STOVES 605MF Operating instructions

605MF
Electronic Multifunction Oven / Grill
User & Installation Instructions
08 27148 00 605MF 8/10/04 12:40 PM Page 1

User’s Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2 - 18
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Be Safe - Not Sorry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Using the grills . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Grilling guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Using the main oven . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Main oven guides. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Roasting guides . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Traditional Fruit cakes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Roast Turkey . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Programmer / Clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Installation Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Technical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Stoves Customer Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . Back page
Please keep this handbook for future reference, and for anyone else
who may use this appliance.
1
Contents
08 27148 00 605MF 8/10/04 12:40 PM Page 2

Thank you for choosing a British
Built appliance by Stoves
We hope the following information will
help you to quickly familiarise yourself
with the features of the appliance, and
to use it successfully and safely.
Our policy is one of constant devel-
opment and improvement. Strict a c c u r a-
cy of illustrations and specifications is not
guaranteed. Modification to design and
materials may be necessary subsequent
to publication.
Please read the instructions in this hand-
book before using or installing this appli-
ance.
This appliance is designed to fit into a
standard 600mm wide housing unit with a
minimum internal height of 580mm.
Your 1st year guarantee
To fulfil the conditions of your guarantee,
this appliance must be correctly installed
and operated, in accordance with these
instructions, and only be used for normal
domestic purposes.
Please note that the guarantee, and
Service availability, only apply to the UK
and Republic of Ireland.
Environmental Protection
We are committed to protecting the envi-
ronment and operate an Environmental
Management System which complies
with BS EN ISO 1400.
Before using your appliance.
Remove any protective polythene film
and wash the oven shelves and furniture
in hot soapy water to remove their pro-
tective covering of oil. Even so, when
you first turn on the oven or grill you
may notice a smell and some smoke.
Disposal of packaging
• All our packaging materials are
recyclable and environmentally
friendly.
•Please help us to protect our envi-
ronment by disposing of all packag-
ing in an environmentally friendly
manner.
•Please contact your local authority
for the nearest recycling centre.
Caution: Packaging materials can pose
a risk of suffocation - keep away from
children.
Electrical connection
Please refer to installation instructions for
electrical connection.
In your own interest, and that of safety,
make sure that any installation/discon-
nection is carried out by a competent per-
son.
Warning: This appliance must be
earthed.
Steam cleaners should not be used to
clean this appliance.
2
Introduction
08 27148 00 605MF 8/10/04 12:40 PM Page 3

3
Introduction
When the power is turned on.
As soon as the power is switched on, the
oven will run a brief self check.
Once this has been done, the timer dis-
play in between the central and right
hand control knob will begin to flash.
We recommend that you set the correct
time of day before using the appliance
for the first time.
If the time of day is not set after one
minute, the timer display will show
“00.01” as the time.
Please remember that this is a 24 hour
timer.
Manual operation
Always make sure that the appliance is
in manual cooking mode before using it.
The Automatic programmer will not
allow the oven/grill to be used if it is
waiting to run a programme.
To change an oven light bulb
Switch off the electricity to the appli-
ance at the socket, to avoid the risk of
electric shock.
Wait until the oven is cool, then remove
the oven shelves.
The lens cover on the light can be
removed by pulling away from the oven
side. Unscrew the bulb and replace.
Please note that oven light bulbs are not
covered by guarantee.
Cooling fan
When any oven or grill heating function
is selected the cooling fan will operate
and continue to operate continuously
and for 15minutes after the last heating
function has been switched off, unless
any oven or grill heating element has not
operated for longer than 90 seconds.
In this case the cooling fan will switch off
immediately.
In all cases the cooling fan will switch on
if it detects a temperature of 150˙C or
above and will not switch off until the
temperature is 150˙C or below.
In the event of a power cut:
1. Switch off the electricity supply to
the appliance.
2. When the power returns, see the
‘Programmer / Clock’ section to ‘Set
the time of day’.
Condensation
When hot moist air, created when cook-
ing, meets a cooler surface such as an
oven door, then the formation of con-
densation is normal, especially when
cooking wet dishes at low temperatures.
Note: Automatic cooking will normally
produce condensation when cooling
down and food is still in the oven.
To minimize this:
Most importantly - pre-heat the oven on
a high temperature before putting food
into the oven
also - Cover the food you are cooking
Where possible cook wet food at higher
temperatures
Do not leave food in the oven to cool
down
08 27148 00 605MF 8/10/04 12:40 PM Page 4

When you are cooking, keep
children away from the vicinity
of the appliance.
This product is designed as a domestic
cooking appliance for the preparation
and cooking of domestic food
products, and should not be used for
any other purpose.
•Remove all packaging, protective
films and oils from the appliance
before using for the first time.
• Make sure you read and
understand the instructions before
using the appliance.
•Keep electrical leads short so they
do not drape over the appliance
or the edge of the worktop.
•Keep all flammable materials (such
as curtains, furnishings & clothing)
away from the appliance.
•Parts of the appliance may be hot
during or immediately after use. Care
should be taken to avoid touching
the heating elements inside the oven.
Allow sufficient time for the appli-
ance to cool after switching off.
• During use, the oven interior
becomes hot, care should be taken
to avoid touching heating elements
inside the oven - children should
be kept away.
• Never use the appliance for
heating a room.
• Switch off the electricity supply
before replacing the oven light bulb,
to avoid the risk electric shock.
•Do not drape tea towels over the
handle as this creates a fire hazard.
• When opening the appliance
door, take care to avoid skin
contact with any steam which may
escape from the cooking.
•Do not place items on the drop-
down door when it is open.
•Do not use the oven with the door
inner glass panel removed.
•Do not use aluminium foil to cover
the grill pan, or put items wrapped
in foil under the grill, as this creates
a fire hazard. The high reflectivity
can also damage the element.
•Use oven gloves when removing
hot food / dishes from the oven or
grill. The oven / grill and utensils
will be very hot when in use.
•Do not use foil on oven shelves
or allow it to block the oven flue,
as this creates a fire hazard, and
prevents heat circulation.
•When cooking heavy items - eg;
turkeys - do not pull the oven shelf
out with the item still on the shelf.
Unless the appliance is fitted with
telescopic shelving.
All installation, servicing and
maintenance work should be carried
out by a competent person who will
comply with current Regulations,
Standards and Requirements. Always
ensure the appliance is switched off
after use.
4
Be Safe - Not Sorry
08 27148 00 605MF 8/10/04 12:40 PM Page 5

Important safety note:
This appliance has built in fail safe
technology to prevent your appliance
from overheating in the event of mis-
use or certain component failures
such as cooling fan failure.
Should any of the above occur the
appliance will automatically show
“FAIL” “FAIL” on both displays.
You should switch off the power to
the appliance and call our Customer
Care Centre - details on the back
page.
The appliance will automatically reset
itself when the appliance is fully-
cooled down and power is restored.
5
Be Safe - Not Sorry
08 27148 00 605MF 8/10/04 12:40 PM Page 6

6
Appliance Functions
Symbol Function / Feature Main Oven and
Grill
Full Grill (conventional) 4
Half Grill (economy - inner element only) 4
Fanned grill 4
Conventional oven 4
Fanned oven 4
Intensive bake 4
Defrosting 4
Details of how to use these functions are detailed in the handbook in the ‘Using
the grill’ and ‘Using the oven’ sections.
08 27148 00 605MF 8/10/04 12:40 PM Page 7

Caution: Accessible parts may
be hot when the grill is used,
young children should be kept
away.
The 605MF is a combined oven and
grill unit. You cannot use the oven and
the grill simultaneously.
Before using the grills
If you have programmed one of the
ovens for automatic cooking, then the
grill functions will not be available for
use, please check that the oven is not
set for automatic cooking before use.
Preheating
This appliance performs at it’s best
when it is preheated.
To show it is preheating, the ‘gr’ flash-
es on the display.
Once preheating has finished, you will
hear a short audible tone, and the ‘gr’
will stop flashing.
The grill is now ready to use.
Aluminium foil
Using aluminium foil to cover the grill
pan, or putting items wrapped in foil
under the grill can create a fire hazard,
and the high reflectivity can damage
the grill element.
Detachable grill pan handle
Place the handle over the edge of the
grill pan, at the narrow side edges.
Slide the handle to the centre, and
locate between the handle position
indicators.
The handle should be removed from
the pan during grilling, to prevent
overheating.
The handle is designed for removing /
inserting the grill pan under the grill
when grilling.
If cleaning the grill pan when it is hot,
use oven gloves to move it. Do not use
the handle to pour hot fats from the
grill pan.
Food for grilling should be positioned
centrally on the trivet.
7
Using the Grills
handle
grill pan
trivet
handle position
indicators
08 27148 00 605MF 8/10/04 12:40 PM Page 8

8
Using the Grills
Using the Grill functions
The grill is controlled by the right hand
control knob, the energy levels are
shown on the left hand display, while
the time of day is shown on the right
hand display.
Important note: There are three
grill functions available:
To activate the grill, press the right
hand control knob once. An audible
tone will sound.
The full grill icon will come on flashing.
This is the default setting.
You can select a different function by
turning the right hand control knob
anti-clockwise, or clockwise the func-
tion Icons will remain flashing while
you do this.
Once you have chosen which function
you wish to use, press the control knob
once, to confirm your choice. An
audible tone will sound.
Your selected icon will remain lit and
the default energy setting, gr:10 will
be displayed on the Left hand display.
This will flash while the grill preheats.
The grill will then start working, and
the lights will switch on inside the cav-
ity.
You can adjust the energy setting by
turning the right hand controller either
anti-clockwise or clockwise and adjust-
ing between gr:1 - low, or, gr:10 -
high.
To switch off.
Press the right hand control knob once
cooking has finished. This will turn off
the appliance and it will begin to cool
down.
The main oven/grill left hand display
reverts back to the temperature display
of the main oven.
+
_
+
_
+
_
Decrease the
energy level Increase the
energy level
+
_
Full Grill Door open
when using
Half Grill Door open
when using
Fanned Grill Door closed
when using
08 27148 00 605MF 8/10/04 12:40 PM Page 9

9
Using the Grills
When using the grill
You cannot use the automatic pro-
grammer with the grill, however the
minute minder function can be used.
(see Programmer/Clock section)
Never leave the grill unattended for
long periods of time when it is in use,
if you do leave the appliance - set the
minute minder as a reminder.
The grill is recommended for toasting
bread, and grilling foods such as
steaks, sausage and bacon.
If you use the fanned grill function, you
do not need to turn thinner foods such
as bacon, fish and gammon streaks.
Always remember when you use the
grill that the Fanned grill function must
have the door closed, while the Full
and Half grill must have the door
open.
Note:
If you accidentally knock the grill con-
trol, the Full grill icon will come on
flashing - however it will not activate
the grill and after a short time will turn
off again automatically.
08 27148 00 605MF 8/10/04 12:40 PM Page 10

Grilling guide
The times given in the grilling guide are based on a pre-heated full grill used on
gr:10. They are only approximate as differences in thickness, size of portion, and
personal preference will influence the timing.
Shelf positions are counted from the bottom position up.
10
Food Shelf Grilling times (mins)
position conventional fanned
Bread
Toast; 3 - 4 rounds 14 2 - 4 mins -
Teacakes 11 2 - 4 mins -
Cheese on toast;
- 4 rounds - full 12 3 - 5 mins -
- 2 rounds - single 12 3 - 5 mins -
Fish
Fish fillets (6 - 8 oz) 12 6 - 10 mins 6 - 10 mins
Poultry
Chicken fillets (6 - 8 oz) 12 15 - 25 mins -
Chicken joints 11 20 - 40 mins -
Meat
Bacon Rashers 14 10 - 12 mins 6 - 8 mins
Sausages 13 15 - 20 mins -
Steak - rare 15 7 - 10 mins 7 - 10 mins
- medium 14 10 - 15 mins 10 - 15 mins
- well done 13 15 - 20 mins 15 - 20 mins
Lamb chops 12 10 - 15 mins -
Pork chops 12 12 - 20 mins -
Gammon steaks 13 12 - 15 mins 10 - 15 mins
Grilling Guide
08 27148 00 605MF 8/10/04 12:40 PM Page 11

11
Using the Grills
lThese functions are all accessed by using the right hand control knob to switch
on, select, confirm and switch off.
l The right hand control knob is also used to set energy level.
Grill Function Pre-set Temperature
˚C
Pre-set Energy Level
Recommended Uses
Half Grill
(economy)
gr:10 - highest grill setting
The half grill uses part of the element and is
ideal for grilling smaller amounts of foods
like steaks, bacon and toast. Use with the
door open
Full Grill
(conventional)
gr:10 - highest grill setting
The full grill allows you to cook foods such as
toast, bason and steaks using heat from the
element above. The full grill is ideal for
large amounts of food. Use with the door
open.
Fanned Grill gr:10 - highest grill setting
Suitable for thinner, flatter foods such as
bacon, fish and gammon steaks. Foods do
not require turning during cooking. Use with
the door closed.
08 27148 00 605MF 8/10/04 12:40 PM Page 12

Using the oven
Please read through these
instructions carefully before
using for the first time.
Never put items directly on the base of
the oven or cover the oven base with
foil, as this can cause the base element
to overheat.
Preheating
The oven performs at it’s best when
preheated.
We recommend that you turn the oven
on, select the function you require,
and allow it to preheat before you put
any foods or dishes in to cook.
While the oven is preheating, the tem-
perature display will show the desired
temperature and the ˙C symbol (shown
below will flash.
Once the oven completes it’s preheat
the ˙C will stop flashing and an audi-
ble tone will be heard.
To help the air circulate freely
•Position the shelves evenly within
the oven and maintain a clearance
from the oven roof and base.
•If more than one cooking dish or
baking tray is to be used on a shelf,
leave a gap of at least 25mm
between the items themselves and
the oven interior.
• Allow enough space between
shelves for food that will rise
during cooking.
•Do not place items on the oven
base as this will prevent air from
circulating freely.
12
Using the Oven
08 27148 00 605MF 8/10/04 12:40 PM Page 13

Caution: Accessible parts may
be hot when the ovens are
used, young children should be
kept away.
The oven is a multi-function oven. It has
a variety of functions which can be
used to achieve different results.
Manual operation
Please ensure that the oven is not
automatically programmed when you
start cooking. A small LED in the bot-
tom right corner of the timer/clock will
be lit if the auto programmer is active.
To turn on the oven
Step 1 - Select the function
Press the left hand control knob once,
a short audible tone will sound
The oven will automatically default
onto the fan oven.
To change the function turn the knob
until the icon for the function you
require is illuminated.
Press the control knob again to confirm
your choice a short audible tone will
sound
The oven has pre-set temperatures pro-
grammed in - detailed on page 19.
Details about the temperature settings,
and how to adjust them are on the fol-
lowing page.
13
Using the Oven
Hours Minutes
Colon
Auto programmer
on
+
_
+
_
+
_
08 27148 00 605MF 8/10/04 12:40 PM Page 14

Step 2 - Select the temperature
Once the oven function has been
selected and confirmed, the preset
temperature will show in the left hand
display.
To adjust the pre-set temperature, just
turn the knob until the display on the
left reads the temperature you require.
1) Pre-set temperature
2) Turn
3) Adjusted temperature
Note:
If you accidentally knock the oven con-
trol, the Fanned oven icon will come
on flashing - however it will not acti-
vate the oven and after a short time
will turn off again automatically.
Automatic operation
See ‘Programmer / Clock’ section.
14
Using the Oven
+
_
Decrease the
temperature Increase the
temperature
08 27148 00 605MF 8/10/04 12:40 PM Page 15

Defrosting and cooling
Important notes:
To defrost frozen foods, place food
in the centre of the oven and close
the door.
To cool foods after cooking prior to
refrigeration or freezing, place food
in the centre of the oven with the
door open.
Be safe
•Do not defrost stuffed poultry using
this method.
•Do not defrost larger joints of meat
or poultry over 2kg / 4lb using this
method.
•Never place uncooked food which
is to be defrosted next to cooked
food which is to be cooled, as this
can lead to cross contamination.
Defrosting times
Small or thin pieces of frozen fish or
meat - eg; fish fillets, prawns and
mince will take approximately 1 - 2
hours. Placing the food in a single
layer will reduce the thawing time.
A medium sized casserole or stew will
take approximately 3 - 4 hours.
A 1.5kg / 3lb chicken will take
approximately 5 hours - remove the
giblets as soon as possible.
15
Using the Oven
08 27148 00 605MF 8/10/04 12:40 PM Page 16

16
Using The Main Oven
Notes:
Shelf positions in an electric oven are counted from the bottom position up.
For best results when using the conventional oven cooking function, only one tray of
cakes or scones should be baked. When baking more than one tray, the fanned
oven cooking function should be used.
Dish Recommended Temperature ˚C Shelf
Approx Cook
Conventional Fanned Intensive Time (mins)
Scones 215 200 200 6 & 12 8 - 15
Meringues 120 110 110 12 2 - 3 hrs
Cakes
Small cakes 180 175 175 10 20 - 25
Whisked sponge 190 175 175 9 20 - 25
Swiss roll 200 190 190 5 10 - 12
Victoria sandwich 180 160 160 7 20 - 30
(2 x 180mm / 7” per shelf)
Genoese sponge 180 160 160 8 25 - 30
Madeira
(180mm / 7”)
170 150 150 5 1 - 11⁄4hrs
Semi rich fruit cake 150 135 135 5 21⁄2- 3 hrs
(205mm /8”)
Dundee cake 150 135 135 5 21⁄2- 3 hrs
(205mm / 8”)
Pastry
Flaky / Puff 220 200 200 15 - 45 mins.
Shortcrust 200 180 180 Depending on
Choux 200 180 180 recipe and type
Plate tarts
(2 x 180mm / 7”)
200 180 180 of filling.
Biscuits
Shortbread rounds 180 160 160 10 10 - 20
Nut brownies 180 160 160 9 35 - 40
Brandy snaps 190 170 170 9 8 - 12
Flapjacks 190 180 180 9 25 - 40
Ginger nuts 180 160 160 9 15 - 20
08 27148 00 605MF 8/10/04 12:40 PM Page 17

17
Using The Main Oven
Dish Recommended Temperature ˚C Shelf
Approx Cook
Conventional Fanned Intensive Time (mins)
Puddings
Rice pudding 150 140 140 6 13⁄4- 2hrs
(1l/ 2 pint dish)
Baked custard 170 150 150 6 50 - 60
(1l/ 2 pint dish)
Bread & butter pudding 170 150 150 6 45 - 1hr
(1l/ 2 pint dish)
Hot soufflé 180 160 160 7 30 - 45
Fruit crumble 200 185 185 9 40 - 1hr
Miscellaneous
Yorkshire pudding (large) 220 200 200 11 40 - 45
Yorkshire pudding (small) 220 200 200 12 15 - 20
Toad in the hole 220 200 220 11 40 - 45
Bread (2 x 1lb loaves) 220 200 200 7 20 - 30
Bread rolls 220 200 200 10 10 - 15
08 27148 00 605MF 8/10/04 12:40 PM Page 18

Roasting guide
Frozen meat should be thoroughly thawed before cooking. For large joints, it is
advisable to thaw overnight.
Frozen poultry should be thoroughly thawed before cooking (unless packaging
advises otherwise). The time required depends on the size of the bird - eg; a large
turkey may take up to 48 hours to thaw.
Adjust the shelf positions so the meat or poultry will be in the centre of the oven.
The times given in the roasting guide are only approximate because the size
and age of the bird will influence cooking times, as will the shape of the joint and
the proportion of bone.
18
Using The Main Oven
Roasting guide
Frozen meat should be thoroughly thawed before cooking. For large joints, it is
advisable to thaw overnight.
Frozen poultry should be thoroughly thawed before cooking (unless packaging
advises otherwise). The time required depends on the size of the bird - eg; a large
turkey may take up to 48 hours to thaw.
Adjust the shelf positions so the meat or poultry will be in the centre of the oven.
The times given in the roasting guide are only approximate because the size
and age of the bird will influence cooking times, as will the shape of the joint and
the proportion of bone.
Cook in oven at: Approximate cooking time
180˚C fan oven (preheated oven)
200˚C conventional oven
Beef Rare 20 minutes per 450g (1lb)
plus 20 minutes
Medium 25 minutes per 450g (1lb)
plus 25 minutes
Well done 30 minutes per 450g (1lb)
plus 30 minutes
Lamb Medium 25 minutes per 450g (1lb)
plus 25 minutes
Well done 30 minutes per 450g (1lb)
plus 30 minutes
Pork 35 minutes per 450g (1lb)
plus 35 minutes
Poultry 20 minutes per 450g (1lb)
plus 20 minutes
08 27148 00 605MF 8/10/04 12:40 PM Page 19

Traditional fruit cakes
It should be remembered that ovens
can vary over time, therefore cooking
times can vary, making it difficult to be
precise when baking fruit cakes.
It is necessary therefore, to test the
cake before removal from the oven.
Use a fine warmed skewer inserted
into the centre of the cake. If the
skewer comes out clean, then the cake
is cooked.
•Do not attempt to make Christmas
cakes larger than the oven can
cope with, you should allow
at least 25mm (1 inch) space
between the oven walls and the tin.
• Always follow the temperatures
recommended in the recipe.
•To protect a very rich fruit cake
during cooking, tie 2 layers of
brown paper around the tin.
•We recommend that the cake tin is
not stood on layers of brown
paper, as this can hinder effective
circulation of air.
•Do not use soft tub margarine for
rich fruit cakes unless the recipe
specifically recommends it.
• Always use the correct size and
shape of tin for the recipe quantities.
Roast turkey
Roasting turkey involves cooking two
different types of meat - the delicate
light breast meat, which must not be
allowed to dry out, and the darker leg
meat, which takes longer to cook.
The turkey must be roasted long
enough for the legs to cook, so fre-
quent basting is necessary. The breast
meat can be covered once browned.
• Always make sure that the turkey
is completely thawed and that the
giblets are removed before cook-
ing.
• Turkey should be roasted at
200˚C - Conventional / 180˚C -
Fanned for 20 minutes per 450g
(1lb), plus 20 minutes, unless
packaging advises otherwise.
•The turkey can be open roasted,
breast side down, for half of the
cook time, and then turned over
for the remainder of the cooking
time.
•If roasting turkey covered with foil,
add 5 minutes per 450kg (1lb) to
the cooking time.
To test if the turkey is cooked, push a
fine skewer into the thickest part of the
thigh. If the juices run clear, the turkey
is cooked. If the juices are still pink,
the turkey will need longer cooking.
19
Using The Main Oven
08 27148 00 605MF 8/10/04 12:40 PM Page 20
