Steel Core 42815 User manual

*Actual product may vary slightly
Please carefully read and save these instructions before appempting to assemble, maintain, install, or operate this product.
Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property
damage and/or personal injury. Please keep instructions for future reference.
For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping.
For Customer Service, Call 1-800-348-5004
or e-mail [email protected] 42815 05/2016
26" 4-DRAWER SERVICE CART
42815

[email protected] 21-800-348-5004
SPECIFICATIONS
Maximum Weight Capacity 580 Lbs. overall;
Top Tray: 200 Lbs.
2 Small Drawers: 30 Lbs. each
Medium Drawer: 50 Lbs.
Bottom Drawer: 70 Lbs.
Bottom Tray: 200 Lbs.
Overall Dimensions 33-1/2” Long x 17-1/2” Deep x 38-1/4” High
Handle 16-1/8” L x 1-1/4” Diameter
Inside Lid Compartment
Dimensions 27” L x 15-1/2” Deep x 2” Deep
Small Drawer Dimension 12-1/4” W x 14-1/2” Deep x 2” Deep
Middle Drawer Dimension 26-3/4” x 14-1/2” Deep x 2-3/4” Deep
Bottom Drawer Dimension 26” W x 14-1/2” Deep x 4” Deep
Net Weight 95 Lbs.
Bottom Shelf Dimension 30-1/4” Wide x 16” Deep x 3” Deep
Caster Dimension 5-1/4” diameter x 1-1/8” Wide (2) Locking, (2) Swivel
Provides over 5,500 cubic inches of storage space. Heavy duty all steel construction
with powder coated handle and ball bearing slides for smooth drawer movement.
Save This Manual
You will need this manual for the safety warnings and precautions, assembly, oper-
.margaidylbmessadnatsilstrap,serudecorpgninaelcdnaecnanetniam,noitcepsni,gnita
Keep your invoice with this manual. Keep this manual and invoice in a safe and dry place
for future reference.
GENERAL SAFETY RULES
WARNING!
READ AND UNDERSTAND ALL INSTRUCTIONS
Failure to follow all instructions listed below may result in
serious injury.
SAVE THESE INSTRUCTIONS
Keep your work area clean and well lit.1. Cluttered benches and dark areas invite
accidents.
Keep bystanders, children, and visitors away.2. Distractions can cause you to
lose control. Keep children out of the work area; do not allow them to climb or sit
on the Roll Cart.
Stay alert. Watch what you are doing and use common sense during assembly3.
and use of this product.

[email protected] 31-800-348-5004
During assembly dress properly. Do not wear loose clothing or jewelry. Con-4.
tain long hair.
Do not overreach. Keep proper footing and balance at all times.5.
Use safety equipment during assembly. Always wear eye protection.6. Always
wear ANSI-approved safety goggles when assembling the Roll Cart.
Do not force the product. Use the correct product for your application.7. The
correct product will do the job better and safer at the rate for which it is designed. Do
not force the product and do not use it for a purpose for which it is not intended.
Store an idle Roll Cart out of reach of children and other untrained persons.8.
Use only accessories that are recommended by the manufacturer for your9.
model. Accessories that may be suitable for one product may become hazardous
when used on another product.
Maintain labels and nameplates on the Roll Cart.10.
Maintain a safe working environment.11. Make sure there is adequate surrounding
workspace. Do not use this product in a damp or wet location.
Make certain Caster Wheels are locked in position when the Roll Cart is sta-12.
tionary.
Do not exceed the maximum weight capacity of 580 Lbs.13. .traClloReritneehtrof
Do not exceed the maximum weight capacity for each individual Drawer and Tray.
Use on a flat, level surface capable of supporting the Roll Cart and the prod-14.
ucts within it.
Keep the lid and all drawers on this Roll Cart closed and locked when not in15.
use. This prevents children from opening any of the drawers and prevents misuse of
any tools stored within. Keep keys in a safe location out of the reach of children.
Load tools evenly.16. As much as possible, distribute the weight of all tools stored
in this Roll Cart evenly.
Do not use this Roll Cart as a stepping stool or ladder.17. Never sit, stand, or
climb on this Roll Cart.
Avoid tipping; do not overload or over-stack this Roll Cart.18. Overloading can
.yrujnilanosrepdnagnippitnitluserylbissopdluocdnasretsacdnasrewardegamad
Over-stacking can result in tools or other objects sliding or falling from the Roll Cart
and could result in damaged tools and/or personal injury.
Be aware of dynamic loading! Dropping or bouncing a load may briefly create19.
excess load causing product damage, severe personal injury, and/or death.

[email protected] 41-800-348-5004
Note: Please note the number on the key and store it in a safe place. This
number may also be on the lock. It will be needed if extra keys are ordered.
ASSEMBLY INSTRUCTIONS
Note: For additional information regarding the parts listed in the following pages, refer to
the Assembly Diagram on page 6.
Attach two Locking Casters (10) and two Swivel Casters (12) to the Bottom Tray1.
(11). Use four Bolts (13), four Spring Washers (3), and four Nuts (4) per caster as
shown in Figure 1 below.
Connect both Right Leg Posts (1) to each other with one Support Frame (9)2.
attached at the center with two Ball Type Bolts (2), two Nuts (4) and two Spring
Washers (3). Repeat same assembly for both Left Leg Posts (6).
Attach the Bottom Tray (11) to both Left Leg Posts (6) using eight Ball Type Bolts3.
(2), eight Nuts (4) and eight Spring Washers (3).
Attach the bottom of the Right Leg Posts (1) to the Bottom Tray (11) using eight Ball4.
Type Bolts (2), eight Nuts (4) and eight Spring Washers (3).
Attach both Right Leg Posts (1) to the Upper Tray/Drawer Unit (5) using eight Ball5.
Type Bolts (2), eight Nuts (4) and eight Spring Washers (3).
Attach both Left Leg Posts (6) to the Upper Tray/Drawer Unit (5) using six Ball Type6.
Bolts (2), six Nuts (4) and six Spring Washers (3).
Attach the Push Handle (7) to the two Left Leg Posts (6) and the Upper Tray/Drawer7.
Unit (5) using two Ball Type Bolts (8), two Nuts (4) and two Spring Washers (3).
Tighten all hardware.8.
Bolts (13), Nuts (4),
Spring Washers (3)
Figure 1
Swivel Casters (12) Locking Casters (10)

[email protected] 51-800-348-5004
Check the Roll Cart to make certain that it sits evenly and that all hardware is9.
squarely set. Make certain all drawers slide properly, that all locks work, and that
Casters roll smoothly and evenly.
OPERATING INSTRUCTIONS
Set the Roll Cart up in the desired location.1.
Make certain to set both Locking Casters (10) once the Roll Cart is in place. To set2.
the brake, pull up on the tab located on each Locking Caster (10).
Fill each of the drawers and trays as desired. Do not exceed the maximum weight3.
capacity of 580 lbs. for the Roll Cart and the maximum weight capacity for each
drawer and tray as follows: Top Tray: 200 Lbs., 2 Small Drawers: 30 Lbs. each, Me-
dium Drawer: 50 Lbs. Bottom Drawer: 70 Lbs. and Bottom Tray: 200 Lbs.
INSPECTION, MAINTENANCE, AND CLEANING
Clean the Roll Cart with a damp cloth. Do not use abrasives, harsh chemicals or1.
detergents as these will scratch and damage the Bins and frame.
BEFORE EACH USE,2. inspect the general condition of the Roll Cart. Check for
loose screws, misalignment or binding of moving parts, cracked or broken parts
and any other condition that may affect its safe operation. Do not use damaged
equipment.

[email protected] 61-800-348-5004
Part Description Q’ty
1Right Leg Post 2
2Ball Type Bolts M8 x 12 34
3Spring Washer 52
4Nut 52
5Upper Tray/Drawer Unit 1
6Left Leg Post 1
7Push Handle 1
Part Description Q’ty
8Ball Type Bolts M8 x 16 2
9Support Frame 2
10 Locking Caster 2
11 Bottom Tray 1
12 Swivel Caster 2
13 Bolts M8 x 16 16
14 Cap 2
PARTS LIST AND ASSEMBLY DIAGRAM
9

Limited Manufacturer Warranty
FOT makes every effort to ensure that this product meets high quality and durability
standards. FOT warrants to the original retail consumer a 1-year limited warranty
from the date the product was purchased at retail and each product is free from
defects in materials. Warranty does not apply to defects due directly or indirectly
to misuse, abuse, negligence or accidents, repairs or alterations, or a lack of
maintenance. FOT shall in no event be liable for death, injuries to persons or
property, or for incidental, special or consequential damages arising from the
use of our products. To receive service under warranty, the original manufacturer
part must be returned for examination by an authorized service center. Shipping
and handling charges may apply. If a defect is found, FOT will either repair or
replace the product at its discretion.
DO NOT RETURN TO STORE
For Customer Service:
Email: [email protected] or Call 1-800-348-5004
