The importance of the installation of the Sub-Zero built-in
unit cannot be overemphasized. Installation should be
done by a qualified installer.
Before you begin the installation process, it is recom-
mended that you read this entire installation guide. There
are key details that you should take special care to
observe during the installation. By reading these instruc-
tions carefully, you will make the installation process
easier, problem-free and most importantly, safe.
Any questions or problems regarding the installation
should be directed to your authorized Sub-Zero dealer or
Sub-Zero customer care at 800-222-7820. You may also
check the contact & support sectionofour website,
subzero.com.
Important product information, including the model and
serial numbers of the built-in unit are listed on the product
rating plate, located on the top frame of the unit inside the
door. Refer to the illustration below.
Before You Start
Make sure that the actual equipment that was shipped to
you matches the design you are expecting to install. The
Sub-Zero built-in line offers the following design alterna-
tives: framed, overlay, flush inset and stainless steel
models.
Each of these design options has specific installation
requirements, which means it is vital that the unit match
your planning and space needs. Before you begin the
installation process, check the exact model number you
need against the model number on the shipping carton.
If the unit you receive does not match your requirements,
contact your authorized Sub-Zero dealer.
TOOLS AND ATERIALS REQUIRED
•Appliance dolly able to support 700 lbs (317 kg) and
adequate manpower to handle the weight of the unit.
•Phillips and slotted screwdrivers.
•Torx drive screwdriver set.
•Allen, standard and crescent wrenches.
•Various sized pliers.
•3/8" hex bolt nut driver.
•Cordless drill and assorted drill bits.
•Level—2' (.6 m) and 4' (1.2 m) recommended.
•4' (1.2 m) of 1/4" copper, braided stainless steel or
PEX tubing and saddle valve for water line (do not use
self-piercing valves).
•Tubing cutter.
•Masonite, plywood, pressed fiberboard, cardboard or
other suitable material to protect finished flooring.
•Appropriate materials to cover and protect the home
and furnishings during installation.
Location of rating plate.
RATING
PLATE
