STOVES Precision 1100DFa Operating instructions

Stoves Precision 1100DFa
Stoves 1100DFa
Stoves Heritage 1100DF
Dual Fuel Range Cookers
For Natural Gas models & LP Gas models
User & Installation Instructions
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 1

The Gas Consumer Council (GCC) is an independent organisation which protects
the interests of gas users. If you need advice, you will find the telephone number is
your local telephone directory under Gas.
If you smell gas:
Do not try to light any appliance. Do not touch any electrical switch.
Call the Gas Emergency Helpline at TRANSCO on: 0800 111999
In the Republic of Ireland, call the Bord Gaìs emergency line on
1850 205050 or contact your local gas supplier.
In case of difficulty within the UK and Northern Ireland, please call
STOVES Customer Care Centre Helpline on
0151 432 7838
When you dial this number you will hear a recorded message and be given a
number of options. This indicates that your call has been accepted and is being
held in a queue. Calls are answered in strict rotation as our Customer Care
Representatives become available.
Opening Hours for Customer Care Centre
Monday to Friday 8am - 8pm
Saturday 8.30am - 6pm
Sunday 10am - 4pm
Enter appliance numbers here for future reference:
28
STOVES CUSTOMER CARE
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 2

User’s Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 19
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Be Safe - Not Sorry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Using the Hob . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Using the Griddle (if supplied) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Using the Grill . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Using the Ovens . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Programmer / Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20 - 24
Regulations and Standards . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Ventilation Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Connect to Electricity Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Connect to the Gas Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Commissioning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Stoves Customer Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
1
Please keep this handbook for future reference, or for anyone else
who may use the appliance.
CONTENTS
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 3

Thank you for choosing a
British built appliance by Stoves
We hope the following information will
help you to quickly familiarise yourself
with the features of the appliance, and
to use it successfully and safely.
Our policy is one of constant
development and improvement. Strict
accuracy of illustrations and specifications
is not guaranteed. Modification to
design and materials may be necessary
subsequent to publication.
This appliance must be installed in
accordance with the regulations in
force, and only in a well ventilated
space. Read the instructions before
installing or using this appliance.
Your appliance is designed to be installed
free-standing or flush to base units.
Your 1st Year Guarantee
To fulfil the conditions of your guarantee,
this appliance must be correctly
installed and operated, in accordance
with these instructions, and only be
used for normal domestic purposes.
Please note that the guarantee, and
Service availability, only apply to the
UK and Republic of Ireland.
The User’s Section in this handbook covers
the operation of the appliance, but to
help you make the most of your cooker,
we have produced the accompanying
Cooking Guide which gives more
details of its features and benefits.
Ventilation
The use of a gas cooking appliance
results in the production of heat and
moisture in the room in which it is
installed. Ensure that the kitchen is
well ventilated: keep natural ventilation
holes open or install a mechanical
ventilation device (mechanical extractor
hood). Prolonged intensive use of the
appliance may call for additional
ventilation, for example, opening of a
window, or more effective ventilation,
for example increasing the level of
mechanical ventilation where present.
Environmental Protection
We are committed to protecting the
environment and operate an
Environmental Management System
which complies with BS EN ISO
14001.
Disposal of packaging
•All our packaging materials are
recyclable and environmentally
friendly.
• Please help us to protect our
environment by disposing of all
packaging in an environmentally
friendly manner.
•Please contact your local authority
for the nearest recycling centre.
Caution: Packaging materials can
pose a risk of suffocation - keep away
from children.
2
INTRODUCTION
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 4

Gas & Electrical connection
Please refer to installation instructions
for the Gas & Electrical Safety Regulations
and the Ventilation Requirements.
In your own interest, and that of safety,
it is the law that all gas appliances be
installed by competent persons, in
accordance with relevant regulations.
Corgi registered installers undertake to
work to satisfactory standards.
Disconnection of gas and electric
appliances should always be carried
out by competent persons.
Warning: This appliance must be
earthed.
If the ignition fails:
•Check there is a spark when the
ignition button is depressed.
•If there is no spark, check that the
electricity supply is switched on at
the socket.
• Check that the gas supply is
switched on.
Stability bracket
If the cooker is to be fitted with a
flexible inlet connection, a stability
bracket should also be fitted to engage
in the back of the cooker. Make sure
this is re-engaged whenever you move
the cooker for cleaning.
Moving the cooker
Do not attempt to move the cooker by
pulling on the doors or handles. Open
the door and grasp the frame of the
cooker, taking care that the door does
not shut on your fingers.
Take care to avoid damage to soft or
uneven floor coverings when moving
the appliance. Some cushioned vinyl
floor coverings may not be designed
to withstand sliding appliances without
marking or damage.
Before using the appliance for
the first time, remove any protective
polythene film and wash the oven
shelves and furniture in hot soapy
water, to remove their protective
coating of oil. Even so, when you first
turn on the oven or grill you may
notice a smell and some smoke.
The cooling fan
When the grill is switched on, you will
hear the cooling fan come on - this keeps
the appliance fascia and control knobs
cool during grilling only. The fan will
continue to operate for a period after
the grill control has been switched off.
If there is no such indication that the
fan is operating, the appliance will
require servicing. DO NOT USE THE
APPLIANCE UNTIL IT HAS BEEN SER-
VICED. Switch the appliance off at the
mains and contact Stoves Customer
Care Centre.
3
INTRODUCTION
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 5

Storage drawer
Your appliance has a generous
storage drawer, located beneath the
right-hand side oven.
The storage drawer should only be
used to store oven furniture.
Baking trays and roasting tins may be
stored in the drawer.
Do not store items with plastic or
wooden handles in the drawer, as
they may be damaged by heat from
the oven.
Do not store flammable liquids, even
when cold, in the storage drawer, as
they may catch fire. Do not store
flammable items - ie; chip pans.
Do not store food / canned items in
the storage drawer.
Do not use the drawer as a
food warming facility.
Note: a greeen adhesive pad
can be found on the front of the
storage drawer. This pad is to be
removed before appliance
instalation.
To replace an oven light bulb
Caution: Switch off the electricity
supply to the appliance at the socket,
to avoid the risk of electric shock.
Wait until the oven is cool, then
remove the oven shelves.
Grasp the lens cover on the light fitting
and pull it away from the side of the
oven. Unscrew the bulb.
Please note that the oven light bulb is
not covered by the guarantee.
Replacement bulbs can be ordered
from your local supplier, or bought
from a hardware store.
4
INTRODUCTION
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 6

When you are cooking, keep
children away from the vicinity
of the appliance.
This product is designed as a domestic
cooking appliance for the preparation
and cooking of domestic food
products, and should not be used for
any other purpose.
•Remove all packaging from the
appliance before using for the
first time.
• Make sure you read and under-
s t a n d the instructions before using
the appliance.
•Keep electrical leads short so they
do not drape over the appliance
or the edge of the worktop.
•Keep all flammable materials (such
as curtains, furnishings & clothing)
away from the appliance.
•Parts of the appliance may be hot
during or immediately after use.
Care should be taken to avoid
touching heating elements inside the
oven. Allow sufficient time for the
appliance to cool after switching off.
•Do not drape tea towels over the
flue vents or doors, as this creates
a fire hazard.
• When opening the appliance
door, take care to avoid skin
contact with any steam which may
escape from the cooking.
•Do not use aluminium foil to cover
the grill pan, or put items wrapped
in foil under the grill, as this creates
a fire hazard.
•Use oven gloves when removing
hot food / dishes from the oven or
grill. The oven / grill and utensils
will be very hot when in use.
•Do not use foil on oven shelves or
allow it to block the oven flue, as
this creates a fire hazard, and
prevents heat circulation.
•When cooking heavy items - eg;
turkeys - do not pull the oven shelf
out with the item still on the shelf.
• The storage drawer should only be
used to store oven furniture. Do not
store any flammable materials in
this drawer.
•Always allow the griddle to cool
before removing it for cleaning.
• Never use the appliance for
heating a room.
As with all gas appliances, it is
recommended that your appliance is
serviced regularly.
When you have finished
cooking check that all controls
are in the off position.
5
BE SAFE - NOT SORRY
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 7

Ignition
Open the metal hotplate lid.
Push in and turn the selected hotplate
control knob anticlockwise to the large
flame symbol and press the IGNITION
SWITCH until the burner lights. Turn the
control knob to the required setting.
Adjust the burner flame so that it does
not extend over the pan base.
To turn off, push in the control knob
and turn clockwise.
To simmer
The simmer position is marked by the
small flame symbol.
Once lit turn the selected control knob
a n t i c l o c k w i s e past the large flame
symbol (“FULL ON”) to the small flame
symbol.
You may hear a slight popping noise
when the hob burners are operating
and this is quite normal, but if anything
about the cooker appears unusual,
such as change in flame appearance,
or the operation of controls - seek
expert advice.
The fold down lid (if fitted)
Caution: Glass lids may shatter when
heated. Turn off all the burners before
shutting the lid.
Any spillage should be removed from
the surface of the lid before opening.
When opening and closing the lid, use
the cooler outer sides of the lid trim.
The lid must be opened fully, so there
is no danger of it closing while the hob
is being used.
The appliance is fitted with a switch-
back system, which will automatically
turn off the hotplate controls if they are
inadvertently left on as the lids are
c l o s e d . Do not use this device as a
quick way to turn off the burners.
The lid is not intended to be used as a
work surface, as it becomes hot when
any part of the cooker is in use, and
the surface may be scratched if items
with rough or sharp surfaces are
placed on it.
6
USING THE HOB
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 8

7
USING THE HOB
Pans
Turn pan handles to a safe position
so they are out of reach of children,
not overhanging the appliance, and
cannot be caught accidentally.
Use pans with a flat base which are
stable in use, and avoid using any old
misshapen pans or any pan which is
unstable when placed on a flat surface.
Position pans over the centre of the
burners, resting on the pan supports.
If positioned off centre, smaller pans
may be unstable.
When cooking with fat or oil, never
leave unattended.
Commercial simmering aids should
not be used as they create excessive
temperatures that can damage the
surface and may cause a hazard.
For optimum safety and performance,
we recommend the use of flat bottomed
pans with a base diameter of minimum
100mm (4”) and maximum 250mm (10”).
Pan supports
Pan support are cast iron, vitreous
enamelled for durability.
Make sure that you use the correct-
shaped pan support for the burner you
wish to use.
The wok burner has a different shaped
pan support to the other hotplate
burners. The wok burner must only be
used with this pan support.
Burner suitable for:
Small (2) Simmering, stewing, smaller pans.
Medium (3) General domestic use, fish kettles, chip pans.
Large (1) Boiling, frying, larger pans.
Wok (1) Wok cooking, larger pans.
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 9

USING THE GRIDDLE (if supplied)
Caution: Accessible parts may
be hot when the griddle is used.
Young children should be kept
away.
Please read these instructions
thoroughly before using the griddle
plate for the first time.
Only use the griddle which has been
approved for use on this appliance.
Do not use any other griddle, as this
may be hazardous.
For instructions on griddle cooking,
please refer to the accompanying
cooking guide.
Before using the griddle for the
first time
Wash the griddle thoroughly in hot
soapy water (see “Cleaning” section).
Season sparingly with a minimum
amount of cooking oil (see below).
Heat the griddle on full rate for 3 minutes.
The griddle plate is now ready for use.
Seasoning the griddle
The griddle is made of quality cast iron,
and has a non-stick cooking surface.
Regular seasoning will prolong the life
of the griddle and prevent rusting. If
the griddle shows signs of rust, wash
and re-season.
To season;
• After cleaning, dry the griddle
thoroughly.
•Rub the cooking side of the griddle
sparingly with a minimum amount
of unsalted vegetable oil. Note that
olive oil is u n s u i t a b l e for seasoning.
Using the griddle
The griddle should only be used with
the small and medium sized burners
on the right-hand side of the hotplate.
Do not use the griddle over large
burners or wok burners, or over the left-
hand side small and medium burners.
Place the griddle carefully on the pan
support over the burners, using the
locating feet on the underside of the
griddle. Take care to avoid damage
to the vitreous enamel surface of the
pan supports.
Before cooking, preheat the griddle
for 3 minutes on full rate, which is
indicated on the control knobs by a
large flame symbol.
After preheating, turn the control
knobs to the small flame symbol.
The griddle is now ready for cooking.
Do not use metal implements, as they
may damage the non-stick surface.
After cooking, allow the griddle
to cool before moving or
cleaning it.
8
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 10

9
USING THE GRILL
Caution: Accessible parts may
be hot when the grill is used.
Young children should be kept
away.
The grill is a variable electric dual grill.
To switch on the grill
Open the grill door.
Turn the grill control knob either clock-
wise to use the full grill settings, or anti-
clockwise to the economy grill settings.
The economy grill settings only use the
inner element of the grill.
Important: Keep the grill door open
when the grill is on.
To switch off, return the control knob to
the “off” position.
Preheating
For best cooked results, always
preheat the grill for about 3 minutes.
The cooling fan
When the grill is switched on, you will
hear the cooling fan come on - this
keeps the fascia and control knobs of
the appliance cool during grilling
only. The fan will continue to operate
for a period after the grill control has
been switched off. Should any fault
occur with the cooling fan, the
appliance will require servicing -
contact Customer Support.
Detachable grill pan handle
Place the handle over the edge of the
grill pan, at the narrow side edges.
Slide the handle to the centre, and
locate between the handle position
indicators.
The handle should be removed from
the pan during grilling, to prevent
overheating.
The handle is designed for removing /
inserting the grill pan under the grill
when grilling.
If cleaning the grill pan when it is hot,
use oven gloves to move it. Do not use
the handle to pour hot fats from the
grill pan.
Food for grilling should be positioned
centrally on the trivet.
handle
grill pan
trivet
handle position
indicators
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 11

Caution: Accessible parts may
be hot when the grill is used.
Young children should be kept
away.
Using the grill
The temperature of the grill is variable,
and can be adjusted by turning the
grill control to the required setting.
Setting 8 is high and 1 is low.
Turn the grill control knob either clock-
wise to use the full grill settings, or anti-
clockwise to the economy grill set-
tings.
The economy grill settings only use the
inner element of the grill.
The speed of grilling can also be
controlled by selecting a higher or
lower shelf position.
It is recommended that the high
temperature setting is used for toasting
and for cooking foods such as bacon,
sausages or steaks. Use a higher shelf
position.
For thicker foods such as chops or
chicken joint pieces, the temperature
may be reduced to a lower setting.
Use a lower shelf position.
Grilling can also be adjusted by
adjusting the trivet position, as detailed
b e l o w ;
• The grill trivet inside the grill pan
can be inverted to give a high or
low position, or it may be removed
altogether.
•For toasting, use the highest trivet
position.
•The lower trivet position is u s e f u l
for grilling all types of meat or fish.
•With trivet removed the food is
placed directly on the base of the
grill pan - eg; when cooking whole
fish, or browning dishes such as
cauliflower cheese.
Push the grill pan to the back of the
shelf, to position it under the centre of
the grill.
Never allow fat to build up in the grill
pan, as this creates a fire hazard.
For best results, preheat the grill for
3 - 5 minutes before use.
When you have finished grilling,
check that the control knob is
returned to the “off” position.
Aluminium foil
Using aluminium foil to cover the grill
pan, or putting items wrapped in foil
under the grill, creates a fire hazard,
and the high reflectivity may damage
the grill element.
10
USING THE GRILL
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 12

Caution: Accessible parts may
be hot when the appliance is in
use. Young children should be
kept away.
The cooker has two electric ovens.
Right-hand side Fanned oven
The right-hand side oven is a fanned
electric oven. It may be controlled by
the automatic programmer.
To switch on, turn the oven control
knob clockwise to the desired temper-
ature setting.
To switch off, return the control knob to
the “off” position.
Left-hand side Conventional oven
The left-hand side oven is a conventional
electric oven. This oven is not controlled
by the automatic programmer.
To switch on, turn the oven control
knob clockwise to the desired
temperature setting.
To switch off, return the control knob to
the “off” position.
Caution: The top element gets
extremely hot when in use, so take
care to avoid touching it.
Important: Never put items directly
on the base of the oven or cover the
oven base with foil, as this may cause
the element to overheat.
Red thermostat indicator neon
(if fitted)
The red thermostat indicator neon will
come on until the selected temperature
is reached, and then go off. It will turn
on and off periodically as the thermostat
operates to maintain oven temperature.
Note:
As part of the cooking process, hot air
is expelled through a vent at the top of
the oven(s). When opening the oven
door, care should be taken to avoid
any possible contact with potentially
hot air, since this may cause discom-
fort to people with sensitive skin.
We recommend that you hold the
underneath of the oven door handle.
11
USING THE OVENS
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 13

Oven furniture
Oven shelves
The oven shelf must be positioned with
the upstand at the rear of the oven and
facing upwards.
Position baking trays and roasting tins
on the middle of the shelves, and leave
one clear shelf position between
shelves, to allow for circulation of heat.
Baking tray and roasting tins
For best cooked results and even
browning, the maximum size baking
trays and roasting tins that should be
used are as follows;
Baking tray 350mm x 280mm
This size of baking tray will hold up to
16 small cakes.
Roasting tin 370mm x 320mm
We recommend that you use good
quality cookware. Poor quality trays
and tins may warp when heated,
leading to uneven baking results.
12
USING THE OVENS
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 14

The Programmer Buttons
minute minder
cook time
ready time
minus
plus
To set the “Time of Day”
Press the cook time and ready time
buttons simultaneously, and keep the
buttons depressed. Use the plus and
minus buttons to set the time of day,
eg; 12.00.
A (Auto) symbol goes out, cookpot
symbol comes on.
To select an alarm tone
Press the minus button to listen to the
first tone.
Release the minus button and press it
again to listen to the second tone, etc.
Releasing the minus button after the
tone has sounded will automatically
select that tone.
Manual operation
To set the programmer to manual
operation at any time (cancelling any
automatic setting), press the cook time and
ready time buttons simultaneously. T h e
programmer must be set to manual before
the appliance can be used manually.
Setting the minute minder
Press the minute minder button, then
use the plus and minus buttons to set
the required time.
The minute minder (bell) symbol will
appear on the display.
You can cancel the minute minder at
any time by pressing the m i n u t e
minder button and the minus button
until the display returns to 0.00.
After setting, the display will revert to
show the time of day, but you can press
the minute minder button, and the
display will show the minutes remaining.
The tone will sound at the end of the
time set - to cancel the tone, press the
minute minder button.
13
PROGRAMMER / CLOCK
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 15

14
1. A (Auto) symbol appears.
2.
3. A (Auto) symbol will flash.
4. A (Auto) symbol goes out.
Semi-automatic cooking ( e x a m p l e )
You have started cooking a meal or
dish in the oven, and want to set the
time for the oven to switch off.
Press the cook time button, then use the
p l u s and m i n u s buttons to set the
display to show the length of cooking
time required, eg; 2 hours as shown (1) .
After setting, the display will revert to
show the time of day, but you can
press the cook time button and the
display will show how much cooking
time still remains on the clock.
Press the ready time button, and the
display will show the actual time the
oven is going to switch off, eg; 18.00
as shown (2).
At the end of the cooking time, the
alarm will sound, and the oven will
automatically switch off.
To switch off the alarm, press the
minute minder button (3).
When the oven has switched off,
return the oven control knob to
the “off” position, and press the
cook time and ready time buttons to
return to manual operation (4).
If you wish to cancel the automatic
setting, or to cancel any remaining
cooking time left on the clock before
the alarm sounds, press the cook time
and ready time buttons simultaneously.
(4).
A
U
T
O
A
U
T
O
A
U
T
O
PROGRAMMER / CLOCK
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 16

15
5. A (Auto) symbol appears.
6. The cookpot symbol will
disappear from display.
7. The cookpot symbol will appear
on display.
8.
Fully automatic cooking ( e x a m p l e )
For use when a delayed start time is
required.
You want to set the length of cooking
t i m e, and the time for the oven to switch
o f f. The programmer will automatically
calculate the cooking start time.
Press the cook time button, then use the
p l u s a n d m i n u s buttons to set the
display to show the length of cooking
time required, eg; 2 hours as shown (5) .
Press the ready time button, and the
present ready time will be displayed.
Using the plus and minus buttons you
can set the display to show the actual
time you want the oven to switch off,
eg; 18.00 hours (6.00 pm) (6).
The display will revert to show time of day.
After setting the programmer,
turn the oven control to the
required temperature.
The oven will automatically switch on
at the calculated start time of 16.00
hours (4.00 pm) (7).
A single press of the cook time button
shows the cooking time remaining
before the oven automatically switches
off (8).
A
U
T
O
A
U
T
O
A
U
T
O
A
U
T
O
PROGRAMMER / CLOCK
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 17

16
9. A (Auto) symbol will flash.
10.
11. A (Auto) symbol goes out.
The oven will automatically switch off
at 18.00 hours (6.00 pm) and the
alarm will sound (9).
To switch off the alarm press the
minute minder button (10).
When the oven has switched off,
return the oven control knob to
the “off” position, and press the
cook time and ready time buttons
simultaneously (11).
If you wish to cancel the automatic
setting before cooking has started,
and return to manual operation, press
the cook time and ready time buttons
simultaneously (11).
To cancel any remaining cooking time
left on the clock before the alarm
sounds, press the cook time and ready
time buttons simultaneously (11).
A
U
T
O
A
U
T
O
PROGRAMMER / CLOCK
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 18

C a u t i o n : Any cleaning agent
used incorrectly may damage
the appliance.
Always let the cooker cool
before cleaning.
Some cooking operations generate
considerable amount of grease, this
combined with spillage can become a
hazard if allowed to accumulate on
the appliance through lack of
cleaning. In extreme cases this may
amount to misuse of the appliance and
could invalidate your guarantee.
It is recommended that the appliance
is cleaned after open roasting.
Do not use caustic, corrosive or
abrasive cleaning products, products
containing bleach, coarse wire wool
or any hard implements, as they will
damage the surfaces.
All parts of the cooker can be safely
cleaned with a cloth wrung out in hot
soapy water.
Vitreous Enamel parts
GRILL PAN &GRILL COMPARTMENT,HOB TOP
& P A N S UPP O R TS, OV E N C OMP A R T ME N T F L OOR
Use a mild cream cleaner - eg; “Cif”.
Stubborn marks may be removed with
a moistened “Brillo” pad.
The grill pan may be cleaned in a
dishwasher, or with a nylon brush in
hot soapy water.
Easy care surfaces
OVEN SIDES AND BACK
We recommend that the appliance is
cleaned after open roasting, and also
after roasting at temperatures higher
than 200˚C, to help prevent a build up
of fats. Use of a trivet in a roasting tin
when roasting will help reduce fat
splashing.
Caution: Most types of cleaning
agent will damage these surfaces.
Only use a few drops of washing up
liquid in hot water. Wipe the surfaces
with a clean cloth wrung out in hot soapy
water - if larger splashes of fat do not
readily disappear, scrub the area with
a nylon brush or nylon pan scourer
and hot soapy water. Rinse well and
heat the oven to dry the surfaces.
Chrome plated parts
OVEN SHELVES &OVEN SHELF RUNNERS,
GRILL PAN TRIVET
Do not use abrasives or polishes, use
a moist soap pad - eg; “Brillo”.
N o t e : Oven shelf runners can be
removed for cleaning. Grasp the
runners, and slide out of the hanging
holes as shown.
Note: These items may also be
cleaned in a dishwasher.
17
CLEANING
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 19

Burner caps & heads
Important: Allow the burners to cool
before cleaning.
Caution: Hotplate burners can be
damaged by soaking, automatic
dishwashers (or dishwasher powders
/ liquids), caustic pastes, hard imple-
ments, coarse wire wool, and abrasive
cleaning pastes.
Burner heads are aluminium. Clean
with a moist soapy pad - eg; “Brillo”.
For the burners to work safely, the slots
in the burner head where the flames
burn need to be kept clear of deposit.
Clean with a nylon brush, rinse, and
dry thoroughly.
Important: The burner caps and
heads must be repositioned correctly
so that they sit properly on the hob as
shown below.
Painted, plastic & metal finish
parts (where fitted)
CONTROL KNOBS &PROGRAMMER BUTTONS,
SIDE PANELS,HANDLES
Only use a clean cloth wrung out in
hot soapy water. Take extra care when
cleaning over symbols on fascia panels.
Ensure that control knobs are replaced
correctly, and on the correct control.
Cast iron griddle (if supplied)
Do not use metal implements when
cooking, as they may damage the
non-stick surface.
After cooking allow the griddle
to cool completely before
attempting to remove or clean.
Once the griddle has cooled, remove
any excess fat with kitchen paper
before moving.
The griddle can be cleaned with hot
soapy water and a nylon brush. If any
food residue is left on the griddle,
leave it to soak for a few minutes in hot
soapy water before attempting to
clean it. Do not use caustic pastes,
abrasive cleaning powders, coarse
wire wool or any hard implements, as
they will damage the surface.
Do not clean in a dishwasher.
After cleaning, dry thoroughly then re-
season the cooking surface by wiping
sparingly with a minimum amount of
unsalted vegetable oil, and store in a
dry place. Note that olive oil is
unsuitable for seasoning.
18
incorrect
burner cap not central
incorrect
angled
correct
parallel
burner cap
burner head
CLEANING
25211 03 - Precision 1100DFa 5/8/04 11:46 AM Page 20
