STRIKEMASTER LITHIUM LAZER User manual

LITHIUM LAZERTM
Owner’s Manual
Battery must be fully charged
prior to first use. Ice depth, blade
condition, loose blade bolts, and
battery maintenance can all aect
the total number of holes you will get
on a full charge.
It is recommended that everyone
who uses this product read
the StrikeMaster Lithium Lazer
owner’s manual.
ATTENTION: PRIOR TO FIRST USE
When charging the internal 50 volt
battery using the StrikeMaster
2 amp battery charger, ALWAYS
connect the charger to a standard
110 volt wall outlet before
connecting to the battery.
SM14
!!
y charged
A
T
T
ENTION: PRIOR TO FIRST US
E
When charging the internal 50 v
us
in
g
th
e
St
rikeMaster
Y
S
!
!

Ice Fishing has become one of the fastest growing and most popular winter sports, allowing the
ardent angler the opportunity to enjoy their favorite outdoor activity year round.
When you purchased a StrikeMaster®power ice auger, you selected a product that has gained a
reputation as the quality leader since 1946. There is no doubt that this year’s model is the finest
ever produced by StrikeMaster®
.
Your new StrikeMaster®ice auger has all of the most wanted features in a power ice auger, to
assure many years of enjoyable ice fishing. Some of these features such as workmanship,
engineering excellence, and dependability have long been standards at StrikeMaster®. Your new
power ice auger boasts many new features while retaining the best features developed in
previous years to enhance your ice fishing experience and add to your satisfaction in
selecting StrikeMaster®.
We know that you are anxious to go fishing and use your new power ice auger, but before you go
fishing, it is important and to your advantage to spend a few minutes getting acquainted with
your new StrikeMaster power ice auger. There is no better way to acquaint yourself with the
product than to read the Owner’s Manual and operating instructions. A few minutes spent
studying this manual before your first ice fishing outing will be time well spent.
Record the motor serial number and date purchased in the space below.
Also, please return the enclosed WARRANTY CARD or submit your
information on our website to validate your limited warranty.
Model: Lithium Lazer
TM
Serial number __ __ -__ __ __ __ __
Date Purchased ______ / ______ / ______
Important Safeguards 3
Assembly Instructions 3
Operation Instructions 3
Battery Charging & Monitoring 4
Replacement Battery Installation 5
Battery Storage 5
STRIKEMASTER Limited Warranty Back Cover
STRIKEMASTER®
Ice Augers
ATTENTION !!
...............................................................................................................................................
..............................................................................................................................................
..............................................................................................................................................
.........................................................................................................................
...........................................................................................................................................................
..............................................................................................................................
...................................................................................................
TABLE OF CONTENTS
Serial Number label is located
on the side of the motor cover.
THIS SYMBOL POINTS OUT IMPORTANT SAFETY INSTRUCTIONS WHICH IF NOT FOLLOWED COULD ENDANGER
THE PERSONAL SAFETY AND/OR PROPERTY OF YOURSELF AND OTHERS. READ AND FOLLOW ALL INSTRUCTIONS
IN THIS MANUAL AND ANY PROVIDED WITH OR ON THE EQUIPMENT ON WHICH THIS ENGINE IS USED BEFORE
ATTEMPTING TO OPERATE YOUR STRIKEMASTER POWER ICE AUGER.
!

!!
1. DO NOT use this product for anything other than its intended purpose.
2. DO NOT use attachments other than those available from the manufacturer.
3. DO NOT alter this product in any manner; doing so is dangerous and voids all warranties.
4. DO NOT allow children or adults weighing under 100 lbs. to operate this equipment.
5. DO NOT allow your body, loose clothing, drawstrings, scarves, hats or other materials to come in contact with the Powerhead,
or Auger (Drill) unit at any time.
6. DO NOT operate under the influence of drugs or alcohol.
7. DO NOT continue to use this product in the event of mechanical or electrical failure.
8. This product produces considerable cutting force that is felt by the operator. Make sure your feet are firmly planted and that
the handles are held firmly while operating this product.
9. During operation, the auger unit could possibly stop. Be prepared at all times to release the switch.
10. Check cutting blades and auger shaft screws before and after each use to make sure they are tight.
It is recommended that everyone who uses this product read this
StrikeMaster OWNER’S MANUAL before operating.
IMPORTANT SAFEGUARDS
OPERATION
! !
1
2
The Lithium Lazer is operated using the 50 volt lithium battery supplied with the unit.
(Additional batteries may be purchased. Model# LLRB)
Secure the unit firmly in your hands in a vertical position. To start, press the main power switch located on the front of the
motor cover until the LED light is on “Its Ready To Drill”. Press the black starter button down to start the auger rotation.
TO STOP - Release the black starter button.
Do not lay down or store auger in any position or location where the electrical components (battery, motor, switch, etc.) are
in contact with snow, water and other moisture. Be sure to situate the auger correctly.
When the auger is not in use, remove the battery. For optimal performance, store battery in a warm location.
The battery has protection circuitry that will temporarily disable the battery in case of short circuiting, abuse from dull
blades or other non-manufacturer approved alterations that may cause it to drill less eectively.
ASSEMBLY
! !
Carefully remove blade
guard and make sure
blade bolts are tight.
Remove metric allen
wrench taped to the
neck of auger and
unscrew the collar
bolt from auger.
(Use an 8mm
closed end wrench)
The large and small holes
from each component
must line up before
installing the collar bolt.
Push down and twist
to line up holes.
Insert collar bolt into the large
hole, passing through the drive
shaft threads into the small hole
of the metal collar. Make sure bolt
is tight. Some wiggle is normal
between the power head and auger.
Check and tighten often.
It is recommended that the collar bolt be checked and torqued
firmly before and after every use.
2a
2a
4
4
3
Lazer
Blade
Metal Collar
Allen
Wrench
Collar Bolt
Large
Holes
Plastic
Collar
Drive Shaft
!
13
2
1
3
3
4
5
2
It is recommended to grease inside
collar and transmission output
shaft on the powerhead. Standard
automotive wheel bearing grease is
suggested. Insert drive shaft into
auger and install collar bolt.
Be sure collar bolt-head counter sinks past the outside face of
the plastic collar. Refer to 2a.

4
BATTERY CHARGING & MONITORING
CHARGING WITH WALL CHARGER ADAPTER
When charging the 50 volt lithium battery using the StrikeMaster 2 amp battery
charger, ALWAYS connect the charger directly to a standard 110 volt wall outlet
BEFORE connecting the battery.
DO NOT rely on the battery status indicator, the battery charger will automatically
stop charging when battery is full. After battery is fully charged, the charger
changes to maintenance/float mode. DO NOT leave the charger
connected to the battery for more than 24 hours.
! !
1. Always charge the battery at room temperature. If the battery is used in a cold
environment, allow it to warm up for at least an hour before charging. Cold
batteries will not charge completely.
2. To charge the battery, ALWAYS connect the charger directly to a standard 110
volt wall outlet BEFORE connecting to battery (red light should come on).
During charging phase, light will be red. Charge the battery until the light on
the charger turns green.
3. To disconnect charger, remove plug from wall outlet then disconnect charger
from battery.
4. Charge time will be 2 hours for completely dead battery.
DO NOT leave the charger connected to the battery for more than 24 hours.
5. The Battery Status Indicator is mounted on the top of the battery to allow you
to see the level of battery power while in use. To check the charge level, simply
push the battery indicator button. The lights on the status indicator show the
charge level of the battery.
Replacement or additional batteries may be purchased. (Model# LLRB).
Visit STRIKEMASTER.COM

REPLACEMENT BATTERY INSTALLATION
! !
Press
Release
Buttons
BATTERY STORAGE
! !
When storing the battery for the o season, fully charge the battery, and store in a dry location that
maintains a temperature of 60-75 degrees F. To help maintain battery life, put battery on charger
10-15 minutes every two months. (Charger may show red after 15 minutes of charging. This is normal)
NOTE: REMEMBER TO FULLY CHARGE BATTERY BEFORE FIRST USE OF THE SEASON.
Lithium ion batteries can reach a point where they can no longer hold a charge and need to be
disposed of. Please recycle the battery at your nearest recycling center or call 1-877-2-RECYCLE
for more information.
To install battery, slide battery into guides on the powerhead until it stops. Press both battery release buttons to fully seat.
To remove battery, press both battery release buttons while pulling straight up on the battery.
5
Lithium LazerTM
Chipper Mag
Chipper Lite
1
1
2
2
Slide Up To
Remove and
Down To
Install The
Battery

WARRANTY SERVICE
LIMITED WARRANTY
Limited Warranty coverage
(with receipt/proof of registration)
30-Day
Warranty
90-Day
Warranty
1-Year
Warranty
2-Year
Warranty
3-Year
Warranty
Wear & tear parts X
12-Volt Battery X
StrikeMaster parts X
Solo engine X
Honda engine X
Lithium Lazer motor X
50-Volt Lithium Lazer battery X
Continued satisfying performance from your StrikeMaster power ice auger may be assured by applying a
minimum amount of preventive maintenance.
Visit our website for up to date warranty service centers.
www.strikemaster.com
The warrantor’s obligation shall be limited to repairing or replacing any part, which upon examination by StrikeMaster, is determined to be defective. This obligation
begins on the date of purchase (as evidenced by a product receipt) and continues for a period of ONE YEAR after purchase (“warranty period”), with the exception of
engines and parts subject to wear and tear. This warranty is non-transferrable; warranty registration must be completed online or via USPS within 30 days of purchase
to validate warranty. The warranty does not apply if product has been negligently used, misused, altered, damaged in an accident or if periodic maintenance has not
been performed. Customer is responsible for shipping and transportation charges to the nearest warranty repair center.
Company warrants that Product, other than engines and parts subject to wear and tear, will perform substantially in accordance with the accompanying written
materials [owner’s manual] for a period of ONE YEAR. In the case of engines and parts subject to wear and tear, please refer to the chart below. Parts subject to
normal wear and tear are not covered by warranty including: air filter, fuel filter, any rubber part that comes in contact with fuel, clutch, spark plug, starter (recoil), 12
volt batteries and blades. In the event applicable law imposes any implied warranties, the implied warranty period is limited to ONE YEAR from the date reflected on the
product receipt. Some jurisdictions do not allow such limitations on the duration of an implied warranty, so the above limitation may not apply.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THE COMPANY AND AUTHORIZED SERVICE CENTERS DISCLAIM ALL OTHER WARRANTIES, EITHER
EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE WITH REGARD TO
THE PRODUCT AND WRITTEN MATERIALS [OWNER’S MANUAL]. THIS LIMITED WARRANTY GIVES CUSTOMER SPECIFIC LEGAL RIGHTS. CUSTOMER MAY HAVE OTHER
RIGHTS DEPENDING ON THE JURISDICTION.
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO EVENT SHALL THE COMPANY OR AUTHORIZED SERVICE CENTER BE LIABLE FOR ANY DAMAGES
WHATSOEVER (INCLUDING WITHOUT LIMITATION, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL OR INDIRECT DAMAGES FOR PERSONAL INJURY, LOSS OF BUSINESS
PROFITS, BUSINESS INTERRUPTION, LOSS OF BUSINESS INFORMATION OR ANY OTHER PECUNIARY LOSS) ARISING OUT OF THE USE OF OR INABILITY TO USE THIS
PRODUCT, EVEN IF THE COMPANY HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN ANY CASE, THE COMPANY’S AND AUTHORIZED REPAIR CENTER’S
ENTIRE LIABILITY UNDER ANY PROVISION OF THIS AGREEMENT SHALL BE LIMITED TO THE AMOUNT ACTUALLY PAID BY YOU FOR THE PRODUCT. BECAUSE SOME
JURISDICTIONS DO NOT ALLOW THE EXCLUSION OR LIMITATION OF LIABILITY FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES, THE ABOVE LIMITATION MAY NOT
APPLY TO YOU.
Continued satisfying performance from your StrikeMaster power ice auger may be assured by applying a minimum amount
of preventive maintenance.
