Stoane Lighting Frog Type X User manual

Stoane Lighting Ltd
20 Dryden Road Bilston Glen Ind Est.
Loanhead Midlothian EH20 9LZ UK
T: [phone]
F: [phone]
[email protected]
www.stoanelighting.com
VAT No GB682885284
Limited Company 188910
Frog Type X Spike
Installation and Maintenance
Instructions
IMPORTANT: All wiring connections must be made before switching on mains power.
European Conformity
Please retain these instructions for future reference
This product should not be disposed of in your general waste IP66 Dust tight and protected against powerful jets of water.
Class III - Extra Low Voltage
Xicato LED Module
All of our in-house printed paper
is 100% recycled and recyclable
Frog X Spike.pdf 1 09/03/2021 13:10:29

Electrical Supply
Installation must be carried out by a qualified electrician in
accordance with BS 7671:2008 Wiring Regulations.
230/240V AC 50/60Hz mains supply to a suitable SELV
LED Driver.
Site conditions: LED equipment is more susceptible to
static damage and over voltage than previous technology.
Before handling or connecting to the mains supply ensure
that all Stoane Lighting (SL) products are protected from
static discharge and that the mains supply is to regulation.
(230V +10 -6%)
This fitting is supplied with a Xicato LED module. Refer to
the fitting label for the module version and wattage. More
information on the module can be found at
www.xicato.com/support
Mains cables must be double insulated, strain relieved
and separated from E.L.V output cables.
If using the Xicato XTM Module;
This unit requires a constant current driver. 700mA Max.
If using the Xicato XIM Module;
This unit requires a 48V constant voltage PSU.
Observe polarity:
Positive (+) is marked as RED.
Incorrect supply or reverse polarity can cause irreparable
damage.
All connections must be made before switching on mains.
If the supply is energised prior to making the connections
to the fitting then the resulting surge will damage the LED.
Maintenance:
All lighting equipment is delicate and easily damaged
through misuse or inappropriate installation (mechanical
or electrical). Repairs and replacements may cause
delays and will be chargeable. Contact SL for support if
required.
All Stoane Lighting products are covered by a five year
Warranty and a 25 year Duty of Care. Products are
designed to be upgraded, adapted and refreshed using
our comprehensive ReNew service. For more information
on our ReNew service and for full Warranty terms and
conditions visit stoanelighting.com or contact us at the
address shown.
The light source contained in this luminaire shall only be
replaced by the manufacturer or his service agent or a
similar qualified person.
Installation
Check that the mounting surface is suitable for the
installation of this fitting. For hard ground some
preparation may be required for spike installation.
Step 1 Make mains connections to SELV LED driver
and extra low voltage connections to the
fitting.
Step 2 Push the spike on the fitting into the ground
until it securely stands. Do not apply force to
the head when placing in the ground.
Adjust the pan and tilt by loosening the locks
using a 2.5mm Allen key. Tighten once all
adjustments are made.
After opening the sealed portion of the luminaire for
any reason, SL recommends running the fitting for 15
minutes with the lid open to expel moisture before
closing it up. This will prevent condensation on the
lens and protect the fitting from corrosion.
Ensure supply driver and connectors are housed
indoors OR in a suitably IP rated enclosure. Cable
ends must be suitably waterproofed. Inspect supply
cables before installation to ensure there is no
damage which will allow water to enter the fitting.
Care must be taken when handling any ingress
protection seals, glands or "O" rings to ensure they
are kept clean, unblemished and replaced exactly in
their required location and suitably fastened home.
The IP rating stated is applicable only when the fitting
has been installed as per these instructions.
WARNING: Do not look at exposed LED lamps in
operation. Eye injury can result.
Cleaning:
Fully isolate the fitting and allow to cool.
Clean the fitting with a slightly damp lint free cloth
from a mild solution of soap and water. The fitting
must be completely dry before reconnecting power.
Incompatible or abrasive chemicals can damage the
fitting, contact SL for advice if required.
Frog X Spike.pdf 2 09/03/2021 13:10:29

2
Pan lock
Tilt lock
Soft ground
1
2
3
Bezel
Accessories
Spacer
Reflector
MODULE AND ACCESSORIES
The fitting uses a Xicato LED module. The colour
temperature and lumen output can be found on the
product label on the fitting.
To Add/Remove accessories:
Isolate the fitting from the supply and allow to cool.
Step 1 Remove the bezel from the lamp tube by
unscrewing in an anti-clockwise direction.
Step 2 Insert/remove any accessories or reflectors.
Step 3 Refit the bezel by rotating it on in a clockwise
direction.
Frog X Spike.pdf 3 09/03/2021 13:10:29

Stoane Lighting firmly believe that we have a responsibility as environmental
custodians, we believe that lighting equipment should be built to last, to be
repaired and to be reused. As a BCorp we have pledged to operate a business not
aiming to just be best in the world but a business best for the world. Stoane
Lighting believe that the circular economy is a fundamental aspect of how we
approach the challenges we face. If you read this at the end of the product life we
encourage you to consider how you can ensure this product sees an extended life.
If removal is unavoidable, please see the disassembly note below.
All Stoane Lighting products are supplied with a 5 year warranty and a 25 year
duty of care.
Stoane Lighting operate a ReNew division, which can take your existing fittings
and refurbish or upgrade without the need for replacing what you already have.
Through the ReNew service, Stoane Lighting provides general repair, deep cleans
and electrical safety checks on luminaires, as well as possible repainting if needed.
We will replace components that are nearing end of life, such as drivers, LEDs,
and optics. If the fittings are to be used in a new area, or the existing space is
undergoing a change in use, ReNew can offer a different mounting method or light
technical performance (such as colour tuning), if needed, alongside the addition of
on-board wireless control. ReNew as a service, depending on location, can be
done on site or by returning equipment to Stoane Lighting.
Once fittings have been repaired or upgraded through ReNew, they will start a new
five-year warrantly period, and any unwanted parts will be recycled.
Product Disassembly and Component Recylcing - While every effort has been
made to ensure that our products are built to last and are ReNewable, there may
come a point when, as a very last resort, the fittings need to be recycled. Stoane
Lighting can provide information on how the fitting can easily be disassembled into
its component parts for more effective recyling. Information on recyling services in
your local region can also be supplied on request.
For more information on the above please visit stoanelighting.com
or contact us at the address shown.
