Stein Mayer DP-220 User manual

Users manual
DP-220
Digital Piano
00027530/00027531
Version 01/2012

CAUTION
1
INSTRUCTIONS PERTAINING TO A RISK OF FIRE,
ELECTRIC SHOCK, OR INJURY TO PERSONS.
Precaution
WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
RISK OF ELECTRIC
SHOCK
CAUTION TO REDUCE THE RISK OF
ELECTRIC SHOCK
DO NOT REMOVE COVER (OR BACK)
NO USER SERVICEABLE PARTS INSIDE
REFER SERVICING TO QUALIFIED SERVICE
PERSONNEL
This Symbol is intended to alert the user to the presence of
uninsulated dangerous voltage within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of fire
or electric shock.
This Symbol is intended to alert the user to the presence of
important in the literature accompanying this appliance.
All information should be read carefully to avoid misuse of
product.
WARNING :
DO NOT OPEN THE CABINET.
DANGEROUS HIGH VOLTAGE IS PRESENT, SERVICING SHOULD ONLY
BE PERFORMED BY QUALIFIED PERSONNEL.
CAUTION : TO PREVENT ELECTRIC SHOCK. MATCH WIDE BLADE OF PLUG
TO WIDE SLOT, FULLY INSERT.
ATTENTION :
POUR ÉVITER LES CHOC ÉLECTRIQUES, INTRODUIRE LA LAME LA PLUS
LARGE DE LA FICHE DANS LA BORNE CORRESPONDANTE DE LA PRISE ET
POUSSER JUSQUAU FOND.

2
Precaution
IMPORTANT SAFETY INSTRUCTIONS
WARNING - When using electric products, basic precaution should always be followed,
including the following:
1. Read all the instructions before using the product.
2. To reduce the risk of injury, close supervision in necessary when a product is used near
children.
3. Do not use this product near water - for example, near a bathtub, washbowl, kitchen
sink, in a wet basement, or near a swimming by the manufacturer.
4. This product should be used only with a cart or stand that is recommended by the
manufacturer.
5. This product, either alone or in combination with an amplifier and headphones or
speakers, may be capable of producing hearing loss. Do not operate for a long period
of time at a high volume level or at a level that is uncomfortable. If you experience any
hearing loss or ringing in the ears, you should consult an audiologist.
6. The product should be located so that its location or position does not interfere with its
proper ventilation.
7. The product should be located away from heat sources such as radiators, heat registers,
or other products that produce heat.
8. The product should be connected to a power supply only of the type described in the
operating instructions or as marked on the product.
9. This product may be equipped with a polarized line plug (one blade wider than the
other). This is a safety feature. If you are unable to insert the plug into the outlet,
contact an electrician to replace your obsolete outlet. Do not defeat the safety purpose
of the plug.
10. The power-supply cord of the product should be unplugged from the outlet when left
unused for a long period of time.
11. Care should be taken so that objects do not fall and liquids are not spilled into the
enclosure through openings.
12. The product should be serviced by qualified service personnel when:
A. The power-supply cord or the plug has been damaged; or
B. Objects have fallen, or liquid has been spilled into the product; or
C. The product has been exposed to rain; or
D. The product does not appear to operate normally or exhibits a marked change
in performance; or
E. The product has been dropped, or the enclosure damaged.

3
Precaution
13. Do not attempt to service the product beyond that described in the user maintenance
instruction. All other servicing should be referred to qualified service personnel.
14. To clean the exterior surfaces, wipe lightly with a clean, dry cloth. Never use solvents
such as benzine or paint thinners.
15. The product should be located away from a television, radio, or heavy equipment that can
generate electromagnetic fields.
16. The product should be located a flat, stable surface that can free of vibration.
17. Be careful to protect the product from knocks, particularly when carrying it.
18. During thunderstorms, turn the product off and disconnect the plug from the power outlet.
INFORMATION TO THE USER
This equipment has been tested and found to comply with the limits for a class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions,may cause harmful interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one more of the following measures :
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
- Consult the dealer or an experienced radio/TV technician for help.
WARNING
Changes or modifications not expressly approved by the manufacturer could void the user ’s
authority to operate the equipment
.

4
Welcome
Thank you and congratulations on your purchase of the SLIM DIGITAL PIANO.
Your new SLIM DIGITAL PIANO is a state-of-the-art musical instrument which incorporates
the latest electronics technology to make its operation as easy as possible.
Your versatile DIGITAL PIANO is ideal for beginners or experienced musicians.
In order to enjoy the features and functions of this unit to their fullest, be sure to carefully
read this manual and follow the instructions contained herein.
Welcome

Precaution
Welcome
Contents
Care of Your Digital Piano
Unpacking (SLP-100/SLP-200/SLP-300)
Setting Up Your Piano (SLP-100/SLP-200/SLP-300)
External Appearance
Panel Controls and Terminals
Adjusting the Volume
Using Pedals
Selecting Voice
Layer
Split
3D (Spatial Effect)
Twin Piano
Reverb
Effect
Tune
Transpose
Touch
Using Metronome
Recording
MIDI & USB MIDI
MIDI Implementation Chart
GM Voice & Drum Table
Troubleshooting
Specifications
5
Contents
목Contents
1
4
5
6
7/11/15
8/12/16
19
20
22
23
24
26
27
28
29
30
31
32
33
34
35
36
37
38
39
42
43

● Avoid heat, humidity or direct sunlight.
● Keep the unit free from liquids, dust, etc...
● During thunderstorms, turn the product off
and disconnect the plug from the power.
●
Take care not to drop the unit and avoid
strong impact.
● Never attempt to modify any parts of the
unit.
6
Care of your Digital Piano
Care of your Digital Piano

7
Unpacking (SLP-100)
Unpacking (SLP-100)
Carefully remove the Digital Piano and its accessories from the packing box. The Digital
Piano set consists of the following items.
Four Bolts
for Main Unit (g)
(M6x15)mm, Black
AC Power Adapter (f) Eight Bolts
for Speaker Box (h)
(M6x25)mm, Gold
Pedal(e)
Right, Left Legs (a, b)
Speaker Box (c)
☞
Inspect each item carefully to make sure that it is in good condition. If you find any item
missing or damaged, contact the place of purchase immediately for replacement.
Main Unit
Music Desk (d)

8
Setting Up Your Piano (SLP-100)
Setting Up Your Piano (SLP-100)
1. Attaching the both legs and speaker box assembly
2. Attaching the main unit and stand
Securely combine both
Legs(a,b) and Speaker Box(c)
assembly using Eight Bolts (h).
Set the stand upright and gently
lower the Main Unit on the stand,
then tighten the main unit with
four Bolts (g) for main unit as
shown in illustration.

9
Setting Up Your Piano (SLP-100)
3. Attaching the music desk on the main unit
4. Connecting the pedal, speaker and AC adapter with main unit
Attach the Music Desk (d) on the
Main Unit as shown in illustration.
Plug Pedal Cord, AC AC adapter and
Speaker Cord into the corresponding
ports on the bottom of the main
unit as shown in illustration.
MAIN UNIT BOTTOM

10
Setting Up Your Piano (SLP-100)
Turning on the Power
① Connect the AC POWER ADAPTER. Insert DC
plug at the end of DC cord of the AC adapter into
the piano and AC plug at end of AC cord of the
AC adapter into a standard AC outlet.
☞ See 'Connecting the pedal, speaker and AC adapter with
main unit' on page 9.
② Press POWER switch. The power is turned on
and the initial display appears in the Multi
Function Display. The voice of Grand Piano is
selected automatically at first.
☞ Adjust the volume by using MASTER VOLUME.
Press POWER switch again when turning off the
power. All lamps and LED display will turn off.
Headphones
Connect a set of stereo headphones(optional) to
PHONES jack.
Insert plug of the headphone into the PHONES
jack on the bottom panel of the piano.
When headphones are connected, the internal
speaker system is automatically shut off.
Since the piano has two PHONES jacks, two sets
of headphones can be used simultaneously, allow
two people to enjoy listening to the performance.

11
Unpacking (SLP-200)
Unpacking (SLP-200)
Carefully remove the Digital Piano and its accessories from the packing box. The
Digital Piano set consists of the following items.
[BOX 1] BODY
Main Unit
[BOX2] STAND
Right, Left Legs (a, b) Pedal Box (c) Rear Plate (d)
☞
Inspect each item carefully to make sure that it is in good condition. If you find any item
missing or damaged, contact the place of purchase immediately for replacement.
Four Bolts for Main
Unit (g) (M6x15)mm,
Black
Four Bolts
for Pedal Box (f)
(PT6x25)mm, Gold
Five Bolts
for Rear Plate (h)
(4x22)mm
AC Power Adapter

12
Setting Up Your Piano (SLP-200)
Setting Up Your Piano (SLP-200 ) )
1. Attaching the both legs and pedal box assembly
2. Assembling the stand
① Securely combine both
Legs(a,b) Pedal Box(c) assembly
using four Bolts(f).
② For pedal stability, rotate the
adjusters on the bottom of the
pedal assembly unit they comes in
firm, contact with the floor surface.
① Attach the Rear Plate(d) to the
legs and pedal box using five Bolts (h)
for rear plate.
② After fixing the crossing plate
to the legs, set the stand upright
and make sure the stand is
parallel.

13
Setting Up Your Piano (SLP-200)
3. Attaching the main unit and stand
4. Connecting the pedal cord and AC adapter
Set the stand upright and gently
lower the main unit on the stand,
then tighten the main unit with four
Bolts (g) for main unit as shown in
illustration.
Plug pedal CORD(c) and AC adapter
plug into the corresponding ports on
the bottom of the main unit.

14
Setting Up Your Piano (SLP-200)
Turning on the Power
① Connect the AC POWER ADAPTER. Insert DC
plug at the end of DC cord of the AC adapter into
the piano and AC plug at end of AC cord of the
AC adapter into a standard AC outlet.
☞ See 'Connecting the pedal cord and AC adapter' on page
13.
② Press POWER switch. The power is turned on
and the initial display appears in the Multi
Function Display. The voice of Grand Piano is
selected automatically at first.
☞ Adjust the volume by using MASTER VOLUME.
Press POWER switch again when turning off the
power. All lamps and LED display will turn off.
Headphones
Connect a set of stereo headphones(optional) to
PHONES jack.
Insert plug of the headphone into the PHONES
jack on the bottom panel of the piano.
When headphones are connected, the internal
speaker system is automatically shut off.
Since the piano has two PHONES jacks, two sets
of headphones can be used simultaneously, allow
two people to enjoy listening to the performance.

15
Unpacking (SLP-300)
Unpacking (SLP-300)
Carefully remove the Digital Piano and its accessories from the packing box. The
Digital Piano set consists of the following items.
[BOX 1] BODY
Main Unit
[BOX2] STAND
Right, Left Legs (a, b) Pedal Box (c) Speaker Box (d)
☞
Inspect each item carefully to make sure that it is in good condition. If you find any item
missing or damaged, contact the place of purchase immediately for replacement.
Four Bolts
for Main Unit (g)
(M6x15)mm, Black
Twelve Bolts
for Pedal Box and Speaker Box (f)
(PT6x25)mm, Gold
AC Power Adapter

16
Setting Up Your Piano (SLP-300)
Setting Up Your Piano (SLP-300 ) )
1. Attaching the both legs and pedal box assembly
2. Assembling the stand
① Securely combine both
Legs(a,b) Pedal Box(c) assembly
using four Bolts(f).
② For pedal stability, rotate the
adjusters on the bottom of the
pedal assembly unit they comes in
firm, contact with the floor surface.
① Attach the Speaker Box (d) to
the legs and pedal box using eight
Bolts (f) for speaker box.
② After fixing the speaker box to
the legs, set the stand upright and
make sure the stand is parallel.

17
Setting Up Your Piano (SLP-300)
3. Attaching the main unit and stand
4. Connecting the pedal cord and AC adapter
Set the stand upright and gently
lower the main unit on the stand,
then tighten the main unit with four
Bolts (g) for main unit as shown in
illustration.
Plug Pedal Cord, AC AC adapter and
Speaker Cord into the corresponding
ports on the bottom of the main
unit as shown in illustration.
MAIN UNIT BOTTOM

18
Setting Up Your Piano (SLP-300)
Turning on the Power
① Connect the AC POWER ADAPTER. Insert DC
plug at the end of DC cord of the AC adapter into
the piano and AC plug at end of AC cord of the
AC adapter into a standard AC outlet.
☞ See 'Connecting the pedal cord and AC adapter' on page
17.
② Press POWER switch. The power is turned on
and the initial display appears in the Multi
Function Display. The voice of Grand Piano is
selected automatically at first.
☞ Adjust the volume by using MASTER VOLUME.
Press POWER switch again when turning off the
power. All lamps and LED display will turn off.
Headphones
Connect a set of stereo headphones(optional) to
PHONES jack.
Insert plug of the headphone into the PHONES
jack on the bottom panel of the piano.
When headphones are connected, the internal
speaker system is automatically shut off.
Since the piano has two PHONES jacks, two sets
of headphones can be used simultaneously, allow
two people to enjoy listening to the performance.

19
External Appearance
External Appearance
2
3
4
5
1
2
3
4
5
1
1. Music Desk
2. Control Panel
3. Keyboard
4. Pedal
5. Stand
1. Keyboard Cover
2. Control Panel
3. Keyboard
4. Pedal
5. Stand
SLP-100
SLP-200
2
3
45
11. Keyboard Cover
2. Control Panel
3. Keyboard
4. Pedal
5. Stand
SLP-300
