StellaX zoomx X-007 User manual

Instruction Manual for Binoculars
BINOCULARS
10x42 waterproof
CREATED BY STELLAX COMPANY
-007

CONTENTS
Instructions for use 1
• Information for Your Safety 1
• Risk of Swallowing 1
• Eyecup Adjustment 3
• IPD (distance) Adjustment 4
• Focus and Diopter Adjustment 5
• Objective Lens Covers 6
Care and Maintenance 7
Waterproof/Fog-proof Information 8
Warranty 8
Setting up the Smartphone Adapter 9
How to Attach the Neck Strap 12

Instruction for use
Information for your safety
Risk of Swallowing
01
Congratulations on purchasing your new ZoomX
«X-007»binoculars. Enjoy the sharp, bright, high
resolution view offered by these outstanding optics.
Follow the instructions for use and your product will
be a reliable companion for many years to come.
Do not, under any circumstances, look through
the binoculars at the sun or laser light sources!
Serious eye injury may result.
Never leave the binoculars in the sun for extend-
ed periods of time without the protective lens
cap. Extreme exposure to direct sunlight through
the objective lens and eyepiece can cause the
device to function as a burning glass and damage
the interior components or cause a fire.
Never leave the removable outer parts within
reach of children (risk of swallowing).

Eyecup (Twist-Up)
Strap Lug
Diopter Adjustment Ring
Center
Focus Knob
Tripod
Adapter
Socket
(under cap)
Ocular Lens (Eyepiece)
Objective Lens
02

Eyecup Adjustment
03
Your ZoomX «X-007» binoculars are fitted with
twist-up eyecups that provide a comfortable view of
the full image and help to exclude extraneous light.
For use without eyeglasses or sunglasses, twist the
eyecups upwards, rotating them counter-clockwise
until they lock into the fully «Up» position (Pic. 1).
If you are wearing glasses, start with the eyecups in
the «Down» position – this will bring your eyes closer
to the binocular’s ocular lenses, allowing you to see
the full field of view. To lower the eyecups from the
full «Up» position, rotate them clockwise (Pic. 2). The
eyecups may also be set to a position midway
between fully up and fully down, which may suit
some individuals better.
Eyecup in «Up» Position
(for use without eyeglasses)
Eyecup in «Down» Position
(for use with eyeglasses)
Pic. 1 Pic. 2

IPD (Interpupillary Distance) Adjustment
04
Point the binoculars at a white wall or blank area
of the sky. Hold them and gaze through them as
you normally would. Don’t worry about focus yet.
Grasp each side of the binoculars firmly. Move
the left and right sides closer together or farther
apart (Pic. 3) until you see a single image with no
shaded areas.
Narrow IPD
Pic. 3 Interpupillary Distance Adjustment
Wide IPD

Focus and Diopter Adjustment
05
Close your right eye and sight an object with your
left eye. Focus the binoculars by rotating the
center focus wheel until the image is sharp and
clear.
Open your right eye and close your left eye.
Rotate the right eyepiece until the object sighted
is sharp and clear (Note the setting of the diopter
scale for later use.)
Both sides (eyes) are now in focus and you will
need to use only the center focus wheel to focus
on other objects.
1
2
3
Center
Focus wheel
Diopter
Adjustment
Ring

06
Objective Lens Covers
When using your «X-007» binoculars, flip open the
objective lens covers. To prevent accidental loss, the
covers are tethered to (removable) rubber security
rings. When you have finished using the binoculars,
put the covers back in place to protect the binoculars'
lenses.
www.zoomx.company

Care and Maintenance
07
First, blow or brush away any dust or debris on the
lens (using «canned air» or a soft lens brush).
To remove dirt or finger prints, clean with the supplied
soft storage bag (made of washable micro-fiber
cloth), rubbing in a circular motion. Use of a coarse
cloth (including paper towels) or unnecessary rubbing
may scratch the lens surface and eventually cause
permanent damage. The included storage bag/mi-
cro-fiber cloth is ideal for the routine cleaning of your
optics. Simply breathe lightly on the lens to provide a
slight amount of moisture, then gently rub the lens
with the micro-fiber cloth.
For more thorough cleaning, photographic lens tissue
and photographic lens cleaning fluid or isopropyl
alcohol may be used. Always apply the fluid to the
cleaning cloth – never directly on the lens.
To prevent potential damage to the optical coatings
on the lens surfaces of the binoculars, never use
household window cleaning liquids, and avoid using
facial tissue or clothing that may have fibers which
can be abrasive and hold oils or dirt.

08
Waterproof/Fog-proof Information
Your ZoomX «X-007»bbinoculars have been
designed and built utilizing the latest waterproof and
fog-proof technology. Fog-proof protection is
achieved from dry nitrogen purging that removes all
internal moisture.
Warranty
Your ZoomX product is covered by our warranty and
guaranteed to be free from manufacturing defects in
materials and workmanship for the life of the product. If
such a defect appears, we will repair your product or
replace it, as appropriate and at our discretion, with the
same or an equivalent model, free of charge. This guaran-
tee is non-transferable and does not cover cosmetic
damage or damage sustained through wear and tear.
Activate your Lifetime Warranty:
www.zoomx.company/warranty
Or scan this QR code
You should do this immediately:
The product must be registered
within 20 days of purchase.

How to use the
Smartphone Adapter
with iPhone
Smartphone Adapter
09
Set your smartphone
to Smartphone Adapter.
Align the camera
Tighten the
locking bolt
Align the hole of the adapter
with the camera of your smartphone.
Tighten the locking bolt.
1 2

10
Turn on the camera
of your smartphone.
Zoom in a little on your smartphone
to get a rectangular image.
5 6
Attach the smartphone adapter
to the binocular eye socket.
Remove the front cover caps
from the binoculars' lenses.
3 4

Setting up the Adapter
for Dual-Camera Smartphones
11
Some smartphones have
two or more cameras on
the back of the device.
For example:
Apple iPhone 8 Plus,
Apple iPhone XS Max
To connect your smartphone
to the smartphone adapter,
you need to use the main
camera.

How to Attach the Neck Strap
12
Push a few inches of
the strap through the
strap attachment on
the binoculars.
1
Hold the buckle and
thread the end of the
strap through the
buckle.
2
Adjust the overall
length, then pull tight
until strap secured
within the buckle.
3
