Stihl 42440111600 User manual

BGA 60
2 - 18 Instruction Manual

Contents
1 Introduction................................................. 2
2 Guide to Using this Manual.........................2
3 Overview..................................................... 3
4 Safety Precautions......................................4
5 Preparing the Blower for Operation.......... 10
6 Charging the Battery, LEDs...................... 10
7 Assembling the Blower............................. 11
8 Removing and Fitting the Battery..............11
9 Switching the Blower On/Off..................... 12
10 Testing the Blower and Battery.................12
11 Operating the Blower................................ 13
12 After Finishing Work..................................13
13 Transporting..............................................13
14 Storing.......................................................13
15 Cleaning....................................................14
16 Maintenance and Repairs......................... 14
17 Troubleshooting........................................ 15
18 Specifications............................................16
19 Spare Parts and Accessories....................17
20 Disposal.................................................... 17
21 EC Declaration of Conformity................... 17
22 UKCA Declaration of Conformity.............. 17
1 Introduction
Dear Customer,
Thank you for choosing STIHL. We develop and
manufacture our quality products to meet our
customers’ requirements. The products are
designed for reliability even under extreme con‐
ditions.
STIHL also stands for premium service quality.
Our dealers guarantee competent advice and
instruction as well as comprehensive service
support.
STIHL expressly commit themselves to a sus‐
tainable and responsible handling of natural
resources. This user manual is intended to help
you use your STIHL product safely and in an
environmentally friendly manner over a long
service life.
We thank you for your confidence in us and hope
you will enjoy working with your STIHL product.
Dr. Nikolas Stihl
IMPORTANT! READ BEFORE USING AND
KEEP IN A SAFE PLACE FOR REFERENCE.
2 Guide to Using this Manual
2.1 Applicable Documentation
Local safety regulations apply.
► Read, understand and save the following
documents in addition to this instruction man‐
ual:
–Safety notes and precautions for STIHL AK
battery.
–Safety information for STIHL batteries and
products with built in batteries:
www.stihl.com/safety-data-sheets
2.2 Symbols used with warnings in
the text
WARNING
■ This symbol indicates dangers that can cause
serious injuries or death.
► The measures indicated can avoid serious
injuries or death.
NOTICE
■ This symbol indicates dangers that can cause
damage to property.
► The measures indicated can avoid damage
to property.
2.3 Symbols in Text
This symbol refers to a chapter in this
instruction manual.
English
2 0458-008-0101-A
© ANDREAS STIHL AG & Co. KG 2022
0458-008-0101-A. VA3.K22.
Printed on chlorine-free paper Paper is recyclable.
Translation of Original Instruction Manual
0000009690_005_GB

3 Overview
3.1 Blower, Battery and Charger
1
2
3
#
#
#
4
5
6
9
8
7
10
11
12
13
15
17
14
16
0000099078_001
1 Nozzle
The nozzle directs and controls the air
stream.
2 Retaining latch
The retaining latch releases nozzle adjust‐
ment.
3 Release slide
The release slide releases the trigger.
4 Ergo lever
The Ergo lever holds the release slide in posi‐
tion when the trigger is released.
5 Control handle
The control handle is used to operate, control
and carry the blower.
6 Locking lever
The locking lever holds the battery in the bat‐
tery compartment.
7 Battery compartment
The battery compartment holds the battery.
8 Shield
The shield protects the user from moving
parts inside the blower.
9 Trigger
The trigger switch switches the blower on and
off.
10 Blower tube
The blower tube directs the air stream.
11 Battery
The battery supplies the blower with energy.
12 LEDs
The LEDs indicate the state of charge of the
battery and any faults.
13 Button
The button activates the LEDs on the battery.
14 Charger
The charger charges the battery.
15 LED
The LED indicates the status of the charger.
16 Connecting cable
The connecting cable connects the charger to
the mains plug.
17 Mains plug
The mains plug connects the connecting
cable to a socket.
# Rating plate with machine number
3.2 Symbols
Meanings of symbols that may be on the blower,
battery and charger:
This symbol indicates the direction the
release slide has to be pushed
towards.
1 LED emits red light. The battery is
too warm or too cold.
4 LEDs flash red. There is a fault in the
battery.
The LED lights up green and the LEDs
on the battery light up or flash green.
The battery is charging.
The LED flashes red. There is no elec‐
trical contact between the battery and
the charger or there is a fault in the
battery or in the charger.
L
W
A
Guaranteed sound power level in
accordance with Directive 2000/14/EC
in dB(A) for the purpose of comparing
the sound emissions of products.
The information next to the symbol indi‐
cates the energy content of the battery
according to the cell manufacturer’s specifi‐
cation. The energy content available in
operation is lower.
Operate the electric product in a dry place,
indoors only.
Do not dispose of the product with your
household waste.
3 Overview English
0458-008-0101-A 3

4 Safety Precautions
4.1 Warning symbols
Meanings of warning signs and labels on the
blower, battery and charger:
Observe safety warnings and take the
necessary precautions.
Read and understand the User Manual
and keep it in a safe place.
Wear protective glasses.
Observe the safety advice concerning
flying objects and associated meas‐
ures.
Secure long hair so that it cannot be
pulled into the blower.
Remove the battery during work inter‐
ruptions, transport, storage, mainte‐
nance or repair.
Protect blower and charger from rain
and moisture.
5m (17 ft)
Maintain a safe distance.
Protect battery against heat and fire.
Protect the battery against rain and
moisture and do not immerse it in liq‐
uids.
4.2 Intended use
The STIHL BGA 60 blower is designed for blow‐
ing leaves, grass, paper and similar matter.
Do not use the blower in the rain.
The STIHL AK battery supplies power to the
blower.
The STIHL AL 101 charger is used to charge the
STIHL AK battery.
WARNING
■ Batteries and chargers not explicitly approved
for the blower by STIHL may cause a fire or
explosion. Persons may be seriously or fatally
injured, and property may be damaged.
►Use the blower with a STIHL AK battery.
►Recharge the STIHL AK bat‐
tery with a STIHL AL 101, AL
301 or AL 500 charger.
■Using the blower, battery or the charger for
purposes for which they were not designed
may result in serious or fatal injuries and dam‐
age to property.
►Use the blower, battery and charger as
described in this User Manual.
4.3 The Operator
WARNING
■ Users without adequate training or instruction
cannot recognize or assess the risks involved
in using the blower, battery and charger. The
user or other persons may sustain serious or
fatal injuries.
► Read, understand and save the
instruction manual.
► If you pass the blower, battery or the
charger on to another person: Always give
them the instruction manual.
►Make sure the user meets the following
requirements:
–The user must be rested.
–The user must be in good
physical condition and
mental health to operate
and work with the blower,
battery and charger. If the
user’s physical, sensory or
mental ability is restricted,
he or she may work only
under the supervision of or
as instructed by a respon‐
sible person.
–The user is able to recognize and
assess the risks involved in using the
blower, battery and charger.
English 4 Safety Precautions
4 0458-008-0101-A

–The user must be of legal
age or is being trained in a
trade under supervision in
accordance with national
rules and regulations.
–The user has received
instruction from a STIHL
servicing dealer or other
experienced user before
working with the blower for
the first time.
–The user must not be under the influ‐
ence of alcohol, medication or drugs.
► If you have any queries: Contact your
STIHL servicing dealer for assistance.
4.4 Clothing and Equipment
WARNING
■ Long hair can be sucked into the blower dur‐
ing operation. This can result in serious inju‐
ries.
► Tie up long hair so that it is above
shoulder level.
■ Objects can be thrown through the air at high
speed during operation. This can result in per‐
sonal injury.
► Wear close-fitting safety glasses.
Suitable glasses that have been tes‐
ted and labeled in accordance with
EN 166 or national standards are
available from retailers.
►Wear long trousers.
■ Dust can be whipped up during operation:
Whipped up dust can damage the respiratory
passages and cause allergic reactions.
►If dust is generated: Wear a dust respirator
mask.
■ Unsuitable clothing can snag on wood, brush
or the blower. Not wearing suitable clothing
may result in serious injury.
►Wear snug-fitting clothing.
► Do not wear a scarf or jewelry.
■ Wearing unsuitable footwear may cause you
to slip or stumble. This can result in personal
injury.
►Wear sturdy enclosed footwear with non-
slip soles.
4.5 Work Area and Surroundings
4.5.1 Blower
WARNING
■Bystanders, children and animals are not
aware of the dangers of the blower and
objects being thrown into the air and cannot
assess them. This may result in serious injury
to bystanders, children and animals and dam‐
age to property.
5m (17 ft)
► Do not allow bystanders,
children or animals within 5
meters of the work area.
► Maintain a clearance of 5 meters from
objects.
► Do not leave the blower unattended.
► Ensure that children cannot play with the
blower.
■ The blower is not waterproof. If you work in
the rain or in a damp environment, an electric
shock may occur. This can result in injuries to
the user and may damage the blower.
► Do not work in the rain or in a damp
environment.
■ Electrical components of the blower can pro‐
duce sparks. Sparks may cause fires and
explosions in highly flammable or explosive
environments. Persons may be seriously or
fatally injured and property may be damaged.
►Do not work in a highly flammable or explo‐
sive environment.
4.5.2 Battery
WARNING
■Bystanders, children and animals cannot rec‐
ognize or assess the dangers of the battery.
Bystanders, children and animals may be seri‐
ously injured.
►Keep bystanders, children and animals
away from the work area.
► Do not leave the battery unattended.
► Make sure that children cannot play with
the battery.
■ The battery is not protected against all ambi‐
ent conditions. If the battery is exposed to cer‐
tain ambient conditions, the battery may catch
fire, explode or be irreparably damaged. This
may result in serious injury to people and
damage to property.
4 Safety Precautions English
0458-008-0101-A 5

► Protect battery from heat and fire.
► Do not throw the battery into a fire.
► Do not charge, use and store the battery
outside of the specified temperature limits,
18.5.
► Protect the battery from rain and
moisture and do not immerse it in liq‐
uids.
► Keep battery away from small metal parts.
► Do not expose the battery to high pressure.
► Do not expose the battery to microwaves.
► Protect the battery from chemicals and
salts.
4.5.3 Charger
WARNING
■ Bystanders and children are not aware of and
cannot assess the dangers of a charger or
electric current. Bystanders, children and ani‐
mals may be seriously or fatally injured.
►Keep bystanders, children and animals
away from the work area.
►Make sure that children can‐
not play with the charger.
■The charger is not waterproof. If you work in
the rain or in a damp environment, an electric
shock may occur. The user may be injured
and the charger may be damaged.
► Do not operate it in the rain or in a
damp environment.
■ The charger is not protected against all ambi‐
ent conditions. If the charger is exposed to
certain ambient conditions, it may catch fire or
explode. This may result in serious injury to
people and damage to property.
►Operate the charger in an enclosed, dry
room.
► Do not operate the charger in a flammable
environment or in an explosive environ‐
ment.
►Do not operate the charger on a readily
combustible surface.
► Do not use and store the charger outside of
the specified temperature limits, 18.5.
■ The connecting cable is a trip hazard. People
may be injured and the charger may be dam‐
aged.
►Lay the connecting cable flat on the floor.
4.6 Safe Condition
4.6.1 Blower
The blower is in a safe condition if the following
conditions are fulfilled:
–The blower is undamaged.
–Blower must be clean and dry.
–The controls function properly and have not
been modified.
–Original STIHL accessories are fitted.
–The accessories are correctly attached.
WARNING
■ If not in safe condition, components may no
longer operate correctly and safety devices
may be disabled. This may result in serous or
fatal injury to people.
►Never use a damaged blower.
► If the blower is dirty or wet: Clean the
blower and allow it to dry.
► Do not modify the blower. Exception:
Mounting a nozzle approved for this blower
model.
►If the controls do not function properly: Do
not work with the blower.
► Fit original STIHL accessories designed for
this blower model.
► Attach accessories as described in this
User Manual or in the User Manual for the
accessories.
►Do not insert objects into the openings in
the blower.
► Replace worn or damaged labels.
► If you have any doubts, be sure to consult a
STIHL dealer.
4.6.2 Battery
The battery is in a safe condition if the following
points are observed:
–Battery is undamaged.
–The battery is clean and dry.
–Battery functions properly and has not been
modified.
WARNING
■A battery that is not in a safe condition cannot
operate safely. Persons may be seriously
injured.
►Never work with a damaged battery.
► Never attempt to charge a damaged or
defective battery.
► If the battery is dirty: Clean the battery.
► If the battery is wet or damp: Allow the bat‐
tery to dry, 18.6.
► Never attempt to modify the battery.
English 4 Safety Precautions
6 0458-008-0101-A

► Never insert objects in the battery’s open‐
ings.
► Never bridge the battery's contacts with
metallic objects (short circuit).
► Do not open the battery.
► Replace worn or damaged labels.
■ Fluid may leak from a damaged battery. If that
liquid comes into contact with the skin or eyes,
the skin or eyes may be irritated.
►Avoid contact with the liquid.
► If skin contact occurs: Wash affected areas
of skin with plenty of water and soap.
► In the event of contact with eyes: Rinse
eyes with plenty of water for at least
15 minutes and consult a doctor.
■A damaged or defective battery may smell
unusual, emit smoke or burn. Persons may be
seriously or fatally injured, and property may
be damaged.
►If the battery smells unusual or emits
smoke: do not use the battery and keep it
away from combustible substances.
►If the battery catches fire: Attempt to extin‐
guish the battery with a fire extinguisher or
water.
4.6.3 Charger
The charger is in a safe condition if the following
points are observed:
–Charger is undamaged.
–Charger is clean and dry.
WARNING
■If components do not comply with safety
requirements, they will no longer function
properly and safety devices may be rendered
inoperative. This can result in serious or fatal
injuries.
►Do not use a damaged charger.
► If the charger is dirty or wet: Clean the
charger and allow it to dry.
► Never attempt to modify the charger.
► Never insert objects in the charger’s open‐
ings.
► Never bridge the charger's contacts with
metallic objects (short circuit).
► Do not open the charger.
4.7 Operation
WARNING
■In certain situations the user may no longer be
able to concentrate on the job. The user may
trip, fall and be seriously injured.
►Keep calm and plan your work.
► In poor light conditions and poor visibility:
Do not operate the blower.
► Do not use the blower on your own.
► Do not work above shoulder height.
► Watch out for obstacles.
► Stand safely on the ground and keep your
balance. If you have to work at a height:
use a lift bucket or secure scaffolding.
►If you experience signs of fatigue: take a
break.
► Blow in direction of the wind.
■ Objects may be thrown into the air at high
speed while working. This can result in injuries
to persons and animals and damage to prop‐
erty.
► Do not direct air blast towards per‐
sons, pets and objects.
■ If the blower starts behaving differently or in
an unusual way while operating, the blower
may be in an unsafe condition. This can result
in serious injuries and damage to property.
►Stop working, remove the battery and con‐
sult a STIHL servicing dealer.
■ The blower may cause vibrations in operation.
► Take breaks.
► If signs of poor circulation appear: consult a
doctor.
■ The blower may become electrostatically
charged due to flying dust. Under certain envi‐
ronmental conditions (e.g. dry environment),
the blower may discharge suddenly resulting
in sparks. Sparks can cause fires and explo‐
sions in a flammable or explosive environ‐
ment. This can result in serious injuries or
death and damage to property.
► Do not work in a flammable environment or
in an explosive environment.
4.8 Charging
WARNING
■A damaged or defective charger may produce
an unusual smell or emit smoke during the
charging process. This may result in personal
injuries and damage to property.
►Disconnect the plug from the wall outlet.
■ The charger can overheat and cause a fire if
heat dissipation is inadequate. This can result
in serious or fatal injuries and damage to prop‐
erty.
►Do not cover the charger.
4 Safety Precautions English
0458-008-0101-A 7

4.9 Connecting to the power supply
Contact with live components may occur for the
following reasons:
–The connecting cable or the extension cord is
damaged.
–The mains plug of the connecting cable or
extension cord is damaged.
–The socket is not properly installed.
DANGER
■ Contact with live parts may result in electric
shock. This may result in serious or fatal injury
to the user.
►Make sure that the connecting cable, exten‐
sion cord and their mains plugs are undam‐
aged.
If the connecting cable or the extension
cord is damaged:
► Do not touch the damaged area.
► Disconnect the mains plug from the
power supply.
►Make sure your hands are dry before touch‐
ing the connecting cable, extension cord or
mains plugs.
►Plug the mains plug of the connecting cable
or extension cord into a properly installed,
shockproof socket with the correct fuse rat‐
ing.
►Install the charger with a ground fault circuit
interrupter (30 mA, 30 ms).
■ A damaged or unsuitable extension cable can
result in electric shock. There is a risk of seri‐
ous or fatal injury.
►Use an extension cable with the correct
cable cross-section, 18.4.
WARNING
■Overvoltage can occur in the charger if the line
voltage or frequency are incorrect during
charging. The charger may be damaged.
►Make sure that the mains voltage and the
mains frequency of the power supply match
the data on the rating plate of the charger.
■If the charger is connected to a power strip,
electrical components may be overloaded dur‐
ing the charging process. The components
may overheat and cause a fire. Persons may
be seriously or fatally injured, and property
may be damaged.
►Ensure that the technical specifications for
the power strip are not exceeded by the
information on the rating plate of the
charger and of all electrical devices connec‐
ted to the power strip.
■An incorrectly routed connecting cable or
extension cord may be damaged, and people
may trip over it. People may be injured, and
the connecting cable or extension cord may be
damaged.
►Route and mark the connecting cable and
extension cord so that people will not trip
over them.
►Route the connecting cable and extension
cord so that they are not under tension or
tangled.
►Route the connecting cable and extension
cord so that they will not be damaged,
kinked or crushed and will not be chafed.
►Protect the connecting cable and extension
cord from heat, oil and chemicals.
► Lay the connecting cable and extension
cord on a dry surface.
■ The extension cable warms up in operation. If
that heat cannot escape, it may cause a fire.
► If using a cable reel: completely unroll the
cable reel.
■ If wiring and pipes are laid in the wall, they
may be damaged if the charger is mounted on
the wall. Contact with wiring can result in elec‐
tric shock. This may result in serious injury to
people and damage to property.
►Make sure there is no wiring or pipes in the
wall at the proposed mounting site.
■ If the charger is not mounted on the wall as
described in this User Manual, the charger or
the battery may fall or the charger may over‐
heat. This may result in injury to people and
damage to property.
►Mount the charger on a wall as described in
this User Manual.
■ If the charger is mounted on a wall with the
battery inserted, the battery may fall out of the
charger. This may result in injury to people
and damage to property.
►Mount the charger on the wall first before
inserting the battery.
4.10 Transporting
4.10.1 Blower
WARNING
■The blower can turn over or move while being
transported. This may result in personal inju‐
ries and damage to property.
► Remove the battery.
► Secure the blower with lashing straps or a
net to prevent it turning over and moving.
English 4 Safety Precautions
8 0458-008-0101-A

4.10.2 Battery
WARNING
■The battery is not protected against all ambi‐
ent conditions. The battery may be damaged if
it is exposed to certain ambient conditions,
and damage to property may occur.
►Never transport a damaged battery.
■ The battery may turn over or shift during trans‐
port. This may result in injury to people and
damage to property.
►Pack the battery in packaging in such a way
that it cannot move.
► Secure the packaging so that it cannot
move.
4.10.3 Charger
WARNING
■ The charger may turn over or move while
being transported. This may result in personal
injuries and damage to property.
►Disconnect the plug from the wall outlet.
► Remove the battery.
► Secure the charger with lashing straps,
belts or a net to prevent it turning over and
moving.
■The connecting cable must not be used for
carrying the charger. The connecting cable
and the charger may be damaged.
►Wind up the connecting cable and attach it
to the charger.
4.11 Storing
4.11.1 Blower
WARNING
■Children are not aware of and cannot assess
the dangers of a blower and can be seriously
injured.
► Remove the battery.
► Store the blower out of the reach of chil‐
dren.
■ Dampness can corrode the electrical contacts
on the blower and metal components. The
blower may be damaged.
► Remove the battery.
► Store the blower in a clean and dry condi‐
tion.
4.11.2 Battery
WARNING
■Children are not aware of and cannot assess
the dangers of the battery Children may be
seriously injured.
►Store the battery out of the reach of chil‐
dren.
■ The battery is not protected against all ambi‐
ent conditions. If the battery is exposed to cer‐
tain ambient conditions, the battery may be
irreparably damaged.
►Store the battery in a clean and dry condi‐
tion.
► Store the battery in an enclosed space.
► Store the battery separately from the
blower.
► If the battery is stored in the charger, dis‐
connect the mains plug and store the bat‐
tery at a state of charge between 40% and
60% (2 lit green LEDs).
►Do not store the battery outside of the
specified temperature limits, 18.5.
4.11.3 Charger
WARNING
■ Children are not aware of and cannot assess
the dangers of a charger. Children can be seri‐
ously injured or killed.
►Disconnect the plug from the wall outlet.
► Store the charger out of reach of children.
■ The charger is not protected against all ambi‐
ent conditions. If the charger is exposed to
certain ambient conditions, the charger may
be damaged.
►Disconnect the plug from the wall outlet.
► If the charger is hot: Allow the charger to
cool down.
► Store the charger in a clean, dry place.
► Store the charger in an enclosed room.
► Do not store the charger outside of the
specified temperature limits, 18.5.
■ The connecting cable should not be used for
carrying the charger or hanging up the
charger. The connecting cable and the
charger may be damaged.
►Hold the charger by the housing in a secure
grip. The charger is provided with a handle
recess to make it easy to pick up the
charger.
►Hang the charger on the wall mounting.
4 Safety Precautions English
0458-008-0101-A 9

4.12 Cleaning, Maintenance and
Repair
WARNING
■If the battery is inserted when carrying out
cleaning, servicing or repairs, it is possible for
the blower to be switched on unintentionally.
This may result in serious injury to people and
damage to property.
► Remove the battery.
■ Sharp cleaning agents, cleaning with a water
jet or pointed objects can damage the blower,
the battery and the charger. If the blower, bat‐
tery or charger are not cleaned as described in
this instruction manual, components may no
longer function properly or safety devices may
be rendered inoperative. They may cause seri‐
ous injury to persons.
► Clean the blower, battery and charger as
described in this instruction manual.
■ If the blower, battery or charge are not serv‐
iced or repaired correctly, components may no
longer function properly or safety devices may
be rendered inoperative. This may result in
serous or fatal injury to people.
►Do not attempt to service or repair the
blower, battery or charger.
► If the blower, battery or the charger require
servicing or repairs: Contact your STIHL
servicing dealer for assistance.
5 Preparing the Blower for
Operation
5.1 Preparing the Blower for Oper‐
ation
The following steps must be performed before
commencing work:
► Ensure that the following components are in
safe condition:
–Blower, 4.6.1.
–Battery, 4.6.2.
–Charger, 4.6.3.
►Check the battery, 10.2.
►Fully charge the battery, 6.2.
►Clean blower, 15.1.
►Attach nozzle, 7.1.
►Check the controls, 10.1.
► If it is not possible to carry out these steps do
not use the blower. Consult a STIHL servicing
dealer.
6 Charging the Battery, LEDs
6.1 Mounting the Charger on a
Wall
The charger can be mounted on a wall.
d
a
12
a
e
e
b
3
0000099636_001
►Check the following points
when mounting the charger on
a wall:
–Suitable fixing materials.
–The charger is level.
The following dimensions are observed:
–a = at least 100 mm
–b (for AL 101) = 75 mm
–b (for AL 301) = 100 mm
–b (for AL 500) = 120 mm
–c = 4.5 mm
–d = 9 mm
–e = 2.5 mm
6.2 Charging the Battery
The charging time depends on various factors,
e.g. the battery temperature or the ambient tem‐
perature. For optimum performance, observe the
recommended temperature ranges, 18.6. The
actual charging time may vary from the charging
time indicated. The charging time is indicated at
www.stihl.com/charging-times.
The charging process starts
automatically when the mains
plug is plugged into a socket
and the battery is inserted into
the charger. The charger
switches off automatically when
the battery is fully charged.
The battery and the charger warm up during
charging.
English 5 Preparing the Blower for Operation
10 0458-008-0101-A

7
6
5
3
2
4
1
0000-GXX-0628-A0
► Plug the mains plug (6) into an easily accessi‐
ble socket (7).
The charger (3) will run a self-test. The
LED (4) will glow green for about 1 second
and red for about 1 second.
► Routing the connecting cord (5).
► Insert the battery (2) in the guides in the
charger (3) and press it home as far as stop.
The LED (4) glows green. The LEDs (1) glow
green and the battery (2) is being charged.
► When the LED (4) and the LEDs (1) on the
battery no longer light up: The battery (2) is
fully charged and can be removed from the
charger (3).
► If the charger (3) is no longer required. Dis‐
connect the mains plug (6) from the wall outlet
(7).
6.3 State of Charge
1
0000-GXX-0629-A0
20-40%
40-60%
60-80%
80-100%
0-20%
► Press the button (1).
The LEDs (5) glow green for about 5 seconds
and indicate the state of charge.
► If the LED on the right flashes green: Charge
the battery.
6.4 LEDs on Battery
The LEDs can show the state of charge or mal‐
functions. The LEDs can glow or flash green or
red.
The state of charge is indicated when the LEDs
glow or flash green.
► If the LEDs glow or flash red: Troubleshooting,
17.1.
Malfunction in blower or battery.
6.5 LED on Charger
The LED indicates the operating status of the
charger.
If the LED glows green, the battery is being
charged.
► If the LED flashes red: Rectify the malfunction.
Malfunction in charger.
7 Assembling the Blower
7.1 Mounting, Adjusting and
Removing the Nozzle
The nozzle can be attached to the blower tube in
3 positions, depending on the height of the user.
The positions are marked on the blower tube.
► Switch off the blower and remove the battery.
23
1
0000099079_001
► Depress the retaining latch (1) and hold it
depressed.
► Push nozzle (3) into required position on
blower tube (2).
► Release the retaining latch (1).
Move the nozzle (3) back and forth until the
lever (1) engages.
8 Removing and Fitting the
Battery
8.1 Fitting the Battery
2
3
1
0000-GXX-0621-A0
7 Assembling the Blower English
0458-008-0101-A 11

► Insert the battery (1) in the battery compart‐
ment (2) and press it home until you hear a
click.
Arrows (3) on battery (1) are still visible and
battery (1) is held securely in battery compart‐
ment (2). There is no electrical contact
between blower and battery (1).
► Push the battery (1) into the battery compart‐
ment (2) as far as stop.
The battery (1) engages with a second click
and is flush with the blower’s housing.
8.2 Removing the Battery
► Place blower on a level surface.
► Keep one hand in front of the battery compart‐
ment so that the battery (2) cannot fall out.
1
2
0000099080_001
► Press the locking lever (1) with your other
hand.
The battery (2) is released and can be
removed.
9 Switching the Blower
On/Off
9.1 Switching On the Blower
► Hold the blower by the control handle with one
hand, wrapping your thumb around the control
handle.
1
3
2
0000-GXX-9903-A0
► Slide the unlocking slide (1) with your thumb in
the direction of the blower tube and keep it
held.
► Squeeze and hold the trigger (2) with your
index finger.
The blower accelerates and air flows out of the
nozzle. The release slide (1) can be released.
The further the trigger switch (2) is depressed,
the more air flows out of the nozzle.
If the ergo lever (3) is pressed, the trigger switch
(2) remains unlocked. This means the trigger can
be released and depressed again without having
to push the release slide in the direction of the
blower tube.
If the trigger switch (2) and the ergo lever (3) are
released, the trigger switch (2) is locked. The
unlocking slide (1) must be slid in the direction of
the blower tube once more and held, to unlock
the trigger switch (2).
9.2 Switching Off
► Release the trigger.
No air flows from the nozzle.
► If air continues to flow from nozzle: Remove
the battery and contact your STIHL servicing
dealer.
Blower has a malfunction.
10 Testing the Blower and
Battery
10.1 Checking the controls
Release slide, Ergo lever and trigger
► Remove the battery.
► Try squeezing the trigger switch without acti‐
vating the release slide.
► If the trigger switch can be squeezed: Do not
use the blower. Consult a STIHL servicing
dealer.
The release slide is faulty.
► Slide the unlocking slide with the thumb in the
direction of the blower tube and keep it held.
► Press and hold Ergo lever.
► Press the trigger.
The release slide can be released.
► Release the trigger and the Ergo lever.
► If release slide, trigger or Ergo lever is stiff or
does not spring back to the initial position:
Stop using the blower and contact a STIHL
dealer.
The release slide, trigger or the Ergo lever is
defective.
Switching On the Blower
► Insert battery.
► Push unlocking slide towards the blower tube
and hold in place.
► Press and hold the trigger.
Air flows out of the nozzle.
English 9 Switching the Blower On/Off
12 0458-008-0101-A

► If 3 LEDs flash red: Remove the battery and
consult a STIHL dealer.
There is a fault in the blower.
► Release the trigger.
Air stops flowing out of the nozzle.
► If air continues to flow out of the nozzle:
Remove the battery and consult a STIHL serv‐
icing dealer.
The blower is faulty.
10.2 Testing the Battery
► Press button on battery.
The LEDs glow or flash.
► If the LEDs do not glow or flash: Do not use
the battery and contact your STIHL servicing
dealer.
There is a malfunction in the battery.
11 Operating the Blower
11.1 Holding and Guiding the
Blower
0000099081_001
► Carry the blower on your back.
► Hold and guide the blower with one hand on
the control handle and wrap your thumb
around the control handle.
11.2 Blowing
0000099082_001
► Point the nozzle at the ground.
► Walk forward slowly and steadily.
For optimum performance, observe the recom‐
mended temperature ranges, 18.6.
12 After Finishing Work
12.1 After Finishing Work
► Turn off the blower and remove the battery.
► If the blower is wet: Allow the blower to dry.
► If the battery is moist or wet: Allow the battery
to dry, 18.6.
► Clean the blower.
► Clean the battery.
13 Transporting
13.1 Transporting the Blower
► Switch off the blower and remove the battery.
Carrying the Blower
► Carry the blower by the control handle.
Transporting the Blower in Vehicles
► Secure the blower to prevent turnover and
movement.
13.2 Transporting the battery
► Turn off the blower and remove the battery.
► Check that the battery is in a safe condition.
► Pack the battery in packaging in such a way
that it cannot move inside the packaging.
► Secure the packaging so that it cannot move.
The battery is subject to the Carriage of Danger‐
ous Goods regulations. The battery is classified
as UN 3480 (lithium ion batteries) and has been
tested pursuant to UN Manual Tests and Criteria
Part III, Subsection 38.3.
The transport regulations can be found at
www.stihl.com/safety-data-sheets.
13.3 Transporting the Charger
► Disconnect the plug from the wall outlet.
► Remove the battery.
► Wind up the connecting cable and attach it to
the charger.
► Transporting the charger in a vehicle: Secure
the charger with lashing straps, belts or a net
to prevent it turning over and moving.
14 Storing
14.1 Storing the Blower
► Switch off the blower and remove the battery.
► Observe the following points when storing the
blower:
–Blower is out of the reach of children.
–Blower is clean and dry.
11 Operating the Blower English
0458-008-0101-A 13

14.2 Storing the Battery
STIHL recommends keeping the battery in a
charging state between 40% and 60 % (2 green
LEDs lit).
► The battery should be stored in such a way
that the following conditions are fulfilled:
–The battery is out of the reach of children.
–The battery is clean and dry.
–The battery is in an enclosed space.
–Battery is stored separately from the blower.
–If the battery is stored in the charger, dis‐
connect the mains plug and store the bat‐
tery at a state of charge between 40% and
60% (2 lit green LEDs).
–Do not store the battery outside of the
specified temperature limits, 18.5.
NOTICE
■ If the battery is not stored as described in this
User Manual, the battery may become deeply
discharged and irreparably damaged.
►Charge a discharged battery before storing
it. STIHL recommends keeping the battery
state of charge between 40% and 60% (2 lit
green LEDs).
►Store the battery separately from the
blower.
14.3 Storing the Charger
► Disconnect the mains plug from the power
supply.
2
1
0000-GXX-0592-A1
3
► Wind up the connecting cable and attach it to
the charger.
► Observe the following points when storing the
charger:
–Charger is out of the reach of children.
–The charger is clean and dry.
–Charger is in an enclosed space.
–The charger is not suspended from the con‐
necting cable or the holder (3) for the con‐
necting cable.
–Do not store the charger outside of the
specified temperature limits, 18.5.
15 Cleaning
15.1 Cleaning the blower
► Switch off the blower and remove the battery.
► Clean blower with a damp cloth.
► Clean vents with a paintbrush.
► Clean the shield with a paintbrush or soft
brush.
► Remove foreign objects from the battery com‐
partment and clean the battery compartment
with a damp cloth.
► Clean the electrical contacts in the battery
compartment with a paintbrush or soft brush.
15.2 Cleaning the Battery
► Clean the battery with a damp cloth.
15.3 Cleaning the Charger
► Disconnect the mains plug from the power
supply.
► Clean the charger with a damp cloth.
► Clean vents with a paintbrush.
► Clean the charger’s electrical contacts with a
paintbrush or a soft brush.
16 Maintenance and Repairs
16.1 Servicing and Repairing the
Blower
The blower cannot be serviced or repaired by the
user.
► If your blower has a malfunction or is dam‐
aged or requires servicing: Contact your
STIHL servicing dealer.
16.2 Servicing and Repairing the
Battery
The battery requires no servicing and cannot be
repaired.
► If the battery has a malfunction or is damaged:
Replace the battery.
16.3 Servicing and Repairing the
Charger
The charger requires no servicing and cannot be
repaired.
►If the charger has a malfunc‐
tion or is damaged: Replace
the charger.
English 15 Cleaning
14 0458-008-0101-A

►If the connecting cable has a
malfunction or is damaged: Do
not use the charger and have
connecting cable replaced by a
STIHL servicing dealer.
17 Troubleshooting
17.1 Troubleshooting the Blower or Battery
Fault LEDs on the
battery
Cause Remedy
The blower does
not start when
switched on.
1 LED flashing
green.
State of charge of the
battery is too low.
► Charge the battery.
1 LED emits
red light.
The battery is too
warm or too cold.
► Remove the battery.
► Allow the battery to cool down or warm
up.
3 LEDs flash
red.
There is a fault in the
blower.
► Remove the battery.
► Clean electrical contacts in the battery
compartment.
► Insert battery.
► Switch on blower.
► If 3 LEDs continue to flash red: Do not
use the blower and contact your STIHL
dealer for assistance.
3 LEDs light up
red.
The blower is too
warm.
► Remove the battery.
► Allow the blower to cool down.
4 LEDs
flash red.
There is a fault in the
battery.
► Remove battery and reinsert it.
► Switch on blower.
► If 4 LEDs continue to flash red: Do not
use the battery; contact a STIHL author‐
ized dealer.
There is a break in the
electrical connection
between the blower
and the battery.
► Remove the battery.
► Clean electrical contacts in the battery
compartment.
► Insert battery.
The blower or the bat‐
tery is damp.
►Allow blower or battery to dry, 18.6.
The blower
switches off
while in opera‐
tion.
3 LEDs light up
red.
The blower is too
warm.
► Remove the battery.
► Allow the blower to cool down.
There is an electrical
fault.
► Remove battery and reinsert it.
► Switch on blower.
The blower oper‐
ating time is too
short.
The battery is not fully
charged.
► Fully charge the battery.
The battery service
life has been excee‐
ded.
► Replace battery.
Charging does
not start when
the battery is
inserted into the
charger.
1 LED emits
red light.
The battery is too
warm or too cold.
► Leave battery inserted in charger.
Charging starts automatically as soon as
the permitted temperature range is
reached.
17 Troubleshooting English
0458-008-0101-A 15

17.2 Troubleshooting the Charger
Fault LED on
Charger
Cause Remedy
Battery not being
charged.
The LED
flashes red.
No electrical contact
between charger and
battery.
► Remove the battery.
► Clean contacts on charger.
► Insert battery.
There is a malfunction
in the charger.
► Do not use the charger and contact your
STIHL dealer for assistance.
18 Specifications
18.1 STIHL BGA 60 Blower
–Approved battery: STIHL AK
–Blowing force: 15 N
–Maximum air velocity: 69 m/s
–Average air velocity: 58 m/s
–Air throughput rate: 780 m³/h
–Weight without battery: 2.3 kg
Consult www.stihl.com/battery-life for the respec‐
tive running time.
18.2 STIHL AK Battery
–Battery technology: lithium-ion
–Voltage: 36 V
–Capacity in Ah: see rating label
–Energy content in Wh: see rating label
–Weight in kg: See rating label
18.3 STIHL AL 101 Charger
–Rated voltage: See rating plate
–Frequency: see rating plate
–Rated power: see rating plate
–Charging current: See rating plate
For charging times, see www.stihl.com/charging-
times.
18.4 Extension Cords
If an extension cord is used, the cross sectional
area of its conductors must meet the following
minimum requirements – depending on the line
voltage and length of the extension cord:
If rated voltage on the rating label is 220V to
240V:
–Cord length up to 20 m: AWG 15 / 1.5 mm²
–Cord length 20 m up to 50 m: AWG 13 /
2.5 mm²
If rated voltage on the rating label is 100V to
127V:
–Cord length up to 10 m: AWG 14 / 2.0 mm²
–Cord length 10 m up to 30 m: AWG 12 /
3.5 mm²
18.5 Temperature limits
WARNING
■ The battery is not protected against all ambi‐
ent conditions. If the battery is exposed to cer‐
tain environmental conditions, it may catch fire
or explode. This may result in serious injury to
people and damage to property.
►Do not charge the battery below -20°C or
above +50°C.
► Do not use the blower, battery or charger
below -20°C or above +50°C.
► Do not store the blower, battery or charger
below -20°C or above +70°C.
18.6 Recommended temperature
ranges
For optimum performance of the blower, battery
and charger, observe the following temperature
ranges:
–Charging: 5°C to 40°C
–Use: - 10 °C to + 40 °C
–Storage: - 20 °C to + 50 °C
If the battery is charged, used or stored outside
the recommended temperature ranges, perform‐
ance may be reduced.
If the battery is wet or moist, allow the battery to
dry for at least 48 h between 15°C and 50°C and
with less than 70% humidity. Higher humidity
may extend the drying time.
18.7 Sound Values and Vibration
Values
The K-value for sound pressure levels is 2 dB(A).
The K-value for sound power levels is 2 dB(A).
K-value for vibration level is 2 m/s².
–Sound pressure level Lp measured according
to EN 50636-2-100: 76 dB(A).
–Sound power level LwA measured as specified
in EN 50636-2-100: 89 dB(A).
–Vibration level ahv measured according to
EN 50636-2-100, control handle: < 1.2 m/s².
English 18 Specifications
16 0458-008-0101-A

The vibration levels indicated were measured
according to a standardized test method and can
be used as a basis for comparing electric power
tools. The vibration levels actually occurring may
vary from the values indicated, depending on the
type of application. The vibration levels indicated
can be used for an initial estimate of the vibration
stress. The actual vibration stress has to be esti‐
mated. The times when the electric power tool is
switched off and the times when it is switched on
but running under no load can be taken into
account in the estimate.
For information on compliance with Employers'
Vibration Directive 2002/44/EC see
www.stihl.com/vib.
18.8 REACH
REACH is an EC regulation and stands for the
Registration, Evaluation, Authorisation and
Restriction of Chemical substances.
For information on compliance with the REACH
regulation see www.stihl.com/reach.
19 Spare Parts and Accesso‐
ries
19.1 Spare parts and accessories
These symbols indicate original STIHL
spare parts and original STIHL acces‐
sories.
STIHL recommends the use of original STIHL
spare parts and accessories.
Despite ongoing market observation, STIHL is
unable to judge the reliability, safety and suitabil‐
ity of other manufacturers' spare parts and
accessories; accordingly, STIHL cannot warrant
for the use of those parts.
Original STIHL spare parts and original STIHL
accessories are available from STIHL dealers.
20 Disposal
20.1 Disposal of Blower, Battery and
Charger
Contact the local authorities or your STIHL
dealer for information on disposal.
Improper disposal can be harmful to health and
pollute the environment.
► Take STIHL products including packaging to a
suitable collection point for recycling in accord‐
ance with local regulations.
► Do not dispose with domestic waste.
21 EC Declaration of Con‐
formity
21.1 STIHL BGA 60 Blower
ANDREAS STIHL AG & Co. KG
Badstraße 115
D-71336 Waiblingen
Germany
declares under our sole responsibility that
–Type: Cordless blower
–Manufacturer's brand: STIHL
–Model: BGA 60
–Serial number: BA04
conforms to the specifications of Directives
2011/65/EU, 2006/42/EC, 2014/30/EU and
2000/14/EC and has been developed and built in
compliance with the versions of the following
standards valid at the production date:
EN 55014‑1, EN 55014‑2, EN 60335‑1 and
EN 50636‑2‑100.
The measured and guaranteed equivalent sound
power level has been determined in accordance
with Directive 2000/14/EC, Annex V.
–Measured sound power level: 89 dB(A)
–Guaranteed sound power level: 91 dB(A)
The technical documents are stored at
ANDREAS STIHL AG & Co. KG Produktzulas‐
sung.
The year of construction, the country of manufac‐
ture and the machine number are shown on the
blower.
Waiblingen, 2022-08-01
ANDREAS STIHL AG & Co. KG
pp
Robert Olma, Vice President, Regulatory Affairs
& Global Governmental Relations
22 UKCA Declaration of Con‐
formity
22.1 STIHL BGA 60 Blower
ANDREAS STIHL AG & Co. KG
Badstraße 115
D-71336 Waiblingen
19 Spare Parts and Accessories English
0458-008-0101-A 17

Germany
declares under our sole responsibility that
–Type: Cordless blower
–Manufacturer's brand: STIHL
–Model: BGA 60
–Serial number: BA04
conforms to the relevant provisions of UK regula‐
tions The Restriction of the Use of Certain Haz‐
ardous Substances in Electrical and Electronic
Equipment Regulations 2012, Supply of Machi‐
nery (Safety) Regulations 2008, Electromagnetic
Compatibility Regulations 2016 and Noise Emis‐
sion in the Environment by Equipment for use
Outdoors Regulations 2001 and has been manu‐
factured in compliance with the following stand‐
ards in the versions valid on the date of produc‐
tion: EN 55014‑1, EN 55014‑2, EN 60335‑1 and
EN 50636‑2‑100.
The measured and guaranteed sound power lev‐
els have been determined in accordance with UK
regulations Noise Emission in the Environment
by Equipment for use Outdoors Regulations
2001, Schedule 8.
–Measured sound power level: 89 dB(A)
–Guaranteed sound power level: 91 dB(A)
The technical documents are stored at
ANDREAS STIHL AG & Co. KG.
The year of construction, the country of manufac‐
ture and the machine number are shown on the
blower.
Waiblingen, 2022-08-01
ANDREAS STIHL AG & Co. KG
pp
Robert Olma, Vice President, Regulatory Affairs
& Global Governmental Relations
English 22 UKCA Declaration of Conformity
18 0458-008-0101-A

22 UKCA Declaration of Conformity English
0458-008-0101-A 19

www.stihl.com *04580080101A*
*04580080101A*
0458-008-0101-A
0458-008-0101-A
