Planning Information
Built-In Model 648PROG
Side-by-Side Refrigerator/ Freezer with Glass Door
1
Dimensions in parentheses are in
millimeters unless otherwise specified.
11/06
Automatic ice
maker
Auto-close
hinge system
Alarm
Water filter
Easy-access grille
Adjustable stainless
steel shelves
Advanced
lighting
Model 648PROG
with Glass Door
Free-Standing
or Built-In
Ofcourse, the true beauty of the Model 648PROG
becomes apparent not in pictures or words but in its
use. Precision-built, auto-close hinges help doors
swing open and easily and tap shut effortlessly.
Intelligent controls sense usage patterns and adjust
accordingly. The see through crisper glides forward
smoothly, giving a bird's-eye view of fresh produce.
The plus points go on and on. Not unlikethe freshness
of food in a Model 648PROG.
The Sub-ZeroModel 648PROG
side-by-side refrigerator / freezer with
glass door is available in the stainless
steel design application with classic
stainless steel finish only. Model
648PROG can be built-in or, with the
free-standing accessory kit, used in a
free-standing application.
Stainless steel
construction
Drawers with
dividers
Adjustable spill-proof
glass shelves
Sabbath Mode
Microprocessor and
interior control panel
Exterior temperature
display
Slide-out stainless
steel bins
Crisper drawer
Triple-pane UV
resistant glass
Dual refrigeration
system
This appliance is certified byStar-K
to meet strict religious regulations in
conjunction with specific instructions
found on www.star-k.org.

Planning Information
Built-In Model 648PROG
2
FEATURES
Can be built-in or, with the free-standing
accessory kit, used in a free-standing
application
Dual refrigeration—two compressors and
three evaporators keep foods fresher longer
and prevent odor transfer
Exterior temperature display with easy-to-
read digital readouts, accurate within one
degree of your preset temperatures
Microprocessor and interior control panel
with up-front touch controls monitor
pattern-sensing defrost and automatic
service alerts
Sabbath Mode—power down one or both
sides for extended periods or just the
weekend
Slide-out stainless steel bins—two versatile,
removable bins hold small items and fit
neatly under any shelf
Crisper drawer is a touch-and-glide crisper
with a tight-seal glass lid that gives vegeta-
bles generous humidity
Drawerswith dividers help you enjoy full
access to food with adjustable, removable,
and interchangeable drawer dividers
Automatic ice maker lets you retrieve filtered
ice from a stainless steel bucket
Shelves are cantilevered and spill-proof, with
stainless steel trim (refrigerator); adjustable,
removable and 100% stainless steel (freezer)
Auto-close system with an advanced hinge
design lets doors finish closing easily and
automatically
Alarm with an audible beep lets you know
when doors or drawers are left ajar
Water filter is easy to replace and just
behind the pop-up grille
Easy-access grille pops up with a simple pull
(no tools needed) to reveal the water filter
and condenser for cleaning
Stainless steel construction and classic
finish (inside and out) for professional
strength and beauty
Advanced lighting—top LED lights bathe
upper compartments in a soft glow; on the
refrigerator side,channeled sidewall LEDs
can even serve as door area night lights
Triple-pane UV resistant—specially treated
glass offers convenient visibility while filter-
ing harmful rays and saving energy
For installations at or above 5,000' (1524 m)
in elevation, high altitude glass is available
as a special order
Certified by Star-K to meet religious
regulations
UL approved for US and Canada
Two, five and twelve year residential
warranty—exclusions apply; warranty
information can be found on our website,
subzero.com

Planning Information
Built-In Model 648PROG
3
Dimensions may vary by ±1/8"(3).
Dimensions in parentheses are in
millimeters unless otherwise specified.
SPECIFICATIONS
Model 648PROG Side-by-Side Refrigerator / Freezer
with Glass Door
Overall Width 48" (1219)
Overall Height 84" (2134)
Depth from behind face frame 23 7/8"(606)
Depth to front of face frame 25 7/8"(657)
Refrigerator Capacity 18.4 cu ft (521 L)
Freezer Capacity 11.7 cu ft (331 L)
Minimum Height (levelers in) 831/2"(2121)
Door Swing Clearance 28 3/4"(730)
Electrical Requirements 115 V AC, 60 Hz
15 amp dedicated circuit
Plumbing Requirements 1/4"copper line
Water Supply 35 psi (2.4 bar) to 120 psi (8.3 bar)
Annual EnergyUsage 689 kWh / $63
(based on 9.06 cents per kilowatt hour)
Shipping Weight 875 lbs (397 kg)
Specifications are subject to change without notice.
ACCESSORIES
90degree door stop kit —
right or left hinge
Dozen egg container with lid
Slide-out refrigerator bin
Stainless steel side panel
Free-standing kit — includes two
stainless steel side panels and
top lid
Refrigerator drawer dividers
Stainless steel front and side
toe kicks
Accessories are available through your
Sub-Zerodealer. To obtain local dealer
information, visit the Locator section of
our website, subzero.com.
237/8"
(606)
BEHIND
FACE
FRAME
257/8"
(657)
TO FRONT
OF FACE
FRAME
283/4"
(730)
201/2"(521)
48"
(1219)
48"
(1219)
84"
(2134)
257/8"
(657)
305/32"
(766)
237/8"
(606)
OVERALL DIMENSIONS

Planning Information
Built-In Model 648PROG
Dimensions in parentheses are in
millimeters unless otherwise specified. 4
INSTALLATION SPECIFICATIONS
DIMENSIONS
Finished Rough Opening Width Standard 471/2"(1206)
Flush 48" (1219)
Finished Rough Opening Height Standard 833/4"(2127)
Flush 841/8"(2137)
Finished Rough Opening Depth Standard 24" (610)
Flush 26" (660)
Location of Electrical Within upper shaded area
Location of Water Supply Within lower shaded area
See Installation Instructions shipped with unit for detailed specifications.
Refer to the Sub-Zero Design Guide pdf file for additional specifications.
7"
(178)
6"
(152)
ROUGH
OPENING DEPTH
24" (610)
STANDARD
26" (660)
FLUSH
ROUGH
OPENING WIDTH
471/2"(1206) STANDARD
48" (1219) FLUSH
E
3" (76)
6"
(152)
W
LOCATE WATER SUPPLY
WITHIN SHADED AREA
LOCATE ELECTRICAL
WITHIN SHADED AREA
53/16"
(132)
SHUT-OFF
VALVE
MIN 36" (914)
1/4"COPPER
WATER LINE
F
TOP VIEW
ROUGH
OPENING HEIGHT
TO FINISHED
FLOORING
833/4"(2127)
STANDARD
841/8"(2137)
FLUSH
MIN HEIGHT
REQUIRED
TO FINISHED
FLOORING
(LEVELERS IN)
831/2"(2121)
STANDARD
833/4"(2127)
FLUSH
751/2"
(1918)

Planning Information
Built-In Model 648PROG
Dimensions in parentheses are in
millimeters unless otherwise specified. 5
INSTALLATION NOTES
Refer to the illustrations and specifications
for overall dimensions, finished rough opening
dimensions and installation specifics.
Model 648PROG can be used free-standing
or installed as a standard or flush built-in appli-
cation. For standard built-in installations, the
face frame of the unit will extend 2" (51)
beyond cabinetry. In flush built-in installations,
the front of the face frame will be flush with
surrounding cabinetry.
The depth of Model 648PROG from the back
of the unit to the front of the face frame is
25 7/8"(657). In flush built-in applications, your
design may necessitate moving the unit back,
or cabinets forward to achieve a flush fit.
The anti-tip bracket must be installed to
prevent the unit from tipping forward.
Allow the doors to open a minimum of 90˚ or
you'll have problems removing shelves. With
the door opening at 90˚, you may have to move
shelves slightly to clear the door interior. Refer
to the minimum door swing clearance in the
specifications chart.
For corner installations, allow for a minimum
3" (76) filler so that the door can open to 90˚.
Model 648PROG comes with an automatic
ice maker and an integrated water filtration
system. This system operates on water
pressure between 35 psi (2.4 bar) and 120 psi
(8.3 bar). To rough in the water supply, connect
a1/4"OD copper line to the house supply,being
sure to use an easily accessible shut-off valve
between the supply and the unit.
Do not use self-piercing valves. A saddle
valve kit (4200880) is available from your
Sub-Zero dealer. To obtain local dealer informa-
tion, visit the Locator section of our website,
subzero.com.
IMPORTANT NOTE: Areverse osmosis system
can be used with Model 648PROG, provided
there is constant water pressure of 20 psi (1.4
bar) to 120 psi (8.3 bar) supplied to the unit at
all times. In this application, the integrated
water filtration system must be set to bypass
mode. This is achieved by removing the water
filter cartridge. Refer to the PRO 48 Installation
Instructions packed with the unit.
The water line should be routed up through
the floor within 1/2"(13) from the back wall and
no higher than 3" (76) off the floor. If you have
to come through the wall, make sure the water
line is no more than 3" (76) from the floor.
Locate water supply within the shaded area
shown in the Installation illustration.
Regardless of the routing, allow a minimum
of 36" (914) of excess copper tubing to remain
outside the wall or floor for easy connection to
the unit.
A115 V AC, 60 Hz, 15 amp electrical supply
is required.The supply circuit for this appliance
must be protected by a 15 amp fuse or circuit
breaker.It is recommended that a separate
circuit, serving only this appliance, be provided.
IMPORTANT NOTE: Aground fault circuit
interrupter (GFCI) is not recommended and may
cause interruption of operation.
Model 648PROG is equipped with a 6'
(1.8 m) power supply cord with a 3-prong
grounding plug which must be plugged into a
mating 3-prong grounding-type wall receptacle.
Locate electrical within the shaded area shown
in the Installation illustration.
You must follow all National Electrical Code
regulations. In addition, be aware of local codes
and ordinances when installing your service.
Refer to the PRO 48 Installation Instructions
packed with the appliance, which provides
step-by-step procedures for making sure the
unit is installed properly.
