StreetGlow Multi-color LED Undercar kit User manual

DISCLAIMER
INFORMATION
Laws concerning the use of aftermarket lighting
products may vary from state to state. For more
information, please check with your local authority.
To insure proper use and operation, please read the
installation and instruction manual carefully.
StreetGlow products may be installed on any 12v
vehicle application.
StreetGlow products are recommended for show and
off-road use only.
WARRANTY
INFORMATION
All StreetGlowproducts are covered by a comprehensive warranty.
StreetGlowneon products are warranted against defective materials and workmanship for as long
as the original purchaser owns the product. StreetGlowRadio Bars and other non-neon products
(excluding fog and driving lights, and HID bulbs) are warranted against defective materials and
workmanship for twoyears from date of purchase. Fog and driving lights, and HID bulbs are
warranted for one year from date of purchase. Anyproduct that should fail for either defective
materials or workmanship will be repaired or replaced, at StreetGlow’s option, as the sole remedy
of the buyer.Proof of purchase is required. All warranty claims are to be handled by selling
agents. Accident, abuse, neglect, modifications, broken glass, labor, transportation, improper
installation and the use of products other than for their intended purposes are not covered.
NEITHER SELLER NOR THE MANUFACTURER SHALL BE LIABLE FOR ANY INJURY,
LOSS OR DAMAGE, DIRECT, INCIDENTAL OR CONSEQUENTIAL (INCLUDING, BUT
NOTLIMITED TO INCIDENTAL OR CONSEQUENTIAL DAMAGES FOR LOST PROFITS,
LOST SALES, INJURYTO PERSON OR PROPERTY OR ANY OTHER INCIDENTAL OR
CONSEQUENTIAL LOSS), ARISING OUT OF THE USE OR THE INABILITY TO USE THE
PRODUCT AND THE USER AGREES THAT NO OTHER REMEDY SHALL BE AVAILABLE
TOIT. Before using, the user shall determine the suitability of the product for the intended use,
and user assumes all risk and liability whatsoever in connection therewith. Some states and
countries do not allowthe exclusion or limitation of incidental or consequential damages, so the
above limitations or exclusions may not apply to you. This warranty gives you specific legal
rights and you may also have other rights, which vary from state to state and from country to
country. DISCLAIMER: THE FOREGOING WARRANTY IS AN EXCLUSIVE WARRANTY
IN LIEU OF ANY OTHER EXPRESS WARRANTIES. ANY IMPLIED WARRANTIES
(INCLUDING, BUT NOT LIMITED TO ANY IMPLIED WARRANTY OF MERCHANTABILITY
OR FITNESS FOR A PARTICULAR PURPOSE) TO THE EXTENT THAT IT COULD
APPLY TO ANY OF THE PRODUCTS MANUFACTURED BY THE COMPANY SHALL BE
LIMITED IN DURATION TO THE PERIODS OF THE EXPRESS WARRANTY GIVEN ABOVE.
Thank you from StreetGlow!
Congratulations on your selection of StreetGlow products and welcome to the
StreetGlow lighting family. With your purchase, you join thousands of car enthusiasts
who have made StreetGlow the number one choice in the Auto-Neon® industry.
As a member of the StreetGlow family, we offer you our full and continued support.
Our staff of highly skilled professionals designs StreetGlow products that combine
the highest standards of performance, craftsmanship and cutting-edge aesthetics
while embracing the latest in lighting technology and styles.
Visit our website, streetglow.com, to learn more about the extensive line of
StreetGlow products.
streetglow.com ©StreetGlow,Inc., 2004

Quick Test Sequence
Step 1 Unpack entire contents of packaging and check for any damaged products before moving to the
testing sequence.
Step 2 Place all four LED tubes on a test bench and connect the tubes to each other. Then, connect them to
the MLC. NOTE: Align arrows on the plugs to ensure proper connection.
Step 3 Using a 12v DC power source, connect the MLC’s RED (ignition) and YELLOW (power) wires to the
positive (+) 12v lead of the power source. Note: DO NOT connect the BLUE (alarm) or WHITE (courtesy light)
wires for this test.
Step 4 Connect the MLC’s BLACK (ground) wire to the power source’s negative (-) output
Step 5 Press and hold the (POWER/MODE) button to activate all LED segments. Note: If none of the LEDs
light up, then go back to Step 3 and check your connections.
Installation Instructions
Step 1 Select a desired location for the Multi-Color LED Controller (MLC) and mount using the supplied
mounting hardware.
Step 2
With MLC mounted, connect power and ground to the MLC’s power harness (see FIGURE 1).
YELLOW wire = 12v battery (+)
RED wire = 12v switched ignition (+)
WHITE wire = courtesy light (+) (optional connection)
BLACK wire = ground (-)
BLUE wire = alarm (-) (optional connection)
Step 3 Select the desired locations for the LED tube placement which are away from all fuel lines,
exhaust systems, areas of extreme heat, ABS components, SRS components, any moving parts
and where lifts or jacks are used to raise your vehicle. Note: LED tubes need to be mounted as
to the recommended configuration (see FIGURE 1).
Step 4 Using the 3/4" tube mounting clamps and the 5/8" self-tapping screws, fasten the LED tubes to
your vehicle in the recommended mounting positions (four mounting clamps per 48" tube, three
clamps per 30" tube).
Step 5 Connect the control wire(s) of each tube together. Secure the wires to your vehicle using the 3/16"
wire clamps and 5/8" screws. NOTE: Be sure to align the arrows on the plugs and use electrical
tape (not supplied) around the secured plugs to insure a proper weather tight connection.
Step 6 Connect the control wire of the MLC to the control wire of the first LED tube.
Step 7 Once wiring and mounting for all components is completed, test the ANLED100MC’smodes of
operation and sequential lighting effects.
Multi-Color LED Controller (MLC) Operation
1) Turn unit on by pressing and holding the button for 2 seconds.
2) Turn unit off by pressing and holding the button for 2 seconds.
3) To change color, press the C(COLOR) button.
4) To change modes, press the button.
5) To change patterns, press the +or –buttons.
6) To increase brightness/speed/sensitivity, press and hold the +button.
7) To decrease brightness/speed/sensitivity, press and hold the –button.
CONTENTS:
2- 48” LED tube
1- 30” LED tube w/ 4' wire
1- 30” LED tube w/ two 4' wires
1- Multi-Color LED Controller (MLC)
ALARM
(-)
BLACK
WHITE
YELLOW
RED
GROUND (-)
COURTESY LIGHT
IGNITION (+)
(OPTIONAL)
12v BATTERY (+)
BLUE
MULTI-COLOR LED
CONTROLLER (MLC)
(mount under dash)
MINI DIN
CONNECTION
MINI DIN
CONNECTION
MINI DIN
CONNECTION
MINI DIN
CONNECTION
FIGURE 1
FRONT
REAR
WIRING DIAGRAM
Modes and Features
MODES: All LEDs On / RPM / Music Interface / Sequential Lighting Effects
Turn unit on and select the desired mode of operation by pressing the (POWER/MODE) button.
Main Functions
1st press button =All LED’s On Mode (solid show of lights)
2nd press button = RPM Mode (kit reacts to the sound of the engine from front to back)
3rd press button = Music Interface Mode (dances to the beat of your music)
NOTE: Use the +or–button to adjust sound sensitivity
4th press button =Sequential Lighting Effects Mode (select from nine different lighting effects)
NOTE: To change pattern, press and RELEASE the +or –button
To increase pattern speed, press and HOLD the +button.
Todecrease pattern speed, press and HOLD the –button.
Changing Colors
Tochange colors, press the C(COLOR) button. Youmay select between seven colors plus AUTO-CHANGE mode
(cycles through all seven colors): RED, YELLOW, GREEN, TURQUOISE, NEO BLUE, CORAL, and WHITE. The indicator
LEDs of the MLC will display the selected color (AUTO-CHANGE mode is indicated by a RED/GREEN/BLUE flash).
Alarm Feature
The ANLED100MC’salarm feature activates when the BLUE wire is triggered with a negative (ground) input.
This feature functions ONLYwhen the vehicle is off or when 12v is disconnected from the ignition RED wire
(see FIGURE 1 for details). When the alarm feature is active, the front and back tubes will flash once per second
under the vehicle.
Courtesy Light Feature
The ANLED100MC’s courtesy light feature activates when the WHITE wire is triggered with a positive 12v input
(dome light circuit). This feature will illuminate the kit for as long as the door is opened.
14 - 3/4" mounting clamps
12 - 3/16" wire clamps
26 - 5/8" self-tapping screws
Sequential Lighting Effects
patterns list and descriptions
CLASSIC SCAN
atraditional light scan moving from the front of
the car to the rear, then reverse
PING-PONG
acontinuous back and forth motion creating a
ping-pong-like effect
THE SHIFT
a3-light bank leapfrog shift: three banks on, 6
banks on, next three banks on.
MARCHING ANTS
alternating light banks turn on to create a forward
marching motion
FILL-REFILL
fills into a solid color, then empties one by one
and reverses direction
CHERRY-PICKING
aquick fill, then “picked out” one by one and
reverses direction
DROP-IT-IN
fills in one by one, then quickly dissolves and
reverses direction
PING-PONG FILL 1
aback and forth motion until all banks are lit,
then quickly dissoves and reverses direction
PING-PONG FILL 2
aback and forth motion until all banks are lit,
then empties one by one and reverses direction
ZIG-ZAG SCAN
azig-zag pattern to the center and back out
