FEATURES
•Upper cabinet freezer and two freezer
drawers.
•Custom front panels and hardware allow
for infinite design options.
•Point-of-use refrigeration that can be
placed anywhere in the home.
•Self-contained compartments preserves
food’s goodness.
•Redesigned sleek, minimalist interior is
lit by LEDs to reduce heat.
•Interactive control panel with touch
screen and precise temperature control.
•Advanced water filtration system.
•Automatic ice maker with max ice
feature to increase ice production up to
30 percent.
•Dampened hinges.
•Smart Grid ready.
•ENERGY STAR®qualified.
•Star-K certified.
MODEL OPTIONS
FREEZER
Model IT-30FI
INTERIOR FEATURES
FREEZER
3 Adjustable wire shelves
4 Adjustable door shelves
3 Adjustable drawer dividers
Removable ice container
30" Integrated All Freezer—Tall
subzero.com
ACCESSORIES
•Stainless steel front panels with tubular
or pro handles and 4" or 6" toe kick.
•Stainless steel tubular and pro handles.
•Dual installation kit.
Accessories available through an authorized
Sub-Zero dealer. For local dealer information,
visit the find a showroom section of our
website, subzero.com.

173/4"
(451)
W24" (610)
84"*
(2134)
109/16"
(268)
447/8"
(1140)
135/16"
(338)
3/8" (10)
41/2" (114)
35/8" (92)
*831/2"(2121) MIN TO 841/2"(2146) MAX
3/8" (10)
A
B
13/4" (45)
SPECIFICATIONS
PRODUCT
Dimensions 30"W x 84"H x 24"D
Weight 400 lb
CAPACITY
Freezer 15.1 cu ft
ELECTRICAL
Supply 115 VAC, 60 Hz
Service 15 amp circuit
PLUMBING
Supply 1/4" OD copper, braided
stainless steel or PEX tubing
Pressure 35–120 psi
Overall dimensions do not include panels or
handles. Dimensions will vary with panel
thickness.
The depth of each integrated model is 24".
Allow for panel thickness when planning the
finished opening depth.
Specifications are subject to change without
notice. Visit subzero.com/specs for the most
up-to-date information.
Dimensions may vary ±1/8"(3). Dimensions in
parentheses are millimeters unless otherwise
specified.
30" Integrated All Freezer—Tall
subzero.com
INSTALLATION
DIMENSIONS
©Sub-Zero, Inc. all rights reserved. 9/2013
A
1/4" (6)
1/4" (6)
41/4"
(108)
41/2"
(114)
FLOOR
LEFT SIDE
OF OPENING
ELECTRICAL
3" (76)
6" (152)
RIGHT SIDE
OF OPENING
AREA EXTENDS 1/2"(13)
FORWARD ON FLOOR
A
PLUMBING
25" (635)
OPENING
DEPTH
W
OPENING WIDTH
H
OPENING
HEIGHT
NOTE: Shaded areas will be visib
le and should be finished to match cabinetry.
SIDE
VIEW
TOP VIEW
FRONT VIEW
3/4" (19)
TYPICAL
31/2"
(89)
TYPICAL
30" (762)
55/8"(143)
281/2"
(724)
84" (2134) 30" (762)
121/2"
(318)
6"
(152)
