Designer Series Undercounter Refrigeration

subzero.com | 3
DESIGNER SERIES UNDERCOUNTER MODELS
Designer Series Undercounter Refrigeration
The Sub-Zero Designer Series Undercounter Refrigeration
is a helpful addition to a master suite, bar, home oce, or
media room. Choose from an all refrigerator, combina-
tion with ice maker, beverage center, wine unit, or outdoor
refrigerator. The design flexibility of these compact yet
roomy units makes them all the more welcome in any
room or outdoor kitchen. They are ready to be fitted with
a custom or stainless steel panel.
DEU2450R
DEU2450RADA
DEU2450CI
DEU2450BG
DEU2450BGADA
DEU2450W
DEU2450WADA
DEU2450RO
Designer Series Undercounter Refrigeration
DEU1550BG
DEU1550B
DEU1550W

4 | Sub-Zero Customer Care 800.222.7820
Specifications
261/2"
(673)
24" (610) 231/8" (587)
H
HEIGHT
DIMENSIONS ±
1/2" (13)
95/8"
(245)
Overall Dimensions
24" DESIGNER SERIES UNDERCOUNTER MODELS
171/2"
(445)
231/8" (587)
57/8"
(149)
15"
(381)
341/2"
(876)
HEIGHT
DIMENSIONS ±
1/2" (13)
231/8" (587)
15" DESIGNER SERIES UNDERCOUNTER MODELS
24" MODEL HEIGHT H
Standard Height 34⁄" (876)
ADA Height 32⁄" (826)
IMPORTANT NOTE: Overall dimensions do not include
panels or handles. Dimensions will vary with panel thick-
ness.

subzero.com | 5
Specifications
The depth of each model is 23⁄" (587). Allow for panel
thickness when planning the finished opening depth. A
minimum 3⁄" (89) finished return is required on all sides of
the opening. Framed cabinets require additional finished
filler material behind the face frame for a proper installa-
tion. Refer to the illustration.
DUAL INSTALLATION
If two units are installed side by side, a dual installation kit
may be required. Installations without a custom filler strip
require a dual installation kit. If a dual installation kit is not
specified, a 2" (51) filler strip is recommended between the
units. Dual installations without a filler strip can only be
accomplished using two units with opposite hinges. Refer
to the illustrations below.
Dual installation kits are available through an authorized
Sub-Zero dealer. For local dealer information, visit the
find a showroom section of our website, subzero.com.
For questions regarding the installation, call Sub-Zero
Customer Care at 800-222-7820.
DUAL OPENING WIDTH W
Two 15" Models 30" (762)
15" and 24" Models 39" (991)
Two 24" Models 48" (1219)
Dual installation kit required.
Opening Dimensions
DESIGNER SERIES UNDERCOUNTER MODELS
W
OPENING WIDTH
H
OPENING
HEIGHT
TOP VIEW
SIDE VIEWF
RONT VIEW
NOTE: 3
1/2" (89) finished returns will be visible and should be finished to match cabinetry.
3/4" (19)
TYPICAL
FRAMED
CABINETRY
W
FILLER
31/2" (89)
FINISHED
RETURN
FRAMELESS
CABINETRY
W
3/4" (19)
TYPICAL
31/2" (89)
FINISHED
RETURN
24" (610)
OPENING
DEPTH
WITHOUT FILLER STRIP FILLER STRIP
Opposite hinges Same side hinges
OPENING DIMENSIONS W H
24" Model (standard height) 24" (610) 34⁄" (876)
24" Model (ADA height) 24" (610) 32⁄" (826)
15" Model (standard height) 15" (381) 34⁄" (876)

6 | Sub-Zero Customer Care 800.222.7820
Electrical Requirements
Installation must comply with all applicable electrical codes.
The electrical supply must be located within the shaded
area shown in the illustration below. A separate circuit
servicing only this appliance is required.
IMPORTANT NOTE: For indoor models, a ground fault cir-
cuit interrupter (GFCI) is not recommended and may cause
interruption of operation.
For the outdoor model, a ground fault circuit interrupter
(GFCI) is required to reduce the risk of electrical shock.
The electrical outlet must be positioned with the ground-
ing prong to the right of the thinner blades.
CAUTION
The outlet must be checked by a qualified electrician
to be sure it is wired with the correct polarity. Verify
the outlet is properly grounded.
WARNING
Do not use an extension cord, two-prong adapter, or
remove the power cord ground prong.
ELECTRICAL REQUIREMENTS
Electrical Supply 115 VAC, 60 Hz
Service 15 amp dedicated circuit
Receptacle 3-prong grounding-type
Specifications
Plumbing Requirements
MODEL DEU2450CI
Installation must comply with all applicable plumbing
codes.
For ease of installation, recess the water shut o into the
wall or place it in an adjacent cabinet. Locate the water
supply line within the shaded area shown in the illustra-
tion below. Connect the water supply line to the house
supply with an easily accessible shut-o valve. Do not use
self-piercing valves.
An in-line filter is required when water conditions have a
high sediment content.
A reverse osmosis system can be used provided there is
constant water pressure of 35–120 psi (2.4–8.3 bar) supplied
to the unit at all times. A copper line is not recommended
for this application.
PLUMBING REQUIREMENTS
Water Supply Line ⁄" OD copper, braided
stainless steel, or PEX tubing
Water Pressure 35–120 psi (2.4–8.3 bar)
Excess Water Line for Connection 5' (1.5 m)
2"
(51)
4"
(102)
2"
(51)
OPENING
AREA EXTENDS
1/2" (13) FORWARD ON FLOOR
Water supply location
5"
(127)
2"
(51)
4"
(102)
FLOOR
OPENING
Electrical supply location

subzero.com | 7
Door Panel
Custom Panel
For Designer Series Undercounter models, a custom door
panel and handle hardware must be provided. Refer to the
charts for panel requirements and dimensions.
Do not install a solid panel on the glass door unit. A solid
door is available as a sales accessory through an autho-
rized Sub-Zero dealer.
The panel cannot exceed the maximum panel weight indi-
cated in the chart below. The depth of each model is 23⁄"
(587). Allow for panel thickness when planning the finished
opening depth.
CAUTION
As reveals between cabinetry and the unit decrease,
severe finger pinching can occur while the door is
closing.
Finish all sides of the custom panel. They may be visible
when the door is open or through the glass of glass door
models.
A D-style handle is recommended. Locate the door handle
near the edge of the panel opposite the hinge and cen-
tered top to bottom. Stainless steel tubular and pro handles
are available through an authorized Sub-Zero dealer. For
local dealer information, visit the find a showroom section
of our website, subzero.com.
PANEL REQUIREMENTS
PANEL WEIGHT MAX
24" Model 22 lb (10 kg)
15" Model 15 lb (7 kg)
PANEL THICKNESS
All Models ⁄" (16) min–⁄" (19) max
Stainless Steel Panel
Stainless steel panels are available through an authorized
Sub-Zero dealer. Stainless steel panels include a stainless
steel kickplate cover. The outdoor model requires the use
of a Sub-Zero stainless steel outdoor accessory panel. For
local dealer information, visit the find a showroom section
of our website, subzero.com.
Minimum ⁄" (3) reveals are required.

8 | Sub-Zero Customer Care 800.222.7820
Custom Panel
TYPICAL PANEL DIMENSIONS
H
W
H
W
PANEL DIMENSIONS
MODEL W H
24" Model (standard height) 23⁄" (603) 30⁄" (772)
24" Model (ADA height) 23⁄" (603) 28⁄" (721)
15" Model (standard height) 14⁄" (375) 30⁄" (772)
STILES / RAILS MIN*
Stiles 3⁄" (83)
Top Rail 3⁄" (89)
Bottom Rail 4⁄" (114)
*Glass door models only.
DUAL INSTALLATION
For dual installations, refer to the chart below for typical
panel dimensions.
PANEL DIMENSIONS—DUAL INSTALLATION
MODEL W H
24" Model (standard height) 23⁄" (605) 30⁄" (772)
24" Model (ADA height) 23⁄" (605) 28⁄" (721)
15" Model (standard height) 14⁄" (376) 30⁄" (772)
Door Panel

subzero.com | 9
Door Panel
Custom Panel
TOE KICK CLEARANCE
The height of the toe kick area can extend beyond the
typical toe kick height, provided it does not exceed the
dimensions in the illustration below. For questions
regarding the installation, call Sub-Zero Customer Care
at 800-222-7820.
MAXIMUM DOOR OPENING
As the panel width and/or depth increases, so does the
potential for panel interference. Interference may be
minimized by using the 90° door stop.
3/8" (10)
DOOR CLOSED
3/4" (19) PANEL
1/8" (3) REVEAL
ADJACENT
CABINETRY
DOOR
OPEN
90°
DOOR OPEN
MAXIMUM 115°
Maximum door opening (top view)
DOOR
PANEL HINGE
231/8" (587)
TO BACK OF UNIT
2" (51)
TO
41/2" (114)
FROM
FLOOR
31/2" (89)
MAX DEPTH
11/8" (29)
KICKPLATE
ADJUSTMENT
341/2" (876)
OR
321/2" (826)
TYPICAL
PRODUCT
HEIGHT
DECORATIVE KICKPLATE
CANNOT EXTEND
BEYOND THIS
POINT
33/8" (86)*
DECORATIVE
KICKPLATE
HEIGHT
*Not included. Dimension will vary as the product height increases or decreases
from the typical product height.
Toe kick clearance (side view)

10 | Sub-Zero Customer Care 800.222.7820
Standard Handles
Optional stainless steel tubular and pro handles are avail-
able through an authorized Sub-Zero dealer. For local
dealer information, visit the find a showroom section of
our website, subzero.com.
Refer to the chart below for standard handle lengths for
Designer Series Undercounter models.
HANDLE LENGTH TUBULAR PRO
Standard Height 24⁄" (614) 22⁄" (572)
ADA Height 22⁄" (564) 20⁄" (521)
Outdoor Model NA 22⁄" (572)
Door Panel
