stellar labs SEA38 User manual

Juice
Extractor
Instruction Manual
Please read this instruction
manual carefully before use
and retain for future reference.
Unpack your Juice Extractor
carefully and remove
temporary packing pieces, labels
and stickers.
Model No. SEA38

Juice Extractor
Page 2
Identifying the parts of your Stellar Juice Extractor
(with part numbers for customer replaceable items)
1. Extractor Body
2. Filter Drive
3. Pulp Separator (SEA38S)
4. Filter Basket (SEA38F)
5. Extractor Cover (SEA38C)
6. Feeder Tube
7. Ingredient Pusher (SEA38P)
8. Extractor Spout
9. Safety Locking Arms
10. Speed Control
11. Jug (SEA38J)
12. Foam Separator
13. Mains cable and plug
(Fig.5)

Juice Extractor
Page 3
Before rst use
1. Remove any labels and/or
swingtickets.
2. Clean all parts, following the
instructions for cleaning.
Assembly
■Conrm that the Extractor is
switched OFF and not plugged in
during assembly.
Follow the steps below:
1. Fit the Pulp Separator to the
Extractor Body (Fig.1) ensuring
that the spout matches with the
notch on the right hand side of the
body.
2. Fit the Filter Basket into the
Pulp Separator (Fig.2) matching
the notches on the underside with
the holes on the Filter Drive .
■Take care when handling the Grater/
Strainer, as the grater is sharp.
3. Fit the Extractor Cover on top
of the Pulp Separator . then raise
the Safety Locking Arms (Fig.3)
and locate into the two grooves
either side of the Extractor Cover
. Press down at the base of each
arm to lock into place (Fig.4).
■For safety the Juice Extractor will
not function until both Safety
Locking Arms are locked into
position.
4. If using the Ingredient Pusher , t
it into the Feeder Tube locating
one of the long grooves in the
Ingredient Pusher over the lug inside
the Feeder Tube.
5. Fit the Foam Separator into the
Jug as shown (Fig.5) and position
the Jug so that the Extractor Spout
is inside the wide Jug spout.
Speed Selector Table
Position 1 (Slower)
Blackcurrants
Blueberries
Broccoli
Cauliower
Cherries (Stone Removed)
Cucumbers
Garlic
Gooseberries
Grapefruit (Peeled)
Grapes (Seedless)
Kiwi Fruit (Peeled)
Lemons (Peeled)
Mango (Peeled, Stone Removed)
Onion
Oranges (Peeled)
Parsley
Peaches (Stone Removed)
Pears (Ripe)
Plums (Stone Removed)
Raspberries
Strawberries
Tomatoes
Watermelon (Peeled)
Position 2 (Faster)
Apples
Beetroot
Brussels Sprouts
Cabbage
Carrots
Celery
Fennel
Pears (Harder)
Peppers
Pineapple (Peeled)
Root Vegetables (Other)
Spinach
Not suitable for juicing
Fruits/vegetables that are rich in
starch are not suitable for use
with this extractor, including:
Avocado
Bananas
Coconut
Figs
Papaya
(Fig.1)
(Fig.2)
(Fig.3)
(Fig.4)

Juice Extractor
Page 4
How to use
1. Place the Juice Extractor on a at, stable
surface. Ensure that there is at least 10cm
clearance on all sides.
2. Ensure that the Speed Control is set
to the O (0) position before plugging
the Mains Plug into a mains socket
and switching on. The outer ring of the
Speed Control will illuminate.
3. With the Ingredient Pusher removed
add your rst ingredients into the Feeder
Tube .
4. Set the Speed Control to either
position “1” (slower) or position “2”
(faster) depending on your choice of
ingredients (see Speed Selector Table
opposite).
5. Gently but rmly push the Ingredient
Pusher to the bottom.
6. Continue to gradually add ingredients
into the Feeder Tube and using the
Ingredient Pusher until you have the
amount of juice desired.
7. When you have nished Juicing, set
the Speed Control to the “0” (o)
position and disconnect the Mains Plug
from the mains socket.
■Do not operate the Juice Extractor
continuously more than 4 minutes to
avoid overheating. After each use, allow
the Extractor to cool for 15 minutes
■Empty the Pulp Separator regularly
during use.
■Do not attempt to raise the Safety
Locking Arms whilst the mixer
is running. Doing so will cause the
extractor to stop automatically, and you
must set the speed control to ”0” before
re-starting.
Hints
■The best results are obtained when using
young and particularly fresh vegetables
and fruits. In general, the softer the
vegetable and riper the fruit, the thicker
and less clear the juice will be.
■Wash fruits and vegetables and dry them
well.
■Roll leafy vegetables into clumps.
■When making a mixed drink from more
than one ingredient, use the softer
ingredients rst, then the harder ones.
■Vitamins disappear quickly after
extraction of the juice, which should
therefore be consumed as soon as
possible.
■Apple juice turns brown rapidly. A few
drops of lemon juice will keep it from
turning brown too quickly.
■Some residue pulp can be used as a base
for soups, sauces, jams, and desserts.
Cleaning
1. Wash all items except the Extractor
Body in a solution of liquid detergent
and warm water then rinse and dry
thoroughly.
■All the items except the Extractor Body
can also be cleaned in a dishwasher.
2. Wipe to clean the Extractor Body
using a cloth, slightly dampened with
liquid detergent and warm water. Dry
thoroughly.
■DO NOT IMMERSE ANY PART OF
THE EXTRACTOR BODY IN
WATER.
■Do not use harsh abrasive cleaners, steel
wool scourers or metal implements.

Juice Extractor
Page 5
Cautions
■Check that the electrical supply rating of
the appliance are correct for your home
(see Specications).
■The appliance must be connected via
a mains socket, which should have an
individually rated load of above 10A.
Ensure that the plug is fully inserted.
■Do not insert plug with wet hands.
■This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities
or lack of experience or knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
■This appliance is not intended to be
operated by means of an external timer
or a separate remote-control system.
■Always keep the appliance out of the
reach of children.
■Do not place the appliance near a hot
gas or electric burner.
■The appliance should be placed on a
level stable worktop at least 10cm from
walls or other solid obstructions.
■Do not use the appliance on a carpet or
tablecloth.
■Do not move the appliance whilst in
operation.
■Do not put ngers or other objects into
Juice Extractor openings while it is in
operation.
■Do not use the appliance if the Filter
Basket is damaged.
■The appliance incorporates a safety
interlock to prevent operation until the
Safety Locking Arms are raised. Do
not attempt to use the appliance unless
assembled.
■Never move the appliance by pulling the
Mains Cable .
■Ensure that the Mains Cable does
not trail over the edge of the worktop,
is positioned where it cannot be
accidentally pulled or snagged, and that it
is kept away from any hot object.
■Never use the appliance when it shows
damage (including to the power cable)
or does not function properly; contact
STELLAR at the address given. Do not
attempt to repair the appliance yourself.
■Use the appliance only for its intended
purpose.
■Do not immerse the appliance in water.
After Sales Service
Do not attempt to repair any part of this
appliance. Please refer any problem to
Stellar Customer Services.

Juice Extractor
Page 6
Specication
Name Model No. Rated Voltage Rated Frequency Rated Power
Juice Extractor SEA38 220-240V 50/60Hz 800W
■The Stellar 2 Year Domestic
Electrical Guarantee covers the
product to be free of defects in
materials and workmanship for a
period of TWO YEARS from the
date of original retail purchase.
■During this period, Stellar will,
at their option, repair or replace
defective parts of the product, or
replace the product, providing the
Use Care and Safety Advice have
been followed.
■The Guarantee does not cover
damage, defect or failure caused
by or resulting from accidents,
external damage, alteration,
modication, abuse, misuse or
misapplication.
■The Guarantee does not cover
any damage caused by taking
the appliance apart yourself, or
attempting to repair the appliance
yourself.
■THE PRODUCT IS INTENDED
FOR DOMESTIC USE ONLY.
■Please keep your Purchase Receipt
and contact us directly if you
encounter any problems with your
product.
Stellar 2 Year Domestic Electrical Guarantee
CORRECT DISPOSAL OF THIS PRODUCT
This marking indicates that this product should not be disposed with other
household wastes throughout the EU. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, recycle it responsibly to promote
the sustainable reuse of material resources. To return your used device, please use
the return and collection systems or contact the retailer where the product was
purchased. They can take this product for environmental safe recycling.
FOR DOMESTIC USE ONLY
YEAR
GUARANTEE
DOMESTIC
ELECTRICAL
USE
STELLAR
HORWOOD SHALL NOT BE
LIABLE FOR INCIDENTAL OR
CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF
THIS PRODUCT (INCLUDING
COLOUR FADING, SCRATCHES OR
ACCUMULATED DIRT) WITHOUT
FOLLOWING THE USE, CARE &
SAFETY INSTRUCTIONS.
Note: Due to the introduction of
improvements from time to time, the
right is reserved to supply products which
dier slightly from those illustrated and
described in this publication.
Errors and Omissions Excepted.
CUSTOMER SERVICES
Horwood, Avonmouth Way,
Bristol, BS11 9HX, Great Britain
www.stellarcookware.co.uk
[e-mail]
Tel: [phone]
