Protocol TREK 4X4 User manual

INSTRUCTION MANUAL
TREK 4X4
R/C CAR WITH LIVE STREAMING HD CAMERA

Thank you for your purchase of Protocol’s Trek 4x4 R/C Car with
Live Streaming HD Camera. You are about to experience the
best of what remote control driving has to offer. We strongly
recommend that you take the time to read this manual thoroughly.
It contains many tips and instructions on how to get the most out
of this vehicle and maintain it for a long life.
As with any vehicle, this is a precision driving machine. Treat it
well and enjoy all the fun it has to offer, drive after drive.
THANK YOU.

01 Safety & Precautions
02 Parts
04 Remote Battery, Phone & Camera Installation
05 Charging the Car
06 Start-Up Procedure
07 Operation: Testing the Car
08 Operation: Driving the Car
09 Correcting Tire Alignment
10 Troubleshooting
11 APP Instructions & Photo/Video
12 Replacement Parts & Limited Warranty
TABLE OF CONTENTS

SAFETY WARNINGS
•Read and follow instructions on how to synchronize electronics before
each use.
•To prevent damage to people or property, always avoid contact with
other objects while driving.
•Inspect car prior to each use and do not drive if damaged.
•Never expose product or any of its electronic parts to moisture, water,
or heat sources.
•To prevent overheating, allow battery a cool-down period
before recharging.
•To prolong engine life, allow a cool-down period between flights.
•Use only the charger and/or charging cable that is supplied with
this item.
•Do not strike, cut, or pierce the internal battery or subject it to
hard impacts.
•Do not mix old and new batteries or mix different types of batteries.
•Never attempt to modify function of vehicle or controller or attempt
repairs using parts other than those supplied by Protocol. Spare parts
are available at www.ProtocolNY.com
HAVE FUN, BUT SAFETY FIRST!
THIS DEVICE USES COMPONENTS THAT OPERATE AT HIGH SPEEDS.
AS WITH ANY SUCH DEVICE, USE CAUTION TO OPERATE SAFELY.
FAILURE TO FOLLOW ANY OF THESE GUIDELINES MAY RESULT IN BODILY
INJURY OR DAMAGE TO PERSONAL OR PUBLIC PROPERTY.
1

PARTS
CAR
1. On/Off Switch
2. Direction Trimmer
3. Battery Compartment
4. Camera
5. Camera Jack
4
2
1
3
2
5

PARTS
3
5
REMOTE
1. Power Switch
2. Power Indicator
3. Trigger
4. Battery Compartment
5. Phone Mount
6. Steering Wheel
3
4
1
2
6

REMOTE BATTERY, PHONE & CAMERA INSTALLATION
4
INSTALLING THE PHONE MOUNT
1. Insert the base of the mount into the slot
until it clicks.
2. Pull the clamp open and insert the phone.
INSTALLING THE CAMERA
1. Slide the camera onto the top of the car.
2. Plug the camera into the camera jack on the car.
1. Install batteries carefully.
2. Do not mix old and new batteries.
3. Do not mix different types of batteries.
Remove battery cover from controller. Insert 4 x ‘AA’ batteries according to
indicated polarities. Replace battery cover.
INSTALLING THE BATTERIES
4 x 1.5vAA Batteries

REMOTE BATTERY, PHONE & CAMERA INSTALLATION CHARGING THE CAR BATTERY
1. Make sure the car is turned off.
2. Remove the battery from the battery compartment.
3. Connect the USB charging cable to the battery.
4. Plug the charger into a USB port. The USB light will turn red while charging
and will turn green once fully charged.
5. Plug the battery back into the car and close the battery compartment..
Charging time: 240 minutes --- Drive time: approximately 25-28 minutes
CAUTION WHEN CHARGING
1. When charging, place product on a dry, well-ventilated surface and keep
away from heat sources.
2. Always use adult supervision while charging.
3. In order to increase battery longevity, avoid repeat charging and
excessive discharging.
4. As battery temperature is high immediately after driving, charge after cooling
down for higher efficiency.
5. Do not strike or subject battery to hard impacts or sharp surfaces.
6. Do not use another charger than that which is supplied with this item.
7. Do not use or leave battery near a heat source such as fire or space heater;
exposure to heat may result in reduced performance or in some cases
dangerous conditions.
8. If battery is left in charging state for an extended period of time after being
fully charged, the battery may automatically discharge.
9. Never leave the battery unattended during charging.
10. Do not disassemble battery.
11. Do not submerge battery in water. 5
DO NOT CHARGE OVERNIGHT OR BEYOND
THE CHARGING TIME STATED. DO NOT LEAVE BATTERY UNATTENDED.
*Battery: Li-ion, 7.4V, 1200mAh
If you purchased extra batteries, allow the engines to cool between uses in
order to prolong engine life.

START-UP PROCEDURE
NOTE:
1. If after 30 seconds, it has not recognized the car, turn off the controller
and repeat Start-Up procedure.
Before driving, the car and controller must be turned on in sequence
1. Turn on the car.
2. Turn on the controller.
3. The power indicator on the remote will blink once to indicate connection
with the car.
6

OPERATION: TESTING THE CAR
7
After turning on the car and remote, pull the trigger back slightly and the car will
move forward. Push the trigger forward slightly and the car will move backward.
To brake, release the trigger.

OPERATION: DRIVING THE CAR
FIRST TIME DRIVERS!!! TAKE YOUR TIME! GO SLOW!
Practice driving back and forth until you are comfortable with speed before
attempting any other maneuvers.
As you are driving, follow the below maneuvers to control the car:
To turn the car right, twist the steering wheel forward.
To turn the car left, twist the steering wheel backward.
8

CORRECTING TIRE ALIGNMENT
If the car veers to the right or left without touching the steering wheel, adjust the
direction trimmer to the opposite direction until the car evens out.
The trimmer is located on the bottom of the car.
9
Direction Trimmer

TROUBLESHOOTING
POSSIBLE CAUSESYMPTOM POTENTIAL SOLUTION
Trek 4x4 does
not respond
1. Communication between
controller and car was not
synchronized during set up
2. Battery power depleted
on car, controller, or both.
1. To synchronize, turn on car first,
place it on level ground, and then
turn on controller
2. Charge car and/or replace
batteries in controller
Response to
control inputs
intermittent or
erratic
1. Controller battery power
nearly depleted.
1. Replace batteries in controller.
*Allow 15 minutes to pass between full drives as this will give the motors a chance
to cool down. Failure to do so could wear out and shorten the life of the engine.
10

APP INSTRUCTIONS & PHOTO/VIDEO
*Please check our website ProtocolNY.com for updates and instructions
to our Apps.
INSTALLING AND CONNECTING TO THE APP
1. The App is available in both Apple and Android App stores. Search
“Protocol Trek 4x4” and download the App to your smartphone.
2. Turn on the car and the remote control.
3. Once it is turned on, Trek 4x4 will transmit a Wi-Fi signal, “Trek 4x4”.
Make sure your smartphone is connected to that signal.
4. Open the app and press “START”.
5. The screen will show and live stream the camera view.
INSTRUCTIONS
Instructions for shooting photo/video and driving the car through the app are
accessible from the home page of the app.
11

REPLACEMENT PARTS
Thank you for your purchase of Protocol’s Trek 4x4 R/C Car. We know that
accidents can sometimes happen and that is why we offer spare parts kits on
our website: www.ProtocolNY.com.
At Protocol, we’re dedicated to bringing you innovative and well-designed
products that make living fun and easy. We stand behind all of our products
and warrant this to be free from defects in workmanship and materials for 30
days from the date of purchase. The warranty does not cover transportation
damage, misuse, accident, or similar events. Specific legal rights pertaining
to this warranty may vary by state.
For service claims or questions please consult our website www.ProtocolNY.com.
LIMITED WARRANTY
