Sub-Zero 700TR User manual

Integrated refrigeration can be used
anywhere in the home. It merges
seamlessly into the décor, with no visible
hinges or grilles. Model 700TR is a 27"
wide tall unit with refrigerator storage in
the upper cabinet, and also in the lower
drawers with a crisper cover standard in
the upper drawer. Two distinct tempera-
ture zones ensure the freshest food and
energy efficiency.
Model 700TR
Integrated All Refrigerator
Features
Integrated design blends invisibly into
custom cabinetry
Dual refrigeration system
Microprocessor offers precise temperature
control
Electronic digital controls
Flat-to-the-ceiling bright interior lighting
Adjustable, spill-proof glass shelves and
adjustable door shelves
Refrigerator deli drawer for storage of
smaller items
Removable, clear-view crisper cover can
be used in either drawer
Door alarm
Exclusive dual-action hinge with built-in
90˚ door stop
Meets strict Department of Energy
requirements
With the installation of a harness kit, this
appliance is certified by Star-K to meet
strict religious regulations in conjunction
with specific instructions found on
www.star-k.org.
Accessories
Stainless steel door and drawer panels
with tubular handles available in three
finishes (see chart above for specifics)
Polished chrome handles for custom
panel applications
Crisper cover with lid
Dozen egg container with lid
Dual installation heater kit
Accessories are available through your Sub-Zero
dealer. To obtain local dealer information, visit the
Showroom Locator section of our website,
subzero.com.
Interior Features
Refrigerator
Dual Refrigeration
2 Temperature Zones
3 Adjustable Glass Shelves
1 Stationary Shelf
2 Storage Drawers
Removable Crisper Cover
2 Removable Drawer Dividers
Adjustable Deli Drawer
3 Adjustable Door Shelves
Adjustable Dairy Compartment
Egg Container
Classic CarbonPlatinum
Model 700TR
Design Integrated
Stainless Steel Panels Classic Platinum Carbon
80" Finished Height
84" Finished Height

Installation Notes
Stainless steel panels with handles are
available as accessories. Panels for an 80"
finished height are offered in classic, platinum
and carbon finishes. Panels for an 84" finished
height come in the classic finish only. These
panels are not installed at the factory.
Complete installation specifications, including
panel sizes, can be found on our website,
subzero.com.
Unit dimensions may vary by ±
1
/ 8 ".
Specifications
Overall Width 27"
Overall Height 80"
Overall Depth 24"
Door Clearance 251/2"
Drawer Clearance 191/2"
Refrigerator Capacity 15.5 cu ft
Opening Width 27"
Opening Height 80"
Opening Depth 25"*
Electrical Requirements 115 V AC, 60 Hz
15 amp dedicated circuit
Annual Energy Usage $39**
Shipping Weight 360 lbs
*Depth is 24" from the front of the unit to its back.
Your design may necessitate moving the unit
back, or cabinets forward to achieve a flush fit.
This will require a minimum opening depth of 25".
**Based on 9.06 cents per kilowatt hour.
ANTI-TIP
BRACKET*
*PLACEMENT OF THE
ANTI-TIP BRACKET
SHOULD BE 24" (610)
FROM THE FRONT OF THE
UNIT WITHOUT PANELS
TO THE BACK OF THE
ANTI-TIP BRACKET.
25"
(635)
27"
(686)
25"
(635)
11/2"
(38)
131/2"
(343)
TOP VIEW
SIDE VIEWFRONT VIEW
ANTI-TIP
BRACKET
80"
(2032)
41/2"
(114)
21/2" (64)
151/2" (394)
1/4"
(6)
13" (330)
ANTI-TIP
BRACKET
LOCATE ELECTRICAL WITHIN
SHADED AREA – ORIENT GROUND
PRONG TO RIGHT AS SHOWN
NOTE: ANTI-TIP BRACKET MUST BE INSTALLED TO
PREVENT UNIT FROM TIPPING FORWARD
Installation Specifications
Overall Dimensions
Model 700TR
Integrated All Refrigerator
TOP OF
ROUGH
OPENING
789/16"*
(1995)
341/2"*
(876)
14"(356)
13/16"
(21)
93/4"
(248)
4"
(102)
80"*
(2032)
27"
(686)
24"
(610)
*
1
/ 2 " (13) +
_ADJUSTMENT IN LEVELING LEGS
FRONT VIEW SIDE VIEW
(UNIT DIMENSION) (UNIT DIMENSION)
3/8"
(10)
131/4"
(337)
1/2"
(13)
101/4"
(260)
203/8"
(518)
DOOR
MOUNTING
DETAIL
DRAWER
MOUNTING DETAIL
105˚
90˚
90˚ DOOR OPENING
DOOR/DRAWER
CLOSED
MAXIMUM DOOR OPENING
*DOOR/DRAWER PANEL THICKNESS NOT INCLUDED – DIMENSION WILL VARY WITH INSTALLATION
DOOR/DRAWER
CLOSED
191/2"*
(495)251/2"*
(648)
24"
(610)
257/8" (657)
45/8"*(117)
TOP VIEW
Dimensions in parentheses are in
millimeters unless otherwise specified.
