Steamtec KSA-Elegance User manual

_______________________________________________________________________________________________________
TOLO SAUNA [e-mail] www.tolosauna.com
1
Steamtec Sauna heater
Touch Screen Control System Manual
Please read the manual carefully before installation & use
and keep the manual for further reference
Table of Contents
1. Introduction...................................................................................................................................... 1
2. Controller Parameters And Dimension............................................................................................. 2
3. Installations....................................................................................................................................... 2
3.1 Installations of controller.........................................................................................................2
3.2 Installations of temp sensor.....................................................................................................3
3.3 Installations of lamp.................................................................................................................4
3.4 Installations of power wire...................................................................................................... 4
4. Functions And Operations.................................................................................................................9
5. Troubleshooting.............................................................................................................................. 10

________________________________________________________________________________
TOLO SAUNA [e-mail] www.tolosauna.com
2
1. Introduction
Thank you for choosing TOLO SAUNA touch screen control system for sauna heater. The touch
screen control system is consist of touch screen controller, central control box and the sauna room
temperature sensor.
2. Controller Parameters And Dimension
Controller
model
Controlling time range
(mins)
Temperature
display range
Temperature
controlling
range
Dimension
(mm)
KSA-Elegance
1～60 or long-term
(CH)
1～100℃
60～100℃
90x90x19
Table 1
3. Installations
3.1. Installations of controller
Attention:The controller and central control box MUST be installed OUTSIDE the sauna room.
The controller should be installed with height
around 1.2 m OUTSIDE the sauna room but
nearby or other place where easy to operate.
Firstly drill a hole with diameter of 16mm on
the installation site.
Pull the control wire through the conduit, then
connect the control wire to the (4-Pin) plug on
circuit board of central control box, refer to
figure 1.
Finally the controller panel can be hanging by
the screws on the wall.
Figure 1 Circuit board

________________________________________________________________________________
TOLO SAUNA [e-mail] www.tolosauna.com
3
WALL
DOUBLE SIDED
ADHESIVE
CONTROLLER
CONTROL WIRE
CONNECTOR 4P
CONDUIT
CONTROL WIRE TEMP SENSOR
WIRE
SEALING GLUE
Figure 2 KSA-elegance controller installation
3.2. Installations of temp sensor
Attention: Temperature sensor should be
installed in sauna room but not directly above
sauna heater, the height must be a minimum
of 1800mm from floor. The horizontal distance
to sauna heater must exceed 500mm, refer to
figure 3.
Please drill a hole (diameter 16mm ), and then
nail down the sensor in the sauna room,
connect the temp sensor wire into the 2 pin
plug on circuit board of central control box, see
figure 1.
Figure 3

________________________________________________________________________________
TOLO SAUNA [e-mail] www.tolosauna.com
4
3.3. Installations of lamp
Open the cover of central control box, and connect lamp wire to the plug on circuit board of
central control box. (See above figure 1)
Only support DC 12V lamp.
3.4. Installations of power wire
Caution
All circuits should be installed by licensed electricians and conform to local and national
codes. Improper electrical connection can cause fire or electric shock.
Power supply must be cut off before installation, maintenance and repair. Touch the on/ off
button on the controller can NOT cut power from the supply.
An Residual Current Device (RCD) must be installed in the power supply circuit for safety
purpose.
Choose the cable wire according to sauna heater manual table 1 and the cable wire need to
be able to bear extremely high temperature 170℃(It is recommended to use rubber cable
wire).
For All TOLO external control sauna heater, power will be supplied into control system first,
and the control system will then give power supply to sauna heater.
(1). First Take off the cover of the central control box, insert the 3-core power wire (single
phase, 215-240V, 50/60Hz ) or 5-core power wire (three phases 380-415V, 50/60Hz) and
connect to the “POWER INPUT” terminal in central control box, see below figure 4-6, so
that power will be supplied to control system.
Single phase, 215-240V ，50/60Hz power supply: connect the live wire to the terminal
labeled as “L” ; connect the null wire to the terminal labeled as “N” ; and connect the
earth wire to the terminal labeled as “ ”.
Three phases, 380-415V ，50/60Hz power supply : connect 3 live wires to the terminal
labeled as “L1”, “L2” and “L3” respectively; connect the null wire to the terminal labeled as
“N”; and connect the earth wire to the terminal labeled as “ ”.
(2). Second, please connect “CONNECT TO SAUNA HEATER ” terminal labeled “ L1, L2, L3, N,
” in central control box (see figure 4-6) to terminal labeled “ L1, L2, L3, N, ” on
sauna heater respectively, so that control system can give the power to sauna heater.

________________________________________________________________________________
TOLO SAUNA [e-mail] www.tolosauna.com
5
N
L1 L2 L3
No connecting
N
U
Inp ut
V W
W
V
UN
Over-heat
protection
KSA-Elegance
CONTROLLER
Room Temp
Sensor
LAMP DC12V LED
Input
Output1
NL1 L2 L3
Sauna heater
SAUNA HEATER
380-415V
3N～ 50/60Hz
4.5～7.5kW
Figure 4
POWER INPUT
CONNECT TO SAUNA HEATER
3KW -9 KW
European 215-240V 1 phase /
380-415V 3 Phase

________________________________________________________________________________
TOLO SAUNA [e-mail] www.tolosauna.com
6
NL1 L2 L3
No connecting
N
U
In p ut
V W
N
Over-heat
protection
KSA-Elegance
CONTROLLER
Room Temp
Sensor
LAMP DC12V LED
Output2 Input Output1
N
Sauna heater
L3L2L1 NNL1 L2 L3
SAUNA HEATER
9～15kW
380-415V
3N～ 50/60Hz
U2 V2 W2 U1 V1 W1
Figure 5
POWER INPUT
CONNECT TO SAUNA HEATER
10.5 KW -15 KW
European
380-415V 3 Phase

________________________________________________________________________________
TOLO SAUNA [e-mail] www.tolosauna.com
7
N
Output1 Input Output2
LAMP DC12V LED
Room Temp
Sensor
KSA-Elegance
CONTROLLER
Over-heat
protection
N
WV
Input
UN
No connecting
L3L2L1 N
Output3
N
L3L2L1 N NL1 L2 L3
Sauna heater
NL1 L2 L3
380-415V
3N～ 50/60Hz
SAUNA HEATER
18～22.5kW
U3 V3 W3 U2 V2 W2 U1 V1 W1
Figure 6
POWER INPUT
CONNECT TO SAUNA HEATER
18KW -27 KW
European
380-415V 3 Phase

________________________________________________________________________________
TOLO SAUNA [e-mail] www.tolosauna.com
8
4. Functions And Operations
Figure 7 KSA Elegance Controller
i. ON/OFF
Touch to switch on and off of the whole system.
The system has memory function, it will remember the last time temperature and time setting,
however if the system has been powered off / outages, it will lose all its memory and will
adapt the default temperature (60℃) and default time(45 minutes); Automatically off when
time runs out or off by touch the ON/OFF button not belong to power off.
However, if the system is shut off automatically when setting time is up, system will remember
the previous temperature and time setting.
ii. Temperature set
Touch to adjust the temperature.
The available temperature setting range is 60～100℃, and the default temperature is 60℃.
The LCD and the white LED on the left will blink and display the last time setting temperature
or default temperature. Then touch the “▲” or “▼” button to adjust.
The system has memory function, it will remember the last time temperature setting,
however if the system has been powered off, it will lose all its memory and with the default
setting, then please reset it again if needed.

________________________________________________________________________________
TOLO SAUNA [e-mail] www.tolosauna.com
9
iii. Working time set
Touch to adjust the working time.
The time setting range is from 1-60 minutes or CH, the default working time is 45 minutes.
Touch “▲” or “▼” button to adjust the working time to the value you want, or touch“▲”
button until the LCD displays “CH”, after that the system automatically enters long-term
working mode. When the system is in long-term mode, the white LED on the right side of the
LCD blinks.
iv. Light
This button is the switch for the external light.
The button can be used as the switch for the external light as long as the system is connected
to power supply. The LED is on when the light is turned on.
But support 12V light.
v. ▲Button
Increase the temperature or time.
vi. ▼Button
Decrease the temperature or time.
5. Troubleshooting
Temperature display screen indicate “-L”, which means temperature sensor not connect well
(or circuit break), or the temperature is below 6 ℃(43℉).
When there is “-H” indicating on screen, it means short circuit of temperature sensor, or the
temperature is higher than 110℃(230℉).
Sauna heater will not work in both above conditions, please check temperature sensor
connection or temperature of sauna room, and seek for dealer’s help if needed.
