Stoves
Freestanding Dual Fuel Wok UK Part No 083286601 Date 01/08/2013
Users Guide & Installation
Handbook

CONTENTS & INTRODUCTION
3.000
CONTENTS
• SAFETY
• USING THE PRODUCT
• CLEANING
• INSTALLATION INSTRUCTIONS
• TECHNICAL DATA
• CUSTOMER CARE
INTRODUCTION
Thank you for buying this British-
built appliance from us.
This guide book is designed to help you
through each step of owning your new
cooker, from installation to use. Please
read it carefully before you start using
your product, as we have endeavored to
answer as many questions as possible,
and provide you with as much support
as we can.
If,however,youshouldndsomething
missing, or not covered, please contact
our Customer Care team. Their number is
located on the back page of this book.
For customers outside the UK and
Northern Ireland, please contact your
local supplier.
When you dial this number you will hear
a recorded message and be given a
number of options. This indicates that
your call has been accepted and is
being held in a queue. Calls are answered
in strict rotation as our Customer Care
representatives become available.
Alternatively, general information, spares
and service information is
available from our website. The address is
located on the back page of this book.
WARRANTY
Your new appliance comes with our
12-month guarantee, protecting you
against electrical and mechanical
breakdown. To register your appliance
please call 0844 481 0182, complete
the registration form included or register
online at the web address located on the
back page of this book.
For full terms & conditions of the manu-
facturer’s guarantee, refer to the website
on the back of this book.
In addition, you may wish to purchase
anextendedwarranty.Aleaet
explaining how to do this is included
with your appliance.
Our policy is one of constant
development and improvement,
therefore we cannot guarantee the strict
accuracy of all of our illustrations and
specications-changesmayhavebeen
made subsequent to publishing.
GAS WARNING
If you smell gas:
Do not try to light any appliance.
Do not touch any electrical switch.
Call the Gas Emergency Helpline at
TRANSCO on: 0800 111999

SAFETY
5.110
BEFORE USING THE PRODUCT
Make sure that you have removed all
packaging and wrapping. Some of the
items inside this appliance may have ad-
ditional wrapping.
It is advised that you turn the ovens and/
or grill on for a short while. This will burn
off any residues left from manufacturing.
There may be a smell which accompanies
this process - but this is nothing to worry
about and is harmless.
It is recommended that you wash the
oven shelves, baking tray, grill pan and
grillpantrivetbeforetheirrstuseinhot
soapy water. This will remove the protec-
tive oil coating.
GENERAL
WARNING! - The
appliance and its
accessible parts become
hot during use. Care
should be taken to
avoid touching heating
elements. Children less
than 8 years of age shall
be kept away unless
continously supervised.
This appliance can
be used by children
aged from 8 years and
above and persons with
reduced physical sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision
or instruction concerning
the use of the appliance
in a safe way and
understand the hazards
involved. Children
shall not play with the
appliance. Cleaning and
user maintenance shall
not be made by children
without supervision.
WARNING! -
Unattended cooking on
a hob with fat or oil can
be dangerous and may
resultinre.
NEVER try to extinguish
arewithwater,but
switch off the appliance
andthencovertheame
with a lid or damp cloth.
WARNING! - Danger of
re:Donotstoreitems
on the cooking surfaces.
WARNING! - Servicing
should be carried out
only by authorised
personnel.

SAFETY
5.110
WARNING! - The
appliance must never
be disconnected from
the mains supply during
use, as this will seriously
affect the safety and
performance, particularly
in relation to surface
temperatures becoming
hot and gas operated
parts not working
efciently.Thecooling
fan(iftted)isdesigned
to run on after the
control knob has been
switched off.
WARNING! -
Do not spray aerosols
in the vicinity of this
appliance while it is in
operation.
WARNING! - Do not
storeoruseammable
liquids or items in the
vicinity of this appliance.
WARNING! -
Do not modify this
appliance.
WARNING! - Do not
use harsh abrasive
cleaners or sharp
metal scrapers to clean
the oven door glass since
they can scratch the
surface, which may
result in shattering of the
glass.
WARNING! - Do not
operate the appliance
without the glass panel
correctlytted.
WARNING! - There is
a risk of electric shock,
so always make sure
you have turned off
and unplugged your
appliance before
starting. Always allow
the product to cool down
before you change a
bulb.
WARNING! - Accessible
parts may become hot
when the grill is in use.
children should be kept

SAFETY
5.110
away.
WARNING! - Never
place food, or dishes on
the base of the main
oven, the element is here
and it will cause over
heating.
WARNING! - Do not
modify the outer panels
of this appliance in any
way.
WARNING! - This
appliance must be
earthed.
WARNING! - The top
element gets extremely
hot when in use, so take
care to avoid touching it.
WARNING! - The use of
inappropriate hob guards
can cause accidents.
GAS WARNING! -
Ifyousmellgas:
Do not try to light any
appliance.
Do not touch any
electrical switch.
Contact your local gas
supplier immediately.
Caution: This appliance
is for cooking purposes
only. It must not be used
for other purposes, for
example room heating.
OVEN / GRILL
Do
• Always take care when removing food
from the oven as the area around the
cavity may be hot.
• Always use oven gloves when han-
dling any utensils that have been in
the oven as they will be hot.
• Always make sure that the oven
shelves are resting in the correct po-
sition between two runners. Do not
place the oven shelves on top of the
highest runner, as this is not stable
and can lead to spillage or injury.
• Always use the Minute Minder (if
tted)ifyouareleavingtheoven
unattended - this reduces the risk of
food burning.
Do Not
• Never place items on the door while
it is open.
• Never wrap foil around the oven
shelvesorallowfoiltoblocktheue.
• Never drape tea towels near the oven
whileitison;thiswillcauseare
hazard.
Never pull heavy items, such as turkeys
or large joints of meat, out from the oven
on the shelf, as they may overbalance and
fall.

SAFETY
5.110
• Never use this appliance to heat any-
thing other than food items and do
not use it for heating the room.
GAS HOB
Do
• Always ensure that pan bases are dry
andatbeforeusingthemonthehob.
• Always position pans over the centre
of the heat zone, and turn the
handles to a safe position so they
cannot be knocked or grabbed.
• Always use pans which are no smaller
than100mm(4”),orlargerthan
250mm(10”).Usea230mm(9”)
pan above the wok burner, if two or
more other hotplate burners are in
use at the same time.
• Always match the size of pan to the
heat zone – do not use large pans
on small zones or vice versa.
• Always make sure that the burner
caps, rings and pansupports are cor-
rectly placed. This will prevent pans
becoming unstable while in use and
ensureanuninterruptedgasow.
Do Not
• Never use double pans, rim-based
pans, old or misshapen pans, or
anypanthatisnotstableonaat
surface.
• Never leave cooking fat, or oil, unat-
tended.
• Never use commercial simmering
aids, or heat diffusers, as they create
excessive heat and can damage the
surface of the hob.
• Never use the hob for any other
purpose than cooking food.
• Plastic cooking utensils can melt if
they come into contact with a warm
hob. Never leave them close to, or
on top of the hob.
• Never leave any heat zone alight
without a pan covering it. This
causesarehazard.
• Never leave an empty pan on a heat-
ing zone.
• Never leave anything lying on the
hob.
• Never heat a sealed tin of food, as it
might explode.
• Never use the hob surface for stor-
age.
Fire Safety Advice
Mostkitchenresoccurwhenpeopleare
distracted or leave things unattended.
Don’t let yourself be distracted while
cooking. If you’re called away from the
cooker, either take pans off the heat, or
switch off your hob.
Ifyoudohaveareinthekitchen,don’t
take any risks - get everyone out of your
home and call the Fire Brigade.
If a pan catches re:
• Do not move it - it is likely to be
extremely hot.
• Turn off the heat if it’s safe to do so
- but never lean over a pan to reach
the controls.
• Ifyouhaveareblanket,putitover
thepan.Ifyouhaveputthereout,
leave the pan to cool completely.
Deep-fat frying presents more dan-
gers in your kitchen.
• Neverllachippan(orotherdeep-
fatfryer)morethanone-thirdfullof
oil
• Donotuseareextinguisherona
pan of oil - the force of the extin-
guishercanspreadthereandcre-
ateareball.

SAFETY
5.110
If you have an electrical re in the
kitchen:
• Pull the plug out, or switch off the
power at the fuse box - this may be
enoughtostopthereimmediately
• Smothertherewithareblanket,
or use a dry powder or carbon diox-
ide extinguisher
• Remember:neverusewateronan
electricalorcookingoilre.

IGNITION PROCEDURE
Prior to ignition:
Hotplate burner(s), position correctly
sized,atbottomedpan(s)directlyonto
the pan support above the selected
burner(s).
Wok burner (if tted)
a)Positionaatbottomedwokoracor-
rectlysized,atbottomedpandirectly
onto the pan support above the wok
burner.
b)Positiontheprovidedwokstanddirect-
ly onto the pan support above the wok
burner, then position a round bottomed
wok directly onto the stand.
Correct procedure for ignition of all
gas burners on this appliance.
Manual ignition (if applicable)
• Push in and keep depressed the igni-
tion button . Sparking to all gas
burners will commence.
• Push in and turn the selected gas
burnercontrolknobtothefullame
symbol . Keep the control knob
depressed.
• As soon as the selected burner ig-
nites release the ignition button.
• Continue to hold the control knob in
for up to 15 seconds then release.
• If the burner fails to ignite within this
time, release the control knob and
wait 1 minute before attempting to
re-ignite.
Automatic ignition (if applicable)
• Push in and turn the selected gas
burnercontrolknobtothefullame
symbol . Keep the control knob
depressed. Sparking to the selected
burner will commence automatically.
Sparking will cease automatically
oncetheameisestablished.
• Continue to hold the control knob in
for up to 15 seconds then release.
• If the burner fails to ignite within this
time, release the control knob and
wait 1 minute before attempting to
re-ignite.
In the event of a power failure, or the
ignition not working, then a lighted match
or taper can be used to ignite the burner.

USING THE HOB - GAS
• Use pans which are large enough to
avoidoverowsontothehobsurface.
• Wipe any spillage as soon as pos-
sible.
• Clean the hob top as regularly as
possible, this will prevent any build
upofgreasewhichmaybeare
hazard.
Use
• Place your pan onto the pan supports
above the burner you wish to use.
• Flat based woks may be positioned
onto the pan support directly above
the wok burner
• To ignite, see IGNITION PROCE-
DURE page.
• To simmer, turn the control knob to
thesmallamesymbol.Thiswill
ensurethattheameisjustlarge
enough to gently heat the contents of
the pan.
• To turn off, turn the control knob to
the off position.
• Always make sure that your pans are
placed centrally on the burners and
donotallowtheametoextendover
the base of the pan.
• Avoid the use of pans that overhang
the edges of the hotplate.
• To use a round bottomed wok, posi-
tion the wok stand provided onto the
pan support above the wok burner,
then position the wok onto the stand.
Energy Saving
• Position pans centrally over the burn-
ers.
• Only heat the amount of liquid you
need.
• Once liquids have been brought to
the boil, reduce the heat setting to a
simmer.
• Consider using a pressure cooker if
possible.
• Vegetables cut into small pieces will
cook more quickly.
• Use a pan which is a close match to
your burner size.
• Smaller burners are ideal for sim-
mering and stewing in smaller pans,
while the larger burners are ideal for
frying and boiling.
FOLD DOWN LID (IF FITTED)
Caution: Glass lids may shatter when
heated. Turn off all the burners before
shutting the lid.
When opening and closing the lid, use the
cooler outer sides of the lid glass.
The lid must be opened fully, so there is
no danger of it closing while the hob is
being used.
Theapplianceisttedwithasafetysys-
tem, which will automatically turn off the
hotplate burners if they are inadvertently
left on as the lid is closed.
The lid is not intended to be used as a
work surface, as it becomes hot when any
part of the cooker is in use. The surface
may be scratched if items with rough or
sharp surfaces are placed on it.
Always remove any spillage from lid be-
fore opening.
Always allow the hob surface to cool
before closing the lid.
Make sure that the wok stand is removed
from the pan support before closing lid.

USING THE GRILL - ELECTRIC
Caution: Accessible parts may be
hot when the grill is used - young
children should be kept away.
A grill pan handle can be purchased as an
optional extra from our spares department
quotingthepartnumbersbelow:
Handle - 082283705
Handlegrip-082469100
Complete grill pan pack - 012635666
Contact details can be found on the
customer care page.
If cleaning the grill pan when it is hot, use
oven gloves to move it.
Food for grilling should be positioned
centrally on the trivet.
Using the grill
Important: The grill door must be fully
open when the grill is used.
Open the grill door. Turn the control knob
to the required setting. For best cooking
results, we recommend that you preheat
the dual grill for 3 minutes and the single
grill for 5 minutes.
For grilling small quantities of food, the
centre(economy)grillcanbeusedwith
the grill trivet inverted. For large quanti-
ties of food, the full grill can be used.
Push the grill pan towards the back of the
shelf, to position it under the grill.
The speed of grilling can be controlled by
adjusting the grill setting or by selecting a
higher or lower shelf position. For toast-
ing, and for grilling foods such as bacon,
sausages or steaks, use a higher shelf
position. For thicker foods such as chops
or chicken joint pieces, use a middle to
low shelf position.
The grill trivet, inside the grill pan, can be
inverted to give a high or low position, or
it may be removed.
To switch off, turn the control knob to the
off position.
Using aluminium foil
Using aluminium foil to cover the grill pan,
or putting items wrapped in foil under the
grillcreatesarehazard.
The cooling fan
When the grill is switched on, the cool-
ing fan comes on to keep the fascia and
control knobs cool during grilling. The fan
may continue to operate for a period after
the grill has been switched off.
During use the fan may cycle on and off,
this is normal.
Alternatively, you may have grill symbols
similar to these below.
or Full grill at 1/4
power
Centre grill at full
power
Full grill area at
full power
Types of grill
Variable rategrill:
has adjustable heat settings
1(low)to8(high)or5(high)-de-
pending on the model.
Single grill:hasonegrillelement.The
grill pan trivet MUST be inverted when
using the single grill function.
Dualgrill: has two grill elements which
can be used together, or as a single
grill.
7.101
