STO N SHO SNS 154 Reference guide

Installation Procedures
2017-2022 Jeep Grand Cherokee Limited,
Laredo, Trail Hawk & Altitude
(Including “L” models)
SNS 154

Warning: Please read directions completely before starting. If you have any
questions, please contact STO N SHO LLC before beginning your installation. Also
please check our website (www.stonsho.com)for any updates or changes. Thank
You.
Parts Included: License Plate mounting bracket Assembly. Includes Base Plate and
License Plate Holder
License Plate Mounting Screws: (4) 6mm X 10mm (Phillips head) screw
and 6mm acorn nut (10mm wrench size)
Base plate mounting screws: (2) 6.3mm X 20mm
Tools Needed: 10mm sockets with ratchet Note: 1/4-inch drive preferred but
3/8 will work but extra caution will be needed when tightening screws
Phillips screwdriver and 10mm wrench
1/8 inch drill bit and drill
Step 1: Ensure all parts listed above are accounted for. Note: If at any time during the
installation process you need assistance please call [phone].
Step 2: Separate the license plate holder from the base by simply pulling the pull pin ring
outward and sliding apart.
Step 3: Center base plate on bumper and up against back edge as shown in figure 1. Base plate
will be properly aligned when base plate is centered on bumper and the back of the front plate
holder sits approximately ¼” from the bump. See figure 2. Note: If the vehicle is equipped with
adaptive cruise control, the bracket must be mounted either left or right of center.
Step 4: Once base plate is correctly positioned and while holding the plate in place, carefully
drill one pilot hole for the rear mounting screw. See figure 3.
Step 5: Using a 6.3mm X 20mm screw, secure the rear of base plate to the vehicle using the
following method. Caution: When tightening the screw, extreme care should be taken not to
over tighten screw, or the hole may become stripped and lose its ability to secure the base
plate. Place the screw into the 10mm socket and begin to tighten. Once the screw is flush with
the plate stop. Now tighten screw one half turn and stop.
Step 6: Verify alignment with front license plate bracket in place. If alignment is correct remove
front license plate bracket and drill pilot hole for front hole and follow step 5 for tightening.

Step 7: Secure the license plate and frame (optional) to the license plate bracket using the
screws and nuts provided. NOTE: Philips screws are inserted through the back of the front
plate and acorn nuts is used on the front. Failure to follow this procedure will result in
damage to the front bumper. Requires the Phillips screwdriver and 10mm wrench (Not
included).
Step 8: Slide the license plate rods into the two tubes located on the base plate. Slide the rods
into the tubes until the rods hit the pull pin. Simply pull the ring on the pull pin and advance the
rods. Release ring and continue to advance rods until the pull pin locks into place. See figure 4.
NOTE: The rods and spring-loaded pull pin are required to be sprayed periodically with WD-40
or any other silicone type spray lube. Failure to do so could result in either the failure of the
pull pin or the rods becoming difficult to remove or reinsert. Note: In harsh environments,
such as areas where roads are either salted or sanded in the winter, spraying of the rods and
pull pin should be performed on a regular basis. Failure to provide this maintenance may void
your warranty. On some occasions the license plate may require a little adjustment to level.
Simply pull pin and slide plate out approximately two inches, grab frame at arrows (See figure
5) and rotate. If the plate is high on left or right side, rotate high side down slightly and release.
Verify alignment and repeat as necessary. Once leveled plate will remain level.
Congratulations! You have just installed the STO N SHOTM (Patented) front license plate
mounting system. Thank You for your purchase.
Caution: Bracket lowers ground clearance by approx. 1/2 inch
Remove prior to entering automated car wash
Exercise care when entering or exiting steep driveways or damage will occur
Parking Stops or high curbs, stop well before or damage will occur
Remove prior to running on track or racing
Medium skill level required. If unsure, have bracket installed by your local Dealer or Body shop.
Limited Lifetime Warranty (Excluding Pull-pin). Pull pin will be warrantied for a period of 1 year
(12 months) from the date of purchase.
STO N SHO LLC warrants to the original purchaser only that this product will be free of
manufacturing defects in material and workmanship for the life of the product (Excluding pull-
pin, see above) provided all maintenance is performed as required to the limitations and
exclusions set forth below:

Return product to any authorized dealer. Contact STO N SHO LLC for the dealer nearest you.
Upon examination, STO N SHO LLC or its representative will, at its sole option and expense,
repair or replace any product found to be defective. If product to be replaced via mail, STO N
SHO LLC will return the repaired or replaced unit to you via its usual shipping method from the
factory to your address in the United States of America or Canada only. Any shipping costs for
addresses outside of the United States or Canada shall be the responsibility of the purchaser.
This warranty is not transferable.
REMEDIES FOR BREACH OF WARRANTY.
This Warranty does not include repair for damage caused by improper use or handling,
including but not limited to damage caused by accident, mishandling, improper installation,
abuse, negligence, or any defect caused by repair to the product by anyone other than STO N
SHO LLC.
This warranty does not cover reimbursement for your costs of removing and transporting the
product for warranty service evaluation, or installation of any replacement product provided
under this warranty.
This Warranty will be void if the product was not purchased from an authorized dealer or
reseller.
THE FOREGOING WARRANTIES ARE EXCLUSIVE AND IN LIEU OF ALL OTHER EXPRESSED AND
IMPLIED WARRANTIES. ALL SUCH OTHER WARRANTIES, INCLUDING BUT NOT LIMITED TO
IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NON-
INFRINGEMENT, WITH RESPECT TO THE PRODUCT. TO THE MAXIMUM EXTENT PERMITTED BY
LAW, STO N SHO LLC SHALL NOT BE RESPONSIBLE FOR ANY INCIDENTAL OR CONSEQUENTIAL
DAMAGES EXCEPT TO THE EXTENT PROVIDED (OR PROHIBITED) BY APPLICABLE LAW, EVEN IF
STO N SHO LLC HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Notwithstanding the above, if you qualify as a “consumer” under the Magnuson-Moss
Warranty Act, or applicable state laws, then you may be entitled to any implied warranties
allowed by law for the Warranty Period. Further, some states do not allow limitations on how
long an implied warranty lasts or allow the exclusion or limitation of consequential damages, so
such limitations may not apply to you. This warranty gives you specific legal rights, and you may
also have other rights which vary from state to state.
For the name of your nearest authorized STO N SHO dealer, contact: STO N SHO LLC at (408)
776-4080 or go to www.stonsho.com.

Fig 1
Fig 2

Fig 3
Fig 4

Fig 5
