STI EZ-PATH 33 Series Assembly instructions

INSTALLING PATHWAY USING WALL PLATES
Prior to Pulling Cables
Device is installed through wall and attached using wall plates
to sandwich the wall. No mechanical attachment to wall itself
is required.
1. If necessary, pre-install required set screws in mounting plates
using Allen wrench (provided). NOTE: When installing a single
wall plate and pathway, two set screws positioned and tightened
at 90 degrees to each other in both plates will adequately hold
device (See Fig. 3). Multiple devices in a ganged installation
using double (Cat No. EZP233W) or triple mounting plates
(EZP333W) require EVERY set screw to be installed.
2. Install a mounting plate around pathway making sure that set screw flanges are facing towards the
end of the device. NOTE: Position plate so that the word TOP stamped on the plate aligns with the
lid of the pathway. Use gauge marks located on lid of pathway to adjust plate to thickness of wall
(See Fig. 4). This will center pathway within the wall. When properly adjusted, tighten set screws to
lock plate onto pathway.
3. Place one of two provided gaskets around opposite end of pathway and carefully slide it back to fit
snugly against back side (wall side) of plate.
4. Insert pathway device through wall (with TOP facing upwards) using previously installed mounting plate
and gasket as a stop (See Fig. 5).
5. Moving to the opposite side of the wall, install remaining gasket around pathway and slide toward wall.
6. Install remaining mounting plate around pathway (TOP up) and slide it toward wall surface. While
pulling pathway toward you, push wall plate and gasket tightly to wall and tighten set screws. Check
device for excessive play. If device appears to be loose or can easily be moved, readjust mounting
plates as necessary to tighten device firmly against wall.
GENERAL - READ COMPLETELY BEFORE INSTALLING
This product allows for several optional installation methods. Available
methods for walls are shown here. The pathway device consists of an
enclosed heavy gauge galvanized steel channel with a detachable lid.
Depending on the type ordered, mounting plates and gaskets are either
included or may be ordered separately. Mounting plates are designed to
accommodate single, double, or triple device installations. Component
requirements will vary according to the method of installation chosen. See
Table B for additional information.
NOTE: WALL INSTALLATIONS REQUIRE THIS DEVICE TO BE
INSTALLED WITH THE TOP (LID) FACING UPWARD. The lid may
be identified by the BARRIER GAUGE stamping. WALL PLATES ARE
ASYMMETRICAL and are marked with the word TOP.
INSTALLATION SHEET
Series 33
Fire Rated Pathway
Page 1 of 2 Installation Sheet • EZ-PATH® SERIES 33 ZIS1003 03/2014
ZIS1003 Rev. 03/2014
CREATING THE OPENING
Gypsum Board Walls (Square Openings):
1. Locate suitable area of the wall to penetrate making sure that there are no studs, wires, pipes or
other obstructions located within wall.
2. Mark a square or rectangular opening as dimensioned in Table A. Make sure opening is square and
plumb. The inside opening of the mounting plates can be used as a template (See Fig. 1).
3. Using a keyhole saw, cut wall board (See Fig. 2). Cutting to the outside of the line will produce a
slightly over-sized opening. Mark and cut opposite side of the wall, exercising care to align both
openings. Insert pathway and check for fit. Remove pathway.
4. Install device per instructions below.
Concrete or Masonry Walls (Square or Round Openings):
1.Cut or form a square or rectangular opening or core drill a round opening per dimensions listed in Table A.
TABLE A: Wall Opening Dimensions
CONFIGURATION SINGLE DOUBLE TRIPLE
Square or Rectangular Using Mounting Plates - Gypsum Board
or Masonry
Opening Height 3-1/8” (79 mm) 3-1/8” (79 mm) 3-1/8” (79 mm)
Opening Width 3-1/8” (79 mm) 6-1/8” (156 mm) 9-1/8” (232 mm)
Square (Using Sealant - No Mounting Plates) - Gypsum Board or
Masonry
Opening Height 3-1/8” (79 mm) N/A N/A
Opening Width 3-1/8” (79 mm) N/A N/A
Round (Using Sealant - No Mounting Plates) - Masonry
Opening Diameter 4” (102 mm) N/A N/A
Fig. 1
ϒ
Fig. 3
Fig. 2
Fig. 4
Fig. 5

GROUNDING
At the option of the installer, this device may be grounded. After device(s) has been installed, insert ground
screws where indicated (See Fig. 10). For installations using single, double, or triple mounting plates, or
optional positioning clamps, two ground screws are required and are included in these kits.
WALL LABELING
Wall labels are provided with the pathway device as well as mounting plate kits. Larger orange colored label is
intended to be used to identify the pathway’s installer as well as to provide applicable UL System information.
Smaller secondary labels are included with double and triple mounting plates as an optional method for
identifying or marking cable types, uses, or trades. Two sets of labels are provided for marking both sides of wall.
MAINTENANCE
No maintenance of the pathway is normally required. Interior of device should be inspected before and after any modifications to
cable bundle. If any damage to intumescent pads lining top and bottom of the pathway is found, contact the factory to determine if
replacement is required.
INSTALLING or PULLING CABLES
A resilient liner provides an adjustable seal within the pathway device. Liner must be protected from damage while adding or removing cables.
Wrap cable ends with a suitable low friction tape before inserting into the pathway. Where cable lubricants are used, low solids, water-based
products are recommended. This device is designed to be fully functional at all cable loadings from completely empty to visually filled, and
cables should easily slide through the pathway using minimal effort. IF RESISTANCE IS ENCOUNTERED, DO NOT FORCE CABLES OR
CABLE BUNDLES THROUGH THE PATHWAY. DAMAGE MAY RESULT. Upper curved liner may be depressed when inserting cables, if
necessary, using a flat, smooth implement and then removing it after cables are installed. The rectangular shape of the loading area coupled
with gentle pressure exerted by resilient liners will naturally distribute the cables at a relatively uniform height across the width of the device. The
use of a cable dressing/combing instrument to straighten and organize cables may help to maximize usable space within the pathway device.
New or Existing Cable Installation
1. With fastening screw removed, install optional Positioning Clamp (Cat No. EZP133PC) around
cable bundle and slide over pathway making sure that the flat feet of clamp are facing towards
wall surface. Use gauge marks located on pathway to adjust clamp to thickness of wall. When
properly adjusted, lock clamp in place by installing and tightening fastening screw.
2. Slide device into properly sized opening and center within wall (See Fig. 9).
3. Moving to opposite side of wall, install second clamp around pathway and snug tightly to wall.
Tighten clamp securely.
4. Caulk using approved sealant (SpecSeal® Series SSS, LCI, LC, or SIL300 Sealants). Apply
sealant to a depth of 5/8” (16 mm) within annulus on both sides of wall. Apply a 3/8” (9.6 mm)
crown bead at areas of point contact.
Page 2 of 2 Installation Sheet • EZ-PATH® SERIES 33 ZIS1003 03/2014
Fig. 10
