Stoll Grate Heater Series User manual

Owners Manual
-Parts List, Installation, Operating Instructions, Warranties -
Publication #: 881
Grate Heater Details
Model Depth Height Width
GH2017 17” 1-3/8” 20”
GH2420 20” 1-3/8” 24”
GH2422 22” 1-3/8” 24”
Warranties
FIVE YEAR LIMITED WARRANTY FOR METAL FRAME & CONSTRUCTION
Stoll Fireplace, Inc. warrants this product to the original retail purchaser against defects in the metal
materials and workmanship for a period of five years from date of the original retail purchase. Stoll
Fireplace, Inc. will replace, at no charge to the original retail purchaser, any part that fails due to a
defect in materials or workmanship.
This warranty covers only parts and applies only to products purchased for consumer use. This
warranty does not cover damage which occurs in transit or results from alteration, accident, misuse,
abuse , or improper installation. It also makes no warranty as to maximum temperature and
stresses which may cause discoloration of the brass. Stoll Fireplace, Inc. shall not be liable for
consequential or indirect damages which are caused by defects in its product, by its repair or re-
placement. Some states do no allow the exclusion or limitation of incidental or consequential dam-
ages. In such cases, the exclusion or limitation may not apply.
The implied warranties of merchantability and fitness for a particular purpose which may arise under
state law are also limited in duration to five years from the original purchase of this product. Some
states do not allow such limitations, in which case this limitation may not apply.
ONE YEAR LIMITED WARRANTY FOR ELECTRONICS
Stoll Fireplace, Inc. warrants this product to the original retail purchaser against manufacturing de-
fects in the glass and electronics (switches, motor, cord) for a period of one year from date of the
original retail purchase. Stoll Fireplace, Inc. will replace, at no charge to the original retail pur-
chaser, any part that fails due to a manufacturing defect.
This warranty covers only parts and applies only to products purchased for consumer use. This
warranty does not cover any damage which occurs in transit or results from alteration, accident,
misuse, abuse, or improper installation. Neither does it cover glass damaged due to extreme heat,
puncture, or other abuse; or damage to electronics due to faulty site wiring, incorrect installation, or
extreme heat. Stoll Fireplace, Inc. shall not be liable for consequential or indirect damages which
are caused by defects in its product, by its repair or replacement. Some states do no allow the
exclusion or limitation of incidental or consequential damages. In such cases, the exclusion or limi-
tation may not apply.
The implied warranties of merchantability and fitness for a particular purpose which may arise under
state law are also limited in duration to one year from the original purchase of this product. Some
states do not allow such limitations, in which case this limitation may not apply.
If you need to take advantage of these limited warranties during the warranted period, simply bring
the part to your Stoll Fireplace, Inc. dealer for adjustment. Proof of the original purchase date will
be required in order for you to take advantage of the limited warranty.
If you have questions or problems with your warranties, please contact us.
Stoll Fireplace, Inc | 153 Hwy. 201 | Abbeville, SC 29620
800-421-0771 | www.stollfireplaceinc.com
Grate Heater
For wood-burning masonry fireplaces
NorthlineExpress.com
http://www.northlineexpress.com
Toll-Free 1-866-667-8454

Installation
Incorrect installation or unheeded warnings could result in
a serious fire, and loss of life and property.
 Product is NOT designed for installation in “zero-clearance” fireboxes
or mobile homes, or in conjunction with gas log sets.
 Inspect the chimney flue and fireplace for loose mortar, damaged
brick, and creosote build-up. Contact a professional chimney sweep or
building contractor for more information or repair.
 Slide unit into fireplace opening, making sure to center unit in the
opening. Use feet adjustment bolts to level unit. Make sure insulation
is properly installed; covering all gaps without being bunched up. Note
that large gaps created by rough openings may require additional in-
sulation.
 Route the blower cord to desired location. Plug in the cord and check
for proper blower operation. See “Blower” section in Operating In-
structions for explanation of switches.
Operating Instructions
Fuel:
 WARNING: Never use gasoline, oil, or any other flammable liquid to
start a fire!
 Dry, seasoned hardwood is the safest and most efficient firewood. Rec-
ommended firewood age is 6-9 months.
 When wood is green and/or burned very slowly, it produces tar and
other organic vapors, which combine with expelled moisture to form
creosote. This creosote residue accumulates on the flue lining, and
when ignited, can start an extremely hot chimney fire. The chimney
should be inspected for creosote build-up twice monthly during the
heating season, and cleaned as necessary.
 Make certain to keep wood well back from the door opening in order to
avoid puncturing or placing extreme heat on the glass.
 Regulate the fire in order to avoid the dangers and unnecessary wear
associated with extreme heat and uncontrolled burning.
 Ashes should be placed in a metal container with a tight fitting lid and
retained there until all cinders have thoroughly cooled. Remember
that bottom, sides, and handles of container may be very hot.
Blower:
 Blower is operated by variable speed switch. To turn on, turn switch
clockwise until desired fan speed is achieved. To turn off, turn switch
counter-clockwise until a positive “click” is heard. Unit is also
equipped with a thermostatically controlled switch which turns
blower off when temperature drops below 90°F.
 In event of power failure, only burn unit with doors open.
 WARNING: Disconnect power source prior to performing any mainte-
nance or diagnostic operation on the blower or switches!
Assembly
Incorrect assembly or unheeded warnings could result in a
damaged unit, or a serious fire and loss of life and property.
Refer to included photo addendum to aid in assembly.
 Step 1. Unpack Heat Grate and identify all parts using Parts List.
 Step 2. Place Heat Grate unit on a flat surface to prepare for assem-
bly. Be sure to orient the unit with the manifold facing you. (Fig. 1)
 Step 3. Choose if you want to place the Blower Assembly on the left or
right side of the fireplace. This is determined by where you want the
Power Cord to exit the unit. Remove cover from Blower Assembly.
Place Blower Assembly on desired side of Heat Grate by tipping the
Heat Grate up and sliding the manifold down between the Blower As-
sembly box and heat shield.
 Step 4. Align holes and bolt the Blower Assembly to the Heat Grate
unit using supplied Philips head screws. (Fig. 2)
 Step 5. Route Cord out of the Blower Assembly on the proper side. Be
sure to place rubber grommet in case opening. (Fig. 3)
 Step 6. Connect Cord wires to Blower and Switch wires by joining ter-
minals. Connect Green Wires to each other. Connect White from
Power Cord to Black from Fan. Connect Black from Power Cord to
Black from Switch. See wiring diagram for more info. (Fig. 4)
 Step 7. Place Blower Vent Assembly on opposite side of Heat Grate
from the Blower Assembly. Bolt to Heat Grate in same manner as
Blower Assembly in Step 4. (Fig. 5)
 Step 8. Assemble Cover by sliding the two cover pieces together. Place
Variable Speed Switch through hole in cover. Trim ends of Cover to fit
into the fireplace opening. Place caps on each end of the Cover, mak-
ing sure to use Cap with cord cutout on the side where the Cord exits
the unit. (Fig. 6)
 Step 9. Slide assembled unit into fireplace. Use feet adjustment bolts
on bottom of feet to level unit in fireplace. (Fig. 7)
 Step 10. Install doors on top of cover and plug Grate Heater power
cord into 110v electrical outlet.
 1 - Heat Grate Unit
 1 - Blower Assembly
 1 - Blower Vent Assembly
 1 - 6’ Cord
 1 - Variable Speed Switch
 1 - Adjustable Cover w/ end caps
 1 - Hardware Pack
(1 Grommet & 4 Philips Head Screws)
Parts List
Grate Heater For wood-burning masonry fireplaces
NorthlineExpress.com
http://www.northlineexpress.com
Toll-Free 1-866-667-8454

Grate Heater
Installation Instructions - Photo Addendum
Fig. 1
Grate Heater unit oriented with
manifolds facing towards you.
Manifolds
Fig. 2
After determining which side to
place the Blower Assembly,
slide the manifold down between
the Main Blower Assembly &
Heat Shield. Attach Blower As-
sembly to Heat Grate unit with 2
of the supplied screws.
Heat Shield
Main Blower Assembly
Attach here
Grate Heater Unit
Fig. 3
Route the Cord out of unit on the
proper side. This illustration is a
right hand install, so cord comes
out on the right side. Make cer-
tain to place grommet into cutout
in the case opening.
Grommet
Main Blower Assembly
Power Cord Variable Speed Switch
Power Cord
Fan
Thermal Switch
Variable Speed
Switch
Power Cord Switch/Fan
Green Fan Green>
Black Switch Black>
White Fan Black>
Green
Black White
Black Green
Black
Fig. 4
NorthlineExpress.com
http://www.northlineexpress.com
Toll-Free 1-866-667-8454

Grate Heater Unit
Grate Heater
Installation Instructions - Photo Addendum
Fig. 5
Attach Blower Vent Assembly to
Grate Heater unit with remaining 2
Phillips head screws.
Blower Assembly
Attach here
Blower Vent
Assembly Grate Heater Unit
Fig. 7
Use feet adjustment bolts to level
unit in fireplace. Bolts can be ad-
justed up and down with a 5/8” end
wrench.
Leg
5/8” End Wrench Adjustment Bolt
Fig. 6
Route the Cord out of unit on the
proper side. This illustration is a
right hand install, so cord comes out
on the right side. Make certain to
place grommet into cutout in the
case opening.
Grommet
Main Blower Assembly
Power Cord
Variable Speed
Switch
Fig. 8
Trim Cover to fit opening. Place end
caps over trimmed ends, making
sure to place the cord cut-out over
the cord.
Trimmed Cover
Cap w/ Cord Cut-out
Cord
