Stromtank S 5000 User manual

S-5000 High-power
OWNER‘S MANUAL

2 3
FOREWORD
Time to make the
best of what you
already own.
Congratulations! You are about to install and
use a device from the Stromtank range. You
have chosen a high-tech device that will play
a central role to hear the excellent quality of
your audio components. Stromtank has been
designed to separate your hi-system comple-
tely from the grid to supply clean, undisturbed
grid power to achieve the next level of music
quality with your hi-system.

4 5
PRECAUTIONS
Important safety instructions. Read carefully and keep for future reference!
When the Stromtank is running, it generates voltage that can be po-
tentially lethal. Work on or close to the installation must only be carri-
ed out by thoroughly trained and qualied personnel. Do not attempt
to carry out on-going maintenance of this product yourself. There are
NO USER SERVICEABLE PARTS INSIDE the unit. Do not open the chas-
sis or remove any of its screws. In case of any service needs contact
your Stromtank dealer.
When working on the electrical installation, it is important to be cer-
tain that the source of DC voltage coming from the battery as well as
the source of AC voltage coming from a generator or electric circuit
have been disconnected from the electrical installation.
Even when the Stromtank has been disconnected from the supply
sources (AC and DC), a dangerous voltage may remain at the out-
puts. To eliminate this risk you must switch the Stromtank OFF using
the ON/OFF button. After 10 seconds the electronics are discharged
and intervention may take place without any danger. All elements
connected to the Stromtank must comply with the applicable laws
and regulations.
Persons not holding written authorisation from manufacturer are not permitted to
proceed with any change, modication or repairs that may be required. Only origi-
nal parts may be used for authorised modications or replacements.
The Stromtank is only designed for indoor use and must under no circumstances be
subjected to rain, snow or other humid or dusty conditions. The maximum speci-
cations of the device shown on the type plate must be adhered to.
The weight of Stromtank can be up to 300 Ibs / 135 kg depending upon the
model. Use an appropriate lifting method as well as help from a third party
when installing the equipment.
TABLE OF CONTENTS
Unpacking .................................................................................
Front view .................................................................................
Rear view ...................................................................................
Rear Panel .................................................................................
Installation / Operation ...........................................................
Display Operation ....................................................................
Advanced Features ..................................................................
Maintenance ............................................................................
Storage ......................................................................................
Specictions .............................................................................
Quality and Warranty...............................................................
6
8
9
10
11
12
13
14
14
17
18

6 7
UNPACKING
ATTENTION: The weight of the Stromtank can be up to 300 Ibs /135 kg depending
upon the model. Use an appropriate lifting method as well as help from a third
party when installing the equipment.
While the Stromtank is still in its case, please move it to a location near the place where
it will be installed. Remove all jewelry including watches, rings and belts from your per-
son to avoid damage to the exterior of the Stromtank during removal and installation.
At rst remove the cardboard box. Then carefully unscrew the upper screws (Torx
size T25) on the wooden case [Fig.1] and remove the top board [Fig.2].
When unpacking, check that the equipment has not been damaged during transpor-
tation and all items listed below are present. If anything is missing it has to be indi-
cated immediately to your dealer. Check the packaging and the Stromtank carefully.
Package contents:
After checking unscrew the screws (Torx size T25) on the front board to open it [Fig. 3].
ATTENTION: Do not hold the Stromtank unit on its front and do not lift it!
Push the unit from the rear side out of the case [Fig 4].
The nish of the Stromtank is extremely delicate. We suggest wearing the supplied
gloves when handling the Stromtank to avoid abrasion or ngerprints caused by oils
from the skin, etc.
Place the Stromtank on a level surface with an adequate ventilation. Make sure the
surface that will support this component can safely hold its weight up to 300 Ibs.
There should be at least 3 inches of clearance space on each side and 3 inches of
clearance at the top as well as above the unit.
Remove the cloth that covers the Stromtank to protect its nish. Save the cloth in
the box to use it again if you ever need to ship the Stromtank.
1 Stromtank unit
1 locking key
1 AC power cord
1 owner manual
1 vacuum cup
1 pair non-slip gloves
1 warranty card
1 microbre cloth

8 9
FRONT VIEW REAR VIEW
display
brightness
switch
ampere meter
front button
connecting plate
lock / unlock
for transport safety

10 11
REAR PANEL – Hubbel duplex
REAR PANEL – SCHUKO SOCKETS
7 power indicator
8AC input
9 main switch ON / OFF
lock / unlock for transport safety
ground terminal
10
1 thermal magnetic fuse
2converter port
3BMS port
4emergency charge input
5AC outlets
6fuse (10A - 230V/16A-120V
slow blowing)
7 power indicator
8AC input
9 main switch ON / OFF
lock / unlock for transport safety
ground terminal
10
11
11
1 AC outlets
2thermal magnetic fuse
3converter port
4BMS port
5emergency charge input
6fuse (10A - 230V/16A-120V
slow blowing)
INSTALLATION / OPERATION
Before you start with the installation take care that no audio parts are connected
with the Stromtank and the unit is not connected with the electric circuit.
To install the Stromtank and connect it with your audio equipment please follow the
steps in order.
1. Make sure that the position of the main switch at the rear is in OFF position.
2. Connect the AC input with a power cord to the next available grid outlet.
ATTENTION: Never connect Stromtank’s AC input with its AC outlets. This will
cause damage to the unit!
3. Insert the supplied key into the key switch, turn it into a horizontal position and
remove the key from the switch.
4. Push the main switch at the rear in ON position. The green LED above must
light up now. After a few seconds the ampere meter at the front is illuminated
by a blue light.
5. Plug your audio AC cords into the AC outlets. It is important to make certain
that all audio units are in OFF position. For best sound results we recommend a
cable length of AC-out power connection between STROMTANK and hi equip-
ment of max. 5 meters.
6. Switch on the fuse switch next to the AC outlets.
7. Turn on your connected audio equipment. ATTENTION: One after the other!
8. To select pure power OFF-grid mode and enjoy best music with stable AC
amplitude, pure sinewave and crystal controlled frequency push the left button
at the front and the light of the meter will change to a green illumination. Or
go to grid mode (switch left button again) for charging and on-grid music listening.
Turn on your audio system. To hear the best quality of your audio components it is
recommended to start with ON-grid mode. This allows Stromtank to warm-up and
shakedown the system.
ATTENTION: Stromtank must always be connected with the ground of the power cord.

12 13
DISPLAY OPERATION
The illuminated display at the top of the Stromtank indicates the state of charging
in 10 steps from 10 % up to 100 %. When all 10 indicators are illuminated the unit is
fully charged (100 %). If only one indicator is shown the unit is nearly empty (state
of charging: 10 %).
If Stromtank is in o-grid mode and reaches a rest capacity of 10 % it automatically
switches back to electric circuit for recharging (the light at the ampere meter chan-
ges to blue illumination). As soon as the battery capacity reaches 20 % it is possible
to switch back to o-grid mode.
This security function ensures that the battery cannot totally be discharged, e.g. if
you forget to switch the unit to on-grid mode (charging) after a music session.
ATTENTION: Do not forget to switch back to ON-grid mode for charging the batteries.
If the display shows a red lighting LED check that the AC-in power cord of Stromtank
is connected properly to the electric circuit. The red LED also indicates that the AC-in
fuse is blown.
ADVANCED FEATURES
Stromtank - Inverter
The Stromtank is equipped with a high-performance inverter, which supplies a per-
fect and very precise sine wave. Any unit designed for the 230V –50 Hz / 115V – 60 Hz
electric circuit can be connected to it without any problem, up to the rated power out
of the Stromtank. The Stromtank is protected against overloads and short-circuits.
Thanks to the largely over-dimensioned performance level, loads up to three times
higher than the Stromtank’s rated power can be faultlessly supplied for short peri-
ods (3 sec) of use, thus allowing the load to be started up without any problem.
Automatic Load Detection (Load Search)
In order to save battery energy, the Stromtank stops and automatically goes into
load search mode when the detected load is lower than the sensitivity (2,5 W). It
automatically goes back into operation when a power consumer greater than this
value demands it.
In load search mode (standby), the system will thus consume minimal power from
the battery.
Blue / Hybride Mode
In this mode the current taken on AC-Input is a sinusoid in phase with voltage. That
means only active power is taken from the generator. The Stromtank compensates
harmonics and reactive current from the source.
This function also avoids fast speed change on the generator due to loads jump.
Battery Undervoltage Protection
Stromtank switches o the AC-output group automatically in case the batteries re-
ach undervoltage level. Before it will be switch o there will be an acoustic alarm
signal for approx. 1 minute. If the red LED on the top is lighting check if Stromtank
is connected by AC-in power cord to the electric circuit. When the red LED on the
top disappears the charging mode started (front meter shows charge current). If the
connection works and the red LED is still on check the AC-input fuse.

14 15
MAINTENANCE
STORAGE
The Stromtank requires no user maintenance other than to keep it clean. Like a
piece of furniture the Stromtank has a ne, highly polished nish that can be easily
damaged. Do not rub or polish the nish and do not allow objects to come in contact
with it.
To clean the Stromtank rst unplug the unit from the electric circuit. To wipe o n-
gerprints and other grease spots spray a small amount of mild detergent dissolved
in water onto the supplied microber cloth and gently wipe the surface with the
cloth.
Caution! The cloth must never be dripping wet! If water or other uids enter the cabi-
net, you risk damaging the unit. Do not spray any liquid directly onto the Stromtank.
Never use scouring pads, steel wool, scouring powders or harsh chemical agents,
alcohol, thinners, benzine, insecticide or other volatile substances, as these can per-
manently scratch and destroy the surface.
If you need to transport or ship the Stromtank, make sure to use the original pa-
cking material. Allow the unit to cool down for at least one hour before you wrap or
package it.
The equipment must be stored in a dry environment at an ambient temperature of
between 10° C (50° F) and 45° C (113° F).

16 17
SPECIFICATIONS
Input AC parameters on grid
Input voltage range 100 – 120 Vac / 200 – 240 Vac
Input frequency 45 to 65 Hz (auto sensing)
Input current max. 16 Aac (transfer relay)
Output AC parameters o grid
Output voltage 100 – 130 Vac / 210 – 245 Vac (pure sine wave +/- 2 %)
Output frequenzy 50 Hz/ 60 Hz +/- 0.05% (crystal controlled)
Harmonic distortion < 2%
Continues power @ 25° C 1,500 VA
Power 3 sec. @ 25° C 5,600 VA
Battery power unit
Battery type LFP - Lithium Iron Phosphate (LiFePO4)
Nominal battery voltage 48 Vdc
Nominal capacity 100 Ah
Terminal area
AC output receptacles 3x Furutech high performance schuko sockets
3x Hubbel duplex, Hospital spec. grade
AC output fuse thermal-magnetic circuit breaker
AC input connection ICE 320 - C14 (fuse 10AT / 16 AT*)
Interface converter, BMS*, emergency charger*
* only for use with Stromtank software and charger
Design and specications are subject to change without notice.

18 19
QUALITY AND WARRANTY
During the production and assembly of the Stromtank, each unit undergoes several pro-
fessional checks and tests. These are carried out with strict adherence to the established
procedures. Each Stromtank owns a serial number allowing complete follow-up on the
checks, according to the particular data for each device. For this reason it is very important
never to remove the type plate which shows the serial number. The manufacture, assem-
bly and tests for each Stromtank are carried out in their entirety by its factory in Germany.
The warranty for this equipment depends upon the strict application of the instructions
appearing in this manual.
Exclusion of warranty
No warranty claims will be accepted for damage resulting from handling, usage or pro-
cessing that does not explicitly appear in this manual. Cases of damage arising from the
following causes are notably excluded from the warranty:
• Surge voltage on the battery input
• Incorrect polarity of the battery
• The accidental ingress of liquids into the device or oxidation resulting from condensation
• Damage resulting from physical or mechanical shocks
• Modications carried out without the explicit authorisation of manufacturer
• Nuts or screws that have not been tightened suciently during the installation or maintenance
• Damage due to atmospheric surge voltage (lightning)
• Damage due to inappropriate transportation or packaging
• Disappearance of original marking elements
Exclusion of liability
The placement, commissioning, use, maintenance and servicing of the Stromtank
cannot be the subject of monitoring by manufacturer. Therefore, we assume no
responsibility and liability for damage, costs or losses resulting from an installation
that does not conform to the instructions, defective functioning or decient main-
tenance. The use of a Stromtank is the responsibility of the customer in all cases.
Manufacturer shall in no event be liable for consequential, incidental, contingent or
special damages, even if having been advised of the probability of such damages.
This equipment is neither designed nor guaranteed to supply installations used for
vital medical care nor any other critical installation carrying signicant potential da-
mage risks to people or the environment.
Manufacturer assumes no responsibility for the infringement of patent rights or
other rights of third parties that result from using the Stromtank.
Manufacturer reserves the right to make any modications to the product without
prior notication.

Made in Germany
V1.0 © 2021 stromtank.com. All rights reserved.
