AML
ALL MATERIALS LOCATOR
www.ssilocators.com
Operator’s Manual
• Designed to Find Buried
PVC Pipes & PE Pipes
• Patented Radio Frequency
Technology
• Lightweight, Durable
Construction
• FCC, IC & CE Approved

ENGLISH
AML
All Materials Locator
Operator’s Manual
3

To learn how to properly operate
your AML unit, view the complete
DVD included. All operating
procedures are demonstrated in
actual use in the field.
Free factory training is available
and recommended. See
www.ssilocators.com for details.
Additional copies of the training
DVDs can be ordered through SSI.
Call 855.422.6346 to order.
Note: Read the Safety Notes
section (page 12) before operating
your AML unit.
OPERATING INSTRUCTIONS
4

FCC
This equipment has been tested and
found to comply with the
limits for a Class A digital device,
pursuant to Part 15 of the FCC
rules. These limits are designed
to provide reasonable protection
against harmful interference
when the equipment is operated
in a commercial environment.
This equipment generates, uses,
and can radiate radio frequency
energy and, if not installed and
used in accordance with the
operator’s manual, may cause
harmful interference to radio
communications. Operation of this
equipment in a residential area is
likely to cause harmful interference
in which case the user will be
required to correct the interference
at his own expense.
IC (Industrie Canada)
Operation is subject to the following
two conditions:
1) This device may not cause
interference, and
2) This device must accept
any interference, including
interference that may cause
undesired operation of
the device.
FCC/IC/CE STATEMENTS
5
CE Approved
(European Countries)
The protection provided by this
equipment may be impaired
if used in a manner other
than that specified within this
manual or training video.
There are no components that
should be or can be changed
by the user of the AML except
for the batteries within the bat-
tery pack.
Because this is a self-
contained sealed unit, any
problems or concerns should
be addressed with the
manufacturer and/or returned
at the recommendation of the
manufacturer.

QUICK START GUIDE
6
1
2
3
4
5
6
7
8
9

1 - EASY BATTERY ACCESS
Powered by a convenient 9-volt battery system, the AML features long, powerful on-the-
job usage between battery changes.
2 - ERGONOMIC HANDLE
Ergonomic handle provides a firm grip in any weather condition.
3 - POWER & 4-POSITION SENSITIVITY SWITCH
This switch controls the unit’s power supply and sensitivity. Once the unit is on,
the operator can choose the appropriate sensitivity setting depending on each job’s
conditions.
4 - RIGHT SIDE & LEFT SIDE TARGET INDICATORS
Easy to read left and right LED target indicators identify when an object has been
located, and when the object is in parallel with the AML. Audio and laser target
indicators work in unison with the right and left LEDs to alert the operator of an
object’s presence, and to place its location.
5 - LED POWER INDICATOR
The power indicator emits a bright green LED light when the unit is on. This LED also
serves as the battery life indicator, and flashes when battery power is low.
6 - LIGHTWEIGHT, DURABLE CONSTRUCTION
The brightly colored AML is constructed from lightweight, shock-resistant materials that
make it easy to use and handle throughout the work day.
7 - GROUND-PENETRATING, ULTRA-HIGH RADIO FREQUENCY TRANSMITTER
Using advanced circuit board technology, a powerful 2.4 GHz ground-penetrating, ultra-
high frequency locates objects. Man-made objects or conditions with a straight edge
create a change in conductivity, density and/or permeability from surrounding materials,
causing a reflection or refraction that is detected by the AML.
8 - LASER TARGET INDICATOR
An easy-to-see laser indicator marks the target position on the ground when an object
has been detected.
9 - ULTRA-HIGH RADIO FREQUENCY RECEIVERS
Highly sensitive left and right side receivers intercept frequency reflections and
refractions set off by the edges of buried objects. When the unit is positioned over and
parallel to an object, both the left and right indicators are activated. The user can then
track the object in slow and deliberate movements, identifying its shape, location and
run direction.
7

With the AML in parallel with the pipe or
underground object, you can now scan the entire
length of the object’s edge. As an alternative, utilize
the “W” method of scanning by sweeping the area
in a back-and-forth “W” motion, marking the object’s
location and run direction as it is tracked.
USING THE AML
UNDERSTANDING
ULTRA-HIGH RADIO
FREQUENCIES
The key to how the AML
works is to understand
how its ground-penetrating
radio frequency detects
objects. Holding the AML’s handle parallel to the ground,
scan the area of the suspected pipe or buried object
until one or both of the AML’s target indicators
activate.
While the left or right target indicator is activated,
rotate the AML until both LED target indicators light
simultaneously, triggering the AML’s tone and laser
marker. This alert indicates that the pipe or object
has been detected and that the AML is now parallel
with the underground object.
8
1
2
3

Safe Maintenance & Inspection
of the AML – DO NOT open the
housing as this is for maintenance
or inspection and this will impair
the transmission and receiving
antennae. There are NO user
serviceable parts inside. Doing so
will void the warranty.
If maintenance or tuning is
required, contact SubSurface
Instruments at:
1841-C Plane Park Drive
De Pere, WI 54115 USA
920.347.1788 phone
920.347.1791 fax
[e-mail]
www.ssilocators.com
Laser – Class II laser: Avoid
direct exposure to beam.
Operation - if the equipment is
used in a manner not specified by
the manufacturer, the protection
provided by the equipment may be
impaired
WARNING
9
Read and Observe All Instructions.
Save these instructions for future reference.
D
F
I
E
P
English
German
French
Italian
Spanish
Portuguese

To Replace Batteries in Your
AML Unit:
1. Unscrew the battery access cap
2. Place the battery pack inside
the ergonomic handle (the silver
end goes in first.)
3. Battery leads face in up position.
4. Use caution when handling
wire harness.
5. Replace battery access cap.
- (2) battery packs included
- Uses (3) 9-volt alkaline batteries
* Replacement battery packs
available at www.ssilocators.com
BATTERY REPLACEMENT
AML
(All Materi-
als Locator)
Easy Battery
Access Cap
Battery Pack
(Houses (3) 9-Volt
Batteries)
10

TECHNICAL SPECIFICATIONS
PRODUCT INFORMATION
Physical Dimensions
•Height........... 11” ........ 27.9cm
•Length .......... 14” ........ 35.6cm
•Width ........... 6” .......... 15.2cm
•Weight.......... 2.0 lbs ... 907g
• Single-Hand Operation
Typical Operating Range
• Temperature: 0°F to 120°F (-17°C to 48°C)
Power Specifications
• Batteries: (3) 9-Volt Alkalines
• Estimated Battery Life:
- 7 hours at continuous full power usage per battery pack
- Under average industry usage, battery pack life is
approximately 40 hours
• Transmitter Frequency: 2.45 GHz
Shipping Dimensions
• Cube.......19”l x 15”w x 8”h ...48.3cm x 38.1cm x 20.3cm
• Weight....14 lbs...................6.4kg
Includes
• (1) AML Unit
• (2) Battery Packs (Housing (3) 9-Volt Batteries)
• (1) Foam-Insulated Hard Case
• (1) User’s Guide
• (1) Training Video
• Batteries Included
11

Laser Safety
Read and strictly observe the
safety warnings in the operating
instructions of the laser.
Do not operate the AML in
explosive atmospheres, such as
in the presence of flammable
liquids, gases or dusts. Sparks
can be created in the AML
which may ignite the dust or
fumes.
Do not direct the laser beam
at persons or animals. Do not
stare into the laser beam. The
AML produces Laser Class 2M
laser radiation according to IEC
60825-1.
Looking or viewing directly into
the laser beam - especially with
optical instruments such as
binoculars or magnifiers, can
permanently damage the eye.
Do not allow children to use the
AML without supervision. They
could unintentionally blind other
persons or themselves.
SAFETY NOTES
12
Read and Observe All Instructions.
Save these instructions for future reference.
D
F
I
E
P
English
German
French
Italian
Spanish
Portuguese

13
Battery Packs/Batteries
Protect batteries from excessive heat,
continuous intense sunlight and fire.
Danger of explosion.
Always replace all batteries at the same
time. Only use batteries from one brand
and with the identical capacity. When
storing for longer periods, the batteries
can corrode and discharge themselves.
Remove the batteries from the AML
when not in use for long periods.
Battery Packs/Disposal
Do not dispose of battery packs/
batteries into household, waste, fire or
water. Battery packs/batteries should
be collected, recycled or disposed of in
an environmental-friendly manner.
European Countries
Defective or dead battery packs/
batteries must be recycled according to
the guideline 91/157/EEC, or per local
regulations.
Repair
Have the AML repaired only through
SubSurface Instruments Inc., using
original replacement parts. This
ensures that the safety of the locator is
maintained.
Disposal
The AML, accessories and packaging
should be sorted for environment-
friendly recycling.

Warranty Period: 36 months
/ (3) years from original user’s
purchase. The All Materials
Locator (AML) is specifically
guaranteed to be free of defect in
both material and workmanship
to the original end user or
purchaser. Save your receipt for
reference.
Physical abuse, battery acid and
water damage as determined at
the sole discretion of SubSurface
Instruments Inc., are explicitly
and entirely excluded from this
warranty. Additionally, this is a
scientific instrument and cannot
be protected by the manufacturer
from damage if dropped or placed
in an environment which will
cause physical or chemical harm
to the unit; therefore this shall be
considered abuse also.
SubSurface Instruments’ Liability
under this warranty is absolutely
limited to repair, service, or
replacement of the product, at
the sole discretion of SubSurface
Instruments Inc. No other
warranty is expressed or implied.
WARRANTY STATEMENT
As always, the responsibility,
reliability, and operator/
bystander safety, of/while
finding/locating and confirming
a target, lies with the
Operator.
SubSurface Instruments, Inc.
is not responsible for errors
and/or omissions in this
manual.
Any unit suspected to be
in need of repair must be
returned to SubSurface
Instruments Inc. at its then
current location, freight
prepaid and free of charge:
FOB Delivered to SubSurface
Instruments Inc. at the
following or a new address at
such time:
SubSurface Instruments, Inc.
1841-C Plane Park Drive
De Pere, WI 54115 USA
920.347.1788 phone
920.347.1791 fax
[e-mail]
www.ssilocators.com
14

SubSurface Instruments Inc.,
its owners, employees, dealers,
distributors, and/or assigns,
shall not be liable for any action,
inaction, injury, or property
damage, sustained or expenses
incurred, whether consequential
or inconsequential; from the
use/non-use, misuse, improper
or proper use of this or any
product designed, manufactured,
and/or distributed by SubSurface
Instruments Inc. Locating accuracy
and safety, all encompassed,
are the sole responsibility of the
“Operator-user” of the product.
Information in this manual is
subject to change without notice.
DISCLAIMER
15

FRANÇAIS
AML
Localisateur de tous matériaux
Manuel de l’opérateur
17

Apprenez à utiliser correctement
votre unité AML, consultez
le DVD exhaustif qui est
inclus. Toutes les procédures
d’utilisation sont explicitées par
une démonstration en conditions
réelles sur le terrain.
Une formation maison est
disponible et recommandée.
Consultez www.ssilocators.com
pour obtenir plus de détails.
Des exemplaires supplémentaires
des DVD de formation peuvent
être commandés au travers de
SSI. Appelez le 855.422.6346
pour commander.
Remarque: Lisez la section notes
en matière de sécurité (page
26) avant d’utiliser votre appareil
AML.
INSTRUCTIONS D’UTILISATION
18

FCC
Cet équipement a été testé
et déterminé comme se
conformant aux limites des
appareils numériques de Classe
A, conformément à la partie 15
des règles de la FCC. Ces limites
sont conçues pour fournir une
protection raisonnable contre les
interférences nuisibles lorsque
l’équipement est utilisé dans un
environnement commercial. Cet
équipement génère, utilise et
peut émettre de l’énergie par
radiofréquence et, s’il n’est pas
installé et utilisé conformément
aux instructions, peut provoquer
des interférences nuisibles aux
communications radio. L’utilisation
de cet équipement dans une
zone résidentielle est susceptible
de provoquer des interférences
nuisibles, auquel cas l’utilisateur
sera tenu de corriger les
interférences à ses propres frais.
IC (Industrie Canada)
Le fonctionnement est soumis aux
deux exigences suivantes:
1) cet appareil ne peut pas provo
quer d’interférences, et
2) cet appareil doit accepter toute
interférence reçue, y compris
des interférences pouvant pro
voquer un fonctionnement
indesirable.
DÉCLARATIONS FCC/IC
19
Homologué
(Pays Européens)
Si vous n’utilisez pas l’appareil
de la façon indiquée dans ce
manuel ou dans la vidéo de
démonstration, la protection
fournie peut en être altérée.
Aucun élément ne doit être
ou ne peut être modifié
par l’utilisateur de l’AML, à
l’exception des piles à l’intérieur
du bloc- batterie.
Étant donné qu’il s’agit d’une
unité scellée autonome, en cas
de problème ou préoccupation,
vous devrez contacter
directement le fabricant et
/ ou le renvoyer selon les
conseils du fabricant.

GUIDE DE PRISE EN MAIN RAPIDE
20
1
2
3
4
5
6
7
8
9
