tools.
Please read this installation guide thor-
oughly before beginning the project. It
will guide you step by step through the
installation. Several of the steps in this
process may require two people to
accomplish.
It is absolutely vital that the enclosure
be properly mounted to the vehicle
according to these instructions. Failure
to mount the enclosure properly pres-
ents two problems: 1) The sub-bass
performance will suffer due to the
movement of the enclosure caused by
the force exerted by the woofer(s) and
2) A loose enclosure presents a serious
safety hazard in the event of a collision
or sudden deceleration.
Please enjoy your JL Audio Stealthbox
responsibly.
STEP 1: Place the supplied 3"x3” wax square,
sticky side down, on the rear driver-side car-
pet as shown in the photo at right.
Insert both supplied socket cup set screws
into the threaded inserts on the underside of
the Stealthbox.
Allow about 1./2” of the socket cup set screw
to protrude to the outside.
STEP 2: Place the Stealthbox into its mount-
ing location, making sure that it fits snugly
against all panels.
Once aligned properly, push down firmly on
the Stealthbox, in order to make a clear
impression on the wax square with the socket
cap screws on its underside.
Remove the enclosure from the vehicle care-
fully by lifting it up and out so as not to disturb
the sheet wax.
STEP 3: *Check under the rear of the
vehicle to make sure there are no
loose wires, brake lines or fuel lines
prior to drilling through the sheet
metal.
Always wear eye protection when
drilling.
*
Using a 1/2" carbide drill bit, drill a hole centered on
the impression on the sheet wax.
Remove the wax square and trim the excess carpet
from the hole you've just drilled.
START
HERE
Continued on Next Page ➔
www.jlaudio.com
➔
STEP4: *At this time double check the
woofer for proper operation.*
Run speaker wire behind the trim panel as shown in
photo and connect to the speaker wire terminal.

Specifications:
Enclosure Type: Acoustic Suspension (Sealed)
Driver Type: 10W3v2-D2
Nominal Impedance: 4Ω
Cont. Power Handling: 300Watts
JL Audio recommends using a high quality amplifier such as the JL Audio 250/1. The diagram below shows the recommended
crossover, infrasonic filter and equalizer settings for the 250/1 when being used to power your Stealthbox®.
Included Hardware:
(1) 3"x3” Sheet Wax Squares
(1) 2-1/4" Socket Cup Set Screw
(1) Flat Washer
(1) Split Lock Washer
10369 N. Commerce Pkwy, Miramar, Florida 33025-392 Phone: [phone] Fax: [phone]
JL AUDIO 250/1
monoblock subwoofer amplifier
Amplifier Input Section
Input Sens.
Input Voltage
Low/High
Left Ch. Right Ch.
Signal Sensing
Off/On
Output Mode
Full-Range/Low-Pass/High-Pass
Left Ch. Right Ch.
Amp LP Filter
Mode/Slope
Off/12dB/24dB
Filter Freq. (Hz)
Bass Control
LF Boost (dB)
Off/30Hz
Infrasonic Filter
+1 +13
+3
+7
+10
Preamp Output Section
+12VDC Ground Remote
The JL Audio 250/1 is a very versatile audio component. Please consult the owner’s manual for detailed information
about installing and tuning this amplifier.
➔➔
STEP5: Back out the socket cap screw to
allow 1-1/2” to protrude out of the
Stealthbox.
Place the enclosure into its mounting location taking
care to route the speaker wire so that it will not get
stuck between the enclosure and the vehicle trim
panel (bad fit) or come into contact with the
woofer (bad sound).
STEP6: Before tightening the nut, apply a bead
of silicone sealant between the flat washer and the
vehicle's sheet metal to prevent leaks.
*IMPORTANT* Once the bolt is tightened, spray
undercoating onto the bolt head to prevent rust,
leaks and loosening of the bolt over time. Failure to
do so may result in corrosion and could present a
safety hazard.
➔
SB-J-GCHER2/10W3v2, JL AUDIO, Inc 2004 Sheet SKU#011147 6/3/2004Page 2
www.jlaudio.com
Mid/High Frequency Driver Information:
CONGRATULATIONS!
INSTALL COMPLETE.
TR690-TXi
TR650-CXi
Front Location Driver Size:
6” x 9”
Applicable JL Audio Products:
TR690-TXi
Rear Location Driver Size:
6.5”
Applicable JL Audio Products:
TR & VR 650-CXi
Cont.
From
Previous
Page
Difficulty Of Installation:
