Sumitomo Z2C User manual

Core Alignment Fusion Splicer
Quick Reference Guide
Fusion splicer Carrying case Battery pack Power cord
AC adapter Electrodes USB cable Cooling tray
Quick reference
guide
What’s included
➋Connect the AC adapter to the splicer to
charge the battery pack.
Getting started
How to check battery capacity left
Push the button
Charging (blinking) Fully charged (steady glow)
1
～
20
％
21
～
40
％
41
～
60
％
61
～
80
％
81
～
％
100
➌Press the POWER key.
➍The splicer turns on.
➊Open the battery slot cover located at the bottom of the splicer and insert the battery pack.
Close and lock the cover.

Sumitomo Electric Industries, Ltd. reserves the right to change the specification or design without
notice and may therefore not coincide with the contents of this quick reference guide. E&OE
For further detailed operating instructions and functions, please see operation manual.
The operation manual can be downloaded via
https://global-sei.com/sumitomo-electric-splicers/support/manual.php
OME2124002/Ver.1.03
➎The splicer shows thumbnails of
tutorial videos.
➏Tap the thumbnail to play the video.
Utilizing Help Videos
On the splicer Also available online
Cleaning
Consumables Software update
V-grooves Heat shrink oven
Replacing the electrodes On a computer On SumiCloud
*AS24H706*
Basic operation
Inserting the fibers
into the splicer
Splice protection
Video contents
... and more in the list.
