OPERATION MANUAL
Revision #0 (07/17/08)
MODEL STR46SPVGHMODEL STR46SPVGH
MODEL STR46SPVGHMODEL STR46SPVGH
MODEL STR46SPVGH
RIDE ON POWER TROWEL
(B & S VANGUARD GASOLINE ENGINE)
P/N 22315
THIS MANUAL MUST ACCOMPANYTHE EQUIPMENT AT ALLTIMES.
To find the latest revision of this
publication, visit our website at:
www.multiquip.com

Grinding/cutting/drilling of masonry, concrete, metal and
other materials with silica in their composition may give
off dust or mists containing crystalline silica. Silica is a
basic component of sand, quartz, brick clay, granite and
numerous other minerals and rocks. Repeated and/or
substantial inhalation of airborne crystalline silica can
cause serious or fatal respiratory diseases, including
silicosis. In addition, California and some other
authorities have listed respirable crystalline silica as a
substance known to cause cancer. When cutting such
materials, always follow the respiratory precautions
mentioned above.
WARNING
Grinding/cutting/drilling of masonry, concrete, metal and
other materials can generate dust, mists and fumes
containing chemicals known to cause serious or fatal
injury or illness, such as respiratory disease, cancer,
birth defects or other reproductive harm. If you are
unfamiliar with the risks associated with the particular
process and/or material being cut or the composition of
the tool being used, review the material safety data
sheet and/or consult your employer, the material
manufacturer/supplier, governmental agencies such as
OSHA and NIOSH and other sources on hazardous
materials. California and some other authorities, for
instance, have published lists of substances known to
cause cancer, reproductive toxicity, or other harmful
effects.
Control dust, mist and fumes at the source where
possible. In this regard use good work practices and
follow the recommendations of the manufacturers or
suppliers, OSHA/NIOSH, and occupational and trade
associations. Water should be used for dust
suppression when wet cutting is feasible. When the
hazards from inhalation of dust, mists and fumes cannot
be eliminated, the operator and any bystanders should
always wear a respirator approved by NIOSH/MSHA for
the materials being used.
WARNING
SILICOSISWARNING RESPIRATORY HAZARDS

STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 3
STR46SPVGH —TABLE OF CONTENTS
STOW — STR46SPVGH RIDE-ON
POWER TROWEL
(VANGUARD ENGINE)
Table of Contents ...................................................... 3
Training Checklist ...................................................... 4
Daily Pre-Operation Checklist ................................... 5
Safety Message Alert Symbols .............................. 6-7
Rules For Safe Operation .................................... 8-11
Dimensions ............................................................. 12
Specifications .......................................................... 13
General Information ................................................ 14
Controls and Indicators ...................................... 15-16
Engine Components ............................................... 17
Setup ....................................................................... 18
Inspection ................................................................ 19
Operation ........................................................... 20-21
Maintenance ...................................................... 22-36
Decals ..................................................................... 37
Troubleshooting ................................................. 38-39
Terms And Conditions of Sale-Parts ....................... 40
NOTE
Specifications and
part numbers are
subject to change
without notice.

PAGE 4 — HHN 31V
STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 4
Operator _________________________________________ Trainee __________________________________________
COMMENTS:
STR46SPVGH —TRAINING CHECKLIST
TRAINING CHECKLIST
This checklist lists some of the minimum requirements for machine operation. Please feel free to make copies for daily use. Use this
checklist when training a new operator or use as a review for more experienced operators.
TSILKCEHCGNINIART
.ON NOITPIRCSED ?KO ETAD
1 .yletelpmoclaunaMs’rotarepOdaeR
2 .slevellioxobraegdnaenignefognikcehc,stnenopmocfonoitacol,tuoyalenihcaM
3 .erudecorpgnileufer,metsysleuF
4 .)deppiuqefi(sthgildnayarpsfonoitarepO
5 .)gninnurtonenihcam(slortnocfonoitarepO
6 .noitarepohctiwSpotSytefaStaes,slortnocytefaS
7 .serudecorppotsycnegremE
8 .enihcamfoputratS
9 .revohagniniatniaM
01 gnirevuenaM
11 gnihctiP
21 .srewotneewtebhctipedalbgnihctaM
31 .seuqinhcetgnihsinifetercnoC
41 .enihcamfonwodtuhS
51 .punaelcenihcaM
61 .)spooltfil(enihcamfognitfiL
71 .egarotsdnatropsnartenihcaM

STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 5
DAILY PRE-OPERATION CHECKLIST
COMMENTS:
DAILY PRE-OPERATION CHECKLIST
TSILKCEHCNOITAREPO-ERPYLIAD
1
.leveLliOenignE
2
diulFxobraeGleveL .
3 .leveLtnalooCrotaidaR
4 sedalBfonoitidnoC .
5 .noitarepOhctiPedalB
6 .noitarepOhctiwSpotS-ytefaS
7 .noitarepOlortnoCgnireetS
8 .stleBfonoitidnoC

PAGE 6 — HHN 31V
STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 6
HAZARD SYMBOLS
Engine exhaust gases contain harmful toxins
and will displace oxygen when running in an
enclosed or confined space. NEVER operate
this equipment in a confined area or enclosed
structure that does not provide ample free
flow air.
Engine fuel is flammable, and its vapors can
cause an explosion if ignited. DO NOT start
the engine near spilled fuel or combustible
fluids. DO NOT fill the fuel tank while the
engine is running or hot. DO NOT overfill
tank, since spilled fuel could ignite if it comes
into contact with hot engine parts or sparks
from the ignition system. Store fuel in
approved containers, in well-ventilated areas
and away from sparks and flames. NEVER
use fuel as a cleaning agent.
Explosive Fuel
Lethal Exhaust Gases
Burn Hazards
Engine components can generate extreme heat.
To prevent burns, DO NOT touch these areas
while the engine is running or immediately after
operations. NEVER operate the engine with
heat shields or heat guards removed.
Rotating Parts
NEVER operate equipment with covers or
guards removed. Keep
fingers , hands , hair
and clothing away from all moving parts to
prevent injury.
Safety precautions should be followed at all times when
operating this equipment. Failure to read, understand and
comply with the Safety Messages and Operating Instructions
could result in injury to yourself and others.
FORYOUR SAFETY ANDTHE SAFETY OF OTHERS!
This Operation Manual has been
developed to provide instructions for the
safe and efficient operation of the STR -
46SPVGH Ride-On Trowel. For engine
maintenance information, please refer to the
engine manufacturer's instructions for data
relative to its safe operation.
Before using this Ride-OnTrowel, ensure that the operating
individual has read, understands, and complies with all
instructions in this manual.
SAFETY MESSAGE ALERT SYMBOLS
The three (3) Safety Messages shown below will inform you
about potential hazards that could injure you or others. The
Safety Messages specifically address the level of exposure to
the operator, and are preceded by one of three words:
DANGER, WARNING, or CAUTION.
You WILL be
KILLED or SERIOUSLY INJURED
if you DO NOT follow these directions.
You CAN be KILLED or
SERIOUSLY INJURED if
you DO NOT follow these directions.
You CAN be
INJURED if you DO NOT follow
these directions.
CAUTICAUTI
CAUTICAUTI
CAUTION
DANGERDANGER
DANGERDANGER
DANGER
WARNINGWARNING
WARNINGWARNING
WARNING
Potential hazards associated with trowel operation will be
referenced with Hazard Symbols which appear throughout this
manual, and will be referenced in conjunction with Safety
Message Alert Symbols.
STR46SPVGH — SAFETY MESSAGE ALERT SYMBOLS

STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 7
Accidental Starting Respiratory Hazard
ALWAYS wear approved respiratory protection.
ALWAYS wear approved eye and
hearing protection.
Sight and Hearing hazard
Equipment Damage Messages
Other important messages are provided throughout this manual
to help prevent damage to your trowel, other property, or the
surrounding environment.
STR46SPVGH — SAFETY MESSAGE ALERT SYMBOLS
Over Speed Conditions
NEVER tamper with the factory settings of the
engine governor or settings. Personal injury
and damage to the engine or equipment can
result if operating in speed ranges above
maximum allowable.
ALWAYS place the ON/OFF switch in the
OFF position. Disconnect and ground spark
plug lead and disconnect negative battery
cable from battery before servicing.
Accidental starts can
cause severe injury or
death.
This Ride-On Trowel, other property, or the
surrounding environment could be damaged
if you do not follow instructions.
CAUTICAUTI
CAUTICAUTI
CAUTION

PAGE 8 — HHN 31V
STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 8
STR46SPVGH — RULES FOR SAFE OPERATION
The following safety guidelines should always be used when
operating the Ride-On Trowel.
SAFETY
■ DONOToperate or service this equipment
before you read, understand, and comply
with all safety messages in this manual.
The manual must be kept available and
accessible to the operator.
■ This equipment should not be operated by persons under the
minimum statutory age limit.
■ ALWAYS use extreme caution when working with flammable
liquids. When refueling, STOP the engine. Allow the engine
to cool before adding fuel or performing service and
maintenance functions.
■ NEVERtouch the hot exhaust manifold, muffler
or cylinder. Allow these parts to cool before
servicing the trowel. Contact with
hot
components can cause serious burns.
■ The engine of this trowel requires an adequate free flow of
cooling air. NEVER operate the trowel in any enclosed or
narrow area where free flow of
the air is restricted. If the air flow
is restricted it will cause serious
damage to the engine and may
cause injury to people.
Remember the engine can give
off harmful toxins and will
displace oxygen.
■ ALWAYS refuel in a well-ventilated area, away from sparks
and open flames.
RULES FOR SAFE OPERATION
■ ALWAYS check the trowel for loosened hardware such as
nuts and bolts before starting.
■ Replace nameplate, operation and safety decals when they
become difficult to read.
■ NEVER use accessories or attachments which are not
recommended by Multiquip for this equipment. Damage to
the equipment and/or injury to user may result.
■ Manufacturer does not assume responsibility for any accident
due to equipment modifications. Unauthorized equipment
modification will void all warranties. Any modification which
could lead to a change in the original characteristics of the
machine should be made only by the manufacturer who shall
confirm that the machine is in conformity with appropriate
safety regulations.
WARNINGWARNING
WARNINGWARNING
WARNING
Failure to follow instructions in this manual may lead to serious
injury or even death! This equipment is to be operated by
trained and qualified personnel only! This equipment is for
industrial use only.
■ NEVER smoke around or near the machine.
Fire or explosion could result from
fuel
vapors
, or if fuel is spilled on a hot! engine.
■ Topping-off to filler port is dangerous, as it tends to spill fuel.
■ NEVER use fuel as a cleaning agent.
■ NEVER operate this equipment when not feeling well due to
fatigue, illness or taking medicine.
■ NEVER operate the trowel under the influence or drugs or
alcohol.
■ NEVERoperate the trowel without proper protective clothing,
shatterproof glasses, steel-toed boots and other protective
devices required for the job.
■ NEVER use this machine for any purpose other than those
described in this manual.
■ NEVER operate the trowel in an
explosive atmosphere where fumes
are present, or near combustible
materials. An explosion or fire could
result in severe
bodily harm or even
death.

STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 9
■ NEVER run engine without air filter. Severe engine damage
may occur. Service air filter frequently to prevent carburetor
malfunction.
■ NEVER place your feet or hands inside the guard rings
while starting or operating this equipment.
■ AVOID wearing jewelry or loose fitting clothing that may snag
on the controls or moving parts as this can cause a serious
injury.
■ ALWAYS keep clear of rotating or moving parts while
operating the trowel.
■ Moving Parts – Shut down the engine before performing
service or maintenance functions. Contact with moving parts
can cause serious injury.
■ ALWAYS check to make sure that the operating area is clear
before starting the engine.
■ NEVER leave the machine unattended while running.
■ ALWAYS be sure the operator is familiar with proper safety
precautions and operations techniques before using trowel.
■ ALWAYS keep the work area well organized.
■ ALWAYS clear the work area of any debris, tools, etc. that
would constitute a hazard while the trowel is in operation.
■ ALWAYS store equipment properly when it is not being used.
Equipment should be stored in a clean, dry location out of the
reach of children.
■ No one other than the operator is to be in the working area
when the trowel is in operation.
■ NEVER allow passengers or riders on the trowel during
operation.
■ Always observe all applicable compulsory regulations
relevant to environmental protection, especially, fuel storage,
the handling of hazardous substances, and the wearing of
protective clothing and equipment. Instruct the user as
necessary, or, as the user, request this information and
training.
ALWAYS check to make sure that the operating area is
clear before starting the engine.
WARNINGWARNING
WARNINGWARNING
WARNING
STR46SPVGH — RULES FOR SAFE OPERATION
NEVERstand under or allow anyone
else to stand under the trowel while it
is being lifted.
Pay close attention to ventilation when
operating the trowel in confined spaces
such as tunnels, buildings or similar areas.
The engine exhaust contains harmful
elements. Ensure proper air flow to move
engine exhaust away from the operator.
Lifting the Ride-OnTrowel
This ride-on trowel is very
heavy and awkward to move
around. Use proper heavy lifting procedures and DO NOT
attempt to lift the ride-on trowel by the guard rings.
The STR46SPVGH Ride-On Power Trowel is designed to be
moved and handled several ways.
The easiest way to lift the trowel is to utilize the lift loops that are
welded to the frame.These lift loops are located to the left and
right sides of the operator’s seat.
A strap or chain can be attached to these lift loops, allowing a
forklift or crane to lift the trowel up onto and off of a slab of concrete.
The strap or chain should have a minimum 2,000 pounds (1000-
kg) lifting capacity and the lifting gear must be capable of lifting
at least this amount.
DANGERDANGER
DANGERDANGER
DANGER
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
DANGERDANGER
DANGERDANGER
DANGER

PAGE 10 — HHN 31V
STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 10
Battery
■ In case the battery electrolyte liquid, (dilute sulfuric acid),
comes in contact with
clothingorskin , rinse skin or clothing
immediately with plenty of water.
■ In case the battery electrolyte liquid, (dilute sulfuric acid),
comes in contact with your
eyes , rinse eyes immediately
with plenty of water, then contact the nearest doctor or hospital
and seek medical attention.
The battery contains acid that can cause injury to the eyes and
skin. To avoid eye irritation,
always wear safety glasses or face
shielding. Use well insulated gloves when handling the battery.
Use the following guidelines when handling the battery.
■ Use chock-blocks underneath each wheel when parked to
prevent trailer from rolling.
■ Use the trailer's swivel jack to adjust the trailer height to a
level position while parked.
■ Avoid sudden stops and starts. This can cause the trailer to
skid or jack-knife. Smooth, gradual starts and stops will
improve towing.
■ Avoid sharp turns.
■ Trailer should be adjusted to a level position at all times
when towing.
■ Raise and lock trailer wheel stand in the "UP" position when
transporting.
■ DOT requirements include the following:
Connect and test electric brake operation.
Secure portable power cables in cable tray with tie wraps.
■ DO NOT drop the battery. Any impact to
the battery may cause it to explode.
■ DONOTexpose the battery to open flames,
sparks, lit cigarettes etc. The battery
contains combustible gases and liquids. If
these gases and liquids come in contact
with a flame or spark an explosion can occur.
■ ALWAYS keep the battery charged. If the
battery is not charged a buildup of combustible gas will occur.
■ ALWAYS keep battery cables in good working condition.
Repair or replace all worn cables.
■ ALWAYS disconnect the negative battery terminal before
performing service on the trowel.
■ ALWAYS recharge the battery in a vented air environment
to avoid risk of a dangerous concentration of combustible
gases.
STR46SPVGH — RULES FOR SAFE OPERATION
Towing Safety Precautions
Conform to
Department ofTransportation (DOT) Safety
Towing Regulations
before transporting trowel on public
roads.
To reduce the possibility of an accident while transporting the
trowel on public roads, always make sure the trailer that supports
the trowel and the towing vehicle are in good operating condition
and both units are mechanically sound.
Transporting
■ ALWAYS shutdown engine before transporting.
■ Tighten fuel tank cap securely and close fuel cock to prevent
fuel from spilling.
■ Drain fuel when transporting trowel for long distances or over
bad roads.
■ When placing the trowel on a truck-bed for transport, always
tie-down the trowel.
■ If the trowel is being transported via a trailer, make sure the
trailer complies with all local and state safety transportation
laws. Refer to the following "
Towing Safety Precautions"
for basic towing techniques.
The following list of suggestions should be used when towing
your trowel:
■ Make sure the hitch and coupling of the towing vehicle are
rated equal to, or greater than the trailer "gross vehicle weight
rating" (GVWR) of 6,000 lbs.
■ ALWAYS inspect the hitch and coupling for wear. NEVER
tow a trailer with defective hitches, couplings, chains, etc.
■ Check the tire air pressure on both towing vehicle and trailer.
Trailer tires should be inflated to 50 psi cold . Also check
the tire tread wear on both vehicles.
■ ALWAYS make sure the trailer is equipped with "Safety
Chains ".
■ ALWAYS attach trailer's safety chains to towing vehicle
properly.
■ ALWAYS make sure the vehicle and trailer directional,
backup, brake, and trailer lights are connected and working.
■ DO NOT exceed the recommended highway speed when
towing.
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION

STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 11
Emergencies
■ ALWAYS know the location of the
nearest
first aid kit .
■ Know the phone numbers of the nearest
ambulance , doctor and fire department .Ensure
that a phone or radio is readily available at the
jobsite. If this is not possible, know the location of
the nearest phone. This information will be
invaluable in the event of an emergency.
STR46SPVGH — RULES FOR SAFE OPERATION
■ DON'TPOLLUTE! Waste oils and other chemicals must be
disposed of in a manner consistent with local and state
environmental protection regulations. Examples of potentially
hazardous waste are used motor oil, fuel and fuel filters.
■ DONOTuse plastic food containers to dispose of hazardous
waste.
■ DO NOT pour waste, oil or fuel directly onto the ground,
down a drain or into any water source.
Maintenance Safety
■ ALWAYS know the location of
the nearest
fireextinguisher .
■ Orientation of the Battery
The positive cable , normally red, is associated with the "+" symbol
on the battery. The negative cable, normally black, is associated
with the "-" symbol on the battery. The positive cable is connected
to the positive terminal on the battery and the negative cable is
connected to the negative terminal.
■ Replace batteries that have cracked or broken cases or
batteries that are otherwise leaking electrolyte.
■ Always replace with battery of equivalent type and rating.
Never replace with a non-rechargeable battery.
■ Always dispose of battery properly. Bring to appropriate facility
for lead reclamation.These facilities can generally be found
in the local phone listings under "Recycling Services".
■ A good practice is to isolate the machine when removing the
battery.
■ ALWAYS shut down the engine and disconnect battery before
performing service or maintenance functions. Contact with
moving parts can cause serious injury.
■ Securely support any trowel components that must be raised.
■ NEVERlubricate components or attempt service on a running
trowel.
■ ALWAYS allow the trowel a proper amount of time to cool
before servicing.
■ Keep the trowel in proper running condition.
■ Make sure that there is no buildup of concrete, grease, oil or
debris on the machine.
■ Fix damage to the trowel immediately and always replace
broken parts.
2
1
1. Negative Cable (BLACK)
2. Positive Cable (RED)

PAGE 12 — HHN 31V
STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 12
STR46SPVGH — SPECIFICATIONS
NOTE:
1. This value does not include seat height.To obtain total
height (seat ) add 4 inches (10.2 cm.).
2. Sound pressure is "A" weighted . Measured at the operators
ear position while the ride-on trowel is operating at full
throttle on concrete in a manner most often experienced in
“
normal ” circumstances. Sound pressure may vary
depending upon the condition of the concrete. Hearing
protection is always recommended.
3. The vibration level indicated is the maximum RMS (Root
Mean Square) value obtained at the handle grip while
operating the ride-on trowel on curing concrete in a
manner most often experienced in “
normal ”
circumstances. Values were obtained from all three axes
of motion.The values shown represent the maximum RMS
value from these measurements.
STR
46
C-HEIGHT
1
A-LENGTH
B-WIDTH
Figure 2. STR46SPVGH
Dimension Specifications
snoitacificepSHGVPS64RTS.1elbaT s
RETEMARAPNOITACIFICEPS )DRAUGNAV(HGVPS64RTS
)mc(.ni–htgneL–A )4.642(0.79
)mc(.ni–htdiW–B )721(0.05
)mc(.ni–thgieH–C
1
)711(0.64
gnitarepO).sgk(.sbl–thgieW )774(240,1
gnippihS).sgk(.sbl–thgieW )555(422,1
ABd–erusserPdnuoS
2
59
s/tf–noitarbiV
2
s/m(
2
)
3
)5.2(0.8<
phbtuptuoxam–enignE 13
)sretil(snollag–knaTleuF )91(5
MPR–rotoR 061ot06
)mc(.ni–htdiWhtaP )132(19
liOnoitacirbuLxobraeG PE5RG022OSI
yticapaCliOxoBraeG )sretil62.4(.zo441
)daoLlluF(noitpmusnoCleuF rh-phb/bl45.0
yticapaCrotaidaR )sretil97.3(.lag0.1

STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 13
STR46SPVGH— SPECIFICATIONS (ENGINE)
snoitacificepSenignEHGVPS64RTS.2elbaT
ledoM DRAUGNAVNOTTARTS&SGGIRB HGVPS64RTS
epyT draugnaV,nottartS&sggirB
HGVPS64RTS
srednilyC3
tnemecalpsiDnotsiP)cc259(.ni.uc1.85
ekortSdnaeroB )mm87xmm27(.ni70.3x.ni38.2
tuptuO.xaM)wK53.52(mpr0063/phb13
euqroT.xaMmpr0032ta)gK4.62(tf-fbl3.85
metsySgnilooC noitalucricdecrof,delooc-diuqil
yticapaCliOenignE )sretil3(.tq2.3
)tnemecalperretliflio/wsretil3.3(.tq5.3
metsySgnitacirbuL retliFrepaPwolF-lluFhtiwebuLerusserP
liOnoitacirbuLenignErehgihrossalcESIPA
knaTleuF)sretil9.81(.lag5
yticapaCdnuopmoCraeGxobraeGlacileH )sretil62.4(.zo441
PE5RGAMGAO22OSI
leuF gnitarenatco58fomuminim-leuFenilosaG
metsySgnitratSretratScirtcelE
thgieWyrDenignE)gK98(.sbl691
)HxWxL(snoisnemiD .ni47.91x.ni28.71x.ni72.71
)mm4.105xmm5.744xmm7.834(

PAGE 14 — HHN 31V
STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 14
STR46SPVGH — GENERAL INFORMATION
STR46SPVGH Ride-On PowerTrowel Familiarization
The STR46SPVGH Ride-On Power Trowel is designed for the
floating and finishing of concrete slabs.
Take a walk around your trowel. Take notice of all the major
components like the engine, blades, air cleaner, fuel system,
fuel shut-off valve, ignition switch etc. Ensure engine and gearbox
lubricant levels are within proper operating range.
Read all the safety instructions carefully. Safety instructions will
be found throughout this manual and on the machine. Keep all
safety information in good, readable condition. Operators should
be well trained on the operation and maintenance of the trowel.
Look at the operator control levers. Grasp the control levers and
move them around a bit. Observe how moving the control levers
cause the gearboxes and frame to move.
Notice the foot pedal which controls the engine and blade speed.
Also take a look at the main driveline of the trowel. Take note
and reference how the belts look, this is the way the belts should
look when adjusted properly.
Before using your trowel, test it on a flat watered down section of
finished concrete.This trial test run will increase your confidence
in using the trowel and at the same time it will familiarize you
with the trowel’s controls and indicators. In addition you will
understand how the trowel will handle under actual conditions.
Engine
This Trowel is equipped with a liquid cooled 31 HP Vanguard
gasoline engine.Refer to the engine owner’s manual for specific
instructions regarding engine operation.This manual is included
with the trowel at the time of shipping. Please contact your nearest
Multiquip Dealer should a replacement manual be required.
Blades
The blades of the STR46SPVGH Ride-On Power Trowel finish
the concrete as they are swirled around the surface. Blades are
classified as combination (10 or 8 inches wide) and finish (6
inches wide). The STR46SPVGH Ride-On Power Trowels are
equipped with five blades, per rotor equally spaced in a radial
pattern and attached to a vertical rotating shaft by means of a
spider assembly.
Figures 3 and 4 show the location of the controls, indicators and
general maintenance parts. Each control may perform more than
one function. The functions of each control or indicator is on
pages 15 and 16.
Gearboxes
The STR46SPVGH Ride-On Power Trowel consist of two
separate gearbox assemblies that are enclosed in rugged cast
aluminum gear cases.
The gearbox casing holds 50% more oil capacity than
competitors, which allows more lubrication to be provided to
critical points.
Steering
Dual control levers located in front of the operator's seat are
provided for steering this trowel.The control levers are linked to
two spring loaded cylinders.
Push the left control lever forward and pull the right control lever
backward and the trowel will rotate clockwise on approximately
a center axis. Pull the left control lever backward and push the
right control lever forward and the trowel will rotate
counterclockwise. See Table 3 on page 21 for a complete
description on the control levers directional positioning.
Constant Velocity Joints (CV-Joints)
Constant velocity joints insure the efficient transfer of power to
the drive shaft and maintain the timing of the gearboxes without
any chance of slippage.
Training
For training, please use the “TRAINING CHECKLIST” located
in the front of this manual (Page 4).This checklist is not intended
to be a substitute for proper training but will provide an outline
for an experienced operator to provide training to a new operator.

STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 15
STR46SPVGH — CONTROLS AND INDICATORS
Figure 3. STR46SPVGH Controls and Indicators (Front)
12. Hour Meter - Indicates number of hours the key switch is
in the "ON" position.
13. Choke Control Lever - In cold weather pull this lever
forward about half way to start engine. After engine warms
push knob all the way in.
14. Fuel Filler Cap - Remove this cap to add fuel.
15. FuelTank - Holds 5 gallons of fuel.
16. Spare Belt Carrier - Contains a spare belt. Belt is used on
the drive pulley.
17. Left Foot Riser – Operator foot rest pedal.
18. EZ-Mover Boss – Front-side insertion point for EZ Mover.
Used when the transporting of the trowel is required.
19. Right Foot Pedal – Controls blade speed. Slow blade
speed is accomplished by slightly depressing the foot pedal.
Maximum blade speed is accomplished by fully depressing
the foot pedal.
1. Seat – Provides comfortable position for operation of the
trowel. Engine will not start unless operator is seated. Seat
is adjustable, fore and aft for operator comfort.
2. Steering Control Lever (right side) -Allows the unit to
move in either a forward, reverse left or right direction.
3. Radiator/Filler Cap – Holds coolant or water necessary to
keep engine at a safe operating temperature. Remove this
cap to add water or antifreeze. DO NOT revove this cap
when the engine is warm.
4. Pitch Control (Right) – Adjusts the blade pitch for right
side of the trowel.
5. Pitch Control (Left) – Adjusts the blade pitch for left side
of the trowel.
6. SteeringControlLever(left side)-Allows the unit to move
in either a forward, reverse left or right direction.
7. Light Switch – When activated, turns on four halogen
lights. Lights offer better visibility when working indoors.
8. Ignition Switch – With key inserted turn clockwise to
start engine.
9. Oil Indicator Light - Lights red when oil pressure is low.
11. Charge Indicator - Lights red when electrical system is
not charging properly.
10. WaterIndicatorLight-Lights red when water temperature
is high.
STR
46
CHG
WATER
OIL
15 16
17
18
18
12
19
7
8
11
4
3
5
6
12
9
14
10

PAGE 16 — HHN 31V
STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 16
27
22
22
31
30
29
25
26
28
23
24
20
21
21
20
STR46SPVGH — CONTROLS AND INDICATORS
20. Oil Sight Glass - Indicates the level of the hydraulic oil in
the gear box.
21. EZ- Mover Boss– Front -side insertion point for EZ Mover.
Used when the transporting of the trowel is required.
22. Lift Loops – Located on both the left and right sides of the
main frame. Used when the trowel must be lifted onto a
concrete slab.
23. Lights – Four 12 volt halogen lights are provided with this
unit.
24. Right-Side Spider – Consists (basic) of trowel arms,
blades, wear plate, and thrust collar etc.
25. Left-SideSpider–Consists (basic) of trowel arms, blades,
wear plate, and thrust collar etc.
26. Belt Guard – Encloses drive belt used in conjunction with
clutch.
30. Oil Filter – Provides oil filtering for the engine.
31. Battery – Provides +12V DC power to the electrical
system
Figure 4. STR46SPVGH Controls and Indicators (Rear)
27. Overflow Bottle - Supplies coolant to the radiator when
radiator coolant level is low. Fill to indicated level as shown
on bottle.
28. Engine Air Filter – Prevents dirt and other debris from
entering the fuel system. Lift locking latch on air filter
cannister to gain access to filter element.
29. Engine Dip Stick – Indicates engine oil level. Add oil as
required.

STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 17
STR46SPVGH — ENGINE
Figure 5. Gasoline Engine Controls and Components
INITIALSERVICING
The gasoline engine (Figure 5) must be checked for proper
lubrication and filled with fuel prior to operation. Refer to the
manufacturer's engine manual for instructions & details of
operation and servicing.The engine shown above is a Briggs&
StrattonVanguardGasolineengine.Operation for other types of
engines may vary somewhat.
WARNINGWARNING
WARNINGWARNING
WARNING
Engine components can generate extreme
heat.To prevent burns, DO NOT touch these
areas while the engine is running or
immediately after operating. NEVERoperate
the engine with the muffler removed.
2. Oil Filler Cap – Remove to add engine oil.
1. Thermostat – Regulates the temperature of the engine
coolant.
3. Ignition Coil – Provides spark to the ignition system.
4. Starter – Starts engine when ignition key is rotated to the
"ON" position.
5. Oil Pan – Reservoir for engine oil.
6. Alternator – Maintains charge of battery.
7. Spark Plug – Provides spark to the combustion chamber.
Clean spark plugs once a week. Set spark plug gap
according to engine manufacturer's specifications.
8. CoolantTemperature Sending Unit – Provides coolant/
water temperature information to the water temperature
indicator. If temperature is too high will cause the
temperature indicator to be ON.
9. Governor Lever – Controls engine speed.
10. Oil Drain – Remove to drain crankcase oil.
11. Oil Filter – Spin-on type, filters oil for contaminants.
12. Oil Dip Stick – Remove to check amount and condition of
oil in crankcase.
13. Oil Pressure Sending Unit – Provides oil pressure
information to the oil pressure indicator. If oil pressure is
too low will cause the oil pressure indicator to be ON.
14. Carburetor – Provides a precise mixture of air and fuel to
run the engine.
15. Air Filter (not shown) – Prevents dirt and other debris
from entering the fuel system. Unsnap air filter cover to
gain access to filter element.

PAGE 18 — HHN 31V
STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 18
STR46SPVGH — NEW MACHINE SETUP INSTRUCTIONS
Trowel Pre-Set-Up Instructions
The purpose of this section is to assist the user in setting up a
NEW trowel. If the trowel is already assembled, (seats, handles,
knobs and battery), this section can be skipped.
Before packaging and shipping this Ride-On Power Trowel was
run and tested at the factory. If there are problems, please let us
know.
Control Handle Assembly
The steering control handles are not attached to the trowel's two
lower handles at the time of shipment. To attach the steering
control handles to the lower handle assemblies perform the
following:
1. Remove the bolts from the plastic bag tied to the control
towers.
2. Remove all protective wrapping and straps from the control
handles.
3. Slip the top (loose) control handle piece into the base of
the corresponding handle, making sure to line up the holes.
4. Install the bolt through the lined up holes and tighten the
acorn nut onto the threaded end.
5. Pay close attention to any wires that may be inside the
control handles. DO NOT pinch or cut any wires during
installation.
6. Remove the two knobs from the plastic bag for the pitch
control tower cranks and install the knobs onto the tower
crank levers.
1. Remove the seat from the protective wrapping.
2. Remove the bolts on the bottom of the seat, and place seat
on the seat mounting plate, then insert the bolts through
the holes or slots on the seat mounting plate and tighten.
Seat Assembly
The seat is not installed on the trowel for shipping purposes.
To attach the seat perform the following:
To install the battery on the trowel, make sure that the battery is
well seated in the battery box. The positive cable , normally red,
is associated with the "+" symbol on the battery. The negative
cable, normally black, is associated with the "-" symbol on the
battery. Connect the positive cable to the positive terminal on
the battery first, then connect the negative cable to the negative
terminal. Close the plastic battery box cover and secure the
battery box.
Use all safety precautions specified by the battery
manufacturer when working with the battery. See further
specific safety information on page 10 & 11 of this manual.
The new ride-on trowel cannot be put
into service until the pre-setup
installation instructions are
completed. These pre-setup
instructions only need to be performed
at the time of unpacking a
NEW
trowel.
NOTE
NOTE
Models equipped with adjustable
height handles are adjusted by
placing the bolt through the set of
holes that bring the handles to a
height most comfortable for the
operator.
NOTE
H-series trowels have a seat that is
mounted on tracks, similar to an
automobile seat. This seat can be
adjusted fore and aft via the control
lever under the front of the seat.
This trowel was shipped with a wet charged battery.This battery
may need to be charged for a brief period of time as per the
manufacturer instructions.
Battery Setup
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
Figure 6. Battery Cable Orientation
2
1
1. Negative Cable (BLACK)
2. Positive Cable (RED)

STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 19
STR46SPVGH — INITIAL START-UP
This section is intended to assist the operator with the initial
start-up of the STR46SPVGH trowel. It is extremely important
that this section be read carefully before attempting to use the
trowel in the field.
DO NOT use your trowel until this section is thoroughly
understood.
1. Check the gearbox oil level in both gearboxes
by viewing the sight glass at the rear of the
gearbox. See Figure 8.
Fuel
Determine if the engine fuel is low (Figure 9). If fuel level is low,
remove the fuel filler cap and fill with appropriate engine fuel.
The STR46SPVGH uses gasoline fuel.
2. The oil level of the gear box should be at the half-way point
of the sight glass (Figure 8). The gear box oil capacity is
144 oz., (4.26 liters). If additional oil is required, unscrew
the oil fill plug located on top of the gearbox, and refill with
ISO 220 A GMA GR 5 EP oil.
Figure 8. Gearbox Oil Plugs/Sight Glass
Figure 9. Fuel Fill Cap
Figure 7. Engine Oil Dipstick
1. Pull the engine oil dipstick from its holder.
2. Determine if engine oil is low (Figure 7), add
correct amount of engine oil to bring oil level
to a normal safe level. (See Recommended
Viscosity Grades, Table 4, Page 24).
Gearbox Oil Level Handle fuel safely. Motor fuels are highly flammable and
can be dangerous if mishandled. DO NOT smoke while
refueling. DO NOT attempt to refuel the ride-on trowel if the
engine is hot or running.
Engine Oil Level
See Figures 3 and 4 (Pages 15 and 16) for the location of
any control or indicator referenced in this manual.
Failure to understand the operation of the STR46SPVGH
Trowel could result in severe damage to the trowels or
personal injury.
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
Never store the ride-on trowel with fuel in the tank for any
extended period of time. Always clean up spilled fuel
immediately.
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
1
2
3
1Fill Plug
2Drain Plug
3Sight Glass (Oil Check)
1Engine Oil Dipstick
2Add Engine Oil
3Safe Operating Oil Level
MAX
MIN
1
3
2
INITIAL START UP
ENGINEFUELONLY

PAGE 20 — HHN 31V
STR46SPVGH • RIDE-ON POWER TROWEL — OPERATION MANUAL — REV. #0 (07/17/08) — PAGE 20
STR46SPVGH — OPERATION
Using the safey stop switch to stop
the engine after every use will verify
that the switch is working properly.
Remember to turn the key to the “OFF”
position after stopping the machine.
Not doing so may drain the battery.
6. Turn ignition key fully clockwise and listen for engine to
start. Once engine has started release ignition key.
Starting the Engine
1. Place one foot on the trowel's platform, grab ahold of any
part of the frame, lift yourself onto the trowel, then sit down
in the operator's seat.
The STR46SPVGH trowel is
equipped with a safety stop switch
that will not allow the engine to start
unless an operator is sitting in the
operator’s seat. The weight of an
operator depresses an electrical
switch, which allows the engine to
start.
Figure 10. Blade Speed Control Foot Pedal
3. Keep your foot OFF the pedal (right foot pedal). Start the
engine at idle (without touching the foot pedal).
4. Insert the
ignition key into the ignition switch .
Figure 11. Oil and Charge Indicator Lights
5. Turn the ignition key clockwise to the (start) position. The
oil , charge, and water indicator lights (Figure 11) should
be ON.
CAUTIONCAUTION
CAUTIONCAUTION
CAUTION
NEVER disable or disconnect the safety stop switch. It is
provided for the operator's safety and injury may result if it
is disabled, disconnected or improperly maintained.
OIL, and CHARGE indicator lights
come on when ignition switch is in the
ON position, and the engine is NOT
running.
NOTE
NOTE
NOTE
2. The right foot pedal (Figure 10) controls blade and engine
speed.The position of the foot pedal determines the blade
speed. Slow blade speed is obtained by slightly depressing
the pedal. Maximum blade speed is obtained by fully
depressing the pedal.
7. If the engine fails to start in this manner, consult the engine
owner's manual supplied with the trowel.
8. Test the safety stop switch by standing up briefly.The switch
under the seat should cause the engine to stop. If the switch
fails to shut down the engine.Turn off the engine with the
key switch and fix the safety stop switch. See Table 5
(Troubleshooting ) for possible problems.
9. Repeat this section a few times to get fully acquainted with
the engine starting procedure.
